Ignition System (H4DOTC): Removal & Installation Subaru Forester SJ

REMOVAL

Spark plug

Refer to "SPECIFICATION" for spark plug. < Ref. to SPECIFICATION , General Description. >

Scheme 16

1. Disconnect the ground cable from battery.
2. Remove the engine control module (ECM). < Ref. to «REMOVAL»(ref-662119-S30397921182014101300000) , Engine Control Module (ECM). >
3. Disconnect the connector from ignition coil.
4. Remove the ignition coil.
5. Remove the spark plug with a spark plug socket.

Scheme 17

1. Remove the battery. < Ref. to «REMOVAL»(ref-662144-S03551831502014101300000) , Battery. >
2. Disconnect the connector from ignition coil.
3. Remove the ignition coil.
4. Remove the spark plug with a spark plug socket.

Direct ignition type is adopted. Refer to "Spark Plug" for removal procedure. < Ref. to REMOVAL , Spark Plug. >

INSTALLATION

Direct ignition type is adopted. Refer to "Spark Plug" for the installation procedure. < Ref. to INSTALLATION , Spark Plug. >
