Ignition System (H4DO): Removal & Installation Subaru Forester SJ

REMOVAL

Spark plug

Refer to "SPECIFICATION" for spark plug. < Ref. to SPECIFICATION , General Description. >

Scheme 7

1. Disconnect the ground cable from battery.
2. Remove the air cleaner case (rear). < Ref. to «REMOVAL»(ref-662120-S29644372242014101300000) , Air Cleaner Case. >
3. Disconnect the connector from ignition coil.
4. Remove the ignition coil.
5. Remove the spark plug with a spark plug socket.

Scheme 8

1. Disconnect the ground cable from battery.
2. Disconnect the connector from ignition coil.
3. Remove the ignition coil.
4. Remove the spark plug with a spark plug socket.

Direct ignition type is adopted. Refer to "Spark Plug" for removal procedure. < Ref. to REMOVAL , Spark Plug. >

INSTALLATION

Direct ignition type is adopted. Refer to "Spark Plug" for the installation procedure. < Ref. to INSTALLATION , Spark Plug. >
