SPECIFICATION
| Fuel tank | Capacity | 64 l (16.9 US gal, 14.1 lmp gal) |
|---|---|---|
| Location | Under rear seat | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 550 - 850 kPa (5.6 - 8.7 kg/cm 2 , 79.7 - 123.2 psi) | |
| Discharge rate | 125 l (33 US gal, 27.5 lmp gal)/h or more [12 V at 300 kPa (3.06 kg/cm 2 , 43.5 psi)] | |
| Fuel filter | In-tank type | |
FUEL TANK SPECIFICATION
Scheme 312
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 17 (1.7, 12.5)
T3: 19 (1.9, 14.0)
T4: 25 (2.5, 18.4)
Scheme 313
Tightening torque: N.m (kgf-m, ft-lb)
T1: 2 (0.2, 1.5)
T2: 8 (0.8, 5.9)
Scheme 314
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 24 (2.4, 17.7)
Scheme 315
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 9 (0.9, 6.6)
T3: 18 (1.8, 13.3)
T4: 33 (3.4, 24.3)
Scheme 316
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 0.9)
T2: 7.5 (0.8, 5.5)
T3: 8 (0.8, 5.9)
T4: 18 (1.8, 13.3)
Scheme 317
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 7.5 (0.8, 5.5)
Scheme 318
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body.
Refer to "Throttle Body" for removal and installation procedure. Refer to REMOVAL , Throttle Body. Refer to INSTALLATION , Throttle Body.
Scheme 319
- Disconnect the ground cable from battery.
- Disconnect the connector from the manifold absolute pressure sensor and remove the manifold absolute pressure sensor from throttle body.
