Scheme 59
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.5 (0.66, 4.8)
T2: 7.5 (0.76, 5.5)
T3: 18 (1.84, 13.3)
Scheme 60
Tightening torque: N.m (kgf-m, ft-lb)
T: 25 (2.55, 18.4)
Scheme 61
Tightening torque: N.m (kgf-m, ft-lb)
T1: 7.5 (0.76, 5.5)
T2: 33 (3.36, 24.3)
Scheme 62
Tightening torque: N.m (kgf-m, ft-lb)
T: 7.5 (0.76, 5.5)
CHECK ROOM LIGHT OPERATION
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK ROOM LIGHT OPERATION . Make sure the room light illuminates when the room light switch is ON, and goes off when the switch is OFF. | Does the room light illuminate or go off? | Go to step 2 . | Check the room light circuit. < Ref. to INSPECTION , Room Light. > |
| 2 CHECK ROOM LIGHT OPERATION. Turn the room light switch to the "DOOR" position. Open and close any door. | Does the room light illuminate <----> go off (including off delay) when the door is opened and closed? | Go to step 3 . | Go to step 4 . |
| 3 CHECK KEYLESS ENTRY OPERATION. Press the LOCK/UNLOCK button of the keyless transmitter. | Does it operate properly? | Room light is normal. | Check keyless entry system. < Ref. to SYMPTOM CHART , INSPECTION, Keyless Entry System. > |
| 4 CHECK ROOM LIGHT. Check the room light. < Ref. to INSPECTION , Room Light. > | Is room light normal? | Go to step 5 . | Replace the bulb or room light assembly. |
| 5 CHECK HARNESS. Disconnect the connectors of body integrated unit and room light. Check the harness between body integrated unit and room light. Connector & terminal (i84) No. 4 - (R52) No. 2 | Is harness normal? | Go to step 6 . | Repair or replace the harness. |
| 6 CHECK HARNESS. Measure the voltage between the room light connector and chassis ground. Connector & terminal (R52) No. 3 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Replace the body integrated unit. < Ref. to BODY INTEGRATED UNIT . > | Repair or replace the harness. |
CHECK HAZARD LIGHT OPERATION
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK HAZARD LIGHT OPERATION . Make sure the hazard light blinks when hazard switch is turned to ON. | Does the hazard light blink? | Go to step 2 . | Check the hazard light circuit. |
| 2 CHECK BODY INTEGRATED UNIT SETTING. Display the data of «Abnormal warning lamp flashing setting» using Subaru Select Monitor. NOTE: For detailed procedures, refer to "PC application help for Subaru Select Monitor". | Is the setting ON? | Go to step 3 . | Turn the setting to ON. |
| 3 CHECK CURRENT DATA. Display the data of «Hazard Output» using Subaru Select Monitor. | Is output signal present when operating the transmitter LOCK/UNLOCK button? | Go to step 4 . | Go to step 5 . |
| 4 CHECK KEYLESS ENTRY OPERATION. Press the LOCK/UNLOCK button of the keyless transmitter. | Does it operate properly? | Replace the body integrated unit. < Ref. to BODY INTEGRATED UNIT . > | Check keyless entry system. < Ref. to SYMPTOM CHART , INSPECTION, Keyless Entry System. > |
| 5 CHECK HAZARD LIGHT CIRCUIT. Disconnect the connectors of the body integrated unit and turn signal & hazard unit. Check the harness between body integrated unit and turn signal & hazard unit. Connector & terminal (i171) No. 18 - (B32) No. 8 | Is harness normal? | Check body integrated unit. < Ref. to BASIC DIAGNOSTIC PROCEDURE . > | Repair or replace the harness. |
| NOTE |
|---|
| For detailed procedures, refer to "PC application help for Subaru Select Monitor". |
For operation procedure, refer to "CHECK HAZARD LIGHT OPERATION" of "Keyless Entry System" < Ref. to CHECK HAZARD LIGHT OPERATION , INSPECTION, Keyless Entry System. >
