INSPECTION
- Check that the air cleaner element has no deformation, cracks or other damages.
- Check the air cleaner element for excessive dirt.
- Replace the air cleaner case (rear) if the HC absorption filter is damaged.
Scheme 881
Scheme 882
Scheme 883
Scheme 884
Scheme 885
- Disconnect the ground cable from battery.
- Remove the air intake duct (rear). < Ref. to «REMOVAL»(ref-662120-S42382818082014101300000) , Air Intake Duct. >
- Disconnect the connector (A) from the mass air flow and intake air temperature sensor, and remove the clip (B).
- Loosen the clamp (A) which secures the air intake boot to the air cleaner case (rear), and then remove the clip (B) from the air cleaner case (front).
- Remove the air cleaner case (rear) and air cleaner element.
- Remove the bolt (A) and nut (B) which secure the air cleaner case (front) to the vehicle and to the air cleaner case bracket.
- Remove the air cleaner case (front).
- Remove the air cleaner case bracket from the vehicle.
- Check that the air cleaner case has no deformation, cracks or other damages.
- Check that the air intake boot has no cracks, damage or loose part.
Scheme 886
- Remove the clip (A) from the air intake boot.
- Loosen the clamp (B) securing the air cleaner case (rear) to the air intake boot.
- Loosen the clamp (C) which secures the throttle body to the air intake boot.
- Disconnect the PCV hose and remove the air intake boot.
- Check that the air intake boot has no deformation, cracks or other damages.
- Inspect that no foreign objects are mixed in the air intake boot.
Scheme 887
Scheme 888
- Remove the clip which secures air intake duct (rear), and remove the air intake duct (rear).
- Remove the clip (A) and four claws and then remove the air intake duct (front).
- Check that the air intake duct has no deformation, cracks or other damages.
- Inspect that no foreign objects are mixed in the air intake duct.
Check that the resonator chamber has no deformation, cracks or other damages.
