CAUTION
- Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
- Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
- Connect the connectors securely during reassembly.
- After reassembly, make sure that the functional parts operate normally.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance and voltage. |
| TORX® T30 | Used for removal/installation of drivers airbag module |
GENERAL TOOL CHART
NOTE
For procedure of each component in the horn system, refer to the appropriate service information.
- Horn assembly: < Ref. to «HORN»(ref-465444-S38602667902012042000000) . >
- Horn switch: < Ref. to «HORN SWITCH»(ref-465444-S01314745832012042000000) . >
Scheme 5
- Disconnect the ground cable from battery.
- Remove the front bumper face. < Ref. to «FRONT BUMPER FACE»(ref-465406-S42885283712012042000000) , REMOVAL, Front Bumper. >
- Disconnect the harness connector.
- Remove the horn bracket mounting bolt to remove the horn assembly.
