INSTALLATION
| CAUTION | Before handling the airbag module, refer to "CAUTION" of "General Description" in "AIRBAG SYSTEM". < Ref. to CAUTION , General Description. > Do not allow harness and connectors to interfere or get tangled up with other parts. If the steering wheel and steering angle sensor (steering roll connector) are removed, adjust the steering angle sensor. < Ref. to ADJUSTMENT , VDC Control Module and Hydraulic Control Unit (VDCCM & H/U). > |
- Before installing steering wheel, be sure to adjust the direction of steering roll connector with steering wheel. < Ref. to «ADJUSTMENT»(ref-662142-S08784213832014101300000) , Roll Connector. >
- Install each part in the reverse order of removal. NOTE: Align the alignment marks on the steering wheel and the column assembly - steering. Tightening torque: Steering wheel: 39 N.m (3.98 kgf-m, 28.8 ft-lb) Clearance: Between cover assembly - column and steering wheel: 4 - 6 mm (0.16 - 0.24 in)
Install each part in the reverse order of removal.
- Install each part in the reverse order of removal. NOTE: Secure the flange section of the bumper face - front to the bracket - front bumper side. Tightening torque: Light assembly - head: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
- Adjust the headlight beam and fog light beam. Adjust the headlight beam. < Ref. to «HEADLIGHT BEAM ADJUSTMENT»(ref-662141-S19693052242014101300000) , ADJUSTMENT, Headlight Assembly. > Adjust the fog light beam. (Model with fog light) < Ref. to «FOG LIGHT AIMING»(ref-662141-S36038988732014101300000) , ADJUSTMENT, Front Fog Light Assembly. >
Install each part in the reverse order of removal.
| CAUTION | After installing the panel center assembly, check that the air vent grille of the panel center assembly is inserted correctly into the air vent duct. |
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
REMOVAL
Note. Since the LED type parking light cannot be disassembled, it cannot be removed.
Scheme 54
- Disconnect the ground cable from battery.
- Remove the clips and remove the air intake duct (rear). (When removing the parking light bulb RH)
- Remove the bulb socket and parking light bulb.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
- Install each part in the reverse order of removal. Tightening torque: Fog light assembly - front: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
- Adjust the fog light beam. < Ref. to «FOG LIGHT AIMING»(ref-662141-S36038988732014101300000) , ADJUSTMENT, Front Fog Light Assembly. >
Scheme 55
Scheme 56
- Before checking the fog light assembly - front beam level, be sure of the following: The area around the fog light assembly - front has not sustained any scratches, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
- Bounce the vehicle several times to normalize the suspension.
- Make certain that someone is seated in the driver's seat.
- Place the vehicle with the front end facing to the measurement panel. h mm (in) at 3 m (10 ft) 40 (1.58)
- Adjust the fog light assembly - front beam. Remove the screw and clips, and turn over the front side of the mud guard - front. Adjust the beam direction by turning the aiming screw from the bottom of the bumper face - front.
Scheme 57
- Disconnect the ground cable from battery.
- Remove the screw and clips, and turn over the front side of the mud guard - front.
- From the bottom of the bumper face - front, remove the front fog light bulb. Disconnect the connector. Remove the bulb.
| CAUTION | After connecting the connector, make sure that the bulb is locked securely. |
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Tightening torque
Light assembly - rear combination: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Tightening torque
Light assembly - high-mounted: 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Note. The ignition switch illumination is integrated into the immobilizer antenna assembly.
Scheme 58
Scheme 59
Scheme 60
- Disconnect the ground cable from battery.
- Remove the cover assembly - column. Remove the screws by turning the steering wheel to right and left. Release the claw, and remove the cover assembly - column UPR and the cover assembly - column LWR.
- Disconnect the connector and remove the ignition switch illumination. CAUTION: Do not apply excessive force to remove the ignition switch illumination lock. Otherwise they may be broken because those parts are the products made of a plastic.
Install each part in the reverse order of removal.
Install each part in the reverse order of removal.
Tightening torque
Relay & fuse box: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Note. When the Auto Headlight Beam Leveler Control Module is removed, perform initialization or reinitialization. < Ref. to PROCEDURE , Auto Headlight Beam Leveler System. >
| CAUTION | Always remove the sensor assembly - headlight beam leveler before removing any parts related to the suspension. Do not apply impact to the sensor assembly - headlight beam leveler or forcibly move the arm. Doing so may cause sensor damage and malfunction. |
Scheme 61
- Disconnect the ground cable from battery.
- Lift up the vehicle, and remove the left rear wheel.
- Remove the sensor assembly - headlight beam leveler. CAUTION: Do not disassemble the sensor and lever. Disconnect the connector. Remove the nuts, and remove the sensor assembly - headlight beam leveler.
| CAUTION | Do not apply impact to the sensor assembly - headlight beam leveler or forcibly move the arm. Doing so may cause sensor damage and malfunction. |
- Install each part in the reverse order of removal. Tightening torque: Sensor assembly - headlight beam leveler: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb) Rear wheel: 120 N.m (12.24 kgf-m, 88.5 ft-lb)
- Perform reinitialization of the sensor assembly - headlight beam leveler. < Ref. to «REINITIALIZATION»(ref-662141-S09380040062014101300000) , PROCEDURE, Auto Headlight Beam Leveler System. > NOTE: When replacing the sensor assembly - headlight beam leveler with a new part, perform the initialization. < Ref. to «INITIALIZATION»(ref-662141-S19064680352014101300000) , PROCEDURE, Auto Headlight Beam Leveler System. >
Install each part in the reverse order of removal.
Tightening torque
Resistor assembly - daytime running light: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
From behind the bumper face - rear, release the nuts and claws and remove the reflex reflector assembly.
Scheme 62
Install each part in the reverse order of removal.
Scheme 63
- Disconnect the ground cable from battery.
- Remove the switch assembly - door. Remove the screws, and pull out the switch assembly - door toward you. Disconnect the connector and remove the switch assembly - door.
Install each part in the reverse order of removal.
