Airbag System (Diagnostics): Other Subaru Forester SJ

Airbag 22 illustrations ~453 words

PROCEDURE

StepCheckYesNo
1 CHECK WARNING LIGHT . Check whether the airbag warning light in the combination meter is lit.Does the airbag warning light illuminate?Go to step 2 .Perform the diagnosis according to phenomenon of the problem.
2 READ DTC. Turn the ignition switch to OFF. Connect the Subaru Select Monitor to data link connector. Turn the ignition switch to ON and run the Subaru Select Monitor. Read the DTC. (Current malfunction) < Ref. to OPERATION , Read Diagnostic Trouble Code (DTC). > NOTE: If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. > Record all DTCs, time stamp and freeze frame data. NOTE: For time stamp, refer to "LAN SYSTEM". < Ref. to TIME STAMP , CAUTION, General Description. >Is DTC displayed?Go to step 3 .Go to "Airbag Warning Light Failure" < Ref. to AIRBAG WARNING LIGHT FAILURE . >.
3 PERFORM DIAGNOSIS. Determine the possible cause from "List of Diagnostic Trouble Code (DTC)" < Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . >. Inspect the DTC using "List of Diagnostic Trouble Code (DTC)". Repair the trouble cause. Perform the Clear Memory Mode. < Ref. to CLEAR MEMORY MODE . > Perform the Inspection Mode. < Ref. to INSPECTION MODE . > Read any other DTCs displayed.Is DTC displayed?Perform the procedure 1 ) to 5 ) in step 3.Finish the diagnosis.
NOTE
If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. >
NOTE
For time stamp, refer to "LAN SYSTEM". < Ref. to TIME STAMP , CAUTION, General Description. >

Scheme 221

Scheme 221: CHECK
Scheme 221: CHECK

CAUTION

Refer to "CAUTION" in "General Description" in Airbag System. < Ref. to CAUTION , General Description. >

PREPARATION TOOL

CAUTIONTo measure the voltage and resistance of airbag system component, be sure to use the specified test harness.

Scheme 222

Scheme 222: SPECIAL TOOL
Scheme 222: SPECIAL TOOL

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226

Scheme 227

Scheme 227
Scheme 227

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230

Scheme 231

Scheme 231
Scheme 231

Scheme 232

Scheme 232
Scheme 232

Scheme 233

Scheme 233
Scheme 233

Scheme 234

Scheme 234
Scheme 234

Scheme 235

Scheme 235
Scheme 235

Scheme 236

Scheme 236
Scheme 236

Scheme 237

Scheme 237
Scheme 237

Scheme 238

Scheme 238
Scheme 238

Scheme 239

Scheme 239
Scheme 239
  1. Subaru Select Monitor ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system.
  2. TEST HARNESS H ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and front door impact sensor.
  3. TEST HARNESS N ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module, seat belt pretensioner and curtain airbag module.
  4. TEST HARNESS Q ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module.
  5. TEST HARNESS AG ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module.
  6. TEST HARNESS V ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor.
  7. AIRBAG RESISTOR ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two STs are required for diagnosis of two-stage inflator type airbag module.
  8. TEST HARNESS AJ ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness.
  9. TEST HARNESS AI ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used for diagnoses of side airbag sensor and curtain airbag sensor. Used together with test harness V.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance, voltage and current.
OscilloscopeUsed for measuring the sensor.
ProbeUsed when measuring voltage and resistance of passenger's airbag module.

HOW TO USE PROBE

Insert the probe into the harness hole, and contact it with the terminal.

Scheme 240

Scheme 240: HOW TO USE PROBE
Scheme 240: HOW TO USE PROBE
CAUTIONDo not insert the probe forcibly. Be careful not to contact it to the connection (5) between the terminal and harness. (Harness will come off easily from connector if doing so.)

Scheme 241

Scheme 241: LOCATION
Scheme 241: LOCATION
Connector No.(AB1)(AB2)(AB6)(AB7)(AB9)(AB13)(AB16)(AB17)(AB18)(AB19)(AB21)(AB23)
Pin243044222424424
ColorGrayYellowYellowYellowYellowYellowYellowYellowYellowYellowBlackYellow
Male/FemaleMaleFemaleFemaleMaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemale
Connector No.(AB24)(AB26)(AB28)(AB30)(AB31)(AB32)(AB33)(AB34)(AB37)(AB38)(AB41)(AB53)
Pin424224242223
ColorYellowBlackYellowOrangeBlackYellowBlackYellowOrangeBlackYellowDark gray
Male/FemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleMale
Connector No.(AB58)(AB59)(AB60)(AB61)(AB62)(AB63)(AB64)(AB66)
Pin23262222
ColorYellowDark grayYellowBlackYellowYellowYellowBlack
Male/FemaleFemaleFemaleMaleFemaleFemaleFemaleFemaleFemale

For operation procedures, refer to "Airbag Connector" of Airbag System. < Ref. to AIRBAG CONNECTOR . >

Scheme 242

Scheme 242: ELECTRICAL SPECIFICATION
Scheme 242: ELECTRICAL SPECIFICATION
  1. Terminal numbers in airbag control module connector are shown in the figure.
  2. The airbag warning light illuminates when the connector is removed from the airbag control module.
ItemControl module terminal No.
Ignition power supplyDedicated fuse(1) - 21
Passenger's airbag module level one+(1) - 4
(1) - 3
Passenger's airbag module level two+(1) - 1
(1) - 2
Driver's airbag module level one+(1) - 5
(1) - 6
Driver's airbag module level two+(1) - 8
(1) - 7
Driver's knee airbag module+(1) - 9
(1) - 10
CAN-H(1) - 13
CAN-L(1) - 22
Front sub sensor LH+(1) - 30
(1) - 28
Front sub sensor RH+(1) - 29
(1) - 27
Ground line (GND)(1) - 25
(1) - 26
Passenger's airbag ON indicator(1) - 23
Passenger's airbag OFF indicator(1) - 17
Passenger's seat belt warning(1) - 15
Side airbag sensor LH Curtain airbag sensor LH Front door impact sensor LH+(2) - 24
(2) - 23
Seat belt pretensioner LH+(2) - 5
(2) - 6
Side airbag module LH+(2) - 1
(2) - 2
Curtain airbag module LH+(2) - 4
(2) - 3
Occupant detection control module+(3) - 16
(3) - 24
Side airbag sensor RH Curtain airbag sensor RH Front door impact sensor RH+(3) - 17
(3) - 18
Side airbag module RH+(3) - 8
(3) - 7
Curtain airbag module RH+(3) - 5
(3) - 6
Seat belt pretensioner RH+(3) - 4
(3) - 3
Lap seat belt pretensioner RH+(3) - 1
(3) - 2
Satellite safing sensor+(3) - 21
(3) - 22

Recreate the circumstance by referring to the conditions described in the checklist.

DETECTING CONDITION

  1. Airbag warning light is faulty.
  2. Airbag control module to combination meter circuit is shorted or open.
  3. Grounding circuit is faulty.
  4. Airbag control module is faulty.
  5. Connector connection is improper.
  6. Connections of (AB6, AB17, AB18) to airbag control module are improper.
CAUTIONBefore performing diagnosis, refer to "CAUTION" in "General Description". < Ref. to CAUTION , General Description. >
StepCheckYesNo
1 CHECK CAN COMMUNICATION. Inspect LAN system. < Ref. to PROCEDURE , Basic Diagnostic Procedure. >Is there any fault?Repair it according to diagnosis of LAN system.Go to step 2 .
2 CHECK DTC. Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 60 seconds or more. Check the connection status of Airbag Control Module connector.Is there poor contact of connector?Reconnect the connector. Or repair the connector.Go to step 3 .
3 CHECK FOR POOR CONTACT. Check the combination meter. < Ref. to PROCEDURE , Basic Diagnostic Procedure. >Is there any fault?Repair it according to INSTRUMENTATION/DRIVER INFO (DIAGNOSTICS).Replace the airbag Control Module. < Ref. to REMOVAL , Airbag Control Module. >

AIRBAG WARNING LIGHT REMAINS OFF

Note. For the diagnostic procedure, refer to "AIRBAG WARNING LIGHT REMAINS ON". < Ref. to AIRBAG WARNING LIGHT REMAINS ON , Airbag Warning Light Failure. >

LIST

DTCItemContent of diagnosisReference
U0073Control Module Communication Bus "A" OffCAN communication error occurred.< Ref. to DTC U0073: CONTROL MODULE COMMUNICATION BUS "A" OFF , Diagnostic Chart with Trouble Code. >
B1000Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1000: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1003Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1003: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1105Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1105: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1106Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1106: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1115Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1115: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1116Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1116: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1120Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1120: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1121Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1121: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1125Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1125: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1126Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1126: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1135Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1135: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1136Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1136: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1145Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1145: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1146Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1146: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1170Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1170: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1185Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1185: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1195Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1195: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1196Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1196: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1199Airbag ECU MalfunctionAirbag control module is faulty.< Ref. to DTC B1199: AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B11E0Rollover IgnitionCurtain airbag module (LH/RH) and seat belt pretensioner (LH/RH) are deployed.< Ref. to DTC B11E0: ROLLOVER IGNITION , Diagnostic Chart with Trouble Code. >
B11F2Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Ref. to DTC B11F2: FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F3Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Ref. to DTC B11F3: FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F4Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Ref. to DTC B11F4: FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F5Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Ref. to DTC B11F5: FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F7Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11F7: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F8Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11F8: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F9Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11F9: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FASide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11FA: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FBSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11FB: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FCSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Ref. to DTC B11FC: SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B1610Front Sub Sensor RH FailureFront sub sensor RH is faulty< Ref. to DTC B1610: FRONT SUB SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1612Front Sub Sensor RH Lost CommunicationOpen or short circuit in harness RH between airbag control module and front sub sensor. Front sub sensor RH is faulty. Airbag control module is faulty.< Ref. to DTC B1612: FRONT SUB SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1613Front Sub Sensor RH Initialization Error< Ref. to DTC B1613: FRONT SUB SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1615Front Sub Sensor LH FailureFront sub sensor LH is faulty.< Ref. to DTC B1615: FRONT SUB SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1617Front Sub Sensor LH Lost CommunicationOpen or short circuit in harness LH between airbag control module and front sub sensor. Front sub sensor LH is faulty. Airbag control module is faulty.< Ref. to DTC B1617: FRONT SUB SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1618Front Sub Sensor LH Initialization Error< Ref. to DTC B1618: FRONT SUB SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B16F2Front Sub Sensor RH Recognition ErrorFront sensor RH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F2: FRONT SUB SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F3Front Sub Sensor LH Recognition ErrorFront sensor LH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F3: FRONT SUB SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1620Side Airbag Sensor RH FailureSide airbag sensor RH is faulty.< Ref. to DTC B1620: SIDE AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1622Side Airbag Sensor RH Lost CommunicationOpen or short circuit in harness RH between airbag control module and side airbag sensor. Side airbag sensor RH is faulty. Airbag control module is faulty.< Ref. to DTC B1622: SIDE AIRBAG SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1623Side Airbag Sensor RH Initialization Error< Ref. to DTC B1623: SIDE AIRBAG SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1625Side Airbag Sensor LH FailureSide airbag sensor LH is faulty.< Ref. to DTC B1625: SIDE AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1627Side Airbag Sensor LH Lost CommunicationOpen or short circuit in harness LH between airbag control module and side airbag sensor. Side airbag sensor LH is faulty. Airbag control module is faulty.< Ref. to DTC B1627: SIDE AIRBAG SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1628Side Airbag Sensor LH Initialization Error< Ref. to DTC B1628: SIDE AIRBAG SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1630Curtain Airbag Sensor RH FailureCurtain airbag sensor RH is faulty.< Ref. to DTC B1630: CURTAIN AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1632Curtain Airbag Sensor RH Lost CommunicationOpen or short circuit in harness RH between airbag control module and curtain airbag sensor. Side airbag sensor RH is faulty. Curtain airbag sensor RH is faulty. Airbag control module is faulty.< Ref. to DTC B1632: CURTAIN AIRBAG SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1633Curtain Airbag Sensor RH Initialization Error< Ref. to DTC B1633: CURTAIN AIRBAG SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1635Curtain Airbag Sensor LH FailureCurtain airbag sensor LH is faulty.< Ref. to DTC B1635: CURTAIN AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1637Curtain Airbag Sensor LH Lost CommunicationOpen or short circuit in harness LH between airbag control module and curtain airbag sensor. Side airbag sensor LH is faulty. Curtain airbag sensor LH is faulty. Airbag control module is faulty.< Ref. to DTC B1637: CURTAIN AIRBAG SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1638Curtain Airbag Sensor LH Initialization Error< Ref. to DTC B1638: CURTAIN AIRBAG SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B16F4Side Airbag Sensor RH Recognition ErrorSide airbag sensor RH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F4: SIDE AIRBAG SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F5Side Airbag Sensor LH Recognition ErrorSide airbag sensor LH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F5: SIDE AIRBAG SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F6Curtain Airbag Sensor RH Recognition ErrorCurtain airbag sensor RH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F6: CURTAIN AIRBAG SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F7Curtain Airbag Sensor LH Recognition ErrorCurtain airbag sensor LH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F7: CURTAIN AIRBAG SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1642Side Satellite Sensor Bus RH Lost CommunicationOpen or short circuit in harness RH between airbag control module and front door impact sensor. Side airbag sensor RH is faulty. Curtain airbag sensor RH is faulty. Front door impact sensor RH is faulty. Airbag control module is faulty.< Ref. to DTC B1642: SIDE SATELLITE SENSOR BUS RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1647Side Satellite Sensor Bus LH Lost CommunicationOpen or short circuit in harness LH between airbag control module and front door impact sensor. Side airbag sensor LH is faulty. Curtain airbag sensor LH is faulty. Front door impact sensor LH is faulty. Airbag control module is faulty.< Ref. to DTC B1647: SIDE SATELLITE SENSOR BUS LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1650Occupant Classification System MalfunctionOccupant detection sensor is faulty. Occupant detection control module is faulty. Occupant detection harness is faulty. Rear airbag harness RH is faulty. Fuse No. 25 is blown.< Ref. to DTC B1650: OCCUPANT CLASSIFICATION SYSTEM MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1655Front Buckle Switch RH FailureBuckle switch RH circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.< Ref. to DTC B1655: FRONT BUCKLE SWITCH RH FAILURE , Diagnostic Chart with Trouble Code. >
B1660Passenger's Airbag On Indicator FailurePassenger's airbag indicator is faulty. Airbag control module is faulty. Airbag main harness circuit is open, shorted or shorted to ground. Body harness circuit is open.< Ref. to DTC B1660: PASSENGER'S AIRBAG ON INDICATOR FAILURE , Diagnostic Chart with Trouble Code. >
B1675Satellite Safing Sensor Failure Satellite safing sensor is faulty.< Ref. to DTC B1675: SATELLITE SAFING SENSOR FAILURE , Diagnostic Chart with Trouble Code. >
B1676Lost Communication With Satellite Safing SensorOpen or short circuit in harness between airbag control module and satellite safing sensor. Satellite safing sensor is faulty. Airbag control module is faulty.< Ref. to DTC B1676: LOST COMMUNICATION WITH SATELLITE SAFING SENSOR , Diagnostic Chart with Trouble Code. >
B1677Satellite Safing Sensor Initialization Incomplete< Ref. to DTC B1677: SATELLITE SAFING SENSOR INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B16F8Satellite Safing Sensor Recognition ErrorSatellite safing sensor is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F8: SATELLITE SAFING SENSOR RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F9Door Sensor RH Recognition ErrorFront door impact sensor RH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16F9: DOOR SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1690Door Sensor RH FailureFront door impact sensor RH is faulty.< Ref. to DTC B1690: DOOR SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1692Lost Communication With Door Sensor RHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor RH is faulty. Curtain airbag sensor RH is faulty. Airbag control module is faulty.< Ref. to DTC B1692: LOST COMMUNICATION WITH DOOR SENSOR RH , Diagnostic Chart with Trouble Code. >
B1693Door Sensor RH Initialization Incomplete< Ref. to DTC B1693: DOOR SENSOR RH INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B16FALost Communication With Door Sensor LHFront door impact sensor LH is misinstalled. Airbag control module is faulty.< Ref. to DTC B16FA: LOST COMMUNICATION WITH DOOR SENSOR LH , Diagnostic Chart with Trouble Code. >
B1695Door Sensor LH FailureFront door impact sensor LH is faulty.< Ref. to DTC B1695: DOOR SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1697Lost Communication With Door Sensor LHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor LH is faulty. Curtain airbag sensor LH is faulty. Airbag control module is faulty.< Ref. to DTC B1697: LOST COMMUNICATION WITH DOOR SENSOR LH , Diagnostic Chart with Trouble Code. >
B1698Door Sensor LH Initialization Incomplete< Ref. to DTC B1698: DOOR SENSOR LH INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B161ALost Communication With Front Satellite Sensor BusOpen or short circuit in harness between airbag control module and front sub sensor. Front sub sensor is faulty. Airbag control module is faulty.< Ref. to DTC B161A: LOST COMMUNICATION WITH FRONT SATELLITE SENSOR BUS , Diagnostic Chart with Trouble Code. >
B16F1Passenger's Seat Belt Warning FailureAirbag control module is faulty. Body integrated unit is faulty. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.< Ref. to DTC B16F1: PASSENGER'S SEAT BELT WARNING FAILURE , Diagnostic Chart with Trouble Code. >
B16F0Passenger's Airbag Off Indicator FailureAirbag warning light is faulty. Open or short circuit in harness between airbag control module and airbag warning light. Poor contact of airbag main harness and instrument panel harness. Ground circuit is faulty. Airbag control module is faulty.< Ref. to DTC B16F0: PASSENGER'S AIRBAG OFF INDICATOR FAILURE , Diagnostic Chart with Trouble Code. >
B1760Sensor Mat AbnormalOccupant detection sensor is open, shorted between terminals, shorted to power supply or shorted to ground. Seat heater is open. Occupant detection control module is faulty.< Ref. to DTC B1760: SENSOR MAT ABNORMAL , Diagnostic Chart with Trouble Code. >
B1771Buckle Switch AbnormalPassenger's buckle switch circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.< Ref. to DTC B1771: BUCKLE SWITCH ABNORMAL , Diagnostic Chart with Trouble Code. >
B1795ECU Internal CircuitFault Occupant detection control module is faulty.< Ref. to DTC B1795: ECU INTERNAL CIRCUIT FAULT , Diagnostic Chart with Trouble Code. >
B1800Short in Driver's AirbagAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1800: SHORT IN DRIVER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1801Open in Driver's AirbagAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1801: OPEN IN DRIVER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1802Short in Driver's Airbag (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1802: SHORT IN DRIVER'S AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1803Short in Driver's Airbag (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1803: SHORT IN DRIVER'S AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1805Short in Passenger's AirbagAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1805: SHORT IN PASSENGER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1806Open in Passenger's AirbagAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1806: OPEN IN PASSENGER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1807Short in Passenger's Airbag (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1807: SHORT IN PASSENGER'S AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1808Short in Passenger's Airbag (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1808: SHORT IN PASSENGER'S AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1810Short in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1810: SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1811Open in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1811: OPEN IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1812Short in Driver's Airbag Dual Stage - 2nd Step (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1812: SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1813Short in Driver's Airbag Dual Stage - 2nd Step Circuit (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1813: SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1815Open in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1815: OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1816Open in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1816: OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1817Short in Passenger's Airbag Dual Stage - 2nd Step (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1817: SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1818Short in Passenger's Airbag Dual Stage - 2nd Step Circuit (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1818: SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1820Short in Side Airbag RHSide airbag harness RH circuit is shorted. Side airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1820: SHORT IN SIDE AIRBAG RH , Diagnostic Chart with Trouble Code. >
B1821Open in Side Airbag RHSide airbag harness RH circuit is open. Side airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1821: OPEN IN SIDE AIRBAG RH , Diagnostic Chart with Trouble Code. >
B1822Short in Side Airbag RH (To Ground)Side airbag harness RH circuit is shorted to ground. Side airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1822: SHORT IN SIDE AIRBAG RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1823Short in Side Airbag RH (To +B)Side airbag harness RH circuit is shorted to power supply. Side airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1823: SHORT IN SIDE AIRBAG RH (TO +B) , Diagnostic Chart with Trouble Code. >
B1825Short in Side Airbag LHSide airbag harness LH circuit is shorted. Side airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1825: SHORT IN SIDE AIRBAG LH , Diagnostic Chart with Trouble Code. >
B1826Open in Side Airbag LHSide airbag harness LH circuit is open. Side airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1826: OPEN IN SIDE AIRBAG LH , Diagnostic Chart with Trouble Code. >
B1827Short in Side Airbag LH (To Ground)Side airbag harness LH circuit is shorted to ground. Side airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1827: SHORT IN SIDE AIRBAG LH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1828Short in Side Airbag LH (To +B)Side airbag harness LH circuit is shorted to power supply. Side airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1828: SHORT IN SIDE AIRBAG LH (TO +B) , Diagnostic Chart with Trouble Code. >
B1830Short in Curtain Airbag RH Squib CircuitCurtain airbag harness RH circuit is shorted. Curtain airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1830: SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1831Open in Curtain Airbag RH Squib CircuitCurtain airbag harness RH circuit is open. Curtain airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1831: OPEN IN CURTAIN AIRBAG RH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1832Short in Curtain Airbag RH Squib Circuit (To Ground)Curtain airbag harness RH circuit is shorted to ground. Curtain airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1832: SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1833Short in Curtain Shield Airbag RH Squib Circuit (To +B)Curtain airbag harness RH is shorted to power supply. Curtain airbag module RH is faulty. Airbag control module is faulty.< Ref. to DTC B1833: SHORT IN CURTAIN SHIELD AIRBAG RH SQUIB CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1835Short in Curtain Airbag LH Squib CircuitCurtain airbag harness LH circuit is shorted. Curtain airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1835: SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1836Open in Curtain Airbag LH Squib CircuitCurtain airbag harness LH circuit is open. Curtain airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1836: OPEN IN CURTAIN AIRBAG LH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1837Short in Curtain Airbag LH Squib Circuit (To Ground)Curtain airbag harness LH circuit is shorted to ground. Curtain airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1837: SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1838Short in Curtain Shield Airbag LH Squib Circuit (To +B)Curtain airbag harness LH is shorted to power supply. Curtain airbag module LH is faulty. Airbag control module is faulty.< Ref. to DTC B1838: SHORT IN CURTAIN SHIELD AIRBAG LH SQUIB CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1860Short in Driver's Knee AirbagAirbag main harness circuit is shorted. Knee airbag module harness circuit is shorted. Knee airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1860: SHORT IN DRIVER'S KNEE AIRBAG , Diagnostic Chart with Trouble Code. >
B1861Open in Driver's Knee AirbagAirbag main harness circuit is open. Knee airbag module harness circuit is open. Knee airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1861: OPEN IN DRIVER'S KNEE AIRBAG , Diagnostic Chart with Trouble Code. >
B1862Short in Driver's Knee Airbag (To Ground)Airbag main harness circuit is shorted to ground. Knee airbag module harness circuit is shorted to ground. Knee airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1862: SHORT IN DRIVER'S KNEE AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1863Short in Driver's Knee Airbag(To +B)Airbag main harness circuit is shorted to power supply. Knee airbag module harness circuit is shorted to power supply. Knee airbag module is faulty. Airbag control module is faulty.< Ref. to DTC B1863: SHORT IN DRIVER'S KNEE AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1900Short in Front P/T RHSeat belt pretensioner RH circuit is shorted. Pretensioner RH is faulty. Pretensioner harness RH is shorted. Airbag control module is faulty.< Ref. to DTC B1900: SHORT IN FRONT P/T RH , Diagnostic Chart with Trouble Code. >
B1901Open in Front P/T RHSeat belt pretensioner RH circuit is open. Pretensioner RH is faulty. Pretensioner harness RH is shorted. Airbag control module is faulty.< Ref. to DTC B1901: OPEN IN FRONT P/T RH , Diagnostic Chart with Trouble Code. >
B1902Short in Front P/T RH (To Ground)Seat belt pretensioner RH circuit is shorted to ground. Pretensioner RH is faulty. Pretensioner harness RH is shorted. Airbag control module is faulty.< Ref. to DTC B1902: SHORT IN FRONT P/T RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1903Short in Front P/T RH (To +B)Seat belt pretensioner RH circuit is shorted to power supply. Pretensioner RH is faulty. Pretensioner harness RH is shorted. Airbag control module is faulty.< Ref. to DTC B1903: SHORT IN FRONT P/T RH (TO +B) , Diagnostic Chart with Trouble Code. >
B1905Short in Front P/T LHSeat belt pretensioner LH circuit is shorted. Pretensioner LH is faulty. Pretensioner harness LH is shorted. Airbag control module is faulty.< Ref. to DTC B1905: SHORT IN FRONT P/T LH , Diagnostic Chart with Trouble Code. >
B1906Open in Front P/T LHSeat belt pretensioner LH circuit is open. Pretensioner LH is faulty. Pretensioner harness LH is shorted. Airbag control module is faulty.< Ref. to DTC B1906: OPEN IN FRONT P/T LH , Diagnostic Chart with Trouble Code. >
B1907Short in Front P/T LH (To Ground)Seat belt pretensioner LH circuit is shorted to ground. Pretensioner LH is faulty. Pretensioner harness LH is shorted. Airbag control module is faulty.< Ref. to DTC B1907: SHORT IN FRONT P/T LH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1908Short in Front P/T LH (To +B)Seat belt pretensioner LH circuit is shorted to power supply. Pretensioner LH is faulty. Pretensioner harness LH is shorted. Airbag control module is faulty.< Ref. to DTC B1908: SHORT IN FRONT P/T LH (TO +B) , Diagnostic Chart with Trouble Code. >
B19F0Short in Front P/T 2 RHLap seat belt pretensioner RH circuit is shorted. Lap seat belt pretensioner RH is faulty. Lap seat belt pretensioner harness RH is shorted. Airbag control module is faulty.< Ref. to DTC B19F0: SHORT IN FRONT P/T 2 RH , Diagnostic Chart with Trouble Code. >
B19F1Open in Front P/T 2 RHLap seat belt pretensioner RH circuit is open. Lap seat belt pretensioner RH is faulty. Lap seat belt pretensioner harness RH is open. Airbag control module is faulty.< Ref. to DTC B19F1: OPEN IN FRONT P/T 2 RH , Diagnostic Chart with Trouble Code. >
B19F2Short in Front P/T 2 RH (To Ground)Lap seat belt pretensioner RH circuit is shorted to ground. Lap seat belt pretensioner RH is faulty. Lap seat belt pretensioner harness RH is shorted to ground. Airbag control module is faulty.< Ref. to DTC B19F2: SHORT IN FRONT P/T 2 RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B19F3Short in Front P/T 2 RH (To +B)Lap seat belt pretensioner RH circuit is shorted to power supply. Lap seat belt pretensioner RH is faulty. Lap seat belt pretensioner harness RH is shorted to power supply. Airbag control module is faulty.< Ref. to DTC B19F3: SHORT IN FRONT P/T 2 RH (TO +B) , Diagnostic Chart with Trouble Code. >

More articles — Airbag System (Diagnostics)
