Engine Cooling System (Sti): Overhaul Subaru Impreza GH

ASSEMBLY

Assemble in the reverse order of disassembly.

Tightening torque

4.41 N.m (0.45 kgf-m, 3.25 ft-lb)

Tightening torque

3.4 N.m (0.3 kgf-m, 2.5 ft-lb)

Scheme 30

1. Set the vehicle on a lift.
2. Disconnect the ground cable from battery.
3. Lift up the vehicle.
4. Remove the under cover.
5. Disconnect the sub fan motor connector (B).
6. Lower the vehicle.
7. Remove the air intake duct. Refer to «REMOVAL»(ref-357076-S39226648372010030800000) , Air Intake Duct.
8. Remove the bolts which secure the radiator sub fan motor assembly and the over flow pipe.
9. Raise the radiator sub fan motor assembly slightly, remove the pin at the lower part of the radiator sub fan motor assembly from the radiator hole, and remove the radiator sub fan motor assembly from the lower side of the vehicle.

Assemble in the reverse order of disassembly.

Tightening torque

4.41 N.m (0.45 kgf-m, 3.25 ft-lb)

Tightening torque

3.4 N.m (0.3 kgf-m, 2.5 ft-lb)

Scheme 31

1. Pull out the over flow hose (A).
2. Pull out the reservoir tank to the arrow direction while pushing the claw (B).
