Engine Mechanical (h4so) Subaru Impreza WRX GH

SPECIFICATION

GENERAL SPECIFICATION

Note. US: Undersize OS: Oversize

BELT TENSION SPECIFICATION

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.
9. All parts should be thoroughly cleaned, paying special attention to engine oil passages, pistons and bearings.
10. Rotating parts and sliding parts such as piston, bearing and gear should be coated with oil prior to assembly.
11. Be careful not to let oil, grease or coolant contact the timing belt, clutch disc and flywheel.
12. All removed parts, if to be reused, should be reinstalled in the original positions and directions.
13. Bolts, nuts and washers should be replaced with new parts as required.
14. Even if necessary inspections have been made in advance, proceed with assembly work while making rechecks.
15. Remove or install the engine in an area where chain hoists, lifting devices, etc. are available for ready use.
16. Be sure not to damage coated surfaces of body panels with tools, or not to stain seats and windows with coolant or oil. Place a cover over fender, as required, for protection.
17. Prior to starting work, prepare the following: Service tools, clean cloth, containers to catch coolant and oil, wire ropes, chain hoist, transmission jacks, etc.
18. Lift up or lower the vehicle when necessary. Make sure to support the correct positions.

SPECIAL TOOL

SPECIAL TOOL CHART ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 18231AA010 CAM SPROCKET WRENCH Used for removing and installing cam sprocket LH. CAM SPROCKET WRENCH (499207100) can also be used. 499207400 CAM SPROCKET WRENCH Used for removing and installing cam sprocket RH. 1B021XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system. 498267800 CYLINDER HEAD TABLE Used for replacing valve guides. Used for removing and installing valve spring. 498277200 STOPPER SET Used for installing automatic transmission assembly to engine. 498457000 ENGINE STAND ADAPTER RH Used together with the ENGINE STAND (499817100). 498457100 ENGINE STAND ADAPTER LH Used together with the ENGINE STAND (499817100). 498497100 CRANKSHAFT STOPPER Used for removing and installing the flywheel and the drive plate. 498747300 PISTON GUIDE Used for installing piston in cylinder. 498857100 VALVE OIL SEAL GUIDE Used for press-fitting of intake and exhaust valve guide oil seals. 499017100 PISTON PIN GUIDE Used for installing piston pin, piston and connecting rod. 499037100 CONNECTING ROD BUSHING REMOVER & INSTALLER Used for removing and installing connecting rod bushing. 499587200 CRANKSHAFT OIL SEAL INSTALLER Used for installing crankshaft oil seal. Used together with the CRANKSHAFT OIL SEAL GUIDE (499597100). 499587500 OIL SEAL INSTALLER Used for installing the camshaft oil seal. Used together with the OIL SEAL GUIDE (499597000). 499587700 CAMSHAFT OIL SEAL INSTALLER Used for installing cylinder head plug. 499097700 PISTON PIN REMOVER ASSY Used for removing piston pin. 499497000 TORX® PLUS Used for removing and installing camshaft cap. 499587100 OIL SEAL INSTALLER Used for installing oil pump oil seal. 499597000 OIL SEAL GUIDE Used for installing the camshaft oil seal. Used together with the OIL SEAL INSTALLER (499587500). 499597100 CRANKSHAFT OIL SEAL GUIDE Used for installing crankshaft oil seal. Used together with the CRANKSHAFT OIL SEAL INSTALLER (499587200). 499718000 VALVE SPRING REMOVER Used for removing and installing valve spring. 499767200 VALVE GUIDE REMOVER Used for removing valve guides. 499767400 VALVE GUIDE REAMER Used for reaming valve guides. 499767700 VALVE GUIDE ADJUSTER Used for installing valve guides. (Intake side) 499767800 VALVE GUIDE ADJUSTER Used for installing valve guides. (Exhaust side) 499817100 ENGINE STAND Stand used for engine disassembly and assembly. Used together with the ENGINE STAND ADAPTER RH (498457000) & LH (498457100). 499977100 CRANK PULLEY WRENCH Used to stop rotation of the crank pulley when loosening or tightening crank pulley bolts. (MT model) 499977400 CRANK PULLEY WRENCH Used to stop rotation of the crank pulley when loosening or tightening crank pulley bolts. (AT model) 499987500 CRANKSHAFT SOCKET Used for rotating crankshaft. 42099AE000 QUICK CONNECTOR RELEASE Used for removing the quick connector. 18354AA000 VALVE ROCKER HOLDER Used for installing the valve rocker assembly (intake). (2-piece set) 18258AA000 SPRING INSTALLER Used for installing the valve rocker assembly (intake)

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

GENERAL TOOL

GENERAL TOOL CHART

PROCEDURE

It is possible to conduct the following service procedures with engine on vehicle, however, the procedures described in this article are based on the condition that the engine is removed from vehicle.

1. V-belt
2. Timing belt
3. Valve rocker assembly
4. Camshaft
5. Cylinder head

INSPECTION

Scheme 105

1. After warming-up the engine, turn the ignition switch to OFF.
2. Make sure that the battery is fully charged.
3. Release the fuel pressure. RELEASING OF FUEL PRESSURE , PROCEDURE, Fuel . >
4. Remove all the spark plugs. REMOVAL , Spark Plug . >
5. Fully open the throttle valve.
6. Check the starter motor for satisfactory performance and operation.
7. Hold the compression gauge tightly against the spark plug hole. NOTE: When using a screw-in type compression gauge, the screw should be less than 18 mm (0.71 in) long.
8. Crank the engine by the starter motor, and read the maximum value on the gauge when the needle of gauge is steady.
9. Perform at least two measurements per cylinder, and check that the values are correct. Compression (throttle full open): Standard 1,020 - 1,275 kPa (10.4 - 13.0 kgf/cm 2 , 148 - 185 psi) Difference between cylinders 49 kPa (0.5 kgf/cm 2 , 7 psi) or less
10. After inspection, install the related parts in the reverse order of removal.

1. Before checking the idle speed, check the following item: Check the air cleaner element is free from clogging, ignition timing is correct, spark plugs are in good condition, and hoses are connected properly. Check the malfunction indicator light does not illuminate.
2. Warm-up the engine.
3. Read the engine idle speed using Subaru Select Monitor. READ CURRENT DATA FOR ENGINE (NORMAL MODE) , OPERATION, Subaru Select Monitor . >
4. Check the idle speed when no-loaded. (Headlight, heater fan, rear defroster, radiator fan, A/C and etc. are OFF) Idle speed [No load and gears in neutral, "P" or "N" range]: 650±100 rpm (MT model) 700±100 rpm (A T model)
5. Check the idle speed when loaded. (Turn the A/C switch to "ON" and operate the compressor for at least one minute before measurement.)

Idle speed [A/C ON and gears in neutral, "P" or "N" range]

850±100 rpm

Note. Idle speed cannot be adjusted manually, because the idle speed is automatically adjusted. If the prescribed idle speed cannot be maintained, refer to the General On-board Diagnosis Table under "Engine Control System". BASIC DIAGNOSTIC PROCEDURE . >

1. Before checking the ignition timing, check the following item: Check the air cleaner element is free from clogging, spark plugs are in good condition, and hoses are connected properly. Check the malfunction indicator light does not illuminate.
2. Warm-up the engine.
3. Stop the engine, and turn the ignition switch to OFF.
4. Connect the timing light to #1 cylinder spark plug cord, and then light the timing mark with the timing light.
5. Start the engine and check the ignition timing at idle speed as shown below.

Ignition timing [BTDC/rpm]

10°±8°/650 (MT Model)

15°±10°/700 (AT Model)

Scheme 106

If the timing is not correct, check the ignition control system. BASIC DIAGNOSTIC PROCEDURE . >

Scheme 107

1. Warm-up the engine.
2. Disconnect the brake vacuum hose from intake manifold, and then install the vacuum gauge.
3. Keep the engine at idle speed and read the vacuum gauge indication. By observing the gauge needle movement, the internal condition of the engine can be diagnosed as described below. Vacuum pressure (at idling, A/C "OFF"): Less than -60.0 kPa (-450 mmHg, -17.72 inHg)

VACUUM PRESSURE REFERENCE

Scheme 108

Scheme 109

1. Disconnect the ground cable from the battery.
2. Remove the oil pressure switch. REMOVAL , Oil Pressure Switch . >
3. Connect the oil pressure gauge to cylinder block.
4. Connect the ground cable to battery.
5. Start the engine, and measure the oil pressure. Oil pressure: Standard 98 kPa (1.0 kg/cm 2 , 14 psi) or more at 600 rpm 294 kPa (3.0 kg/cm 2 , 43 psi) or more at 5, 000 rpm If the oil pressure is out of specification, check oil pump, oil filter and lubrication line. INSPECTION , Engine Lubrication System Trouble in General . > If the oil pressure warning light is ON and oil pressure is within specification, check the oil pressure switch. INSPECTION , Engine Lubrication System Trouble in General . > NOTE: Standard value is based on an engine oil temperature of 80°C (176°F).
6. After measuring the oil pressure, install the oil pressure switch. INSTALLATION , Oil Pressure Switch . >

Note. Check or replace the fuel pump and fuel delivery line if the fuel pressure is out of the standard.

Scheme 110

Scheme 111

1. Release the fuel pressure. RELEASING OF FUEL PRESSURE , PROCEDURE, Fuel . >
2. Disconnect the fuel delivery hose from the fuel damper, and connect the fuel pressure gauge.
3. Install the fuse of fuel pump to main fuse box.
4. Start the engine.
5. Measure the fuel pressure after warming up the engine.

Note. The fuel pressure gauge registers 10 to 20 kPa (0.1 to 0.2 kg/cm 2 , 1 to 3 psi) higher than standard values during high-altitude operations.

Fuel pressure

Standard

338 - 348 kPa (3.4 - 3.5 kg/cm 2 , 49 - 50 psi)

Note. Inspection and adjustment of valve clearance should be performed while engine is cold.

Scheme 112

Scheme 113

Scheme 114

1. Disconnect the ground cable from the battery.
2. Remove the timing belt cover LH.
3. Remove the fuel injector. REMOVAL , Fuel Injector . >
4. When inspecting #1 and #3 cylinders Disconnect the spark plug cords from spark plugs RH side. RH SIDE , REMOVAL, Spark Plug . > Place a suitable container under the vehicle. Disconnect the PCV hose from the rocker cover RH. Remove the bolts, then remove the rocker cover RH.
5. When inspecting #2 and #4 cylinders Disconnect the spark plug cords from spark plugs LH side. LH SIDE , REMOVAL, Spark Plug . > Place a suitable container under the vehicle. Disconnect the PCV hose from the rocker cover LH. Remove the bolts, then remove the rocker cover LH.
6. Set #1 cylinder piston to top dead center of compression stroke by rotating the crank pulley clockwise using the socket wrench. NOTE: When the arrow mark (A) on cam sprocket LH is at the top position, the #1 cylinder piston is at top dead center of the compression stroke.
7. Measure #1 cylinder valve clearance by using thickness gauge (A). NOTE: Insert the thickness gauge (A) in as horizontally as possible with respect to the valve stem end face. Lift up the vehicle and measure the exhaust valve clearances. Valve clearance: Intake 0.20±0.04 mm (0.0079±0.0016 in) Exhaust 0.25±0.04 mm (0.0098±0.0016 in)
8. If necessary, adjust the valve clearance. ADJUSTMENT, Valve Clearance. >
9. Measure the valve clearance in #3, #2 and #4 cylinder in the same measurement procedure as #1 cylinder in this order. NOTE: Be sure to set the cylinder pistons to their respective top dead centers on compression stroke before measuring valve clearances. By rotating the crank pulley clockwise every 180° from the state that #1 cylinder piston is on the top dead center of compression stroke, #3, #2 and #4 cylinder pistons come to the top dead center of compression stroke in this order.
10. After inspection, install the related parts in the reverse order of removal.

ADJUSTMENT

Note. Adjustment of valve clearance should be performed while engine is cold.

Scheme 115

1. Set #1 cylinder piston to top dead center of compression stroke by rotating the crank pulley clockwise using the socket wrench. NOTE: When the arrow mark (A) on cam sprocket LH is at the top position, the #1 cylinder piston is at top dead center of the compression stroke.
2. Adjust the #1 cylinder valve clearance. Loosen the valve rocker nut and screw. Set a suitable thickness gauge. While noting the valve clearance, tighten the valve rocker adjusting screw. When the specified valve clearance is obtained, tighten the valve rocker nut. NOTE: Insert a thickness gauge in a direction as horizontal as possible with respect to the valve stem end face. Lift up the vehicle and adjust the exhaust valve clearances. Valve clearance: Intake 0.20±0.04 mm (0.0079±0.0016 in) Exhaust 0.25±0.04 mm (0.0098±0.0016 in) Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
3. Adjust the valve clearance in #3, #2 and #4 cylinder in the same adjustment procedure as #1 cylinder in this order. NOTE: Be sure to set the cylinder pistons to their respective top dead centers on compression stroke before adjusting valve clearances. By rotating the crank pulley clockwise every 180° from the state that #1 cylinder piston is on the top dead center of compression stroke, #3, #2 and #4 cylinder pistons come to the top dead center of compression stroke in this order.
4. Ensure the valve clearances of each cylinder are within specifications. If necessary, readjust the valve clearances.

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

1. Set the vehicle on a lift.
2. Change the bolt mounting position from (A) to (B), and completely open the front hood. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
3. Remove the V-belt covers.
4. Collect the refrigerant from the A/C system. PROCEDURE , Refrigerant Recovery Procedure . >
5. Release the fuel pressure. RELEASING OF FUEL PRESSURE , PROCEDURE, Fuel . >
6. Disconnect the battery cable, and then remove the battery from the vehicle body.
7. Remove the air intake duct, air cleaner case and air intake chamber. REMOVAL , Air Intake Duct . > REMOVAL , Air Cleaner Case . > REMOVAL , Air Intake Chamber . >
8. Remove the under cover.
9. Remove the radiator from the vehicle. REMOVAL , Radiator . >
10. Disconnect the A/C pressure hoses from A/C compressor.
11. Remove the air intake chamber stay.
12. Disconnect the following connectors and cables. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine ground terminal Engine harness connectors Generator connector and terminal A/C compressor connector Power steering switch connector
13. Disconnect the following hoses. Brake booster vacuum hose Heater inlet and outlet hoses
14. Remove the power steering pump. Remove the front side belts. FRONT SIDE BELT, REMOVAL, V-belt. > Remove the bolts which secure the power steering pump to the bracket. Place the power steering pump on the right side wheel apron.
15. Lift up the vehicle.
16. Remove the front and center exhaust pipes. REMOVAL , Front Exhaust Pipe . >
17. Disconnect the engine ground terminal from the cylinder head.
18. Remove the bolts and nuts which hold lower side of transmission to engine. AT model MT model
19. Remove the nuts which hold the engine mount to the front cross member.
20. Separate the torque converter clutch from drive plate. (AT model) Lower the vehicle. Remove the service hole plug. Remove the bolts which hold torque converter clutch to drive plate. Remove all bolts while turning the crankshaft with a socket wrench.
21. Remove the pitching stopper.
22. Disconnect the fuel hoses from fuel pipe. Disconnect the quick connector on the fuel delivery line by pushing the ST in the direction of the arrow. ST 42099AE000 QUICK CONNECTOR RELEASE Remove the clip and disconnect the evaporation hose from the pipe. CAUTION: Be careful not to spill fuel. Catch the fuel from hoses using a container or cloth.
23. Support the engine with a lifting device and wire ropes.
24. Support the transmission with a garage jack. CAUTION: Doing this is very important to prevent the transmission from lowering due to its own weight.
25. Separation of engine and transmission CAUTION: Before removing the engine away from transmission, check to be sure no work has been overlooked. Remove the starter. REMOVAL , Starter . > Set the ST to torque converter clutch case. (AT model) ST 498277200 STOPPER SET Remove the bolts which hold upper side of transmission to engine. AT model MT model
26. Remove the engine from vehicle. Slightly raise the engine. Raise the transmission with garage jack. Move the engine horizontally until main shaft is withdrawn from clutch cover. Slowly move the engine away from engine compartment. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
27. Remove the engine mounting.

Scheme 140

1. Install the engine mounting onto the engine. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
2. Apply a small amount of grease to splines of main shaft. (MT model)
3. Position the engine in engine compartment and align it with transmission. NOTE: Be careful not to damage adjacent parts or body panels with crank pulley, oil level gauge, etc.
4. Tighten the bolts which hold upper side of transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb) AT model MT model
5. Remove the lifting device and wire ropes.
6. Remove the garage jack.
7. Install the pitching stopper. Tightening torque: T1:50 N.m (5.1 kgf-m, 36.9 ft-lb) T2:58 N.m (5.9 kgf-m, 42.8 ft-lb)
8. Remove the ST from the torque converter clutch case. (AT model) NOTE: Be careful not to drop the ST into the torque converter clutch case when removing the ST. ST 498277200 STOPPER SET
9. Install the starter. INSTALLATION , Starter . >
10. Install the torque converter clutch to drive plate. (AT model) Tighten the bolts which hold torque converter clutch to drive plate. Tighten other bolts while rotating the crankshaft using socket wrench. NOTE: Be careful not to drop bolts into the torque converter clutch housing. Tightening torque: 25 N.m (2.5 kgf-m, 18.4 ft-lb) Install the service hole plug.
11. Install the power steering pump. Install the power steering pump to the bracket. Tightening torque: Refer to "COMPONENT" of "Power Steering" for the tightening torque. COMPONENT , General Description . > Connect the power steering switch connector. Install and adjust the front side belt. FRONT SIDE BELT, INSTALLATION, V-belt. >
12. Lift up the vehicle. >
13. Tighten the bolts and nuts which hold lower side of the transmission to engine. Tightening torque: 50 N.m (5.1 kgf-m, 36.9 ft-lb) AT model MT model
14. Tighten the nuts which hold the engine mounting to the cross member. Tightening torque: 85 N.m (8.7 kgf-m, 62.7 ft-lb)
15. Install the engine ground terminal to the cylinder head.
16. Install the front and center exhaust pipe. INSTALLATION , Front Exhaust Pipe . >
17. Lower the vehicle.
18. Connect the following hoses. Fuel delivery hose and evaporation hose Heater inlet and outlet hoses Brake booster vacuum hose
19. Connect the following connectors and terminals. Front oxygen (A/F) sensor connector Rear oxygen sensor connector Engine harness connectors Generator connector and terminal Tightening torque: 15 N.m (1.5 kgf-m, 11.1 ft-lb) A/C compressor connector
20. Install the air intake chamber stay. Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)
21. Tighten the engine ground cable. Tightening torque: 14 N.m (1.4 kgf-m, 10.1 ft-lb)
22. Install the A/C pressure hoses. INSTALLATION , Hose and Tube . >
23. Install the radiator to vehicle. INSTALLATION , Radiator . >
24. install the air intake duct, air cleaner case and air intake chamber. INSTALLATION , Air Intake Duct . > INSTALLATION , Air Cleaner Case . > INSTALLATION , Air Intake Chamber . >
25. Install the under cover.
26. Install the battery in the vehicle, and connect cables.
27. Fill engine coolant. FILLING OF ENGINE COOLANT , REPLACEMENT, Engine Coolant . >
28. Check the ATF level and replenish it if necessary. INSPECTION , Automatic Transmission Fluid . >
29. Charge the A/C system with refrigerant. PROCEDURE , Refrigerant Charging Procedure . >
30. Install the V-belt cover. Tightening torque: 13 N.m (1.3 kgf-m, 9.6 ft-lb)
31. Change the bolt mounting position from (B) to (A), and close the front hood. Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
32. Lower the vehicle from the lift.

1. Check that pipes, hoses, connectors and clamps are installed firmly.
2. Check the engine coolant is at specified level.
3. Check the ATF is at specified level. (AT model)
4. Start the engine and check for exhaust gas, engine coolant, leaks of fuel, etc. Also check for noise and vibrations.

REMOVAL

1. Remove the engine unit. REMOVAL, Engine Assembly. >
2. Remove the engine mounting from engine assembly.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

Engine mounting

35 N.m (3.6 kgf-m, 25.8 ft-lb)

Make sure that no crack or other damages do not exist.

Scheme 141

1. After removing the engine from body, secure it to ST in the following procedure. ST1 498457000 ENGINE STAND ADAPTER RH ST2 498457100 ENGINE STAND ADAPTER LH ST3 499817100 ENGINE STAND
2. In this article the procedures described under each index are all connected and stated in order. The procedure for overhauling of the engine will be completed when you go through all steps in the process. Therefore, in this article, to conduct the particular procedure within the flow of a section, you need to go back and conduct the procedure described previously in order to do that particular procedure.

Note. Perform the work with the engine installed to body when replacing a single part.

FRONT SIDE BELT

1. Remove the V-belt covers.
2. Remove the air intake duct. REMOVAL , Air Intake Duct . >
3. Loosen the bolt (A).
4. Loosen the slider bolt (B).
5. Remove the front side belt (C).

Scheme 142

REAR SIDE BELT

1. Remove the front side belts. FRONT SIDE BELT, REMOVAL, V-belt. >
2. Cut the rear side belt with a wire cutter, etc., and discard.

Scheme 143

1. Wipe off any sand, dust, oil or water from the pulley grooves with a cloth.
2. Install the front side belt (C), and adjust the slider bolt (B) so as to obtain the specified belt tension. INSPECTION, V-belt. >
3. Tighten the bolt (A).
4. Tighten the slider bolt (B). Tightening torque: Bolt (A) 25 N.m (2.5 kgf-m, 18.4 ft-lb) Slider bolt (B) 8 N.m (0.8 kgf-m, 5.9 ft-lb)
5. Install the air intake duct. INSTALLATION , Air Intake Duct . >
6. Install the V-belt cover.

Tightening torque

13 N.m (1.3 kgf-m, 9.6 ft-lb)

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

1. Wipe off any sand, dust, oil or water from the pulley grooves with a cloth.
2. Wipe off any oil, water, mud or rust attached to the front side of the crank pulley with a cloth.
3. Turn the crank pulley to the right slowly, until the crank pulley service hole near the top. CAUTION: Never turn the crank pulley to the left.
4. Attach a new rear side belt on the A/C compressor pulley.
5. Insert the claw of the belt stopper (A) into the lower hole (B) on the compressor bracket as shown in the figure, and attach using bolt (C).
6. Mount the belt guide by matching to the belt line on the front side belt of the crank pulley.
7. Insert the belt guide holder into the crank pulley service hole so as to clamp the belt guide. NOTE: The longer side of the belt guide holder is the upper side.
8. Turn the crank pulley slowly to the right, and set the belt guide at an approximately 45° position.
9. Place the rib face of the rear side belt onto the grooves of the crank pulley, and sandwich the rear side belt with the belt guide holder.
10. Place the tool through the loop of the rear side belt, and set on the crank pulley bolt.
11. While checking for the following, turn the crank pulley slowly to the right by approximately 90° and set the belt guide to the position shown in the figure. The ribs of the rear side belt are properly riding on the grooves of the A/C compressor pulley. The ribs of the rear side belt are properly riding on the grooves of the crank pulley. The surface of the rear side belt is being pressed by the belt stopper. The rear side belt is riding properly on the belt guide.
12. While checking for the following, turn the crank pulley slowly to the right by approximately 90° and set the belt guide to the position shown in the figure. The rear side belt is not twisted. The ribs of the rear side belt are properly riding on the grooves of the A/C compressor pulley. The ribs of the rear side belt are properly riding on the grooves of the crank pulley. The surface of the rear side belt is being pressed by the belt stopper. The rear side belt is riding properly on the belt guide.
13. Turn the crank pulley slowly to the right, and attach the rear side belt. CAUTION: Because there is a possibility of damage to the rear side belt, and the belt guide holder falling off, care must be taken to make sure that the total of steps 8), 11), 12), and 13) does not exceed 330°.
14. Remove the belt guide and belt guide holder from the crank pulley.
15. Remove the belt stopper from the compressor bracket. CAUTION: Make sure to remove the belt stopper, as leaving it on can cause smoke, flames or belt breakage.
16. Make sure that the belt ribs are properly riding on the grooves of the pulleys, and turn the crank pulley slowly to the right twice to break in the rear side belt.
17. Discard the provided tools (belt stopper, belt guide, belt guide holder, bolt).
18. Install the front side belt. FRONT SIDE BELT, INSTALLATION, V-belt. >

1. Replace the front side belt, if cracking, fraying or wear is found.
2. Check the front side belt tension and adjust it if necessary by changing the generator installing position.

Front side belt tension

(when using a belt tension gauge): When installing new parts

640 - 780 N (65 - 80 kgf, 144 - 175 lbf)

At inspection

490 - 640 N (50 - 65 kgf, 110 - 144 lbf)

Scheme 165

Front side belt tension (when not using a belt tension gauge)

When installing new parts

7 - 9 mm (0.276 - 0.354 in)

At inspection

9 - 11 mm (0.354 - 0.433 in)

Scheme 166

If cracks, fraying or wear is found, and when abnormal noise is produced, replace the rear side belt.

Note. Because the rear side belt is a stretch type belt, it is not necessary to check deflection and tension.

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 167

1. Remove the V-belts. REMOVAL, V-belt. >
2. Use the ST to lock the crank pulley, and remove the crank pulley bolts. ST 499977100 CRANK PULLEY WRENCH (MT model) ST 499977400 CRANK PULLEY WRENCH (AT model)
3. Remove the crank pulley.

AT MODEL

1. Install the crank pulley.
2. Use the ST to lock the crank pulley, and attach the crank pulley bolts. ST 499977400 CRANK PULLEY WRENCH Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 32.5 ft-lb). Tighten the crank pulley bolts. Tightening torque: 130 N.m (13.3 kgf-m, 95.9 ft-lb)
3. Check that the tightening angle of the crank pulley bolt is 45° or more. Perform the following procedure when less than 45°. CAUTION: If the tightening angle of crank pulley bolt is less than 45°, the bolt is damaged. In this case, the bolt must be replaced. Replace the crank pulley bolts and clean them. Crank pulley bolt: Part No. 12369AA011 Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 32.5 ft-lb). Tighten the crank pulley bolts 45° to 60°. NOTE: Conduct the tightening procedures by confirming the turning angle of crank pulley bolt referring to the gauge indicated on timing belt cover.
4. Install the V-belts. INSTALLATION, V-belt. >

MT MODEL

1. Install the crank pulley.
2. Use the ST to lock the crank pulley, and attach the crank pulley bolts. ST 499977100 CRANK PULLEY WRENCH Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 32.5 ft-lb). Tighten the crank pulley bolts. Tightening torque: 180 N.m (18.4 kgf-m, 132.8 ft-lb)
3. Check that the tightening angle of the crank pulley bolt is 65° or more. Perform the following procedure when less than 65°. CAUTION: If the tightening angle of crank pulley bolt is less than 65°, the bolt is damaged. In this case, the bolt must be replaced. Replace the crank pulley bolts and clean them. Crank pulley bolt: Part No. 12369AA011 Clean the crankshaft thread using compressed air. Apply engine oil to the crank pulley bolt seat and thread. Tighten the bolts temporarily with tightening torque of 44 N.m (4.5 kgf-m, 32.5 ft-lb). Tighten the crank pulley bolts 65° to 75°. NOTE: Conduct the tightening procedures by confirming the turning angle of crank pulley bolt referring to the gauge indicated on timing belt cover.
4. Install the V-belts. INSTALLATION, V-belt. >

1. Make sure the V-belt is not worn or otherwise damaged.
2. Check the tension of the front side belt. INSPECTION, V-belt. >

Note. Perform the work with the engine installed to body when replacing a single part.

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover LH.
4. Remove the front timing belt cover.

Scheme 168

Scheme 169

1. Install the front timing belt cover. Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
2. Install the timing belt cover LH. Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
3. Install the crank pulley. INSTALLATION, Crank Pulley. >
4. Install the V-belts. INSTALLATION, V-belt. >

Check the cover for damage.

Note. Perform the work with the engine installed to body when replacing a single part. For operation procedures, refer to "Timing Belt" in the PM article. TIMING BELT . >

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
4. Remove the timing belt guide. (MT model)
5. If the alignment mark or arrow mark (which indicates the direction of rotation) on timing belt fade away, put new marks before removing the timing belt as shown in procedures below. Use the ST to turn crankshaft. Align the mark (a) of sprocket to the cylinder block notch (b), and then ensure the right side cam sprocket mark (c), cam cap and cylinder head matching surface (d) or left side cam sprocket mark (e), timing belt cover notch (f) are properly adjusted. ST 499987500 CRANKSHAFT SOCKET Using white paint, put an alignment mark or an arrow mark on timing belts in relation to the crank sprocket and cam sprockets. Z 1 :46.8 teeth Z 2 : 43.7 teeth
6. Remove the belt idler (A).
7. Remove the belt idler (B).
8. Remove the timing belt.

Scheme 177

1. Remove the belt idler No. 1.
2. Remove the automatic belt tension adjuster assembly.

Scheme 178

Scheme 179

Scheme 180

1. Prepare for installation of automatic belt tension adjuster assembly. CAUTION: Always use a vertical type pressing tool to move the adjuster rod down. Do not use a lateral type vise. Push the adjuster rod vertically. Press-in the push adjuster rod gradually taking three minutes or more. Do not allow press pressure to exceed 9, 807 N (1, 000 kgf, 2, 205 lb). Push in the adjuster rod to the end face of the cylinder. However, do not push in the adjuster rod below the end face of the cylinder. Doing so may damage the cylinder. Do not release the press pressure until stopper pin is completely inserted. Attach the automatic belt tension adjuster assembly to vertical pressing tool. Slowly push in the adjuster rod with a pressure of 165 N (16.8 kgf, 37.1 lb) or more until the adjuster rod is aligned with the stopper pin hole in the cylinder. With a 2 mm (0.08 in) dia. stopper pin or a 2 mm (nominal) dia. hex wrench inserted into the stopper pin hole in cylinder, secure the adjuster rod.
2. Install the automatic belt tension adjuster assembly. Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)
3. Install the belt idler No. 1. Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

1. Prepare for installation of the automatic belt tension adjuster assembly. AUTOMATIC BELT TENSION ADJUSTER ASSEMBLY AND BELT IDLER, INSTALLATION, Timing Belt. >
2. Align the mark (A) on crank sprocket with the mark on oil pump cover at cylinder block.
3. Turn the camshaft sprocket No. 2 using ST1, and turn the camshaft sprocket No. 1 using ST2 so that their alignment marks (A) come to top positions. ST1 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used. ST2 499207400 CAM SPROCKET WRENCH
4. While aligning the alignment mark (B) on timing belt with the mark (A) on sprockets, position the timing belt properly.
5. Install the belt idler (B). Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)
6. Install the belt idler (A). Tightening torque: 39 N.m (4.0 kgf-m, 28.8 ft-lb)
7. After ensuring the marks on timing belt and camshaft sprockets are aligned, remove the stopper pin from belt tension adjuster.
8. Install the timing belt guide. (MT model) Temporarily tighten the bolts mounting the timing belt guide. Check and adjust the clearance between timing belt and timing belt guide by using thickness gauge. Clearance: 1.0±0.5 mm (0.039±0.020 in) Tighten the bolts mounting the timing belt guide. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
9. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
10. Install the crank pulley. INSTALLATION, Crank Pulley. >
11. Install the V-belts. INSTALLATION, V-belt. >

TIMING BELT

1. Check the timing belt teeth for breaks, cracks or wear. If any fault is found, replace the timing belt.
2. Check the condition on the back surface of the timing belt. If cracks are found, replace the belt.

In radial diameter h

60 mm (2.36 in) or more

Scheme 188

Scheme 189

1. Visually check the oil seals for leaks, and rod ends for abnormal wear and scratches. If necessary, replace the automatic belt tension adjuster assembly. NOTE: Slight traces of oil at rod's oil seal does not indicate a problem.
2. Check that the adjuster rod does not move when a pressure of 165 N (16.8 kgf, 37.1 lb) is applied to it. This is to check adjuster rod stiffness.
3. If the adjuster rod is not stiff and moves freely when applying 165 N (16.8 kgf, 37.1 lb), check it using the following procedures: Slowly press the adjuster rod down to the end surface of cylinder. Repeat this operation two to three times. With the adjuster rod moved all the way up, apply a pressure of 165 N (16.8 kgf, 37.1 lb) to it. Check the adjuster rod stiffness. If the adjuster rod is not stiff and moves down, replace the automatic belt tension adjuster assembly with a new part. CAUTION: Always use a vertical type pressing tool to move the adjuster rod down. Do not use a lateral type vise. Push the adjuster rod vertically. Press the adjuster rod gradually taking three minutes or more. Do not allow press pressure to exceed 9, 807 N (1, 000 kgf, 2, 205 lb). Push in the adjuster rod to the end face of the cylinder. However, do not push in the adjuster rod below the end face of the cylinder. Doing so may damage the cylinder. Measure the amount of rod protrusion "H" from the end surface of the body. If it is not within specified range, replace with new part. Amount of rod protrusion H: 5.2 - 6.2 mm (0.204 - 0.244 in)

BELT TENSION PULLEY

1. Check the mating surfaces of timing belt and contact point of adjuster rod for abnormal wear or scratches. Replace the automatic belt tension adjuster assembly with a new part if faulty.
2. Check the belt tension pulley for smooth rotation. Replace if noise or excessive play occurs.
3. Check the belt tension pulley for grease leakage.

BELT IDLER

1. Check the belt idler for smooth rotation. Replace if noise or excessive play occurs.
2. Check the outer contacting surfaces of idler pulley for abnormal wear and scratches.
3. Check the belt idler for grease leakage.

Note. Perform the work with the engine installed to body when replacing a single part.

Scheme 190

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
4. Remove the timing belt. REMOVAL, Timing Belt. >
5. Remove the camshaft position sensor. REMOVAL , Camshaft Position Sensor . >
6. Fasten the cam sprocket and remove from the cam shaft using ST. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used.

1. Fasten the cam sprocket and install to the cam shaft using ST. NOTE: Do not confuse left and right side cam sprockets during installation. They should be distinguished by the L or R indication. ST 18231AA010 CAM SPROCKET WRENCH NOTE: CAM SPROCKET WRENCH (499207100) can also be used. Tightening torque: 78 N.m (8.0 kgf-m, 57.5 ft-lb)
2. Install the camshaft position sensor. INSTALLATION , Camshaft Position Sensor . >
3. Install the timing belt. INSTALLATION, Timing Belt. >
4. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
5. Install the crank pulley. INSTALLATION, Crank Pulley. >
6. Install the V-belts. INSTALLATION, V-belt. >

1. Check the cam sprocket teeth for abnormal wear and scratches.
2. Make sure there is no free play between cam sprocket and key.
3. Check the cam sprocket protrusion used for sensor for damage and contamination of foreign matter.

Note. Perform the work with the engine installed to body when replacing a single part.

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
4. Remove the timing belt. REMOVAL, Timing Belt. >
5. Remove the crank sprocket.

Scheme 191

1. Install the crank sprocket.
2. Install the timing belt. INSTALLATION, Timing Belt. >
3. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
4. Install the crank pulley. INSTALLATION, Crank Pulley. >
5. Install the V-belts. INSTALLATION, V-belt. >

1. Check the crank sprocket teeth for abnormal wear and scratches.
2. Make sure there is no free play between crank sprocket and key.
3. Check the crank sprocket protrusion used for sensor for damage and contamination of foreign matter.

Note. Perform the work with the engine installed to body when replacing a single part. Refer to " VALVE CLEARANCE " for preparation. VALVE CLEARANCE. >

Scheme 192

Scheme 193

Scheme 194

Scheme 195

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
4. Remove the timing belt. REMOVAL, Timing Belt. >
5. Remove the cam sprocket. REMOVAL, Cam Sprocket. >
6. Remove the high tension cord.
7. Disconnect the PCV hose and remove the rocker cover.
8. Remove the valve rocker assembly. Use the ST to rotate the spring stopper in the direction of the arrow to remove it from adjuster pin. ST 18258AA000 SPRING INSTALLER Remove the bolts (a) through (j) in alphabetical sequence. NOTE: Leave two or three threads of bolts (i) and (j) engaged in order to retain the valve rocker assembly. Remove the valve rocker assembly. NOTE: Set the ST in the position shown in the drawing to remove the intake valve rocker assembly. ST 18354AA000 VALVE ROCKER HOLDER

Scheme 196

Scheme 197

Scheme 198

Scheme 199

1. Install the valve rocker assembly. Temporarily tighten the bolts equally in alphabetical order as shown in the figure. NOTE: Do not temporarily tighten the bolts (i) and (j). Set the ST in the position shown in the drawing to mount the intake valve rocker assembly. ST 18354AA000 VALVE ROCKER HOLDER Tighten the bolts (a) through (h) to specified torque. Tightening torque: 25 N.m (2.5 kgf-m, 18.4 ft-lb) Tighten the bolts (i) through (j) to specified torque. Tightening torque: 6 N.m (0.6 kgf-m, 4.3 ft-lb) Use the ST to rotate the spring stopper in the direction of the arrow to fasten the adjuster pin. ST 18258AA000 SPRING INSTALLER
2. Install the cam sprocket. INSTALLATION, Cam Sprocket. >
3. Install the timing belt. INSTALLATION, Timing Belt. >
4. Adjust the valve clearance. ADJUSTMENT, Valve Clearance. >
5. Install the rocker cover. Install the rocker cover gasket to the rocker cover. NOTE: Use a new rocker cover gasket. Temporarily tighten the bolts in alphabetical sequence as shown in figure, then tighten the bolt in 2 steps. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
6. Connect the PCV hose.
7. Install the high tension cord.
8. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
9. Install the crank pulley. INSTALLATION, Crank Pulley. >
10. Install the V-belts. INSTALLATION, V-belt. >

DISASSEMBLY

Note. Intake valve rocker assembly cannot be disassembled.

1. Remove the exhaust valve rocker arm from the rocker shaft. NOTE: Keep all the removed parts in order for re-installing in their original positions.
2. Remove the nut and adjusting screw from exhaust valve rocker.

ASSEMBLY

Note. Intake valve rocker assembly cannot be disassembled.

1. Install the adjusting screw and nut to the exhaust valve rocker.
2. Insert the exhaust valve rocker arm to rocker shaft.

Note. Valve rocker arms, and rocker shaft have identification marks. Make sure the parts with same markings are properly assembled.

INTAKE VALVE ROCKER ASSEMBLY

1. If the roller or valve contact surface of valve rocker arm is worn or dented excessively, replace the valve rocker assembly.
2. Check that the valve rocker arm roller rotates smoothly. If not, replace the valve rocker assembly.

Scheme 200

Scheme 201

1. Measure the inner diameter of valve rocker arm and outer diameter of valve rocker shaft, and confirm the difference (oil clearance) between the two values. Clearance between arm and shaft: Standard 0.020 - 0.054 mm (0.0008 - 0.0021 in)
2. If the oil clearance exceeds the limit, replace the valve rocker arm or shaft, whichever shows the greater amount of wear. Rocker arm inside diameter: 22.020 - 22.041 mm (0.8669 - 0.8678 in) Rocker shaft diameter: 21.987 - 22.000 mm (0.8656 - 0.8661 in)
3. If the roller or valve contact surface of valve rocker arm is worn or dented excessively, replace the valve rocker arm.
4. Check that the valve rocker arm roller rotates smoothly. If not, replace the valve rocker arm.

Note. Perform the work with the engine installed to body when replacing a single part. Refer to " VALVE CLEARANCE " for preparation. VALVE CLEARANCE. >

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the crank pulley. REMOVAL, Crank Pulley. >
3. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
4. Remove the timing belt. REMOVAL, Timing Belt. >
5. Remove the cam sprocket. REMOVAL, Cam Sprocket. >
6. Remove the timing belt cover No. 2 LH.
7. Remove the timing belt cover No. 2 RH. NOTE: Do not damage or lose the seal rubber when removing the timing belt covers.
8. Remove the tensioner bracket.
9. Remove the camshaft position sensor support. (LH side only)
10. Remove the valve rocker assembly. REMOVAL, Valve Rocker Assembly. >
11. Remove the camshaft cap. Remove the bolts (a) and (b) in alphabetical sequence. Equally loosen the bolts (c) through (j) all the way in alphabetical sequence. Remove the bolts (k) through (p) in alphabetical sequence using ST. ST 499497000 TORX® PLUS Remove the camshaft cap.
12. Remove the camshaft.
13. Remove the oil seal.
14. Remove the plug from rear side of camshaft. CAUTION: Do not scratch the journal surface when removing the oil seal.
15. Similarly, remove the camshaft RH and related parts.

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

1. Apply a thin coat of engine oil to camshaft journals, and install the camshaft.
2. Install the camshaft cap. Apply liquid gasket to the mating surfaces of camshaft cap. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent NOTE: Apply a coat of liquid gasket of 3 mm (0.12 in) in diameter (A) along the edge (B) of camshaft cap (C) mating surface. Temporarily tighten the bolts (a) through (d) in alphabetical sequence. Install the valve rocker assembly. INSTALLATION, Valve Rocker Assembly. > Tighten the TORX® bolts (e) through fl) in alphabetical sequence using the ST. ST 499497000 TORX® PLUS Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb) Tighten the bolts (k) through (r) in alphabetical sequence. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb) Tighten the bolts (s) and (t) in alphabetical sequence. NOTE: Use a new seal washer. Install and tighten the seal washer to the bolt. Tightening torque: 9.75 N.m (1.0 kgf-m, 7.2 ft-lb)
3. Apply a coat of engine oil to camshaft oil seal periphery and oil seal lips and install the oil seal (A) on camshaft using ST1 and ST2. NOTE: Use a new oil seal. ST1 499597000 OIL SEAL GUIDE ST2 499587500 OIL SEAL INSTALLER
4. Apply a coat of engine oil to plug periphery and Install the plug (A) using ST. ST 499587700 CAMSHAFT OIL SEAL INSTALLER
5. Install the camshaft position sensor support. (LH side only) Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
6. Similarly, install the parts on right-hand side.
7. Install the tensioner bracket. Tightening torque: 24.5 N.m (2.5 kgf-m, 18.1 ft-lb)
8. Install the timing belt cover No. 2 RH. Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
9. Install the timing belt cover No. 2 (LH). Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
10. Install the cam sprocket. INSTALLATION, Cam Sprocket. >
11. Install the timing belt. INSTALLATION, Timing Belt. >
12. Adjust the valve clearance. ADJUSTMENT, Valve Clearance. >
13. Install the rocker cover. Install the rocker cover gasket to the rocker cover. NOTE: Use a new rocker cover gasket. Temporarily tighten the bolts in alphabetical sequence as shown in figure, then tighten the bolt in 2 steps. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
14. Connect the PCV hose.
15. Install the high tension cord.
16. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
17. Install the crank pulley. INSTALLATION, Crank Pulley. >
18. Install the V-belts. INSTALLATION, V-belt. >

Scheme 217

Scheme 218

1. Measure the bend, and repair or replace if necessary. Service limit: 0.025 mm (0.00098 in)
2. Check the journal for damage and wear. Replace if faulty.
3. Measure the outer diameter of camshaft journal and inner diameter of cylinder head journal, and check the difference (oil clearance) between the two values. If the oil clearance is not within the standard, replace the camshaft or cylinder head as necessary. CAMSHAFT JOURNAL DIAMETER SPECIFICATION Unit: mm (in) Oil clearance Standard 0.055 - 0.090 (0.0022 - 0.0035) Camshaft journal O.D. 31.928 - 31.945 (1.2570 - 1.2577) Journal hole I.D. 32.000 - 32.018 (1.2598 - 1.2605)
4. Check the cam face condition, and remove the minor faults by grinding with oil stone. Measure the cam height H. If it is not within the standard or offset wear occurs, replace it. Cam height H: CAM HEIGHT SPECIFICATION Unit: mm (in) Intake Constant Standard 40.075 - 40.175 (1.5778 - 1.5817) Low speed Standard 35.496 - 35.596 (1.3975 - 1.4014) High speed Standard 40.315 - 40.415 (1.5872 - 1.5911) Exhaust Standard 39.289 - 39.389 (1.5468 - 1.5507) Cam base circle diameter A: Intake 34.00 mm (1.3386 in) Exhaust 34.00 mm (1.3386 in) Base circle step of adjacent intake cams (low speed and high speed): 0.03 mm (0.001 in) or less
5. Measure the thrust clearance of camshaft with setting the dial gauge at end of camshaft. If the thrust clearance is not within the standard or there is offset wear, replace the camshaft caps and cylinder head as a set. If necessary, replace the camshaft.

Standard

0.030 - 0.090 mm (0.0012 - 0.0035 in)

Note. Perform the work with the engine installed to body when replacing a single part. Refer to " VALVE CLEARANCE " for preparation. VALVE CLEARANCE. >

Scheme 219

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the intake manifold. REMOVAL , Intake Manifold . >
3. Remove the crank pulley. REMOVAL, Crank Pulley. >
4. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
5. Remove the timing belt. REMOVAL, Timing Belt. >
6. Remove the cam sprocket. REMOVAL, Cam Sprocket. >
7. Remove the bolt which installs the A/C compressor bracket on cylinder head.
8. Remove the valve rocker assembly. REMOVAL, Valve Rocker Assembly. >
9. Remove the camshaft. REMOVAL, Camshaft. >
10. Remove the oil level gauge guide. (LH side)
11. Remove the cylinder head bolts in alphabetical sequence as shown in the figure. NOTE: Leave bolts (a) and (c) engaged by three or four threads to prevent the cylinder head from falling.
12. While tapping the cylinder head with a plastic hammer, separate it from cylinder block. Remove the bolts (a) and (c) to remove cylinder head.
13. Remove the cylinder head gasket. CAUTION: Be careful not to scratch the mating surface of cylinder head and cylinder block.
14. Similarly, remove the right side cylinder head.

Scheme 220

1. Install the cylinder head and gaskets on cylinder block. CAUTION: Be careful not to scratch the mating surface of cylinder block and cylinder head. NOTE: Use a new cylinder head gasket.
2. Tighten the cylinder head bolts. Apply a thin coat of engine oil to washer and bolt thread. Tighten all bolts to 29 N.m (3.0 kgf-m, 21.4 ft-lb) in alphabetical order. Tighten all bolts to 69 N.m (7.0 kgf-m, 50.9 ft-lb) in alphabetical order. Loosen all the bolts by 180° in the reverse order of installing, and loosen them further by 180°. Tighten all bolts to 42 N.m (4.3 kgf-m, 31.0 ft-lb) in alphabetical order. Tighten all bolts by 80 to 90° in alphabetical order. Tighten all bolts by 40 to 45° in alphabetical order. CAUTION: The tightening angle of the bolt should not exceed 45°. Further tighten the bolts (a) and (b) by 40 - 45°. CAUTION: Make sure the total "re-tightening angle" of the step (7) and (8) does not exceed 90°.
3. Install the oil level gauge guide. (LH side) Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
4. Install the camshaft. INSTALLATION, Camshaft. >
5. Install the valve rocker assembly. INSTALLATION, Valve Rocker Assembly. >
6. Install the A/C compressor bracket on cylinder head. Tightening torque: 36 N.m (3.7 kgf-m, 26.6 ft-lb)
7. Install the cam sprocket. INSTALLATION, Cam Sprocket. >
8. Install the timing belt. INSTALLATION, Timing Belt. >
9. Adjust the valve clearance. ADJUSTMENT, Valve Clearance. >
10. Install the rocker cover. Install the rocker cover gasket to the rocker cover. NOTE: Use a new rocker cover gasket. Temporarily tighten the bolts in alphabetical sequence as shown in figure, then tighten the bolt in 2 steps. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
11. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
12. Install the crank pulley. INSTALLATION, Crank Pulley. >
13. Install the intake manifold. INSTALLATION , Intake Manifold . >
14. Install the V-belts. INSTALLATION, V-belt. >

Scheme 221

1. Place the cylinder head on the ST. ST 498267800 CYLINDER HEAD TABLE
2. Compress the valve spring and remove the valve spring retainer key using ST. Remove each valve and valve spring. ST 499718000 VALVE SPRING REMOVER NOTE: Keep all the removed parts in order for re-installing in their original positions. Mark each valve to prevent confusion. Pay careful attention not to damage the lips of intake valve oil seals and exhaust valve oil seals.

Scheme 222

Scheme 223

1. Install the valve spring and valve. Coat the stem of each valve with engine oil and insert the valve into the valve guide. NOTE: When inserting the valve into valve guide, use special care not to damage the oil seal lip. Set the cylinder head on ST. ST 498267800 CYLINDER HEAD TABLE Install the valve spring and retainer. NOTE: Be sure to install the valve spring with its close-coiled end facing the seat on cylinder head. Set the ST on valve spring. ST 499718000 VALVE SPRING REMOVER Compress the valve spring and fit the valve spring retainer key. After installing, tap the valve spring retainers lightly with a plastic hammer for better seating.

Scheme 224

1. Check for cracks or damage. Use liquid penetrant tester on the important sections to check for fissures. Check that there are no marks of gas leaking or water leaking on gasket installing surface.
2. Place the cylinder head on the ST. ST 498267800 CYLINDER HEAD TABLE
3. Measure the warping of the cylinder head surface that mates with cylinder block using a straight edge (A) and thickness gauge (B). If the warping exceeds the limit, correct the surface by grinding it with a surface grinder. Warping limit: 0.035 mm (0.0014 in) Grinding limit: 0.1 mm (0.004 in) Standard height of cylinder head: 97.5 mm (3.839 in) NOTE: Uneven torque for the cylinder head bolts can cause warping. When reassembling, pay special attention to the torque so as to tighten evenly.

VALVE SEAT

Inspect the intake and exhaust valve seats, and correct the contact surfaces with a valve seat cutter if they are defective or when valve guides are replaced.

Valve seat width W

Standard

Intake (A)

0.8 - 1.4 mm (0.03 - 0.055 in)

Exhaust (B)

1.2 - 1.8 mm (0.047 - 0.077 in)

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

1. Check the clearance between valve guide and valve stem. The clearance can be checked by measuring respectively the outer diameter of valve stem with a micrometer and the inner diameter of valve guide with a caliper gauge. Clearance between the valve guide and valve stem: Standard: Intake 0.035 - 0.062 mm (0.0014 - 0.0024 in) Exhaust 0.040 - 0.067 mm (0.0016 - 0.0026 in)
2. If the clearance between the valve guide and valve stem exceeds the standard, replace the valve guide or valve itself, whichever shows greater amount of wear or damage. See the following procedure for valve guide replacement. Valve guide inner diameter: 6.000 - 6.012 mm (0.2362 - 0.2367 in) Valve stem outer diameters: Intake 5.950 - 5.965 mm (0.2343 - 0.2348 in) Exhaust 5.945 - 5.960 mm (0.2341 - 0.2346 in) Place the cylinder head on ST1 with the combustion chamber upward so that valve guides fit the holes in ST1. Insert the ST2 into valve guide and press it down to remove the valve guide. ST1 498267800 CYLINDER HEAD TABLE ST2 499767200 VALVE GUIDE REMOVER Turn the cylinder head upside down and place the ST as shown in the figure. Intake side ST 499767700 VALVE GUIDE ADJUSTER Exhaust side ST 499767800 VALVE GUIDE ADJUSTER Before installing a new valve guide, make sure that neither scratches nor damages exist on the inner surface of valve guide holes in cylinder head. Put a new valve guide, coated with sufficient oil, in cylinder, and insert the ST1 into valve guide. Press in until the valve guide upper end is flush with the upper surface of ST2. ST1 499767200 VALVE GUIDE REMOVER Intake side ST2 499767700 VALVE GUIDE ADJUSTER Exhaust side ST2 499767800 VALVE GUIDE ADJUSTER Check the valve guide protrusion. Valve guide protrusion L: Intake 20.0 - 21.0 mm (0.787 - 0.827 in) Exhaust 16.5 - 77.5 mm (0.650 - 0.689 in) Ream the inside of valve guide using ST. Put the ST in valve guide, and rotate the ST slowly clockwise while pushing it lightly. Bring the ST back while rotating it clockwise. NOTE: Apply engine oil to the ST when reaming. If the inner surface of valve guide is damaged, the edge of ST should be slightly ground with oil stone. If the inner surface of valve guide becomes lustrous and the ST does not chip, use a new ST or remedy the ST. ST 499767400 VALVE GUIDE REAMER After reaming, clean the valve guide to remove chips. Recheck the contact condition between valve and valve seat after replacing the valve guide.

Scheme 234

1. Inspect the flange and stem of valve, and replace the valve with a new part if damaged, worn, deformed, or if dimension "H" in the figure is outside of the specified limit. Head edge thickness H: Intake (A) Standard: 0.8 - 1.2 mm (0.03 - 0.047 in) Exhaust (B) Standard: 1.0 - 1.4 mm (0.039 - 0.055 in)
2. Put a small amount of grinding compound on the seat surface, and lap the valve and seat surface. Replace with a new valve oil seal after lapping.

Note. It is possible to differentiate between the intake valve and the exhaust valve by their overall length.

Valve overall length

Intake

120.6 mm (4.75 in)

Exhaust

121.7 mm (4.79 in)

Scheme 235

1. Check the valve springs for damage, free length, and tension. Replace the valve spring if it is not within the standard value presented in the table.
2. To measure the squareness of the valve spring, stand the spring on a surface plate and measure its deflection at the top of spring using a try square. VALVE SPRING SPECIFICATION Free length mm (in) 55.2 (2.173) Tension/spring height N (kgf, lbf)/mm (in) Set 235.3 - 270.7 (24 - 27.6, 52.9 - 60.8)/45.0 (1.772) Lift 578.9 - 639.9 (59.1 - 65.3, 130.3 - 143.9)/34.7 (1.366) Squareness 2.5°, 2.4 mm (0.094 in) or less

Scheme 236

1. For the following, replace the oil seal with a new part. When the lip is damaged. When the spring is out of the specified position. When readjusting the surfaces of valve and valve seat. When replacing the valve guide.
2. Place the cylinder head on ST1, and use ST2 to press-fit the oil seal. ST1 498267800 CYLINDER HEAD TABLE ST2 498857100 VALVE OIL SEAL GUIDE NOTE: Apply engine oil to oil seal before press-fitting. When press-fitting the oil seal, do not use a hammer or strike in. The intake valve oil seal and exhaust valve oil seal can be distinguished by colors. Color of rubber part: Intake [Gray] Exhaust [Green]

Note. Before conducting this procedure, drain the engine oil completely.

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

1. Remove the V-belts. REMOVAL, V-belt. >
2. Remove the intake manifold. REMOVAL , Intake Manifold . >
3. Remove the crank pulley. REMOVAL, Crank Pulley. >
4. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
5. Remove the timing belt. REMOVAL, Timing Belt. >
6. Remove the cam sprocket. REMOVAL, Cam Sprocket. >
7. Remove the crank sprocket. REMOVAL, Crank Sprocket. >
8. Remove the valve rocker assembly. REMOVAL, Valve Rocker Assembly. >
9. Remove the camshaft. REMOVAL, Camshaft. >
10. Remove the generator and A/C compressor with their brackets.
11. Remove the cylinder head. REMOVAL, Cylinder Head. >
12. Remove the clutch disc and cover. (MT model) REMOVAL , Clutch Disc and Cover . >
13. Remove the flywheel. (MT model) REMOVAL , Flywheel . >
14. Remove the drive plate. (AT model) Using the ST, lock the crankshaft. ST 498497100 CRANKSHAFT STOPPER
15. Remove the oil separator cover.
16. Remove the water by-pass pipe for heater.
17. Remove the water pump. REMOVAL , Water Pump . >
18. Remove the bolts which install oil pump onto cylinder block. NOTE: When disassembling and checking the oil pump, loosen the relief valve plug before removing the oil pump.
19. Remove the oil pump from cylinder block using a flat tip screwdriver. CAUTION: Be careful not to scratch the mating surface of cylinder block and oil pump.
20. Remove the front oil seal from the oil pump.
21. Remove the oil pan. Set the part so that the cylinder block LH is on the upper side. Remove the bolts which secure oil pan to cylinder block. Insert an oil pan cutter blade between cylinder block-to-oil pan clearance and remove the oil pan. CAUTION: Do not use a screwdriver or similar tools in place of oil pan cutter.
22. Remove the oil strainer.
23. Remove the baffle plate.
24. Remove the oil filter. REMOVAL , Engine Oil Filter . >
25. Remove the water pipe.
26. Remove the service hole plugs using a hexagon wrench [14 mm].
27. Remove the service hole cover.
28. Rotate the crankshaft to bring #1 and #2 pistons to bottom dead center position, then remove the piston snap ring through service hole of #1 and #2 cylinders.
29. Draw out the piston pin from #1 and #2 pistons using ST. ST 499097700 PISTON PIN REMOVER NOTE: Be careful not to confuse the original combination of piston, piston pin and cylinder.
30. Similarly draw out the piston pins from #3 and #4 pistons.
31. Remove the cylinder block connecting bolt on the RH side.
32. Loosen the cylinder block connecting bolt on the LH side by 2-3 turns.
33. Set the part so that the cylinder block LH is on the upper side, and remove the cylinder block connecting bolt.
34. Separate the cylinder block LH and RH. NOTE: When separating the cylinder block, do not allow the connecting rod to fall and damage the cylinder block.
35. Remove the rear oil seal.
36. Remove the crankshaft together with connecting rod.
37. Remove the crankshaft bearings from cylinder block using a hammer handle. NOTE: Push the opposite side of the crank shaft bearing locking lip to remove. Be careful not to confuse the crankshaft bearing combination.
38. Remove each piston from cylinder block using wooden bar or hammer handle.

Note. Be careful not to confuse the original combination of piston and cylinder.

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

1. Remove oil on the mating surface of cylinder block before installation. Apply a coat of engine oil to the bearing and crankshaft journal.
2. Position the crankshaft and O-ring on cylinder block RH.
3. Apply liquid gasket to the mating surfaces of cylinder block RH, and position cylinder block LH. NOTE: Install within 5 min. after applying liquid gasket. Do not allow liquid gasket to jut into O-ring grooves, oil passages, bearing grooves, etc. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent
4. Apply a coat of engine oil to the washer and bolt thread. NOTE: Use a new seal washer.
5. Tighten the 10 mm cylinder block connecting bolts on the LH side (A - D) in alphabetical order. Tightening torque: 10 N.m (1.0 kgf-m, 7.2 ft-lb)
6. Tighten the 10 mm cylinder block connecting bolts on the RH side (E - J) in alphabetical order. Tightening torque: 10 N.m (1.0 kgf-m, 7.2 ft-lb)
7. Tighten the LH side cylinder block connecting bolts (A - D) further in alphabetical order. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
8. Tighten the RH side cylinder block connecting bolts (E - J) further in alphabetical order. Tightening torque: 18 N.m (1.8 kgf-m, 13.3 ft-lb)
9. Tighten the LH side cylinder block connecting bolts (A - D) further in alphabetical order. (A), (C): Angle tightening Tightening angle: 90° (B), (D): Torque tightening Tightening torque: 40 N.m (4.1 kgf-m, 29.6 ft-lb)
10. Tighten the RH side cylinder block connecting bolts (E - J) in alphabetical order. Tightening angle: 90°
11. Tighten the 8 mm and 6 mm cylinder block connecting bolts on LH side (A - H) in alphabetical sequence. Tightening torque: (A) - (G): 25 N.m (2.5 kgf-m, 18.4 ft-lb) (H): 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
12. Apply a coat of engine oil to the oil seal periphery, then install the rear oil seal using ST1 and ST2. NOTE: Use new rear oil seal. ST1 499597100 CRANKSHAFT OIL SEAL GUIDE ST2 499587200 CRANKSHAFT OIL SEAL INSTALLER
13. Position the top ring gap at (A) or (B) in the figure.
14. Position the second ring gap at 180° on the reverse side the top ring gap.
15. Position the upper rail gap at (C) in the figure.
16. Align the upper rail spin stopper (E) to the side hole (D) on the piston.
17. Position the expander gap at (F) in the figure.
18. Position the lower rail gap at (G) in the figure. NOTE: Make sure ring gaps do not face the same direction. Make sure ring gaps are not within the piston skirt area.
19. Install the snap ring. Before positioning the piston on the cylinder block, attach the snap ring in the service hole of the cylinder block, and the piston hole on the opposite side. NOTE: Use new snap rings.
20. Install the piston. Set the parts so that the #1 and #2 cylinders are on the upper side. Using the ST1, turn the crankshaft so that #1 and #2 connecting rods are set at bottom dead center. ST1 499987500 CRANKSHAFT SOCKET Apply a coat of engine oil to the pistons and cylinders and insert pistons in their cylinders using ST2. ST2 498747300 PISTON GUIDE NOTE: Face the piston front mark towards the front of the engine.
21. Install piston pin. Apply a coat of engine oil to ST3. Insert ST3 into the service hole to align piston pin hole with connecting rod small end. ST3 499017100 PISTON PIN GUIDE Apply a coat of engine oil to piston pin, and insert the piston pin into piston and connecting rod through service hole. Install the snap ring. NOTE: Use new snap rings. Apply liquid gasket to the threaded portion of the service hole plug. Liquid gasket: THREE BOND 1105 (Part No. 004403010) or equivalent Install the water pump and gasket. NOTE: Use a new gasket. Set the parts so that the #3 and #4 cylinders are on the upper side. Following the same procedures as used for #1 and #2 cylinders, install the pistons and piston pins. Install the service hole cover. NOTE: Use new O-rings.
22. Install the water pipe. NOTE: Use new O-rings. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
23. Install the baffle plate. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
24. Install the oil strainer. NOTE: Use new O-rings. Tightening torque: 10 N.m (1.0 kgf-m, 7.4 ft-lb)
25. Tighten the oil strainer stay together with the baffle plate. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
26. Apply liquid gasket to the mating surfaces of the oil pan, and install the oil pan. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent Tightening torque: 5 N.m (0.5 kgf-m, 3.7 ft-lb)
27. Apply liquid gasket to the mating surfaces of the oil separator cover and the threaded portion of bolt (A) shown in the figure (when reusing the bolt), and then install the oil separator cover. NOTE: Install within 5 min. after applying liquid gasket. Use a new separator cover. Liquid gasket: Mating surface THREE BOND 1217G (Part No. K0877Y0100) or equivalent Bolt thread area (A) (when reusing the bolt) THREE BOND 1324 (Part No. 004403042) or equivalent Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
28. Install the flywheel. (MT model) INSTALLATION , Flywheel . >
29. Install the clutch disc and cover. (MT model) INSTALLATION , Clutch Disc and Cover . >
30. Install the drive plate. (AT model) To lock the crankshaft, use the ST. ST 498497100 CRANKSHAFT STOPPER Tightening torque: 72 N.m (7.3 kgf-m, 53.1 ft-lb)
31. Install the oil pump. Using the ST, install the front oil seal. ST 499587100 OIL SEAL INSTALLER NOTE: Use a new front oil seal. Apply liquid gasket to the matching surface of oil pump. NOTE: Install within 5 min. after applying liquid gasket. Liquid gasket: THREE BOND 1217G (Part No. K0877Y0100) or equivalent Apply a coat of engine oil to the inside of oil seal. Install the oil pump to cylinder block. Be careful not to damage the oil seal during installation. NOTE: Make sure the oil seal lip is not folded. Align the flat surface of oil pump's inner rotor with crankshaft before installation. Use new O-rings and oil seals. Do not forget to assemble O-rings. Apply liquid gasket to the three bolts thread shown in figure, (when reusing bolts) Liquid gasket: THREE BOND 1324 (Part No. 004403042) or equivalent Tightening torque: T: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
32. Install the service hole plug and gasket. NOTE: When installing the water pump, tighten bolts in two stages in alphabetical order as shown in the figure. Use a new gasket. Tightening torque: First: 12 N.m (1.2 kgf-m, 8.7 ft-lb) Second: 12 N.m (1.2 kgf-m, 8.7 ft-lb)
33. Install the water by-pass pipe for heater. Tightening torque: 6.4 N.m (0.65 kgf-m, 4.7 ft-lb)
34. Install the oil filter. INSTALLATION , Engine Oil Filter . >
35. Install the cylinder head. INSTALLATION, Cylinder Head. >
36. Install the camshaft. INSTALLATION, Camshaft. >
37. Install the valve rocker assembly. INSTALLATION, Valve Rocker Assembly. >
38. Install the generator and A/C compressor with their brackets. Tightening torque: 36 N.m (3.7 kgf-m, 26.6 ft-lb)
39. Install the crank sprocket. INSTALLATION, Crank Sprocket. >
40. Install the cam sprocket. INSTALLATION, Cam Sprocket. >
41. Install the timing belt. INSTALLATION, Timing Belt. >
42. Adjust the valve clearance. ADJUSTMENT, Valve Clearance. >
43. Install the rocker cover. Install the rocker cover gasket to the rocker cover. NOTE: Use a new rocker cover gasket. Temporarily tighten the bolts in alphabetical sequence as shown in figure, then tighten the bolt in 2 steps. Tightening torque: 1st 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) 2nd (only (a) and (b) are tightened) 6.4 N.m (0.65 kgf-m, 4.7 ft-lb) RH side LH side
44. Install the timing belt cover. INSTALLATION, Timing Belt Cover. >
45. Install the crank pulley. INSTALLATION, Crank Pulley. >
46. Install the intake manifold. INSTALLATION , Intake Manifold . >
47. Install the V-belts. INSTALLATION, V-belt. >

Scheme 272

1. Remove the connecting rod cap.
2. Remove the connecting rod bearing. NOTE: Keep the removed connecting rods, connecting rod caps and bearings in order so that they are kept in their original combinations/groups, and not mixed together.
3. Remove the piston rings using piston ring expander.
4. Remove the oil ring by hand. NOTE: Arrange the removed piston rings in proper order, to prevent confusion.
5. Remove the snap ring.

Scheme 273

1. Apply oil to the surface of the connecting rod bearings, and install the connecting rod bearings on connecting rods and connecting rod caps.
2. Position each connecting rod with the side with a side mark facing forward, and install it.
3. Attach the connecting rod cap, and tighten with connecting rod nut. Make sure the arrow mark on connecting rod cap facing front during installation. NOTE: Each connecting rod has its own mating cap. Make sure that they are assembled correctly by checking their matching number. When tightening the connecting rod nuts, apply oil on the threads. Tightening torque: 45 N.m (4.6 kgf-m, 33.2 ft-lb)
4. Install the oil ring upper rail, expander and lower rail by hand.
5. Install the second ring and top ring using piston ring expander.

Note. Assemble so that the piston ring mark "R" faces the top side of the piston.

CYLINDER BLOCK

1. Check for cracks or damage. Use liquid penetrant tester on the important sections to check for fissures. Check that there are no marks of gas leaking or water leaking on gasket installing surface.
2. Check the oil passages for clogging.
3. Inspect the cylinder head to cylinder block mating surface for warpage by using a straight edge, and correct by grinding if necessary. Warping limit: 0.025 mm (0.00098 in) Grinding limit: 0.1 mm (0.004 in) Standard height of cylinder block: 201.0 mm (7.91 in)

Scheme 274

Scheme 275

Scheme 276

1. The cylinder bore size is stamped on the front upper face of the cylinder block. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Standard sized pistons are classified into two grades, "A" and "B". These grades should be used as guide lines in selecting a standard piston. Standard diameter: A: 99.505 - 99.515 mm (3.9175 - 3.9179 in) B: 99.495 - 99.505 mm (3.9171 - 3.9175 in)
2. Measure the inner diameters of the cylinders. Measure the inner diameter of each cylinder in both the thrust and piston pin directions at the heights as shown in the figure, using a cylinder bore gauge. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Taper: Standard: 0.015 mm (0.0006 in) Out-of-roundness: Standard: 0.010 mm (0.0004 in)
3. When the piston is to be replaced due to general or cylinder wear, determine a suitable sized piston by measuring the piston clearance.
4. Measure the outer diameters of the pistons. Measure the outer diameter of each piston at the height as shown in the figure. (Thrust direction) NOTE: Measurement should be performed at a temperature of 20°C (68°F). Piston grade point H: 38.2 mm (1.504 in) Standard: A: 99.505 - 99.515 mm (3.9175 - 3.9179 in) B: 99.495 - 99.505 mm (3.9171 - 3.9175 in) 0.25 mm (0.0098 in) oversize: 99.745 - 99.765 mm (3.9270 - 3.9278 in) 0.50 mm (0.0197 in) oversize: 99.995 - 100.015 mm (3.9368 - 3.9376 in)
5. Calculate the clearance between cylinder and piston. NOTE: Measurement should be performed at a temperature of 20°C (68°F). Cylinder to piston clearance at 20°C (68°F): Standard: -0.010 - 0.010 mm (-0.00039 - 0.00039 in)
6. Boring and honing If any of the measured value of taper, out-of-roundness or cylinder-to-piston clearance is out of standard or if there is any damage on the cylinder wall, rebore it to replace with an oversize piston. CAUTION: When any of the cylinders needs reboring, other cylinders must be bored at the same time, and replaced with oversize pistons. If the cylinder inner diameter exceeds the limit after boring and honing, replace the cylinder block. NOTE: Immediately after reboring, the cylinder diameter may differ from its real diameter due to temperature rise. Thus, when measuring the cylinder diameter, wait until it has cooled to room temperature. Cylinder inner diameter boring limit (diameter): To 100.005 mm (3.9372 in)

Scheme 277

Scheme 278

Scheme 279

1. Check the piston and piston pin for breaks, cracks or wear. Replace if faulty.
2. Check the piston ring groove for wear and damage. Replace if faulty.
3. Make sure that the piston pin can be inserted into the piston pin hole with a thumb at 20°C (68°F). Replace if faulty. Clearance between piston hole and piston pin: Standard 0.004 - 0.008 mm (0.0002 - 0.0003 in)
4. Check the snap ring installation groove (A) on the piston for burr. If necessary, remove burr from the groove so that the piston pin can lightly move.
5. Check the piston pin snap ring for distortion, cracks and wear.

Scheme 280

Scheme 281

1. If the piston ring is broken, damaged and worn, or if its tension is insufficient, or when the piston is replaced, replace the piston ring with a new part of the same size as the piston. NOTE: The top ring and second ring have the mark to determine the direction to install on them. When installing them to piston, face this mark to the top side. Oil ring consists of the upper rail, expander and lower rail. Be careful about the direction of rail when installing the oil ring to piston.
2. Squarely place the piston ring and oil ring in cylinder using the piston, and measure the piston ring gap with a thickness gauge. PISTON RING GAP SPECIFICATION Standard mm (in) Piston ring gap Top ring 0.20 - 0.35 (0.0079 - 0.0138) Second ring 0.37 - 0.52 (0.0144 - 0.0203) Oil ring rail 0.20 - 0.50 (0.0079 - 0.0197)
3. Fit the piston ring straight into the piston ring groove, then measure the clearance between piston ring and piston ring groove with a thickness gauge.

Note. Before measuring the clearance, clean the piston ring groove and piston ring.

PISTON RING AND GROOVE CLEARANCE SPECIFICATION

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

1. Replace the connecting rod, if the large or small end thrust surface is damaged.
2. Check for bend or twist using a connecting rod aligner. Replace the connecting rod if the bend or twist exceeds the limit. Limit of bend or twist per 100 mm (3.94 in) in length: 0.10 mm (0.0039 in)
3. Install the connecting rod fitted with bearing to the crankshaft, and measure the thrust clearance using a thickness gauge. If the thrust clearance exceeds the standard or uneven wear is found, replace the connecting rod. Connecting rod thrust clearance: Standard 0.070 - 0.330 mm (0.0028 - 0.0130 in)
4. Inspect the connecting rod bearing for scar, peeling, seizure, melting, wear, etc.
5. Measure the oil clearance on each connecting rod bearing using plastigauge. If any oil clearance is not within the standard, replace the defective bearing with a new part of standard size or undersize as necessary. Connecting rod oil clearance: Standard 0.016 - 0.044 mm (0.00063 - 0.0017 in) CONNECTING ROD SPECIFICATION Unit: mm (in) Bearing Bearing size (Thickness at center) Outer diameter of crank pin Standard 1.492 - 1.501 (0.0587 - 0.0591) 51.984 - 52.000 (2.0466 - 2.0472) 0.03 (0.0012) Undersize 1.510 - 1.513 (0.0594 - 0.0596) 51.954 - 51.970 (2.0454 - 2.0461) 0.05 (0.0020) Undersize 1.520 - 1.523 (0.0598 - 0.0600) 51.934 - 51.950 (2.0446 - 2.0453) 0.25 (0.0098) Undersize 1.620 - 1.623 (0.0638 - 0.0639) 51.734 - 51.750 (2.0368 - 2.0374)
6. Inspect the bushing at connecting rod small end, and replace with a new part if worn or damaged.
7. Measure the piston pin clearance at connecting rod small end. If the measured value is not within the standard, replace it with a new part. Clearance between piston pin and bushing: Standard 0 - 0.022 mm (0 - 0.0009 in)
8. The replacement procedure for the connecting rod small end bushing is as follows. Remove the bushing from connecting rod with ST and press. Press the bushing with the ST after applying oil on the periphery of new bushing. ST 499037100 CONNECTING ROD BUSHING REMOVER AND INSTALLER Make two 3 mm (0.12 in) holes in the pressed bushing by aligning with the pre-manufactured holes on the connecting rod, and ream the inside of the bushing. After completion of reaming, clean the bushing to remove chips.

Scheme 287

Scheme 288

Scheme 289

1. Clean the crankshaft completely, and check it for cracks using liquid penetrant tester. If defective, replace the crankshaft.
2. Measure the bend of crankshaft. If it exceeds the limit, correct or replace it. NOTE: If a suitable V-block is not available, using just the #1 and #5 crankshaft bearings on cylinder block, position the crankshaft on cylinder block. Then, measure the crankshaft bend using a dial gauge. Crankshaft bend limit: 0.035 mm (0.0014 in)
3. Inspect the crank journal and crank pin for wear. If they are not within the specification, replace the bearing with a suitable (undersize) one, and replace or grind to correct the crankshaft as necessary. When grinding the crank journal or crank pin, finish them to the specified dimensions according to the undersize bearing to be used. Crank pin: Out-of-roundness 0.003 mm (0.0001 in) Cylindrically 0.004 mm (0.0002 in) Grinding limit (dia.) To 51.750 mm (2.0374 in) Crank journal: Out-of-roundness 0.005 mm (0.0002 in) Cylindrically 0.006 mm (0.0002 in) Grinding limit (dia.) To 59.758 mm (2.3527 in) CRANK JOURNAL OUTER DIAMETER SPECIFICATION Unit: mm (in) Crank journal outer diameter Crank pin outer diameter #1, #3 #2, #4, #5 Standard Journal O.D. 59.992 - 60.008 (2.3619 - 2.3625) 59.992 - 60.008 (2.3619 - 2.3625) 51.984 - 52.000 (2.0466 - 2.0472) Bearing size (Thickness at center) 1.998 - 2.011 (0.0787 - 0.0792) 2.000 - 2.013 (0.0787 - 0.0793) 1.492 - 1.501 (0.0587 - 0.0591) 0.03 (0.0012) Undersize Journal O.D. 59.962 - 59.978 (2.3607 - 2.3613) 59.962 - 59.978 (2.3607 - 2.3613) 51.954 - 51.970 (2.0454 - 2.0461) Bearing size (Thickness at center) 2.017 - 2.020 (0.0794 - 0.0795) 2.019 - 2.022 (0.0795 - 0.0796) 1.510 - 1.513 (0.0594 - 0.0596) 0.05 (0.0020) Undersize Journal O.D. 59.942 - 59.958 (2.3599 - 2.3605) 59.942 - 59.958 (2.3599 - 2.3605) 51.934 - 51.950 (2.0446 - 2.0453) Bearing size (Thickness at center) 2.027 - 2.030 (0.0798 - 0.0799) 2.029 - 2.032 (0.0799 - 0.0800) 1.520 - 1.523 (0.0598 - 0.0600) 0.25 (0.0098) Undersize Journal O.D. 59.742 - 59.758 (2.3520 - 2.3527) 59.742 - 59.758 (2.3520 - 2.3527) 51.734 - 51.750 (2.0368 - 2.0374) Bearing size (Thickness at center) 2.127 - 2.130 (0.0837 - 0.0839) 2.129 - 2.132 (0.0838 - 0.0839) 1.620 - 1.623 (0.0638 - 0.0639)
4. Use a thickness gauge to measure the thrust clearance of the crankshaft at the #5 crank journal bearing. If the thrust clearance is not within the standard, replace the bearing. Crankshaft thrust clearance: Standard 0.030 - 0.115 mm (0.0012 - 0.0045 in)
5. Inspect individual crankshaft bearings for signs of flaking, seizure, melting and wear.
6. Measure the oil clearance on each crankshaft bearing using plastigauge. If the measured value is out of standard, replace the defective bearing with an undersize one, and replace or grind to correct the crankshaft as necessary.

Crankshaft oil clearance

Standard

0.010 - 0.030 mm (0.0004 - 0.0012 in)

Scheme 290

1. Disconnect the ground cable from the battery.
2. Remove the air intake chamber. REMOVAL , Air Intake Chamber . >
3. Remove the engine harness connector from the bracket.
4. Disconnect the connector from the oil switching solenoid valve.
5. Remove the oil switching solenoid valve.
6. Remove the variable valve lift diagnosis oil pressure switch. REMOVAL , Variable Valve Lift Diagnosis Oil Pressure Switch . >
7. Remove the oil temperature sensor. REMOVAL , Oil Temperature Sensor . >
8. Remove the oil switching solenoid valve holder from the cylinder head.

Scheme 291

LH SIDE

1. Disconnect the ground cable from the battery.
2. Remove the V-belts. REMOVAL, V-belt. >
3. Remove the crank pulley. REMOVAL, Crank Pulley. >
4. Remove the timing belt cover. REMOVAL, Timing Belt Cover. >
5. Remove the timing belt. REMOVAL, Timing Belt. >
6. Remove the cam sprocket. REMOVAL, Cam Sprocket. >
7. Remove the timing belt cover No. 2 (LH).
8. Disconnect the connector from the oil switching solenoid valve.
9. Remove the oil switching solenoid valve.
10. Remove the variable valve lift diagnosis oil pressure switch. REMOVAL , Variable Valve Lift Diagnosis Oil Pressure Switch . >
11. Remove the oil switching solenoid valve holder from the cylinder head.

Scheme 292

RH SIDE

Install in the reverse order of removal.

Note. Use a new gasket. Apply liquid gasket to variable valve lift diagnosis oil pressure switch threads. Install the oil switching solenoid valve to the holder, then install it to the cylinder head.

Tightening torque

T1

8 N.m (0.8 kgf-m, 5.9 ft-lb)

T2

10 N.m (1.0 kgf-m, 7.4 ft-lb)

T3

17 N.m (1.7 kgf-m, 12.5 ft-lb)

T4

18 N.m (1.8 kgf-m, 13.3 ft-lb)

Liquid gasket

THREE BOND 1324 (Part No. 004403042) or equivalent

Scheme 293

Install in the reverse order of removal.

Note. Use a new gasket. Apply liquid gasket to variable valve lift diagnosis oil pressure switch threads. Install the oil switching solenoid valve to the holder, then install it to the cylinder head.

Tightening torque

T1

8 N.m (0.8 kgf-m, 5.9 ft-lb)

T2

10 N.m (1.0 kgf-m, 7.4 ft-lb)

T3

17 N.m (1.7 kgf-m, 12.5 ft-lb)

Liquid gasket

THREE BOND 1324 (Part No. 004403042) or equivalent

Scheme 294

Refer to " CYLINDER HEAD " for removal and installation procedures of intake and exhaust valves. REMOVAL, Cylinder Head . > INSTALLATION, Cylinder Head. >

Refer to " CYLINDER BLOCK " for removal and installation procedures of pistons. REMOVAL, Cylinder Block. > INSTALLATION, Cylinder Block. >

Refer to " CYLINDER BLOCK " for removal and installation procedures of connecting rod. REMOVAL, Cylinder Block. > INSTALLATION, Cylinder Block. >

Refer to " CYLINDER BLOCK " for removal and installation procedures of the crankshaft. REMOVAL, Cylinder Block. > INSTALLATION, Cylinder Block. >

Note. The "RANK" shown in the chart shows the possibilities of the cause of trouble in order from "Very often" to "Rarely".

A - Very often

B - Sometimes

C - Rarely

PROBLEM SYMPTOMS CHART

ENGINE NOISE POSSIBLE CAUSE CHART

See also:
• VALVE CLEARANCE
