SPECIFICATION
| Fuel tank | Capacity | 64 l (16.9 US gal, 14.1 lmp gal) |
|---|---|---|
| Location | Under rear seat | |
| Fuel pump | Type | Impeller |
| Shutoff discharge pressure | 550 - 850 kPa (5.61 - 8.67 kgf/cm 2 , 79.8 - 123.3 psi) | |
| Discharge rate | 155 l (40.9 US gal, 34.1 lmp gal)/h or more [12 V at 300 kPa (3.06 kgf/cm 2 , 43.5 psi)] | |
| Fuel filter | In-tank type | |
FUEL TANK SPECIFICATION
Scheme 538
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 0.9)
T2: 6.4 (0.7, 4.7)
T3: 8.3 (0.8, 6.1)
T4: 19 (1.9, 14.0)
T5: 25 (2.5, 18.4)
Scheme 539
Tightening torque: N.m (kgf-m, ft-lb)
T: 8(0.8,5.9)
Scheme 540
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
72: 24 (2.4, 17.7)
Scheme 541
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4, 3.2)
T2: 9 (0.9, 6.6)
T3: 18 (1.8, 13.3)
T4: 33 (3.4, 24.3)
Scheme 542
Tightening torque: N.m (kgf-m, ft-lb)
T1: 1.25 (0.1, 0.9)
T2: 2.5 (0.3, 1.8)
T3: 7.5 (0.8, 5.5)
T4: 8 (0.8, 5.9)
T5: 18 (1.8, 13.3)
Scheme 543
Tightening torque: N.m (kgf-m, ft-lb)
T1: 4.4 (0.4,3.2)
T2: 7.5 (0.8,5.5)
Scheme 544
Throttle body is a non-disassembled part, so do not remove the throttle position sensor from throttle body.
Refer to "Throttle Body" for removal and installation procedure. Refer to REMOVAL, Throttle Body. Refer to INSTALLATION, Throttle Body.
The tumble generator valve assembly cannot be disassembled.
Refer to "Tumble Generator Valve Assembly" for removal and installation procedures. Refer to REMOVAL, Tumble Generator Valve Assembly. Refer to INSTALLATION, Tumble Generator Valve Assembly.
