REPLACEMENT
| CAUTION | Because the pressure sensor built into the H/U is easily damaged by static electricity, start the operation after performing static electricity measures. Be careful not to touch the sensors in the H/U to prevent damage. Because the seal of the VDCCM cannot be replaced, do not pull or peel it by lifting it up. Because the screw of the H/U will become slightly worn in every replacement procedure, 5 times is the maximum number of times for replacement. If a problem is found such as not being able to torque the screw to specifications even before 5 replacement operations are performed, replace the H/U body. When installing the VDCCM, always use new screws. When the sealing surface of the VDCCM or HI U is dirty or damaged and it cannot be cleaned or repaired, replace with a new part. |
Scheme 45
Scheme 46
Scheme 47
- Remove the VDCCM&H/U. < Ref. to «REMOVAL»(ref-465437-S09822615612012042000000) , VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >
- To prevent entry of foreign objects and brake fluid leakage, plug the oil pressure port of the VDCCM&H/U using a screw plug, etc.
- Set the pump motor section of the removed VDCCM&H/U face down on a vise. NOTE: Before securing a part on a vise, place cushioning material such as wood blocks, aluminum plate, or cloth between the part and the vise.
- Using TORX® bit E5, remove the four screws of VDCCM. NOTE: These screws cannot be reused.
- Slowly pull out the VDCCM upward from the H/U. NOTE: To prevent damaging of coil section, remove the VDCCM straight up from H/U without twisting.
- Make sure there is no dirt or damage on the sealing surface of the H/U. CAUTION: Do not clean the VDCCM&H/U by applying compressed air. Even if damage is found on the H/U seal, do not attempt repair by filing or with a metal scraper. To remove the seal residue, always use a plastic scraper. Do not use chemical such as paint thinner, etc, to clean.
- Position the coil of the new VDCCM to align with the H/U valve.
- To prevent deformation of the VDCCM housing cover, hold the corner of VDCCM and install it to the H/U without tilting.
- Using a TORX® bit E5, attach/tighten new screws in the order of (1) through (4). CAUTION: Always use new screws. Tightening torque: 1.5 N.m (0.15 kgf-m, 1.1 ft-lb)
- Check that there is no foreign matter in mating surface between the VDCCM&H/U.
- Using a TORX® bit E5, tighten the screws in the order of (1) through (4) again. Tightening torque: 3 N.m (0.31 kgf-m, 2.2 ft-lb)
- Check that there is no gap in the mating surface between VDCCM&H/U.
- Install the VDCCM&H/U to the vehicle.
- Bleed air from the brake system. < Ref. to «PROCEDURE»(ref-465400-S28290080402012042000000) , Air Bleeding. >
- Perform the selection. registration operation of parameter. < Ref. to «PARAMETER SELECTION»(ref-465420-S32718710582012042000000) , OPERATION, Subaru Select Monitor. > NOTE: After replacing the VDCCM, be sure to perform the selection registration operation of parameter. For the selection and registration of parameter, the Subaru Select Monitor is required. When the registration has not been performed, the DTC code "Parameter selection error" is detected together with the ABS/EBD/VDC warning light illumination.
- Check the parameter to confirm that the applied models and grades of the relevant vehicle are included. < Ref. to «PARAMETER CHECK»(ref-465420-S39279974242012042000000) , OPERATION, Subaru Select Monitor. >
- If the applied models and grades of the relevant vehicle are not included, perform the selection. registration operation of parameter with the {Confirm on parameter} screen again. < Ref. to «PARAMETER SELECTION»(ref-465420-S32718710582012042000000) , OPERATION, Subaru Select Monitor. >
- Execute Clear Memory after parameter selection and registration operations because the DTC for "Parameter selection error" is memorized.
INSTALLATION
| CAUTION | After completion of installation, set the following two positions. Positioning to the center of steering angle sensor Positioning the yaw rate & G sensors to zero The above procedure is required VDCCM&H/U to identify the vehicle position afterward. For the setting procedures of the 2 steps above, refer to "VDC Control Module and Hydraulic Control Unit (VDCCM&H/U)". < Ref. to ADJUSTMENT , VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). > |
Install each part in the reverse order of removal.
Tightening torque
7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
| CAUTION | Do not perform the removal except unless replacing. When replacing three times or more, replace by using the combination switch assembly to protect the threads. |
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
- Set the steering wheel in a straight-ahead position.
- Disconnect the ground cable from battery.
- Remove the driver's airbag module. < Ref. to «REMOVAL»(ref-465432-S02801909522012042000000) , Driver's Airbag Module. > CAUTION: Before handling the airbag module, refer to "CAUTION" of "General Description" in "AIR-BAG SYSTEM". < Ref. to «CAUTION»(ref-465432-S09321667812012042000000) , General Description. >
- Remove the steering wheel. < Ref. to «REMOVAL»(ref-465415-S03651163672012042000000) , Steering Wheel. >
- Remove the screws and remove the steering column lower cover.
- Remove the harness cover lock.
- Remove the screws and detach the knee protector.
- Remove the screws and remove the steering column cover upper.
- Disconnect the connector of roll connector and steering angle sensor.
- Remove the screws which secure the roll connector to steering column.
- Remove the vinyl tape binding the harness, and remove the steering angle sensor from roll connector.
- Turn the protrusion portion of new steering angle sensor to match the alignment mark of inspection hole. CAUTION: Be careful not to allow foreign matter to enter into inspection hole.
- Align the center of roll connector. < Ref. to «INSTALLATION»(ref-465432-S39548604432012042000000) , Roll Connector. >
- Apply the grease provided with the new part on the 4 locations of the protrusion on the steering angle sensor.
- Align the position of the protrusion and install roll connector to steering angle sensor. Tightening torque: 0.5 N.m (0.05 kgf-m, 0.36 ft-lb)
- Install the roll connector to combination switch and bind the harness with vinyl tape as originally bound.
- Install the steering wheel. < Ref. to «INSTALLATION»(ref-465415-S26331939102012042000000) , Steering Wheel. > Tightening torque: 39 N.m (3.98 kgf-m, 28.8 ft-lb)
- Install the airbag module to the steering wheel. < Ref. to «INSTALLATION»(ref-465432-S29943611812012042000000) , Driver's Airbag Module. > CAUTION: Before handling the airbag module, refer to "CAUTION" in "AIR-BAG SYSTEM". < Ref. to «CAUTION»(ref-465432-S09321667812012042000000) , General Description. >
- Connect the ground cable to battery. CAUTION: After completion of installation, adjust the following two positions. Positioning to the center of steering angle sensor Positioning the yaw rate & G sensors to zero The above procedure is required for the VDC-CM to identify vehicle position afterward. For the setting procedures of the 2 steps above, refer to "VDC Control Module and Hydraulic Control Unit (VDCCM&H/U)". < Ref. to «ADJUSTMENT»(ref-465437-S42416539772012042000000) , VDC Control Module and Hydraulic Control Unit (VDCCM&H/U). >
Scheme 57
Scheme 58
- Disconnect the ground cable from battery.
- Disconnect the ABS wheel speed sensor connector located next to the front strut mounting house in the engine compartment.
- Remove the bolts and then remove the sensor harness bracket.
- Remove the bolts which secure the sensor harness to the front strut.
- Remove the bolts, and remove the front ABS wheel speed sensor from the front housing. CAUTION: Be careful not to damage the sensor. Do not apply excessive force to the sensor harness.
| CAUTION | Be careful not to damage the sensor. |
Install each part in the reverse order of removal.
Tightening torque
Sensor
7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Bracket
33 N.m (3.36 kgf-m, 24.3 ft-lb)
Note. Check the identification (mark) on the harness to make sure there is no warpage. (RH: K1 (White), LH: K2 (Yellow)) Check if the harness is not pulled and does not come in contact with the suspension or body during steering wheel effort.
| CAUTION | Be careful not to damage the sensor. |
Install each part in the reverse order of removal.
Tightening torque
Sensor
7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Bracket
7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
Note. Check the identification (mark) on the harness to make sure there is no warpage. (RH: P3 (Aqua), LH: P4 (Brown))
REMOVAL
Refer to "Front Hub Bearing" for removal, because the front magnetic encoder is integrated with front hub bearing. < Ref. to REMOVAL , Front Hub Unit Bearing. >
Refer to "Front Hub Bearing" for installation, because the front magnetic encoder is integrated with front hub bearing. < Ref. to INSTALLATION , Front Hub Unit Bearing. >
Refer to "Rear Hub Unit Bearing" for removal, because the rear magnetic encoder is integrated with rear hub unit bearing. < Ref. to REMOVAL , Rear Hub Unit Bearing. >
Refer to "Rear Hub Unit Bearing" for installation, because the rear magnetic encoder is integrated with rear hub unit bearing. < Ref. to INSTALLATION , Rear Hub Unit Bearing. >
Install each part in the reverse order of removal.
