Starting System & Charging System (Sti): Other Subaru Impreza GH

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

GENERAL TOOL

GENERAL TOOL CHART

Scheme 118

Scheme 119

Scheme 120

1. Disconnect the ground cable from the battery.
2. Remove the intercooler. Ref. to «REMOVAL»(ref-357076-S27886545212010030800000) , Intercooler.
3. Disconnect the connector (B) and terminal (A) from starter.
4. Remove the starter from transmission.

YOKE

Make sure that the pole is set at the predetermined position.

OVERRUNNING CLUTCH

Check that there is no wear or damage to the piston teeth. Replace the overrunning clutch if it is damaged.

Check that it rotates smoothly when rotated in the correct direction (counterclockwise) and does not return to the other direction. Replace the overrunning clutch if any fault is found.

Scheme 121

1. Measure the length of the brush. Replace if it exceeds service limits or there is abnormal wear or cracks. Brush length: Standard 12.3 mm (0.484 in) Limit 7.0 mm (0.276 in)
2. Check that the brush moves smoothly in the brush holder.
3. Measure the brush spring force with a spring scale. Replace the brush holder if below the service limit. Brush spring force: Standard 75.9 - 19.5 N (1.62 - 1.99 kgf, 3.57 - 4.38 lbf) (When new) Limit 2.5 N (0.25 kgf, 0.56 lbf)

DIODE

Scheme 122

Scheme 123

1. Check for continuity between the diode lead and positive side heat sink. If resistance is 1 ohms or more only in the direction from the diode lead to the heat sink, replace the rectifier.
2. Check for continuity between the negative side heat sink and diode lead. If resistance is 1 ohms or more only in the direction from the heat sink to the diode lead, replace the rectifier.

Scheme 124

Scheme 125

1. Inspect the slip rings for contamination or any roughness on the sliding surface. Repair the slip ring surface using a lathe or sand paper.
2. Measure the slip ring outer diameter. Replace the rotor assembly if the slip ring is worn. Slip ring outer diameter: Standard 22.7 mm (0.894 in) Limit 22.1 mm (0.870 in)
3. Using a circuit tester, check the resistance between slip rings. If resistance exceeds the standard, replace the rotor assembly. Standard: Approx. 1.8 - 2.2 ohms
4. Check the continuity between slip ring and rotor core or shaft. If the resistance is 1 ohms or less, replace the rotor assembly.
5. Check the rear ball bearing. If there is any noise, or the rotor does not rotate smoothly, replace the bearings.

Scheme 126

Scheme 127

1. Inspect continuity between the stator coil lead wire terminals. If the resistance is 1 ohms or more, replace the stator assembly.
2. Inspect the continuity between the stator coil stator core and lead wire terminals. If the resistance is 1 ohms or less, replace the stator assembly.

Scheme 128

Scheme 129

1. Measure the length of each brush. Replace the brush if wear exceeds service limits. There is a service limit mark (A) on each brush. Brush length: Standard 18.5 mm (0.728 in) Limit 5.0 mm (0.197 in)
2. Using a spring pressure indicator, push the brush into the brush holder until its tip protrudes 2 mm (0.08 in). Then measure the pressure of brush spring. If the pressure is 2.648 N (270 g, 9.52 oz) or less, replace the brush spring with a new part. 4.609 - 5.786 N (470 - 590 g, 16.58 - 20.810 oz) pressure is required on the new spring.

BEARING (FRONT SIDE)

Check the front ball bearing. Replace the ball bearings if there is resistance in the rotation, or if there is any abnormal noise.

Scheme 130

1. Disconnect the positive (+) terminal after disconnecting the negative (-) terminal of battery.
2. Remove the harness clip of the negative terminal from the battery rod.
3. Remove the flange nut from battery rod and remove battery holder.
4. Remove the battery.

EXTERNAL PARTS

Check the battery case, top cover, vent plugs, and terminal posts for dirt or cracks. If necessary, clean with water and wipe with a dry cloth.

Apply a thin coat of grease on the terminal posts to prevent corrosion.

ELECTROLYTE LEVEL

Check the electrolyte level in each cell. If the level is below MIN level, bring the level to MAX level by pouring distilled water into the battery cell. Do not fill beyond MAX level.

Scheme 131

1. Measure specific gravity of electrolyte using a hydrometer and a thermometer. Specific gravity varies with temperature of electrolyte so that it must be corrected at 20°C (68°F) using the following calculation: S 20 = St + 0.0007 x (t - 20) S 20 : Specific gravity corrected at electrolyte temperature of 20°C St: Measured specific gravity t: Measured temperature (°C) Judge whether or not the battery requires charging according to corrected specific gravity. Standard specific gravity: 1.220 - 1.290 [at 20°C (68°F)]
2. Measuring the specific gravity of the electrolyte in the battery will disclose the state of charge of the battery. The relation between specific gravity and state of charge is as shown in the figure.

MEASUREMENT

JUDGEMENT OF BATTERY IN CHARGED CONDITION

1. Specific gravity of electrolyte should be held within the specific range of 1.250 - 1.290 for one hour or more.
2. Voltage per battery cell should be held at a specific value in a range of 2.5 - 2.8 V for one hour or more.

CHECK CONDITION OF CHARGE WITH HYDROMETER

HYDROMETER INDICATOR CONDITION CHART

NORMAL CHARGING

Charge the battery at the current value specified by manufacturer or at approximately 1/10 of battery's ampere-hour rating.

QUICK CHARGING

Quick charging is a method that the battery is charged in a short period of time with a relatively large current by using a quick charger.

Since a large current flow raises electrolyte temperature, the battery is subject to damage if the large current is used for prolonged time. For this reason, the quick charging must be carried out within a current range that will not raise the electrolyte temperature to 40°C (104°F) or more.

Also the quick charging is a temporary mean to bring battery voltage up to some level, and battery should be charged slowly with low current as a rule.
