Electric Cooling Fan Subaru Impreza WRX GD/GG рестайлинг

COMPONENT LOCATIONS

For location of radiator and radiator fan components (Scheme 1)or (Scheme 2).

Scheme 1

Scheme 2

TROUBLE SHOOTING

For engine cooling system mechanical component trouble shooting, see appropriate table in TROUBLE SHOOTING article in GENERAL INFORMATION.

RELAYS

Information not available through manufacturer.

Detecting Condition

1. Engine coolant temperature is above 203°F (95°C).
2. Vehicle speed is below 12 MPH (19 km/h).

Scheme 3

Scheme 4

Scheme 5

1. Engine coolant temperature is above 205°F (96°C).
2. A/C compressor is rotated.
3. Vehicle speed is below 12 MPH (19 km/h).

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

INTRODUCTION

Note. System for A/C equipped vehicles only.

Detecting Condition No. 1

1. Engine coolant temperature is below 203°F (95°C).
2. A/C switch is turned ON.
3. Vehicle coolant below 12 MPH (19 km/h).

Detecting Condition No. 2

1. Engine coolant temperature is above 212°F (100°C).
2. A/C switch is turned OFF.
3. Vehicle speed is below 12 MPH (19 km/h).

Scheme 11

Scheme 12

Scheme 13

1. Engine coolant temperature is above 205°F (96°C).
2. A/C compressor is rotated.
3. Vehicle speed is below 12 MPH (19 km/h).

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Removal & Installation

1. Disconnect the battery ground cable.
2. Lift-up the vehicle.
3. Remove the under cover.
4. Remove the radiator under cover (A/T vehicle only). (Scheme 19)
5. Disconnect the connector of main fan motor (A). (Scheme 20)
6. Lower the vehicle.
7. Remove the air intake duct. (Turbo model). (Scheme 21)
8. Disconnect the over flow hose. (Scheme 22)
9. Remove the over flow pipe. (Turbo model)
10. Remove the reservoir tank. (Scheme 23)
11. Remove the radiator main fan motor assembly. (Scheme 24)
12. Install in the reverse order of removal. (Scheme 24)and (Scheme 23).

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Disassembly & Assembly

1. Remove the clip which holds motor connector onto the shroud. (Scheme 25)
2. Remove the nut which holds fan itself onto the fan motor and shroud assembly. (Scheme 26)
3. Remove the bolts which install fan motor onto the shroud. (Scheme 28)
4. Assemble in the reverse order of disassembly. (Scheme 28)and (Scheme 26).

Scheme 25

Scheme 26

Scheme 27

Scheme 28

1. Disconnect the battery ground cable.
2. Lift-up the vehicle.
3. Remove the under cover.
4. Remove the radiator under cover.
5. Disconnect the connector of sub fan motor. (Scheme 29)
6. Lower the vehicle.
7. Remove the air intake duct (Turbo model). (Scheme 21)
8. Remove the bolts which hold sub fan shroud to the radiator.
9. Remove the over flow pipe (Turbo model).
10. Remove the radiator sub fan shroud through the under side of vehicle. (Scheme 24)
11. Install in the reverse order of removal. (Scheme 24)

Scheme 29

1. Remove clip which holds motor harness onto shroud. (Scheme 25)
2. Remove nut which install fan itself onto fan motor and shroud assembly. (Scheme 27)
3. Remove bolts which install fan motor onto shroud. (Scheme 28)
4. Installation is in the reverse order of removal. (Scheme 28)and (Scheme 27).

WIRING DIAGRAMS

For electric cooling fan system wiring diagram, see COOLING FAN under SYSTEM WIRING DIAGRAMS in ELECTRICAL.
