DISASSEMBLY
| CAUTION | When removing the mirror - repair, be careful not to damage the back surface of mirror - repair with a flat tip screwdriver. When installing the mirror - repair, insert the connector and clip securely. |
Scheme 43
Scheme 44
Scheme 45
Scheme 46
- Operate the remote control mirror switch to face the mirror - repair upward.
- Disconnect the ground cable from battery.
- Remove the mirror - repair. Using a flat tip screwdriver, release the clip, and slide the mirror - repair downward to remove. Disconnect the mirror heater connector. (Model with mirror heater)
- Release the claws, and then remove the cover - cap outer mirror lower.
- Release the claws, and then remove the cover - cap outer mirror. CAUTION: Be careful not to apply excessive force when removing the cover - cap outer mirror, as the lower hooks may become damaged.
Scheme 47
Scheme 48
- Engage the claws into the hole and install the cover - cap outer mirror.
- Engage the claws into the hole and install the cover - cap outer mirror lower.
- Check that all the claws are securely engaged.
- Install the mirror - repair in the reverse order of removal. CAUTION: Be sure to insert the connector and clips securely.
Scheme 49
- Disconnect the outer mirror connector.
- Apply battery voltage between the outer mirror connector terminals and check the mirror operation. Terminal No. Inspection conditions Switch position - - OFF 3 (+) - 8 (-) Apply battery voltage between terminals. UP 8 (+) - 3 (-) Apply battery voltage between terminals. DOWN 7 (+) - 3 (-) Apply battery voltage between terminals. LEFT 3 (+) - 7 (-) Apply battery voltage between terminals. RIGHT
- If it does not operate normally, replace the outer mirror assembly.
Scheme 50
- Remove the panel - power window main switch. < Ref. to «MAIN SWITCH»(ref-662103-S28828582442014101300000) , REMOVAL, Power Window Control Switch. >
- Release the claws, and then remove the switch - door mirror.
