Engine Intake System - Intake (induction) (h4dotc) Subaru Impreza WRX GH

Scheme 45

Scheme 46

Scheme 47

Scheme 48

GENERAL TOOL

GENERAL TOOL CHART

CAUTION

1. Wear appropriate work clothing, including a cap, protective goggles and protective shoes when performing any work.
2. Remove contamination including dirt and corrosion before removal, installation or disassembly.
3. Keep the disassembled parts in order and protect them from dust and dirt.
4. Before removal, installation or disassembly, be sure to clarify the failure. Avoid unnecessary removal, installation, disassembly and replacement.
5. Vehicle components are extremely hot after driving. Be wary of receiving burns from heated parts.
6. Be sure to tighten fasteners including bolts and nuts to the specified torque.
7. Place shop jacks or rigid racks at the specified points.
8. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from the battery.

Scheme 49

Scheme 50

1. Disconnect the ground cable from battery.
2. Remove the air intake duct. REMOVAL, Air Intake Duct. >
3. Disconnect the connector (A) from mass air flow and intake air temperature sensor.
4. Remove the clip (B) from the air cleaner case.
5. Open the air cleaner case, and remove the air cleaner element.

Scheme 51

INSTALLATION

Install in the reverse order of removal.

Note. Check that there are no foreign objects in the air cleaner case.

INSPECTION

Replace if excessively damaged or dirty.

Scheme 52

Scheme 53

1. Disconnect the ground cable from the battery.
2. Remove the air intake duct. REMOVAL, Air Intake Duct. >
3. Disconnect the connector (A) from mass air flow and intake air temperature sensor.
4. Loosen the clamp (B) which connects the air intake boot and intake duct.
5. Remove the clip (C) from the air cleaner case.
6. Remove the air cleaner case (rear) and air intake boot.
7. Remove the air cleaner element.
8. Remove the bolts (A) and nuts (B) which secure the air cleaner case (front) to the body.
9. Remove the air cleaner case (front).

Install in the reverse order of removal.

Note. When installing the air cleaner case (rear), align the protrusion of the air cleaner case (rear) to the hole on the air cleaner case (front) to install.

Scheme 54

Tightening torque

Bolt (A)

6 N.m (0.6 kgf-m, 4.4 ft-lb)

Nut (B)

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Check for cracks or loose connections.

REMOVAL

1. Remove the clip which installs the air intake duct on the front side of body.
2. Remove the air intake duct.

Scheme 55

Install in the reverse order of removal.

1. Check for cracks or loose connections.
2. Inspect that no foreign objects in the air intake duct.

1. Disconnect the ground cable from the battery.
2. Remove the intake manifold. REMOVAL , Intake Manifold . >
3. Remove the sensor, engine harness and fuel pipe attached to the intake manifold. DISASSEMBLY , Intake Manifold . >
4. Remove the intake duct from intake manifold.

Scheme 56

Install in the reverse order of removal.

Tightening torque: 17 N.m (1.7 kgf-m, 12.5 ft-lb)

Scheme 57

Scheme 58

Scheme 59

1. Loosen the clamp and remove the air by-pass pipe (A) and vacuum hose (B) from the air by-pass valve.
2. Loosen the clamp, and then remove intake duct (C) from the intercooler.
3. Remove the bolts which secure the intercooler to the turbocharger.
4. Remove the bolts which secure the intercooler to the intercooler stay, and remove the intercooler.
5. Remove the brake booster vacuum hose from the brake booster vacuum hose clip (A), and remove bolts (B), then remove the intercoolers stay (C).

Scheme 60

Install in the reverse order of removal.

Note. Use new O-rings. Be careful not to pinch the O-ring.

Tightening torque: 16 N.m (1.6 kgf-m, 11.8 ft-lb)

Scheme 61

Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)

Scheme 62

DISASSEMBLY

1. Remove the air by-pass valve from intercooler.

Scheme 63

ASSEMBLY

Assemble in the reverse order of disassembly.

Note. Use new O-rings. Be careful not to pinch the O-ring.

Tightening torque: 6.5 N.m (0.66 kgf-m, 4.8 ft-lb)

Check for cracks or loose connections.

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Set the vehicle on a lift.
2. Disconnect the ground cable from the battery.
3. Lift up the vehicle.
4. Drain engine coolant. DRAINING OF ENGINE COOLANT , REPLACEMENT, Engine Coolant . >
5. Lower the vehicle.
6. Remove the intercooler. REMOVAL, Intercooler. >
7. Remove the center exhaust pipe. REMOVAL , Center Exhaust Pipe . >
8. Lower the vehicle.
9. Separate the turbocharger joint pipe from turbocharger.
10. Disconnect the engine coolant hose which is connected to coolant filler tank.
11. Loosen the clamp which secures turbocharger to intake duct.
12. Remove the oil inlet pipe from the turbocharger.
13. Disconnect the engine coolant hose from the water pipe.
14. Disconnect the oil outlet hose from the oil outlet pipe.
15. Take out the turbocharger from engine compartment.

Scheme 70

1. Connect the oil outlet hose to the oil outlet pipe.
2. Install the turbocharger to intake duct. Tightening torque: 3 N.m (0.3 kgf-m, 2.2 ft-lb)
3. Install the oil inlet pipe to the turbocharger. Tightening torque: T1: 5 N.m (0.5 kgf-m, 3.7 ft-lb) T2: 16 N.m (1.6 kgf-m, 11.8 ft-lb) T3: 20 N.m (2.0 kgf-m, 14.5 ft-lb)
4. Connect the engine coolant hoses to the water pipe.
5. Install the joint pipe to turbocharger. NOTE: Replace the gasket with a new part. Tightening torque: 35 N.m (3.6 kgf-m, 25.8 ft-lb)
6. Connect the engine coolant hose which is connected to the coolant filler tank.
7. Lift up the vehicle.
8. Install the center exhaust pipe. INSTALLATION , Center Exhaust Pipe . >
9. Lower the vehicle.
10. Install the intercooler. INSTALLATION, Intercooler. >
11. Fill engine coolant. FILLING OF ENGINE COOLANT , REPLACEMENT, Engine Coolant . >
12. Connect the ground cable to battery.

Scheme 71

Scheme 72

1. Remove the intercooler. REMOVAL, Intercooler . >
2. Remove the turbocharger upper cover.
3. Remove the boost hose (B) from the waste gate actuator (A) of the turbo charger, and connect the Mighty Vac to the waste gate actuator (A).
4. Pressurize slowly with the Mighty Vac, and measure the pressure when the control rod stroke (D) becomes 2 mm (0.08 in). If it is not within the standard, replace the turbocharger assembly. CAUTION: Do not pressurize over 89.8 kPa (0.92 kgf/cm 2 , 13.0 psi) to prevent damaging the waste gate actuator. Control pressure (Control rod stroke 2 mm (0.08 in)): Standard value 74.6 - 80.8 kPa (0.76 - 0.82 kgf/cm 2 , 10.8 - 11.7 psi)
5. After inspection, install the related parts in the reverse order of removal.

Tightening torque: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

OIL PIPE AND WATER PIPE

1. Check that there are no oil leaks or water leaks from the pipe attachment section.
2. Check for cracks or loose connections.

1. Disconnect the air by-pass valve (A) and vacuum hose (B) from the air by-pass valve (C).
2. Remove the air by-pass valve (C) from the inter-cooler.

Scheme 73

Install in the reverse order of removal.

Note. Use new O-rings. Be careful not to pinch the O-ring.

Tightening torque: 6.5 N.m (0.66 kgf-m, 4.8 ft-lb)

Scheme 74
