INTRODUCTION

Pin voltage charts are supplied to reduce diagnostic time. Checking pin voltages at the ECM determines whether it is receiving and transmitting proper voltage signals. Charts may also help determine if ECM harness is open or shorted.

Note. Unless stated otherwise in testing procedures, perform all voltage tests using a Digital Volt-Ohmmeter (DVOM) with a 10-megohm input impedance. Voltage readings may vary slightly due to battery condition or charging rate.

TESTING

  1. ECM circuits are checked at ECM connectors. (Scheme 1), (Scheme 2), (Scheme 3) and (Scheme 4). Testing may be performed with ignition off, with ignition on and engine off, and/or with ignition on and engine running. Test between indicated terminal and good body ground. (Scheme 5)- (Scheme 18). When testing pin voltage, carefully backprobe terminal at harness side of ECM connector.
  2. If voltage is not as specified, test, repair or replace circuit or affected component. Retest circuit to verify repair has been made. Unless stated otherwise, perform all tests with ECM harness connected.

Scheme 1

Scheme 1: IDENTIFYING ECM HARNESS CONNECTORS (BAJA, LEGACY & OUTBACK 2.5L)

Scheme 2

Scheme 2: IDENTIFYING ECM HARNESS CONNECTORS (FORESTER & IMPREZA 2.5L)

Scheme 3

Scheme 3: IDENTIFYING ECM HARNESS CONNECTORS (IMPREZA 2.0L)

Scheme 4

Scheme 4: IDENTIFYING ECM HARNESS CONNECTORS (OUTBACK 3.0L)

Scheme 5

Scheme 5: PIN VOLTAGE CHARTS (BAJA, LEGACY & OUTBACK 2.5L)

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8: PIN VOLTAGE CHARTS (FORESTER & IMPREZA 2.5L)

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11: PIN VOLTAGE CHARTS (IMPREZA WRX 2.0L)

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15: PIN VOLTAGE CHARTS (OUTBACK 3.0L)

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18
