ELECTRICAL SPECIFICATION
| CAUTION | Never remove the occupant detection control module, occupant detection sensor or seat frame because they are integrated into one unit. |
Scheme 185
| Terminal No. | Terminal name | Input/Output value | Note |
|---|---|---|---|
| 1 | Buckle switch (+) | 0 - IG voltage | When buckle switch is ON |
| 2 | Buckle switch (-) | 0 V | Switch ground |
| 3 | Not used | ||
| 4 | Airbag CM communication (-) | ||
| 5 | Airbag CM communication (+) | ||
| 6 | IG power supply | 8 - 16 V | When IG switch is ON |
Note. Occupant detection sensor signal is unmeasurable.
