GENERATOR SPECIFICATIONS
| Application (1) | Specification |
|---|
| Brush Length |
| Standard | .728" (18.5 mm) |
| Limit | .197" (5 mm) |
| Brush Spring Pressure |
| New | 16.58-20.81 oz. (4.61-5.78 N) |
| Replace | 9.52 oz. (2.65 N) |
| (1) See BRUSH under COMPONENT TESTS. |
| Application | Specifications |
|---|
| Slip Ring Continuity Test |
| Specified Resistance | 1.8-2.2 Ohms |
| Slip Ring Outer Diameter |
| Standard | .894" (22.7 mm) |
| Limit | .87" (22.1 mm) |
ROTOR ASSEMBLY SPECIFICATIONS
Scheme 1
TORQUE SPECIFICATIONS
| Application | Specifications - Ft. Lbs. (N.m) |
|---|
| Generator (1) |
| Bearing Retainer Screw (T1) | (2) |
| Nut-To-Rear Cover (T1) | (2) |
| Pulley Nut | 33 (44) |
| Through-Bolt & Screw-To-Front Cover (T1) | (2) |
| Through-Bolt-To-Rear Cover (T1) | (2) |
| V-Belt |
| Lock Bolt Through Bolt (Generator Belt Tensioner Lock Bolt) | 18 (25) |
| Slider Bolt (Generator Belt Tensioner Adjustment Bolt) | (3) |
| (1) See COMPONENT LOCATIONS . (2) Not available through manufacturer. (3) Tighten to 71 INCH (8 N.m). |
| (2) | Not available through manufacturer. |
| (3) | Tighten to 71 INCH (8 N.m). |
