OUTLINE OF DIAGNOSIS
Judge as NG with either Low NG or High NG.
A variable valve lift diagnosis oil pressure switch is installed for diagnosis. It is possible to determine whether the intake valve is in high mode (increase the amount of lift) or in low mode (suppressing the amount of lift) when the variable valve lift diagnosis oil pressure switch is turned ON or OFF.
- Normal VALVE LIFT DIAGNOSIS REFERENCE CHART Oil switching solenoid valve duty Intake valve Variable valve lift diagnosis oil pressure switch Large High mode ON Minimum Low mode OFF
- Low NG
When the variable valve lift diagnosis oil pressure switch remains OFF even though the intake valve tried to enter high mode (oil switching solenoid valve duty is large), this is judged as a Low NG.
- High NG
When the variable valve lift diagnosis oil pressure switch remains ON even though the intake valve tried to enter low mode (oil switching solenoid valve duty is small), this is judged as a High NG.
DIAGNOSTIC METHOD
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Duty ratio | > or = 62 % |
| Variable valve lift diagnosis oil pressure switch | OFF |
| High Duty ratio | < 33 % |
| Variable valve lift diagnosis oil pressure switch | ON |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low side: 784 ms
High side: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Duty ratio | > or = 62 % |
| Variable valve lift diagnosis oil pressure switch | ON |
| High Duty ratio | < 33 % |
| Variable valve lift diagnosis oil pressure switch | OFF |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low side: 208 ms
High side: 3000 ms
Note. For the detection standard, refer to DTC P0026. Refer to DTC P0026 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE/PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect functional errors of the front oxygen (A/F) sensor heater.
Judge as NG when it is determined that the front oxygen (A/F) sensor impedance is large when looking at engine status such as deceleration fuel cut.
Scheme 193
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | > 50 ohms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front oxygen (A/F) sensor impedance | < or = 50 ohms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10000 ms
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 194
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Front oxygen (A/F) sensor heater control duty | < 87.5 % |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 4 ms x 250 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect front oxygen (A/F) sensor heater open or short circuit.
The front oxygen (A/F) sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 195
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Front oxygen (A/F) sensor heater control duty | > or = 12.5 % |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 4 ms x 500 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains Low.
Scheme 196
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
| Rear oxygen sensor heater control duty | < 75 % |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 8 ms x 320 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the rear oxygen sensor heater open or short circuit.
The rear oxygen sensor heater performs duty control, and the output terminal voltage at ON is 0 V, and the output terminal voltage at OFF is the battery voltage.
Judge as NG when the terminal voltage remains High.
Scheme 197
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | High |
| Rear oxygen sensor heater control duty | > or = 20 % |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 8 ms x 320 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage level | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect problems in the intake manifold pressure sensor output properties.
Judge as NG when the intake air pressure AD value is Low whereas it seemed to be High from the viewpoint of engine condition, or when it is High whereas it seemed to be Low from the engine condition.
Scheme 198
- Abnormality Judgement
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Engine speed | < 2500 rpm |
| Throttle position | > or = 12° |
| Output voltage | < 1.63 V |
| Engine load | > 0.6 g/rev (0.02 oz/rev) |
| High Engine speed | 600 rpm - 900 rpm |
| Throttle position | < 2.44° |
| Output voltage | > or = 3.4 V |
| Engine load | < 0.4 g/rev (0.01 oz/rev) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low side: 3000 ms
High side: 7000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG when both Low side and High side become OK.
If the duration of time while the following conditions are met is longer than the time indicated, judge as OK.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Engine speed | < 2500 rpm |
| Throttle position | > or = 12° |
| Output voltage | > or = 1.63 V |
| Engine load | > 0.6 g/rev (0.02 oz/rev) |
| High Engine speed | 600 rpm - 900 rpm |
| Throttle position | < 2.44° |
| Output voltage | < 3.4 V |
| Engine load | < 0.4 g/rev (0.01 oz/rev) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low side: Less than 1 second
High side: Less than 1 second
Detect the open circuit of the oil switching solenoid valve.
Judge as NG when the current is small even though the output duty is large.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio | > or = 30 % |
| Control current | < 0.026 A |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Oil switching solenoid valve target current value - Oil switching solenoid valve current value. | < 0.08 A |
| Target current | > or = 0.11 A |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2000 ms
Detect short circuits of the oil switching solenoid valve.
Judge as a short NG when the current is large even though the output duty is small.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio | < 7 % |
| Control current | > or = 0.465 A |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Oil switching solenoid valve target current value - Oil switching solenoid valve current value | < 0.08 A |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2000 ms
Note. For the detection standard, refer to DTC P0076. Refer to DTC P0076 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0077. Refer to DTC P0077 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect the malfunction of air flow sensor output properties.
Judge as a low side NG when the air flow voltage indicates a small value regardless of running in a state where the air flow voltage increases. Judge as a high side NG when the air flow voltage indicates a large value regardless of running in a state where the air flow voltage decreases. Judge air flow sensor property NG when the Low side or High side becomes NG.
Scheme 199
- Abnormality Judgement
Judge as NG when Low side or High side becomes NG.
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Output voltage | < 1.49 V |
| Engine speed | > or = 2000 rpm |
| Throttle opening angle | > or = 12° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High (1) Output voltage | > or = 2.66 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 2.44° |
| Intake manifold pressure | < 40 kPa (300 mmHg, 11.8 inHg) |
| High (2) Output voltage | > or = 1.45 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 2.44° |
| Intake manifold pressure | < 40 kPa (300 mmHg, 11.8 inHg) |
| Fuel system diagnosis | Rich side malfunction |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low: 5000 ms
High: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG when both Low side and High side become OK.
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Low Output voltage | > or = 1.49 V |
| Engine speed | > or = 2000 rpm |
| Throttle opening angle | > or = 12° |
| Intake manifold pressure | > or = 66.7 kPa (500 mmHg, 19.7 inHg) |
| High Output voltage | < 2.66 V |
| Engine speed | 600 rpm - 900 rpm |
| Throttle opening angle | < 2.44° |
| Intake manifold pressure | < 40 kPa (300 mmHg, 11.8 inHg) |
| Fuel system diagnosis | Rich side normal |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Low: Less than 1 second
High: Less than 1 second
Detect open or short circuits of the air flow sensor. Judge as NG if out of specification.
Scheme 200
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < or = 0.22 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.22 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuits of the air flow sensor.
Judge as NG if out of specification.
Scheme 201
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.179943192 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.179943192 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 202
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < or = 0.573 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > 0.573 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of intake manifold pressure sensor.
Judge as NG if out of specification.
Scheme 203
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.38757221 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.38757221 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of intake air temperature sensor output property.
Judge as NG when the intake air temperature is not varied whereas it seemed to be varied from the viewpoint of engine condition.
Scheme 204
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | < 0.02 V (Equivalent to approximately 0.5°C (0.9°F) near 25°C) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage difference between Max. and Min. | > or = 0.02 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 205
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.230975449 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.230975449 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the intake air temperature sensor.
Judge as NG if out of specification.
Scheme 206
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 207
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.264738528 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.264738528 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the engine coolant temperature sensor.
Judge as NG if out of specification.
Scheme 208
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 209
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < or = 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Detect the open or short circuit of throttle position sensor 1.
Judge as NG if out of specification.
Scheme 210
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.858 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.858 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Detect the malfunction of engine coolant temperature output property.
Judge as NG when the engine coolant temperature does not rise in driving conditions where it should.
Scheme 211
- Abnormality Judgement
Judge as NG if the criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | < 20 °C (68 °F) |
| Timer for diagnosis after engine start | > or = Judgement value of timer after engine start |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Timer for diagnosis after engine start
- Timer stop at fuel cut
- During the driving conditions except a) above, timer counts up as follows.
64 milliseconds + TWCNT milliseconds (at the time of 64 milliseconds)
TWCNT is defined as follows
TWCNT = 0 at idle switch ON
TWCNT show on the following table at idle switch OFF.
| Vehicle speed km/h (MPH) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0 (0) | 8 (5) | 16 (9.9) | 24 (14.9) | 32 (19.9) | 40 (24.9) | 48 (29.8) | 56 (34.8) | ||
| Temperature °C (°F) | 20 (-4) | 0 ms | 32.076 ms | 39.977 ms | 47.879 ms | 82.544 ms | 117.209 ms | 154.214 ms | 185.26 ms |
| 10 (14) | 0 ms | 25.704 ms | 33.606 ms | 41.508 ms | 68.52 ms | 95.532 ms | 125.667 ms | 155.802 ms | |
| 0 (32) | 0 ms | 17.646 ms | 25.548 ms | 33.45 ms | 53.652 ms | 73.855 ms | 97.12 ms | 120.386 ms | |
| 10 (50) | 0 ms | 7.901 ms | 15.802 ms | 23.704 ms | 37.941 ms | 52.177 ms | 68.573 ms | 82.538 ms | |
| 20 (68) | 0 ms | 7.901 ms | 15.802 ms | 23.704 ms | 37.941 ms | 52.177 ms | 68.573 ms | 82.538 ms | |
VEHICLE SPEED SPECIFICATION CHART
Judgement value of timer after engine starting
t = 573669 ms-33924 ms x Ti
Ti: The lowest coolant temperature after engine start
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature | > or = 20 °C (68 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of the engine coolant temperature sensor characteristics.
Memorize the engine coolant temperature and fuel temperature at the last engine stop, and use them to judge as NG when the engine coolant temperature does not decrease when it should.
Scheme 212
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature at the last engine stop - Minimum engine coolant temperature after the engine start | < 2.5 °C (36.5 °F) |
| Fuel temperature at the last engine stop - Fuel temperature | > or = 5 °C (41 °F) |
| Intake air temperature - Fuel temperature | < 2.5 °C (36.5 °F) |
| Fuel temperature | < 35 °C (95 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine coolant temperature at the last engine stop - Minimum engine coolant temperature after the engine start | > or = 2.5 °C (36.5 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect malfunctions of the thermostat function.
Judge as NG when the engine coolant temperature is lower than the estimated engine coolant temperature and the difference between them is large. Judge as OK when the engine coolant temperature becomes to 75°C (167°F), and the difference is small, before judging NG.
Scheme 213
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Estimate ambient temperature | > or = -7°C (19.4°F) |
| Thermostat malfunction diagnosis | Incomplete |
| Engine coolant temperature at engine starting | < 55°C (131°F) |
| Estimated coolant temperature | > or = 75°C (167°F) |
| Engine coolant temperature | < or = 75°C (167°F) |
| (Estimated - Measured) Engine coolant temperature | > 30 °C (86 °F) |
| Vehicle speed | > or = 30 km/h (18.6 MPH) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 64 ms x 3 time(s) x 152 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Estimate ambient temperature | > or = -7°C (19.4°F) |
| Thermostat malfunction diagnosis | Incomplete |
| Engine coolant temperature at engine starting | < 55°C (131°F) |
| Engine coolant temperature | > or = 75°C (167°F) |
| (Estimated - Measured) Engine coolant temperature | < or = 30 °C (86 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 214
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) or | < 1.128 V |
| Input voltage (-) or | < 0.23 V |
| Input voltage (+) - Input voltage (-) | < 0.644 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Input voltage (+) - Input voltage (-): 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | > or = 1.128 V |
| Input voltage (-) | > or = 0.23 V |
| Input voltage (+) - Input voltage (-) | > or = 0.644 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of sensor.
Judge as NG, when the element voltage is out of the specified range.
Scheme 215
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) or | > 3.589 V |
| Input voltage (-) | > 3.541 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
Input voltage (+): 1000 ms
Input voltage (-): 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Input voltage (+) | < or = 3.589 V |
| Input voltage (-) | < or = 3.541 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the slow response of front oxygen (A/F) sensor.
Front oxygen (A/F) sensor cover has some ventilation holes for exhaust gas. Clogged ventilation holes are diagnosed.
When the holes are clogged, the A/F output variation becomes slow comparing with the actual A/F variation because oxygen which reaches the zirconia layer is insufficient. Therefore, if the sensor cover holes are clogged, the rich to lean judgement in the ECM is delayed when the actual change from rich to lean occurs. Judge as NG when the actual movement in comparison to the ECM control amount is slow.
Scheme 216
Scheme 217
Calculate faf difference every 32 ms x 4, and the lambda value difference. Calculate the diagnosis value after calculating 1640 time(s).
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Parafca = td2faf/td2lmd where, td2faf (N) = td2faf (n-1) + d2faf (n) td2lmd (N) = td2lmd (n-1) + d2lmd (n) add up to 32 ms x 4 x 1640 time(s). d2faf (n) = (faf (n) - faf (n-1)) - (fef (n-1) - faf (n-2)) d2lmd (n) = (lmd (n) - lmd (n-1)) - (lmd (n-1) - lmd (n-2)) faf = main feedback compensation coefficient every 128 milliseconds lmd = output lambda every 128 milliseconds | > 0.45 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 32 ms x 4 x 1640 time(s)
Malfunction Indicator Light Illumination: illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Parafca = td2faf/td2lmd where, td2faf (N) = td2faf (n-1) + d2faf (n) td2lmd (N) = td2lmd (n-1) + |d2lmd (n)| add up to 32 ms x 4 x 1640 time(s). d2faf (n) = (faf (n) - faf (n-1)) - (faf (n-1) - faf (n-2)) d2lmd (n) = (lmd (n) - lmd (n-1)) - (lmd (n-1) - lmd (n-2)) faf = main feedback compensation coefficient every 128 milliseconds lmd = output lambda every 128 milliseconds | < or = 0.45 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 32 ms x 4 x 1640 time(s)
Detect open circuits of the sensor.
Judge as NG when the impedance of the element is large.
Scheme 218
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Time of heater control duty at 70 % or more | > or = 36000 ms |
| Front oxygen (A/F) sensor impedance. | > 500 ohms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 5000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Front oxygen (A/F) sensor impedance. | < or = 500 ohms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect continuity NG of the oxygen sensor. If the oxygen sensor voltage reading is not within the probable range considering the operating conditions, judge as NG.
Scheme 219
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | > 1.2V | |
| Low | P0137 | |
| Sensor output voltage | < 0.03 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
High: 2500 ms
Low (1): 20000 ms
Low (2): 40000 ms
Low (3): Value from Map
Map
| Fuel Cut Time (second) | 0 | 2000 | 10000 |
|---|---|---|---|
| Time needed for diagnosis (second) | 40000 | 40000 | 60000 |
MAP SPECIFICATION CHART
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| High | P0138 | |
| Sensor output voltage | < or = 1.2 V | |
| Low | P0137 | |
| Sensor output voltage | > or = 0.03 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
High: Less than 1 second
Low (1): Less than 1 second
Low (2): Less than 1 second
Low (3): Less than 1 second
Note. For the detection standard, refer to DTC P0137. Refer to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect the slow response of the oxygen sensor.
Judge as NG if either the rich to lean response diagnosis or lean to rich response diagnosis is NG, and Judge as OK if both are OK.
[Rich --> lean diagnosis response]
- Measure the response time for oxygen sensor output changes when the A/F ratio changes from rich to lean. If the measured response time is larger than the threshold value, it is NG. If it is smaller, it is OK.
- Judge as NG when the oxygen sensor voltage is large (rich) when recovering from a deceleration fuel cut.
[Lean --> rich diagnosis response]
- Measure the response time for oxygen sensor output changes when the A/F ratio changes from lean to rich. If the measured response time is larger than the threshold value, it is NG.
- Judge as NG when the oxygen sensor voltage remains small when recovering from a deceleration fuel cut.
Diagnostic method
Measure the response time of the output change of the oxygen sensor when the A/F ratio changes from rich to lean. And Judge as NG when the measured response time is larger than the threshold value.
Scheme 220
When the oxygen sensor output voltage changes from 0.55 V (rich) to 0.15 V (lean), calculate the minimum response time for output change between 0.5 V and 0.2 V for the judgement criteria.
Scheme 221
- Abnormality Judgement
- Judge as NG when the judgement value is larger than the threshold value after deceleration fuel cut. Response time (diagnosis value) > Threshold value --> abnormal NOTE: Variation time of rear oxygen sensor output voltage is short during fuel cut in deceleration. NG judgement should be performed after deceleration fuel cut. Even without deceleration fuel cut, judge as OK if the value is below the threshold. When the deceleration fuel cut time is 6000 ms or more, judge as NG if the following criteria are met 2000 ms after recovering from the deceleration fuel cut.
- Judge as NG when the oxygen sensor voltage at recovery from a deceleration fuel cut is large.
If the fuel cut time in a deceleration fuel cut is long (6000 ms or more), and even after recovering from a deceleration fuel cut, the oxygen sensor voltage is high (0.55 V or more), judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from rich (0.5 V O 2 output) to lean (0.2 V) when voltage reduces from 0.55 V to 0.15 V | > 491 ms |
| Or Longest time over 0.55 V | > or = 2000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
- Regardless of a deceleration fuel cut, if the response time (diagnosis value) when the oxygen sensor voltage has changed from rich to lean is shorter than the threshold value (judgement value), judge as a normal condition. Response time (diagnosis value) < Threshold value --> normal
- Do not judge as a normal condition.
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from rich (0.5 V O 2 output) to lean (0.2 V) when voltage reduces from 0.55 V to 0.15 V | < or = 491 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time(s)
When the oxygen sensor output voltage changes from 0.25 V (lean) to 0.55 V (rich), calculate the minimum response time for output change between 0.3 V and 0.5 V for the judgement criteria.
Scheme 222
- Abnormality Judgement
- Judge as NG when the judgement value is larger than the threshold value after deceleration fuel cut. Response time (diagnosis value) > threshold value --> abnormal
- If the oxygen sensor voltage is small after recovering from a deceleration fuel cut, and remains small, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from lean (0.3 V O 2 output) to rich (0.5 V) when voltage changes from 0.25 V to 0.55 V | > 2000 ms |
| Or Longest time under 0.25 V | > or = 120000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
- Regardless of a deceleration fuel cut, if the response time (diagnosis value) when the oxygen sensor voltage has changed from rich to lean is shorter than the threshold value (judgement value), judge as a normal condition. Response time (diagnosis value) < or = threshold value --> normal
- Do not judge as a normal condition.
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Shortest time change from lean (0.3 V O 2 output) to rich (0.5 V) when voltage changes from 0.25 V to 0.55 V | < 2000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time(s)
Detect the rear oxygen sensor open or short circuit. Judge as NG when the rear oxygen sensor voltage can be determined to be abnormal considering conditions such as intake air amount, engine coolant temperature, main feedback control and deceleration fuel cut.
Scheme 223
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Minimum output voltage or | > 0.15 V |
| Maximum output voltage | < 0.55 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 200000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Diagnosis of the rear oxygen sensor voltage low side | Incomplete |
| Minimum output voltage | < or = 0.15 V |
| Maximum output voltage | > or = 0.55 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect fuel system malfunction by the amount of main feedback control.
Diagnostic method
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
- Abnormality Judgement
Compare the diagnosed value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time(s) or more, judge that there is a fault in the fuel system.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient every 64 milliseconds flaf = main feedback learning compensation coefficient | > or = Value of Map 2 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 2
| Amount of air (g (oz)/s) | 0(0) | 3.2 (0.11) | 6.4 (0.23) | 9.6 (0.34) | 12.8 (0.45) | 16 (0.56) | 19.2 (0.68) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 1.4 | 1.4 | 1.332 | 1.265 | 1.265 | 1.265 | 1.265 |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 10 s x 5 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | < 1.2 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s
Detect fuel system malfunction by the amount of main feedback control.
Diagnostic method
Fuel system is diagnosed by comparing the target air fuel ratio calculated by ECM with the actual air fuel ratio measured by sensor.
- Abnormality Judgement
Compare the diagnosed value (fsobd) with the threshold value, and if a condition meeting the malfunction criteria below continues for 10 s x 5 time(s) or more, judge that there is a fault in the fuel system.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf In this case: sglmd = measured lambda tglmda = target lambda faf = main feedback compensation coefficient every 64 milliseconds flaf = main feedback learning compensation coefficient | < Value of Map 2 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 2
| Amount of air (g (oz)/s) | 0 (0) | 3.2 (0.11) | 6.4 (0.23) | 9.6 (0.34) | 12.8 (0.45) | 16 (0.56) | 19.2 (0.68) |
|---|---|---|---|---|---|---|---|
| FsobdL1 (%) | 0.6 | 0.6 | 0.668 | 0.735 | 0.735 | 0.735 | 0.735 |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 10 s x 5 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK when the malfunction criteria below continues for 10 seconds.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fsobd = (sglmd - tglmda) + faf + flaf | > or = 0.8 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s
Detect faults in the fuel temperature sensor output properties.
Diagnosis is performed in two methods (drift diagnosis and stuck diagnosis). If either is NG, judge as NG. If both are OK, Judge as OK and clear the NG.
DRIFT DIAGNOSIS
Normally fuel temperature is lower than engine coolant temperature. When the fuel temperature becomes higher than the engine coolant temperature, the range is considered to be shifted, and judged as NG.
Stuck Diagnosis
As the engine warms up (cumulative amount of intake air after starting is large), if the fuel temperature which should rise does not, determine as being stuck and NG.
Scheme 224
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Elapsed time after starting the engine | > or = 20s |
| Engine coolant temperature - Engine coolant temperature at engine start | > 10 °C (50 °F) |
| Fuel temperature - Engine coolant temperature | > or = 10°C (50°F) |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 120 s
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel level | > or = 9.6 l (2.54 US gal, 2.11 lmp gal) |
| Elapsed time after starting the engine | > or = 20 s |
| Engine coolant temperature - Engine coolant temperature at engine start | > 10°C (50°F) |
| Fuel temperature - Engine coolant temperature | < 10°C (50°F) |
| Battery voltage | > or = 10.9 V |
| Engine coolant temperature | < 75°C (167°F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 551043 g (19435.29 02) |
| Fuel temperature difference between Max. and Min. | < 2 °C (35.6 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel temperature difference between Max. and Min. | > or = 2 °C (35.6 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel temperature sensor.
Judge as NG if out of specification.
Scheme 225
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.343951474 V |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.343951474 V |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel temperature sensor.
Judge as NG if out of specification.
Scheme 226
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect for abnormal values in the oil temperature sensor output properties.
Judge as NG when the oil temperature does not rise even though the engine is running under a condition where it should rise.
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine oil temperature | < 15 °C (59 °F) |
| After engine start oil temperature sensor characteristic diagnosis timer. | > or = Judgement value for after engine start oil temperature sensor characteristic diagnosis timer |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
After engine start oil temperature sensor characteristic diagnosis timer (timer for diagnosis).
- Timer stop at fuel cut
- During the driving conditions except a) above, timer counts up as follows.
64 milliseconds + TOILCNT milliseconds (at the time of 64 milliseconds).
Where, TOILCNT is determined as follows
TOILCNT = 0 at idle switch ON
For TOILCNT at Idle switch off, refer to the following table.
| Vehicle speed km/h (MPH) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0 (0) | 8 (5) | 16 (9.9) | 24 (14.9) | 32 (19.9) | 40 (24.9) | 48 (29.8) | 56 (34.8) | ||
| Temperature °C (°F) | 30 (-22) | 64 ms | 73.2 ms | 83.9 ms | 96.3 ms | 113.2 ms | 133.9 ms | 160.2 ms | 194.6 ms |
| 20 (-4) | 64 ms | 73.3 ms | 84 ms | 96.6 ms | 113.7 ms | 135 ms | 162 ms | 197.4 ms | |
| 10 (14) | 64 ms | 73.4 ms | 84.2 ms | 96.9 ms | 114.5 ms | 136.4 ms | 164.4 ms | 201.5 ms | |
| 0 (32) | 64 ms | 73.5 ms | 84.5 ms | 97.4 ms | 115.6 ms | 138.5 ms | 168 ms | 207.6 ms | |
| 10 (50) | 102.2 ms | 114.8 ms | 129.4 ms | 146.7 ms | 171.7 ms | 203.4 ms | 245.1 ms | 302.1 ms | |
VEHICLE SPEED SPECIFICATION CHART
After engine start oil temperature characteristic diagnosis timer judgement value (t).
t = 1882940 ms - 43302 ms x Ti (t > or = 2400000)
Ti = The lowest coolant temperature after starting the engine.
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine oil temperature | > or = 15 °C (59°F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the oil temperature sensor.
Judge as NG when outside of the judgement value.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.166 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.166 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the oil temperature sensor.
Judge as NG when outside of the judgement value.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.716 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 227
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < or = 0.926256 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > 0.926256 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Detect the open or short circuit of throttle position sensor 2.
Judge as NG if out of specification.
Scheme 228
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.858 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.858 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Detect the presence of misfire occurrence. (Revolution fluctuation method)
Monitoring Misfire which influences exhaust deterioration (1.5 times of FTP) and catalyst damage is made obligatory by the law. Misfire affecting these two has two patterns below
- Intermittent misfire (The same cylinder misfires in random, or different cylinders misfire in random.): FTP 1.5 times misfire
- Every time misfire (The same cylinder misfires every time.): FTP 1.5 times misfire, Catalyst damage misfire
The following detecting methods are adopted for these detection.
- Intermittent misfire: FTP 1.5 times misfire 180° Interval Difference Method (MT: 1,800 rpm or less; AT: None) 360° Interval Difference Method (whole range) 720° Interval Difference Method (3,000 rpm or more)
- Misfire every time: FTP 1.5 times misfire, Catalyst damage misfire
- 360° Interval Difference Method
When a misfire occurs, the engine speed will decrease and the crankshaft position speed will change. Calculate the interval difference value (diagnostic value) from crankshaft position speed by the following formula, and judge whether a misfire is occurring or not comparing the calculated result with judgement value. Count the number of misfires, if the misfire ratio is higher during 1000 revs, or 200 revolutions, judge corresponding cylinders as NG.
| Diagnostic value calculation (Calculate from angle speed) --> | Misfire detection every single ignition (Compare diagnostic value with judgement value) --> | NG judgement (Misfire occurrence judgement required by the law) (Compare number of misfire with judgement) |
|---|---|---|
| 180° Interval Difference Method 360° Interval Difference Method 720° Interval Difference Method | FTP 1.5 times misfire NG judgement Catalyst damage misfire NG judgement |
DIAGNOSTIC METHOD CHART
As shown in the following figure, pick a cylinder as the standard and name it omg 0. And the former crankshaft position speed is named omg 1, the second former crankshaft position speed is named omg 2, the third is named omg 3, etc.
Scheme 229
180° Interval Difference Method
| Diagnostic domg 180 = (omg 1 - omg 0) - (omg 5 - omg 1)/4 value |
|---|
| Judge as a misfire in the following cases. domg 180 > judgement value of positive side domg 180 < or = judgement value of negative side (Judgement value before 180° CA) |
INTERVAL DIFFERENCE METHOD CHART
Scheme 230
360° Interval Difference Method
| Diagnostic value | Domg 360 = (omg 1 - omg 0) - (omg 3 - omg 2) |
|---|---|
| Misfire judgement | Domg 360 > Judgement value --> Judge as misfire |
INTERVAL DIFFERENCE METHOD CHART
Scheme 231
720° Interval Difference Method
| Diagnostic value | Domg 720 = (omg 1 - omg 0) - (omg 5 - omg 4) |
|---|---|
| Misfire judgement | Domg 720 > Judgement value --> Judge as misfire |
INTERVAL DIFFERENCE METHOD CHART
Scheme 232
- FTP 1.5 times misfire (Misfire occurrence level which influences exhaust gas)
- Abnormality Judgement
Judgement Value (Judge that malfunction occurs when the misfire ratio is high in 1000 engine revs.)
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission judgement value | > or = 20 x 100/2000% in 1000 revs. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| FTP emission judgement value | < 20 x 100/2000% in 1000 revs. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 engine revs.
- Catalyst damage misfire (Misfire occurrence level damaging catalyst)
- Abnormality Judgement
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire judgement value | > or = Value from Map 3 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 3
| Intake air (g(oz)/rev) | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| 0.16 (0.01) | 0.28 (0.01) | 0.4 (0.01) | 0.52 (0.02) | 0.64 (0.02) | 0.76 (0.03) | 0.92 (0.03) | 1.1 (0.04) | ||
| Engine speed (rpm) | 700 | 100 | 100 | 100 | 100 | 90 | 80 | 64 | 48 |
| 1000 | 100 | 100 | 100 | 100 | 90 | 80 | 63 | 44 | |
| 1500 | 100 | 100 | 90 | 80 | 73 | 67 | 54 | 40 | |
| 2000 | 80 | 80 | 80 | 80 | 68 | 57 | 51 | 44 | |
| 2500 | 80 | 80 | 73 | 67 | 62 | 57 | 51 | 44 | |
| 3000 | 67 | 67 | 62 | 57 | 51 | 44 | 44 | 44 | |
| 3500 | 67 | 67 | 56 | 44 | 40 | 36 | 34 | 31 | |
| 4000 | 57 | 57 | 44 | 31 | 24 | 20 | 20 | 20 | |
| 4500 | 44 | 44 | 33 | 31 | 20 | 20 | 20 | 20 | |
| 5000 | 44 | 44 | 38 | 31 | 20 | 20 | 20 | 20 | |
| 5500 | 36 | 36 | 31 | 27 | 20 | 20 | 20 | 20 | |
| 6000 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
| 6300 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 200 engine revs.
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Catalyst damage misfire judgement value | < Value of Map 3 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 200 engine revs.
Note. For the detection standard, refer to DTC P0301. Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0301. Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0301. Refer to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 233
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 0.243 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 0.243 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of knock sensor.
Judge as NG if out of specification.
Scheme 234
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.709 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.709 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the crankshaft position sensor.
Judge as NG when the crank signal is not input even though the starter was rotated.
Scheme 235
Scheme 236
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter switch | ON |
| Crankshaft position sensor signal | Not detected |
| Battery voltage | > or = 8V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 3000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Crankshaft position sensor signal | Input exists |
| Battery voltage | > or = 8 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect for faults in crankshaft position sensor output properties.
Judge as NG when there is a problem in the number of crankshaft signals for every revolution.
Scheme 237
Scheme 238
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev. | Not = 30 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Cylinder number identification | Completed |
| Amount of crank sensor signal during 1 rev. | = 30 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the camshaft position sensor.
Judge as NG when the number of camshaft signals remains abnormal.
Scheme 239
Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 8V |
| Amount of camshaft sensor signal during 2 revs. | Not = 2 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Two engine revs, x 4 time(s)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage | > or = 8V |
| Amount of camshaft sensor signal during 2 revs. | = 2 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Two engine revs.
Detect the malfunction of camshaft position sensor output property.
Judge as NG when the camshaft line signal input timing is shifted from the crankshaft signal because of timing belt tooth chip etc.
Scheme 240
Scheme 241
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Position of camshaft position sensor signal | Not between BTDC 10°CA and BTDC 80°CA |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 engine revs.
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Position of camshaft position sensor signal | Between BTDC 10°CA and BTDC 80°CA |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Engine two revolutions
Detect EGR system malfunction.
Intake manifold pressure (negative pressure) is constant because the throttle valve is fully closed during deceleration fuel cut. At this time, when the EGR valve is opened/closed, the intake manifold pressure will change. EGR System OK/NG is judged by the range of this change.
Scheme 242
Measure the pressure values when the enable conditions are established, and perform diagnosis by calculating those results.
- Label the intake manifold pressure value as PMOF1, which is observed when enable conditions are established, and set the EGR target step to 50 steps (nearly full open).
- Label the intake manifold pressure value as PMON, which is observed after one second has passed since EGR target step was set to 50 steps (when the enable conditions were established), and set the EGR target step to 0.
- Label the intake manifold pressure as PMOF2, which is observed after one second has passed since EGR target step was set to 0 (after two seconds have passed since the enable conditions were established).
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| PMON - (PMOF1 + PMOF2)/2 | < 2.5 kPa (18.63 mmHg, 0.7 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Scheme 243
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| PMON - (PMOF1 + PMOF2)/2 | > or = 2.5 kPa (18.63 mmHg, 0.7 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1 time
Detect the deterioration of the catalyst function.
Though the front oxygen sensor output would change slowly with a new catalyst, the sensor output with a deteriorated catalyst becomes high and the inversion time is shortened.
For this reason, the catalyst diagnosis is carried out by monitoring the front oxygen sensor output and comparing it with the front oxygen (A/F) sensor output.
Scheme 244
After establishing the execution conditions, calculate the front oxygen (A/F) sensor lambda deviation cumulative value per 32 milliseconds x 4 (Sum |(sglmd n - sglmd n_1 )|) and rear oxygen sensor output voltage deviation cumulative value (Sum (ro2sad n - ro2sad n_1 )), and when the front oxygen (A/F) sensor lambda deviation cumulative value (Sum |(sglmd n - sglmd N-1 )|) becomes the predetermined value or more, calculate the diagnostic value.
- Abnormality Judgement
If the duration of time while the following conditions are met is within the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum (ro2sad n - ro2sad n_1 )|/Sum |(sglmd n - sglmd n_1 ) | > 15.5 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 30 - 55 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is within the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sum (ro2sad n - ro2sad n_1 )/Sum (sglmd n - sglmd n_1 ) | < or = 15.5 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 30 - 55 seconds
Check if there is a leakage in fuel system or not, and perform the function diagnosis of valve.
Scheme 245
In this system diagnosis, check for leakage and valve function is conducted by changing the fuel tank pressure and monitoring the pressure change using the fuel tank pressure sensor. When in 0.04 inch diagnosis, perform in the order of mode Z --> mode A --> mode B --> mode C and mode D; When in 0.02 inch diagnosis, perform in the order of mode A --> mode B --> mode C --> mode D and mode E.
0.04-inch Diagnosis
Scheme 246
| Mode | Mode Description | Diagnosis Period |
|---|---|---|
| Mode Z (Purge control solenoid valve opening failure diagnosis) | Perform purge control solenoid valve opening failure diagnosis from the size of tank pressure variation from diagnosis start. | 0 ms + 3000 ms - 0 ms + 3000 ms + 13000 ms |
| Mode A (Estimated evaporation amount) | Calculate the tank pressure change amount (P1). | 10000 ms |
| Mode B (Sealed negative pressure, large leakage judgement) | Decrease the pressure in the tank to the target value by introducing the intake manifold pressure to the fuel tank. If the tank pressure cannot be reduced, it is diagnosed as large leak. | 0 - 10000 ms + 25000 ms |
| Mode C (Pressure increase check, advanced OK judgement) | Wait until the tank pressure returns to the target (start level of P2 calculation). If the tank pressure does not become the value, make advanced OK judgement. | 0 - 18600 ms |
| Mode D (Negative pressure variation measurement, evaporation leakage diagnosis) | Calculate the tank pressure variation (P2), and obtain the diagnostic value using P1 found in Mode A. Perform the evaporation diagnosis using the diagnostic value. | 0 ms + 10000 ms |
DIAGNOSIS MODE DESCRIPTION CHART
Mode Table for Evaporative Emission Control System Diagnosis
| Mode | Behavior of tank internal pressure under normal conditions | Diagnostic item | DTC |
|---|---|---|---|
| Mode Z | Roughly the same as barometric pressure (Same as 0 kPa (0 mmHg, 0 inHg)) | Purge control solenoid valve is judged to be open. | P0457 |
| Mode A | Pressure is in proportion to amount of evaporative emission. | None | |
| Mode B | Negative pressure is formed due to intake manifold negative pressure | Large leak | P0457 |
| Mode C | Reaches target pressure | None | |
| Mode D | Pressure change is small. | EVAP system large leak determination. 1.0 mm (0.04 in) | P0442 |
EVAPORATIVE EMISSION CONTROL SYSTEM DIAGNOSIS MODE CHART
0.02-Inch Diagnosis
Scheme 247
| Mode | Mode Description | Diagnosis Period |
|---|---|---|
| Mode A (0 point compensation) | When the pressure in the tank is not near 0 mmHg, wait until it returns to 0 point (near 0 mmHg). | 0 - Value of Map 1 |
| Mode B (Negative pressure introduced) | Decrease the pressure in the tank to the target value by introducing the intake manifold pressure to the fuel tank. | 0 - Value of Map 2 |
| Mode C (Negative pressure maintained) | Wait until the tank pressure returns to the target (start level of P2 calculation). | 0 - 25290 ms + 0 + Value of Map 2 |
| Mode D (Negative pressure change calculated) | Calculate the time it takes for the tank pressure to change to the Mode E shifting pressure. If the tank pressure does not change to the Mode E shifting pressure, make advanced OK judgement. | 0 - 0 ms + 200000 ms |
| Mode E (Evaporation generated amount calculation) | Calculate the amount of evaporation (P1). | 0 - 0 ms + 200000 ms + Value of Map 3 |
DIAGNOSIS MODE DESCRIPTION CHART
Map 1
| Fuel level ( l , US gal, lmp gal) | 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57, 8.8 | 50,13.21, 11 | 60,15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 13800 | 13800 | 11400 | 9000 | 7000 | 5000 | 5000 |
MAP SPECIFICATION CHART
Map 2
| Fuel level ( l , US gal, lmp gal) | 0 | 10,2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57, 8.8 | 50,13.21, 11 | 60,15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 20030 | 20030 | 20800 | 21580 | 21970 | 22360 | 22360 |
MAP SPECIFICATION CHART
Map 3
| Fuel level ( l , US gal, lmp gal) | 0 | 10,2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40, 10.57, 8.8 | 50,13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Time Needed for Diagnosis (ms) | 80000 | 80000 | 70000 | 60000 | 60000 | 60000 | 60000 |
MAP SPECIFICATION CHART
Purge control solenoid valve stuck open fault diagnosis
DTC
P0457 Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)
Purpose of Mode Z
When performing the leakage diagnosis of EVAP system, the purge control solenoid valve must operate normally. Therefore, mode Z is used to diagnose the purge control solenoid valve stuck open condition. Note that if a purge control solenoid valve stuck open fault is detected, the EVAP system leakage diagnosis is cancelled.
Diagnostic method
Purge control solenoid valve functional diagnosis is performed by monitoring the tank pressure in mode Z.
- Abnormality Judgement
If OK judgement cannot be made, extend Mode Z, and Judge as NG when the following conditions are established after predetermined amount of time.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Evptez - evptezha | > 0.9 kPa (6.5 mmHg, 0.3 inHg) | P0457 |
| Evptezini | < or = 1.4 kPa (10.7 mmHg, 0.4 inHg) | |
| Time of 2 l (0.53 US gal, 0.44 lmp gal) or more fuel no sloshing | > or = 40000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 0 ms + 3000 ms + 13000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
When judgement for purge control solenoid valve stuck open NG is made, end the evaporative diagnosis. Cancel the evaporative diagnosis when the OK/NG judgement for purge control solenoid valve stuck open cannot be made in Mode Z.
- Normality Judgement
Judge as OK and change to Mode A when the following conditions are established after predetermined time has passed since Mode Z started.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Evptez - evptezha | < or = 0.4 kPa (3 mmHg, 0.1 inHg) | P0457 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Normal
Scheme 248
Normal when evptez - evptezha < or = 0.4 kPa (3 mmHg, 0.1 inHg) is established
Time Needed for Diagnosis: 0 ms + 3000 ms
Purge control solenoid valve Open Fixation
Scheme 249
- evptezini < or = 1.4 kPa (10.7 mmHg, 0.4 inHg)
- evptez - evptezha > 0.9 kPa (6.5 mmHg, 0.3 inHg)
- No fuel sloshing of over 2 l (0.53 US gal, 0.44 lmp gal) lasts for more than 40000 ms
Judge as abnormal when all are established.
Leak Diagnosis
DTC
P0442 Evaporative Emission Control System Leak Detected (Small Leak)
P0457 Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)
- The diagnostic consists of creating a sealed vacuum in the fuel tank and then determining the presence of leakage from the speed at which the tank internal pressure returns to barometric pressure.
- The diagnosis is divided into the following five phases.
Mode A: (Estimated evaporation gas amount)
Calculate the tank pressure change amount (P1) when using mode A. After calculating P1, switch to mode B.
Mode B: (Negative pressure sealed)
Introduce negative pressure in the intake manifold to the tank.
Approx. 0 --> -1.4 kPa (0 --> -10.5 mmHg, 0 --> -0.4 inHg)
When the pressure above (desired negative pressure) is reached, enters Mode C.
In this case, if the tank pressure does not reach the target negative pressure, judge that there is a large leakage in the system and terminate the evaporative emission control system diagnosis.
Abnormality Judgement
Judge as NG (large leakage) when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| Time to reach target negative pressure or | > or = 10000 ms + 25000 ms | P0457 |
| Mode B time | > or = 10000 ms | |
| (Min. pressure value in tank when in mode B) - (Tank pressure when mode B started) | > -0.3 kPa (-2.5 mmHg, -0.1 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 0 ms + 3000 ms + 10000 ms + 10000 ms + 25000 ms
Mode C: (Check pressure rise)
Stop the introduction of negative pressure. (Wait until the tank pressure returns to the start level of P2 calculation.)
Change to Mode D when the tank pressure returns to the start level of P2 calculation.
Judge advanced OK and change to Mode E when it does not return in spite of spending the specified time.
| Tank pressure when starting calculation of P2 | Time for advanced OK judgement |
|---|---|
| 1.4 kPa (-10.5 mmHg, -0.4 inHg) | 18600 ms |
TANK PRESSURE STARTING CALCULATION CHART
Time Needed for Diagnosis: 0 ms + 3000 ms + 10000 ms + 10000 ms + 25000 ms + 18600 ms
Mode D: (Measure amount of negative pressure change)
Monitor the tank pressure change amount when using mode D. In this case, the tank pressure increases, (nears barometric pressure) because evaporation occurs. However, if any leakage exists, the pressure increases additionally in proportion to this leakage. The pressure variation of this tank is P2.
After calculating P2, perform a small leak diagnosis according to the items below.
When Mode D is ended
Assign tank variations measured in Mode A and Mode D, P1 and P2, to the formula below, judge small leaks in the system. If the measured judgement value exceeds the threshold value, it is judged to be a malfunction.
Abnormality Judgement
Judge as NG when the following conditions are established within the predetermined time. Judge as OK and clear the NG if the following conditions are not established within the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value | DTC |
|---|---|---|
| P2 - 1.5 - x P1 | > Value of Map 5 | P0442 |
| P2: Tank pressure that changes every 10000 ms in mode D | ||
| P1: Tank pressure that changes every 10000 ms in mode A |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
*1.5 -: Evaporation amount compensation value when below negative pressure (Amount of evaporation occurrence increases as a vacuum condition increases.)
Map 5 Malfunction criteria limit for evaporation diagnosis
| Fuel temperature vs. Fuel level | 25 °C (77 °F) | 30 °C (86 °F) | 35 °C (95 °F) | 40°C (104°F) | 45°C (113°F) |
|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0.3 kPa (2.1 mmHg, 0.1 inHg) | 0.3 kPa (2.2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.35 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0.3 kPa (2.1 mmHg, 0.1 inHg) | 0.3 kPa (2.2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.35 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) |
| 20 l (5.28 US gal, 4.4 lmp gal) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.4 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.6 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 30 l (7.93 US gal, 6.6 lmp gal) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (3.05 mmHg, 0.1 inHg) | 0.4 kPa (3.15 mmHg, 0.1 inHg) | 0.4 kPa (3.25 mmHg, 0.1 inHg) | 0.4 kPa (3.35 mmHg, 0.1 inHg) |
| 40 l (10.57 US gal, 8.8 lmp gal) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (3.15 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 lmp gal) | 0.4 kPa (3.2 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.5 kPa (3.6 mmHg, 0.1 inHg) | 0.5 kPa (3.7 mmHg, 0.1 inHg) |
| 60 l (15.85 US gal, 13.2 lmp gal) | 0.4 kPa (3.2 mmHg, 0.1 inHg) | 0.4 kPa (3.3 mmHg, 0.1 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.5 kPa (3.6 mmHg, 0.1 inHg) | 0.5 kPa (3.7 mmHg, 0.1 inHg) |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 0 ms + 3000 ms +10000 ms +10000 ms + 25000 ms +18600 ms + 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Leak Diagnosis
DTC
P0456 Evaporative Emission Control System Leak Detected (very small leak)
- The diagnostic consists of creating a sealed vacuum in the fuel tank and then determining the presence of leakage from the speed at which the tank internal pressure returns to barometric pressure.
- The diagnosis is divided into the following five phases.
Mode A: (0 point compensation)
When the pressure in the tank is not near 0 mmHg, wait until it returns to 0 point (near 0 mmHg). Shift to mode B when returned to the 0 point. Cancel the diagnosis when 0 point does not return in the specified time.
Mode B: (Negative pressure introduced)
Introduce negative pressure in the intake manifold to the tank.
Approx. 0 --> -2 kPa (0 --> -15 mmHg, 0 --> -0.6 inHg)
When the pressure above (desired negative pressure) is reached, enters Mode C.
When the tank internal pressure does not reach the target negative pressure, the diagnosis is cancelled.
Mode C: (Negative pressure maintained)
Stop the introduction of negative pressure. (Wait until the tank pressure returns to the start level of P2 calculation.)
Change to Mode D either when the tank pressure returns to the start level of P2 calculation, or when the predetermined amount of time has passed.
Mode D: (Calculate the amount of negative pressure change)
Monitor the tank pressure in mode D, calculate the pressure change in the tank (P2), and measure the time (evpdset) for the tank pressure to change to the Mode E shifting pressure. When the Mode E shifting pressure is reached, Mode E is entered. If it does not change to the Mode E shifting pressure after the predetermined amount of time has passed, make advanced OK judgement or cancel the diagnosis according to the value of P2.
Normality Judgement
Judge as OK when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Advanced OK judgement 1 | |
| Mode D time | > or =0 ms + 10000 ms |
| Tank internal pressure | < or = Value of Map 6 |
| Advanced OK judgement 2 | |
| Mode D time | > or =0 ms + 200000 ms |
| P2 | < or = Value of Map 7 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 6
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10,2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57, 8.8 | 50, 13.21, 11 | 60,15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Tank pressure (kPa, mmHg, inHgl) | 1.9, -14.62, -0.6 | 1.9, -14.62, -0.6 | 1.9, -14.59, -0.6 | 1.9, -14.56, -0.6 | 1.9, -14.42, -0.6 | 1.9, -14.28, -0.6 | 1.9, -14.28, -0.6 |
MAP SPECIFICATION CHART
Map 7
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10, 2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57, 8.8 | 50,13.21, 11 | 60, 15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Tank pressure (kPa, mmHg, inHgl) | 0.9, 7, 0.3 | 0.9, 7, 0.3 | 0.9, 7.05, 0.3 | 0.9,7.1, 0.3 | 1.1,8.2, 0.3 | 1.3, 9.6, 0.4 | 1.3,9.6, 0.4 |
MAP SPECIFICATION CHART
Mode E: (Evaporation occurrence amount calculation)
Calculate the change of tank pressure with the time evpdset (P1) to judge as NG/OK according to the value of P1. (ambiguous determination acceptable).
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| P1 | < Value of Map 8 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 8 Malfunction criteria limit for evaporation diagnosis
| Time (evpdset) vs. Fuel level | 0 ms | 30000 ms | 50000 ms | 100000 ms | 160000 ms | 200000 ms |
|---|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 20 l (5.28 US gal, 4.4 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 30 l (7.93 US gal, 6.6 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) | 0.4 kPa (2.7 mmHg, 0.1 inHg) |
| 40 l (10.57 US gal, 8.8 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.2 kPa (1.85 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) | 0.3 kPa (2.5 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.3 kPa (2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0 kPa (0 mmHg, 0 inHg) |
| 60 l (15.85 US gal, 13.2 lmp gal) | 0 kPa (0 mmHg, 0 inHg) | 0.1 kPa (0.5 mmHg, 0 inHg) | 0.3 kPa (2 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0.3 kPa (2.3 mmHg, 0.1 inHg) | 0 kPa (0 mmHg, 0 inHg) |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: Value of Map 1+ Value of Map 2 + 25290 ms + 0 + Value of Map 2 + 0 ms + 200000 ms + Value of Map 3 + 0 ms + 200000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| P1 | > Value of Map 9 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map 9 Malfunction criteria limit for evaporation diagnosis
| Time (evpdset) vs. Fuel level | 0 ms | 30000 ms | 50000 ms | 100000 ms | 160000 ms | 200000 ms |
|---|---|---|---|---|---|---|
| 0 l (0 US gal, 0 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) |
| 10 l (2.64 US gal, 2.2 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.5 kPa (3.5 mmHg, 0.1 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) | 0.6 kPa (4.2 mmHg, 0.2 inHg) |
| 20 l (5.28 US gal, 4.4 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.4 kPa (3.25 mmHg, 0.1 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) | 0.5 kPa (4.1 mmHg, 0.2 inHg) |
| 30 l (7.93 US gal, 6.6 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.4 kPa (3 mmHg, 0.1 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) | 0.5 kPa (3.9 mmHg, 0.2 inHg) |
| 40 l (10.57 US gal, 8.8 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.3 kPa (2.25 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) | 0.5 kPa (3.4 mmHg, 0.1 inHg) |
| 50 l (13.21 US gal, 11 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.2 kPa (1.5 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) |
| 60 l (15.85 US gal, 13.2 lmp gal) | 0.1 kPa (1 mmHg, 0 inHg) | 0.2 kPa (1.5 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) | 0.4 kPa (2.9 mmHg, 0.1 inHg) |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: Value of Map 1 + Value of Map 2 + 25290 ms + 0 + Value of Map 2 + 0 ms + 200000 ms + Value of Map 3 + 0 ms + 200000 ms
Detect open or short circuit of the drain valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 250
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the drain valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 251
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the tank pressure sensor output property abnormality.
Judge as NG when there is no pressure variation, which should exist in the tank, considering the engine status.
Scheme 252
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Number of times that the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is 2 l (0.53 US gal, 0.44 lmp gal) or more (with enable condition established) | > or =16 time(s) |
| Maximum - Minimum tank pressure (with enable condition completed) | < 0 kPa (0.375 mmHg, 0 inHg) |
| Maximum - Minimum fuel temperature (with enable condition completed) | > or = 7 °C (44.6 °F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
If the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is less than 2 l (0.53 US gal, 0.44 lmp gal), extend 60 s and make judgement with the Max. and Min. values for the fuel level in 60 s x 2. If a difference does not appear, extend the time (60 s x 3, 60 s x 4, 60 s x 5) and continue the judgement. If the difference between the Max. fuel level every 60 s and Min. fuel level every 60 s is 2 G (0.53 US gal, 0.44 lmp gal) or more, the diagnosis counter counts up.
Time Needed for Diagnosis: 60 s x 16 time(s) or more
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Maximum - Minimum tank pressure | > or = 0 kPa (0.375 mmHg, 0 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the fuel tank pressure sensor.
Judge as NG if out of specification.
Scheme 253
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < -7.5 kPa (-65.9 mmHg, -2.2 inHg) |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 15000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > or = -7.5 kPa (-55.9 mmHg, -2.2 inHg) |
| Battery voltage | > or = 10.9 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of the fuel tank pressure sensor.
Judge as NG if out of specification.
Scheme 254
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > or = 7.9 kPa (59.6 mmHg, 2.3 inHg) |
| Fuel temperature | < 35 °C (95 °F) |
| Barometric pressure | > or = 75 kPa (563 mmHg, 22.2 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 15000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < 7.9 kPa (59.6 mmHg, 2.3 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0442. Refer to DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0442. Refer to DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 255
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | <0.75 |
| Terminal output voltage | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect open or short circuit of the purge control solenoid valve.
Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 256
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Duty ratio of "ON" | > or = 0.25 |
| Terminal output voltage | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal output voltage | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect malfunctions of the fuel level sensor output property.
If the fuel level does not vary in a particular driving condition/engine condition where it should, judge as NG.
Scheme 257
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 330957 g (11672.85 oz) |
| Max. - Min. values of fuel level output | < 2.6 l (0.69 US gal, 0.57 lmp gal) |
| Battery voltage | > or = 10.9 V |
| Engine speed | < 6000 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Malfunction indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Accumulated amount of intake air | > or = 330957 g (11672.85 oz) |
| Max. - Min. values of fuel level output | > or = 2.6 l (0.69 US gal, 0.57 lmp gal) |
| Battery voltage | > or =10.9 V |
| Engine speed | < 6000 rpm |
| Elapsed time after starting the engine | > or = 5000 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 258
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 0.173 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | > or = 0.173 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of fuel level sensor. Judge as NG if out of specification.
Scheme 259
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or =3000 ms |
| Output voltage | > or = 7.212 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 3000 ms |
| Output voltage | < 7.212 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the unstable output faults from the fuel level sensor caused by noise. Judge as NG when the max. value and cumulative value of output voltage variation of the fuel level sensor is larger than the threshold value.
Calculate the Max. value (DELFLMAX) and cumulative value (SUMFL) of output voltage variation of fuel level sensor during 12.2 seconds. Judge it normal when both max. and cumulative values are not over the threshold value. Otherwise, when either of them is over the threshold value, the diagnosis counter counts up. Judge as NG if the counter indicated 4 time(s).
Scheme 260
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Integrated times of the condition reaching follows | > or = 4 time(s) |
| DELFLMAX or SUMFL | > or = Value from Map |
| At this time, DELFLMAX: Maximum difference of sensor output for 12288 ms SUMFL: Integrated value of the sensor output deviation for 12288 ms | > or = 25.92 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map
| Fuel level ( l , US gal, lmp gal) | 0, 0, 0 | 10,2.64, 2.2 | 20, 5.28, 4.4 | 30, 7.93, 6.6 | 40,10.57, 8.8 | 50,13.21, 11 | 60,15.85, 13.2 |
|---|---|---|---|---|---|---|---|
| Measured voltage (V) | 0.27 | 0.27 | 0.426 | 0.582 | 0.738 | 0.894 | 0.894 |
MAP SPECIFICATION CHART
The diagnosis counter does not count up when the following conditions are completed within 12288 ms.
| Maximum value - Minimum value of change of tank pressure during 12288 ms | > or = 0 kPa (0.375 mmHg, 0 inHg) |
|---|---|
| Maximum value - Minimum value of battery voltage during 12288 ms | > or = 1.09 V |
MAXIMUM VALUE - MINIMUM VALUE BATTERY VOLTAGE SPECIFICATION CHART
Time Needed for Diagnosis: 12288 ms x 4 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| DELFLMAX | < Value from Map |
| SUMFL | < 25.92 V |
| At this time, DELFLMAX: Maximum difference of sensor output for 12288 ms SUMFL: Integrated value of the sensor output deviation for 12288 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 12288 ms
Judge as NG when outside of the judgement value.
Judge NG when the received data from ABSCM&H/U is abnormal vehicle speed, and the vehicle speed data is impossible.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front ABS wheel speed sensor status Either of the following is established | Malfunction |
| Front left wheel speed | > or = 300 km/h (186.4 MPH) |
| Front right wheel speed | > or = 300 km/h (186.4 MPH) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Front left wheel speed | > 0 km/h (0 MPH) and < 300 km/h (186.4 MPH) |
| Front right wheel speed | > 0 km/h (0 MPH) and < 300 km/h (186.4 MPH) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual engine speed - Targeted engine speed | < - 100 rpm |
| Feedback value for ISC | Max. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s x 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual engine speed - Targeted engine speed | > or = -100 rpm |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s
Detect the malfunction that actual engine speed is not close to target engine speed during idling. Judge as NG when actual engine speed is not close to target engine speed during idling.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual - Target engine speed | > or = 200 rpm |
| Feedback value for ISC | Min. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s x 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Actual - Target engine speed | < 200 rpm |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10 s
Detect the open or short circuit of starter SW.
Judge as ON NG when the starter SW signal remains ON.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Engine condition | After engine starting |
| Starter OFF signal | Not detected |
| Battery voltage | > or = 8 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 180000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Starter OFF signal | Detected |
| Battery voltage | > or = 8 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
| DTC | Item | Outline of Diagnosis |
|---|---|---|
| P0513 | Incorrect Immobilizer Key | Incorrect immobilizer key (Use of unregistered key in body integrated unit) |
| P1570 | Antenna | Faulty antenna |
| P1571 | Reference Code Incompatibility | Reference code incompatibility between body integrated unit and ECM |
| P1572 | IMM Circuit Failure (Except Antenna Circuit) | Communication failure between body integrated unit and ECM |
| P1574 | Key Communication Failure | Failure of body integrated unit to verify key (transponder) ID code or transponder failure |
| P1576 | EGI Control Module EEPROM | ECM malfunctioning |
| P1577 | IMM Control Module EEPROM | Body integrated unit malfunctioning |
| P1578 | Meter Failure | Reference code incompatibility between body integrated unit and combination meter |
DTC REFERENCE CHART
Judge as NG when the conditions for the outline of the diagnosis of the top are established.
Detect malfunction of CAN communication.
When CAN communications is not possible, and CAN communications with TCM is not possible, judge as NG if data from the TCM is not normal.
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Bus off flag or error warning flag | Set (error) |
| Or ID received from control module connected to driving system CAN | None during 500 milliseconds |
| Or Data updated from control module connected to driving system CAN | None during 500 milliseconds |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > 10.9 V |
| Starter switch | OFF |
| Engine | Run |
| Bus off flag or error warning flag | Clear (No error) |
| ID received from control module connected to driving system CAN | Yes |
| Data updated from control module connected to driving system CAN | Yes |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 1000 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Detect the malfunction of microcomputer (RAM).
When there is a problem in the main CPU normal RAM, or the sub CPU normal RAM, judge as NG. Judge as OK when both are operating properly.
If it is possible to write data to the whole area of RAM in the initial routine, and is possible to read the same data, it is judged as OK, and if not, NG.
Abnormality Judgement
Judge as NG if the criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Main CPU normal RAM abnormal | |
| Write 5AA5A55A and then read. (Whole area of RAM) | 5AA5A55A cannot be read. |
| Write A55A5AA5 and then read. (Whole area of RAM) | A55A5AA5 cannot be read. |
| Sub CPU normal RAM abnormal | |
| Write 5AA5 and then read. (Whole area of RAM) | 5AA5 cannot be read. |
| Write A55A and then read. (Whole area of RAM) | A55A cannot be read. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Undetermined
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Normality Judgement
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Main CPU normal RAM abnormal | |
| Write 5AA5A55A and then read. (Whole area of RAM) | 5AA5A55A can be read. |
| And write A55A5AA5 and then read. (Whole area of RAM) | A55A5AA5 can be read. |
| Sub CPU normal RAM abnormal | |
| Write 5AA5 and then read. (Whole area of RAM) | 5AA5 can be read. |
| And write A55A and then read. (Whole area of RAM) | A55A can be read. |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Judge as NG when SUM value of ROM is outside the standard value.
Abnormality Judgement
Judge as NG if the criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| SUM value of ROM | Standard |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Undetermined
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when any one of the followings is established.
- When the read value of throttle position sensor 1 signal is mismatched between main CPU and sub CPU.
- When the read value of accelerator pedal position sensor 1 signal is mismatched between main CPU and sub CPU.
- When the sub CPU operates abnormally.
- When the communication between main CPU <--> sub CPU is abnormal.
- When the input amplifier circuit of throttle position sensor 1 is abnormal.
- When the cruise control cannot be canceled correctly.
- When the signal of brake SW1 and 2 is mismatched.
Scheme 261
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| (1) Difference of CPU reading value of the throttle position sensor signal | > or = 0.0858 V |
| (2) Difference of CPU read value of the accelerator pedal position sensor signal | > or = 0.35 V |
| (3) WD pulse from sub CPU | WD pulse occur |
| (4) Communication between CPU | Possible to communicate |
| (5) Throttle position sensor 1 opening angle - (Throttle position sensor 1 opening angle after passing amplifier) 1/4 | < 3° |
| (6) Cruise control cancel signal at brake ON | Cruise control cancel signal ON |
| (7) Brake switch 1,2 signal | SW1 and 2 are matched |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
- 600 milliseconds
- 830 milliseconds
- 200 milliseconds
- 200 milliseconds
- 24 milliseconds
- 250 milliseconds
- 200 milliseconds
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when the target opening angle and actual opening angle is mismatched or the current to motor is the specified duty or more for specified time continuously.
Scheme 262
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Difference between target opening angle and actual opening angle | 3.5° or less |
| Output duty to drive circuit | 95% or less |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
- Target opening angle and actual opening angle: 250 milliseconds (For NG) 2000 milliseconds (For OK)
- Output duty to drive circuit: 2000 milliseconds
Details of Judgement Value
Scheme 263
Details of Judgement time (The actual opening angle < target opening angle is always 1000 milliseconds)
Scheme 264
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when there is CAN communication with the TCM and there is a MIL lighting request.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | Yes |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| MIL lighting request from TCM | None |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Judge the open or short circuit of the neutral SW.
Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON" | LOW (ON) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "OFF" and when the other switches are "ON" | HIGH (OFF) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
- Abnormality Judgement
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | LOW (ON) continues. |
| Driving condition change Engine speed 600 rpm - 900 RPM&Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 2550 RPM&Vehicle speed > or = 64 km/h (39.8 MPH) | From a) to b) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear NG when there is change in the neutral SW.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to HIGH (OFF). |
| Driving condition change Engine speed 600 rpm - 900 RPM&Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 2550 RPM&Vehicle speed > or = 64 km/h (39.8 MPH) | From a) to b) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Judge the open or short circuit of the neutral SW.
Judge as NG when the ECM neutral terminal input differs from the reception data from TCM.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | HIGH (OFF) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal in ECM when "P"/"N" range in TCM are "ON" and when the other switches are "OFF" | LOW (ON) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open or short circuit of neutral SW.
Judge as NG when there is no change in the neutral SW even if the driving shift was applied. (There is neutral SW ON/OFF inversion from the vehicle speed and engine speed.)
- Abnormality Judgement
Judge NG when the malfunction criteria below are completed determined times or more after the neutral SW change.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | HIGH (OFF) continues. |
| Driving condition change Engine speed 600 rpm - 900 RPM&Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 2550 RPM&Vehicle speed > or = 64 km/h (39.8 MPH) | From a) to b) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 3 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear NG when there is change in the neutral SW.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Neutral switch signal (while changing from a to b below) | Changes to LOW (ON). |
| Driving condition change Engine speed 600 rpm - 900 RPM&Vehicle speed = 0 km/h (0 MPH) Engine speed 1600 rpm - 2550 RPM&Vehicle speed > or = 64 km/h (39.8 MPH) | From a) to b) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect that lambda value remains low.
Judge as NG when lambda value is abnormal in accordance with lambda value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio lambda > 1: Lean lambda < 1: Rich |
AIR FUEL RATIO REFERENCE CHART
Scheme 265
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | < 0.85 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > or =0.85 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect that lambda value remains high.
Judge as NG when lambda value is abnormal in accordance with A, value of front oxygen (A/F) sensor and running conditions such as vehicle speed, amount of intake air, engine coolant temperature, sub feedback control, etc.
| Lambda value = Actual air fuel ratio/Theoretical air fuel ratio lambda > 1: Lean lambda < 1: Rich |
AIR FUEL RATIO REFERENCE CHART
Scheme 266
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | > 1.15 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 10000 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Lambda value | < or = 1.15 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Judge as NG when the valve is opened more than the default opening angle, but does not move to the close direction with the motor power stopped.
Scheme 267
- Abnormality Judgement
Judge as NG when the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | < 2° |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Opening variation after continuity is set to OFF | > or = 2° |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 3400 ms
Detect the open/short circuit of pressure control solenoid valve.
Judge as NG when ECM output level is different from actual terminal level.
Scheme 268
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or =10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs OFF signal | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open/short circuit of pressure control solenoid valve.
Judge as NG when ECM output level is different from actual terminal level.
Scheme 269
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Elapsed time after starting the engine | > or = 1 second |
| Terminal output voltage when ECM outputs ON signal | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the abnormal function (stuck closed) of the drain valve.
Judge as NG when fuel tank pressure is low.
Scheme 270
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | < or =-4 kPa (-30 mmHg, -1.2 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 3000 s
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Fuel tank pressure | > -4 kPa (-30 mmHg, -1.2 inHg) |
| Cumulative time when all the malfunction criteria below are met. | > or = 30000 s |
| Purge control solenoid valve duty | Not = 0 |
| Fuel temperature | 10°C (14°F) - 70 °C (158 °F) |
| Intake manifold relative pressure | > or = -26.7 kPa (-200 mmHg, -7.9 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the blow-by hose disconnection abnormality.
Judge as NG when the diagnosis terminal voltage is high.
Scheme 271
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
| Positive crankcase ventilation diagnosis voltage | High |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
| Positive crankcase ventilation diagnosis voltage | Low |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
- Detects open or short circuit of EGR.
- Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 272
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | Low level |
| Or Terminal voltage level when EGR operates | Low level |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | High level |
| Terminal voltage level when EGR operates | High level |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 128 ms
- Detects open or short circuit of EGR.
- Judge as NG when the ECM output level differs from the actual terminal level.
Scheme 273
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | High level |
| Or Terminal voltage level when EGR operates | High level |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Terminal voltage level when ECM outputs OFF signal | Low level |
| Terminal voltage level when EGR operates | Low level |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 128 ms
Note. For the detection standard, refer to DTC P1492. Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P1493. Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P1492. Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P1493. Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P1492. Refer to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P1493. Refer to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect the open/short circuit of back-up power supply circuit.
Judge as NG when the backup power voltage is low.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | Low |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 2500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Voltage of back-up power supply | High |
| Battery voltage | > or = 10.9 V |
| Engine condition | After engine starting |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Note. For the detection standard, refer to DTC P0513. Refer to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria.
Detect malfunctions of the catalyst advanced idling retard angle control.
Judge as NG when ECM is not controlling the angle properly during catalyst advanced idling retard angle control.
Judge as NG if there is exhaust gas temperature diagnosis and idle speed diagnosis and if either of them is NG.
- Exhaust gas temperature diagnosis Judge as NG when the estimated exhausted gas temperature in 14 seconds after the cold start is below the specified value.
- Idle speed diagnosis
Judge as NG when actual engine speed is not close to target engine speed after terminating the retard angle control.
- Exhaust gas temperature diagnosis
Abnormality Judgement
Calculate the estimated exhaust gas temperature when the diagnostic enable condition is established. Judge as NG when the following conditions are established after engine starting within the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Estimated exhaust gas temperature | < Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map
| Coolant temperature after starting the engine | 40 °C (-40 °F) | 30 °C (-22 °F) | 20 °C (-4°F) | 10 °C (14°F) | 0°C (32 °F) | 10 °C (50 °F) | 20 °C (68 °F) | 30 °C (86 °F) | 40 °C (104 °F) | 50 °C (122 °F) |
|---|---|---|---|---|---|---|---|---|---|---|
| Threshold value (AT model) | 162 °C (323.6 °F) | 162°C (323.6 °F) | 162 °C (323.6 °F) | 162 °C (323.6 °F) | 162 °C (323.6 °F) | 162 °C (323.6 °F) | 162 °C (323.6 °F) | 154 °C (309.2 °F) | 142°C (287.6 °F) | 142 °C (287.6 °F) |
| Threshold value (MT model) | 168°C (334.4 °F) | 168 °C (334.4 °F) | 168 °C (334.4 °F) | 168 °C (334.4 °F) | 168 °C (334.4 °F) | 168°C (334.4 °F) | 168 °C (334.4 °F) | 160 °C (320 °F) | 145 °C (293 °F) | 145 °C (293 °F) |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 14 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Estimated exhaust gas temperature | > or = Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
- Idle speed diagnosis
Abnormality Judgement
Judge as NG when the following conditions are established after the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Continuous time of (Target engine speed - Actual engine speed > -300 rpm) | > or = 6000 ms |
| Continuous time of (actual retard amount > 30 °CA) | > or = 0 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 14 seconds
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
Normality Judgement
Judge as OK and clear the NG if the following conditions are established.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Continuous time of (Target engine speed - Actual engine speed > -300 rpm) | < 6000 ms |
| Continuous time of (actual retard amount > 30 °CA) | < 0 ms |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the malfunction of fuel system from the size of the sub feedback learning value.
Control the sub feedback learning and judge as NG when the learning value is in the lean zone.
Scheme 274
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < -0.04 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 5 s x 1 time(s)
Malfunction Indicator Light illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = -0.04 + 0 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 5 s
Detect the malfunction of fuel system from the size of the sub feedback learning value.
Sub feedback learning is being performed. When the learning value goes to the rich side, judge as NG.
Scheme 275
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | > or = 0.04 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 5 s x 1 time(s)
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sub feedback learning value | < 0.04 + -0.002 |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 5 s
Judge as NG when the motor current becomes large or drive circuit is heated.
Scheme 276
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor current | < or = 8A |
| Drive circuit inner temperature | < or = 175°C (347°F) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
- 500 milliseconds (For NG)
- 2000 milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when the electronic throttle control power is not supplied even when ECM sets the electric control throttle relay to ON.
Scheme 277
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | > or = 5 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
- 400 milliseconds (For NG)
- 2000 milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when the electronic throttle control power is supplied even when ECM sets the electronic throttle control relay to OFF.
Scheme 278
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Motor power voltage | < or = 5 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis
- 600 milliseconds (For NG)
- 400 milliseconds (For OK)
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Judge as NG when full close point learning cannot conducted or abnormal value is detected.
Scheme 279
Judge as OK and clear the NG when the malfunction criteria below are met.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Throttle sensor opening angle at full close point learning | 10.127° or more, 19.872° or less |
| Throttle opening angle when the ignition switch is ON - Throttle minimum stop position | > or = 1.683° |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 8 - 80 milliseconds
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 280
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Malfunction indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Detect the open or short circuit of accelerator pedal position sensor 1.
Judge as NG if out of specification.
Scheme 281
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | > or = 4.783 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 32 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 1 input voltage | < 4.783 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 32 ms
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 282
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 0.217 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Detect the open or short circuit of accelerator pedal position sensor 2.
Judge as NG if out of specification.
Scheme 283
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | > or = 4.783 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Sensor 2 input voltage | < 4.783 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 100 ms
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 284
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | > Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map
| Throttle position sensor 1 opening angle (°) = d | 0° < or = d < 2.125 ° | 2.125 ° < or = d < 4.25° | 4.25° < or = d < 9° | 9 ° < or = d < 31.625° | 31.625 ° < or = d |
|---|---|---|---|---|---|
| Sensor output difference (°) | 5.15° | 6.15° | 8.28° | 10.4° | 12.4° |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 212 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | < or = Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 24 ms
Judge as NG when the signal level of throttle position sensor 1 is different from the throttle position sensor 2.
Scheme 285
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | > Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Map
| Throttle position sensor 1 opening angle (°) = d | 0° < or = d < 0.6 ° | 0.6°< or = d < 1.2° | 1.2° < or = d < 2° | 2° < or = d < 4° | 4° < or = d |
|---|---|---|---|---|---|
| Sensor output difference (°) | 1.465° | 1.597° | 1.663° | 2.455 ° | 3.116° |
MAP SPECIFICATION CHART
Time Needed for Diagnosis: 116 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Signal difference between two sensors | < or = Value from Map |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 116 ms
Detect the malfunction of barometric pressure sensor output property.
Judge as NG when the barometric pressure sensor output is largely different from the intake manifold pressure at engine start.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Barometric pressure - Intake manifold pressure | > or = 26.7 kPa (200 mmHg, 7.9 inHg) |
| Intake manifold pressure at engine start - intake manifold pressure] | < 1.3 kPa (9.99 mmHg, 0.4 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 328 ms
Malfunction Indicator Light Illumination: Illuminates when malfunction occurs in 2 continuous driving cycles.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Barometric pressure - Intake manifold pressure | < 26.7 kPa (200 mmHg, 7.9 inHg) |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 262 ms
Detect the open/short circuit of the barometric pressure sensor.
Judge as NG if out of specification.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 1.706646812 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 1.706646812 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
Detect the open/short circuit of the barometric pressure sensor.
Judge as NG if out of specification.
- Abnormality Judgement
If the duration of time while the following conditions are met is longer than the time indicated, judge as NG.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | > or = 4.233789985 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: 500 ms
Malfunction Indicator Light Illumination: Illuminates as soon as a malfunction occurs.
- Normality Judgement
Judge as OK and clear the NG if the continuous time while the following conditions are established is more than the predetermined time.
Judgement Value
| Malfunction Criteria | Threshold Value |
|---|---|
| Output voltage | < 4.233789985 V |
MALFUNCTION CRITERIA AND THRESHOLD VALUE REFERENCE CHART
Time Needed for Diagnosis: Less than 1 second
