STARTER SPECIFICATIONS
Note. For additional starter specifications (Scheme 1)or (Scheme 2).
| Application | Specifications | ||
|---|---|---|---|
| Brush Length | |||
| Standard | .484" (12.3 mm) | ||
| Limit | .276" (7 mm) | ||
| Brush Spring Force | |||
| Except DOHC Turbo M/T Model | |||
| Standard (New) | 3.57-4.38 Lbs (15.9-19.5 N) | ||
| Limit | .56 Lbs (2.5 N) | ||
| DOHC Turbo M/T Model | |||
| Standard (New) | 4.9 Lbs (21.6 N) | ||
| Limit | 1.3 Lbs (5.9 N) | ||
| Commutator Run-Out | |||
| Standard | .002" (.05 mm) | ||
| Service Limit | Less than .0039" (.10 mm) | ||
| Depth Of Segment Mold | .02" (.5 mm) | ||
STARTER SPECIFICATIONS
Scheme 1
Scheme 2
TORQUE SPECIFICATIONS
For starter specification for 2002-03 models, see STARTING SYSTEM article in SPECIFICATIONS.
For starter specification for 2004 models, see STARTING SYSTEM article in SPECIFICATIONS.
