WITH SUBARU SELECT MONITOR
| CAUTION | Subaru Select Monitor is required for reading DTC, performing diagnosis and reading current data. Remove foreign matter (dust, water, oil, etc.) from the body integrated unit connector during removal and installation. For model with immobilizer, registration of immobilizer may be needed after the replacement of controller etc. For detailed procedure, refer to the REGISTRATION MANUAL FOR IMMOBILIZER. |
Note. To check harness for open or short circuits, shake the suspected trouble spot or connector. Check List for Interview Refer to CHECK LIST FOR INTERVIEW .
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK PRE-INSPECTION . Ask the customer when and how the trouble occurred using the interview check list. Refer to CHECK LIST FOR INTERVIEW . | Did you interview the customer? | Go to step 2 . | Interview the customer. |
| 2 BASIC INSPECTION . Check the components which might affect body control. Refer to INSPECTION , General Description . | Is the component that might influence the body control problem normal? | Go to step 3 . | Repair or replace each component. |
| 3 CHECK DTC . Read the DTC. Refer to READ DIAGNOSTIC TROUBLE CODE (DTC) . NOTE: If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . Record all DTCs and freeze frame data. | Is DTC displayed on the Subaru Select Monitor? | Go to step 5 . | Go to step 4 . |
| 4 PERFORM GENERAL DIAGNOSTICS . Inspect using "General Diagnostics Table". Refer to GENERAL DIAGNOSTIC TABLE . | Is result of inspection OK? | LAN system is normal. | Go to step 5 . |
| 5 PERFORM DIAGNOSIS . Correct the cause of trouble. Perform the Clear Memory Mode. Refer to CLEAR MEMORY MODE . Read the DTC. Refer to READ DIAGNOSTIC TROUBLE CODE (DTC) . | Is DTC displayed on the Subaru Select Monitor? | Repeat step 5 until DTC is not shown. | Finish the diagnosis. |
| NOTE |
|---|
| If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
DIAGNOSIS PROCEDURE CHART
CHECK
Inspect the following item about the vehicle's state.
Scheme 22
Scheme 23
Scheme 24
SUPPLEMENTAL RESTRAINT SYSTEM "AIRBAG"
Airbag system wiring harness is routed near the body integrated unit and twisted pair line.
| CAUTION | Do not use electric test equipment on any wiring harnesses and connectors in the airbag system. Be careful not to damage the airbag system wiring harness when servicing the body integrated unit and LAN system. |
Scheme 25
Scheme 26
- Bus line of LAN system is twisted pair line. Be careful not to bypass or partly unbind the twisted pair line.
- Do not make clearance between bus lines (CAN High, CAN Low).
- Difference of bus line length should be within 10 cm (3.94 in).
- Fray near the connector should be within 8 cm (3.14 in).
- If the characteristics of the twisted pair line are changed, it may extremely weaken against noise.
- When repairing the harness, connect the wires using soldering and protect it with insulating tape etc.
GENERAL TOOL
| TOOL NAME | REMARKS |
|---|---|
| Circuit tester | Used for measuring resistance, voltage and current. |
GENERAL TOOL DESCRIPTION CHART
Scheme 27
Scheme 28
Scheme 29
| Contents | Terminal No. | Standard value | Measuring conditions |
|---|---|---|---|
| BAT (control) | B6 <--> chassis ground | 10 - 14V | Always |
| BAT (backup) | C2 <--> chassis ground | 10 - 14V | Always |
| BAT (door lock) | A34 <--> chassis ground | 10 - 14V | Always |
| BAT (shift lock/key lock) | D22 <--> chassis ground | 10 - 14V | Always |
| ACC (rear wiper) | D21 <--> chassis ground | 10 - 15V | When ACC is ON |
| Ground | A28 <--> chassis ground | Less than 1.5 V | Always |
| Ground | B17 <--> chassis ground | Less than 1.5 V | Always |
| Ground | C20 <--> chassis ground | Less than 1.5 V | Always |
| Ground | D27 <--> chassis ground | Less than 1.5 V | Always |
| Key warning switch | D2 <--> chassis ground | Less than 1.5 V --> 10 - 15V | With key removed --> inserted |
| ACC | B7 <--> chassis ground | Less than 1.5 V --> 10 - 15V | IGN OFF --> ACC ON |
| IGN | B1 <--> chassis ground | Less than 1.5 V --> 10 - 15V | IGN OFF --> IGN ON |
| P range switch | C4 <--> chassis ground | Less than 1.5 V --> 8 V or more | P range --> other than P range |
| Stop light switch | B2 <--> chassis ground | Less than 1.5 V --> 8 V or more | With brake pedal released --> depressed |
| Door switch, driver's seat | A19 <--> chassis ground | 8 V or more --> less than 1.5 V | With driver's door closed --> opened |
| Door switch, passenger's seat | A32 <--> chassis ground | 8 V or more --> less than 1.5 V | With passenger's door closed --> opened |
| Door switch, rear RH seat | A6 <--> chassis ground | 8 V or more --> less than 1.5 V | With rear RH seat door closed --> opened |
| Door switch, rear LH seat | A20 <--> chassis ground | 8 V or more --> less than 1.5 V | With rear LH seat door closed --> opened |
| Door switch, trunk/rear gate | A33 <--> chassis ground | 8 V or more --> less than 1.5 V | With trunk/rear gate closed --> opened |
| Rear gate opener button | C24 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (LOCK) | A15 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Manual switch (UNLOCK) | A29 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Delivery (test) mode connector | A17 <--> chassis ground | 8 V or more --> less than 1.5 V | When delivery (test) mode connector is connected |
| Front wiper input RTN | C5 <--> chassis ground | 8 V or more --> less than 1.5 V | When front wiper is reversed |
| Rear wiper switch ON | C18 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch (INT) | C27 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Rear wiper switch, washer | C28 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting 1 switch | B11 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Lighting II switch | C8 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| D6 <--> chassis ground | 8 V or more --> less than 1.5 V | Key warning switch ON and lighting switch OFF --> ON | |
| Dimmer switch, Hi beam | B12 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Dimmer switch, passing | B22 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Front fog light switch | B24 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| TPMS answer-back request input | B13 <--> chassis ground | 8 V or more --> less than 1.5 V | When TPMS transmitter registration answer-back is output |
| MT reverse switch | B18 <--> chassis ground | 8 V or more --> less than 1.5 V | Other than reverse --> reverse |
| Parking brake switch | C15 <--> chassis ground | 8 V or more --> less than 1.5 V | With parking brake not operated --> operated |
| Bright switch | A14 <--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF --> ON |
| Illumination (Vi1) | A12 <--> chassis ground | Approx. 5 V | While clearance light illuminates |
| Illumination (Vi2) | A3 <--> chassis ground | 0.5 V - 4.5 V | While clearance light illuminates |
| Illumination (Vi3) | A26 <--> chassis ground | Less than 1.5 V | Always |
| Fuel level sensor | C7 <--> chassis ground | Approx. 2 - 96 ohms | Ignition ON |
| Wiper deicer & rear defogger switch | A16<--> chassis ground | 8 V or more --> less than 1.5 V | Switch OFF--> ON |
| Seat belt switch (driver's seat) | C16<--> chassis ground | Less than 1.5 V --> 8 V or more | With seat belt unbuckled --> buckled |
| Impact sensor | B8 <--> chassis ground | Less than 1.5 V 8 V or more --> 8 V or more | When impact is applied |
| Key lock solenoid output | D11 <--> chassis ground | Less than 1.5 V --> 6 V or more | While key is inserted in other than P range |
| Shift lock solenoid output | D12 <--> chassis ground | Less than 1.5 V --> 10 V or more | When vehicle stopped, IGN ON, other than P range, brake pedal depressed |
| Rear wiper output ON | D9 <--> chassis ground | Less than 1.5 V --> 10 V or more | When rear wiper operates |
| Rear wiper output RTN | D8 <--> chassis ground | Less than 1.5 V --> 10 V or more | When rear wiper reversed |
| Door lock output | A7 <--> A8 | Less than 1.5 V --> 10 V or more | While lock output |
| Door unlock output | A8 <--> A7 | Less than 1.5 V --> 10 V or more | While unlock output |
| Driver's door unlock output | A23 <--> chassis ground | Less than 1.5 V --> 10 V or more | While unlock output |
| Trunk/rear gate UNLOCK output | A22 <--> chassis ground | Less than 1.5 V --> 10 V or more | Sedan: While trunk UNLOCK output Wagon: While rear gate UNLOCK output |
| Lighting power supply | C1 <--> chassis ground | Less than 1.5 V --> 10 V or more | With back-up fuse inserted, ACC ON or IGN ON |
| D1 <--> chassis ground | Less than 1.5 V --> 10 V or more | When key warning switch is ON | |
| Clearance light relay output | D19 <--> chassis ground | 8 V or more --> less than 1.5 V | Small light ON |
| Lo beam relay output | C3 <--> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON |
| D7 <--> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON | |
| Hi beam relay output | D20 <--> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON and Hi beam ON Passing switch ON |
| Front fog light relay output | D17 <--> chassis ground | 8 V or more --> less than 1.5 V | Headlight switch ON, and front fog light switch ON |
| DRL cancel output | D18 <--> chassis ground | 8 V or more --> less than 1.5 V | When Hi beam 100 % illuminates |
| Room light output | D5 | Pulse control | Illumination is adjusted through PWM control |
| Key ring illumination output | C23 | Pulse control | Illumination is adjusted through PWM control |
| Illumination output | A2 | Pulse control | Illumination is adjusted through PWM control |
| Foot light output | D4 <--> chassis ground | Pulse control | Illumination is adjusted through PWM control |
| Seat belt warning light (passenger's seat) | A25 <--> chassis ground | 8 V or more --> less than 1.5 V | Indicator go off --> illuminate |
| Answer-back buzzer output | D24 <--> chassis ground | Less than 1.5 V --> 10 V or more | When LOCK/UNLOCK is operated with keyless entry |
| Rear defogger relay output | D16 <--> chassis ground | 8 V or more --> less than 1.5 V | While rear defogger output |
| Wiper deicer relay output | D15 <--> chassis ground | 8 V or more --> less than 1.5 V | While wiper deicer output |
| Seat belt warning light (passenger's seat) | A25 <--> chassis ground | 8 V or more --> less than 1.5 V | Indicator go off --> illuminate |
| Answer-back buzzer output | D24 <--> chassis ground | Can not be measured because of high speed ON/OFF | Door lock --> unlock with keyless entry system |
| Turn & hazard output | C22 <--> chassis ground | 8 V or more --> less than 1.5 V | Door lock or unlock with keyless entry system |
| Horn relay output | D29 <--> chassis ground | 8 V or more --> less than 1.5 V | While security alarm operates |
| Security indicator output | A10 <--> chassis ground | 8 V or more --> less than 1.5 V | While indicator in combination meter blinks |
| Immobilizer antenna 1 | B26 <--> B25 | 30 - +30 V | While key secret code is verified |
| Immobilizer antenna 2 | B25 <--> B26 | ||
| Immobilizer communication_1 | B4 | Can not be measured because of digital communication | Serial communication line |
| Immobilizer communication_2 | B15 | Can not be measured because of digital communication | Serial communication line |
| Keyless entry control module communication | A24 | Can not be measured because of digital communication | Serial communication line |
| SSM communication (K line) | B20 | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Hi | A1 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Body system CAN_Lo | A9 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN-Hi | B3 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
| Driving system CAN_Lo | B9 <--> chassis ground | Can not be measured because of digital communication | Serial communication line |
CONNECTOR TERMINALS REFERENCE CHART
LIST
| Items to be displayed | Unit of measure | Remarks | Note |
|---|---|---|---|
| BATT voltage (control) | 10 - 15V | Body integrated unit input value | Always |
| BATT voltage (BACKUP) | 10 - 15V | Body integrated unit input value | Always |
| IG Power Supply Voltage | 10 - 15V | Body integrated unit input value | Ignition switch ON |
| ACC voltage | 10 - 15V | Body integrated unit input value | Ignition switch ACC |
| Illumination VR Voltage | 0 - 5V | Body integrated unit output value | Input value from illumination volume |
| Illumi. output d-ratio | 0 - 100% | Body integrated unit input value | Small light ON Illumination volume is other than bright. |
| Ambient Temperature | 40 - 87.5°C | Body integrated unit output value | Ignition switch ON |
| Fuel level voltage | 0 - 10V | Body integrated unit input value | Ignition switch ON |
| Fuel level resistance | 0 - 102.3 ohms | Body integrated unit input value | Ignition switch ON |
| Key-lock solenoid V | 6 - 15V | Body integrated unit output value | Key warning switch ON, other than parking range Ignition ON |
| Number of regist. | 0 - 4 | Number of keyless key registered | Number of transmitter registered is displayed |
| Front Wheel Speed | Km/h | CAN data input value | Reception from VDC unit |
| VDC/ABS latest f-code | DTC display (Temporarily) | CAN data input value | It is normal when DTC is not been input even if this code is displayed. Received from VDC (displayed by hexadecimal number system) |
| Blower Fan Steps | 0 - 2 levels | CAN data input value | 0: OFF, 1: Low, 2:2 levels or more Reception from air conditioner ECM |
| Fuel level resistance 2 | 0 - 102.3 ohms | CAN data output value | Reception from body integrated unit |
| Fuel consumption | Cc/s | CAN data input value | Reception from ECM and transmission to center monitor |
| Coolant Temp. | 40 - 130°C | CAN data input value | Reception from ECM |
| Vehicle lateral G | M/s 2 | CAN data input value | Reception from VDC unit |
| SPORT Shift Stages | 0 - 7 levels | CAN data input value | (0: Light OFF; 1 - 5: Gear display; 6: Fail; 7: ATF temperature High/Low) Reception from TCM |
| Shift Position | 0 - 7 levels | CAN data input value | 0:1; 1: 2; 2: 3; 3: 4; 4: D, 5: N; 6: R; 7: P shift position (There is no 8 input). 8 is displayed in manual mode Reception from TCM |
| VDC/ABS condition | 0 - 4 | CAN data input value | |
| Destination Code | 0 - 16 | CAN data input value | |
| Touch SW | 0 - 64 | CAN data input value | |
| Key-lock warning SW | ON/OFF | Body integrated unit input value | ON when ignition key is inserted |
| Stop Light Switch | ON/OFF | Body integrated unit input value | ON when brake pedal is depressed |
| Front fog lamp SW input | ON/OFF | Body integrated unit input value | When front fog light switch is ON |
| TPMS input | ON/OFF | Body integrated unit input value | Registration done signal |
| Door key-lock SW input | ON/OFF | Body integrated unit input value | Not supported |
| Door unlock SW input | ON/OFF | Body integrated unit input value | Not supported |
| Driver's door SW input | ON/OFF | Body integrated unit input value | ON when driver's door is open |
| P-door SW input | ON/OFF | Body integrated unit input value | ON when passenger's door is open |
| Rear right door SW input | ON/OFF | Body integrated unit input value | ON when rear right door is open |
| Rear left door SW input | ON/OFF | Body integrated unit input value | ON when rear left door is open |
| R Gate SW input | ON/OFF | Body integrated unit input value | ON when trunk/rear gate is open |
| Manual lock SW input | ON/OFF | Body integrated unit input value | Manual lock switch ON |
| Manual unlock SW input | ON/OFF | Body integrated unit input value | Manual unlock switch ON |
| Lock SW | ON/OFF | Body integrated unit input value | Not supported |
| Bright SW input | ON/OFF | Body integrated unit input value | ON when bright switch is ON |
| PSW | ON/OFF | Body integrated unit input value | ON when shift range is in parking Shift lever P SW signal |
| MT Reverse Switch | ON/OFF | Body integrated unit input value | Shift lever is at reverse position |
| R wiper ON SW input | ON/OFF | Body integrated unit input value | Rear wiper switch ON |
| R wiper INT SW input | ON/OFF | Body integrated unit input value | Rear wiper switch INT ON |
| R washer SW input | ON/OFF | Body integrated unit input value | Rear washer switch ON |
| Wiper deicer SW input | ON/OFF | Body integrated unit input value | Wiper deicer switch ON |
| Rear Defogger SW | ON/OFF | Body integrated unit input value | Rear defogger switch ON (only manual A/C) |
| Driver's Seat SW input | ON/OFF | Body integrated unit input value | Driver's seat buckle switch ON |
| P seatbelt SW input | ON/OFF | Body integrated unit input value | With passenger's seat occupied and buckle switch ON |
| Fr wiper input | ON/OFF | Body integrated unit input value | ON when front wiper is operating |
| Parking Brake Switch Input | ON/OFF | Body integrated unit input value | When parking brake locked |
| Registration SW input | ON/OFF | Body integrated unit input value | When keyless registration connector is connected |
| Identification SW input | ON/OFF | Body integrated unit input value | ON with wagon |
| Driver's seat lock status SW input | ON/OFF | Body integrated unit input value | ON with door locked condition |
| Passenger's seat lock status SW input | ON/OFF | Body integrated unit input value | ON with door locked condition |
| R gate lock status SW input | ON/OFF | Body integrated unit input value | ON with door locked condition |
| R Gate Release SW input | ON/OFF | Body integrated unit input value | When rear gate opener button is ON |
| Rr defogger output | ON/OFF | Body integrated unit output value | ON when rear defogger relay is operating |
| Lock actuat. LOCK output | ON/OFF | Body integrated unit output value | ON when lock signal is output |
| All seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| D-seat UNLOCK output | ON/OFF | Body integrated unit output value | ON when unlock signal is output |
| R gate/trunk UNLK output | ON/OFF | Body integrated unit output value | ON when rear gate/trunk unlock signal is output |
| R wiper output | ON/OFF | Body integrated unit output value | ON when rear wiper motor is operating |
| Shift Lock Solenoid | ON/OFF | Body integrated unit output value | ON when shift lock solenoid is ON (only AT) |
| Key locking output | ON/OFF | Body integrated unit output value | With ignition switch ON and in other than the shift P range, with key in switch ON |
| Wiper deicer output | ON/OFF | Body integrated unit output value | ON when wiper deicer relay is operating |
| Hazard Output | ON/OFF | Body integrated unit output value | ON when answer-back signal is received or when hazard is operating |
| Keyless Buzzer Output | ON/OFF | Body integrated unit output value | ON when lock/unlock signal is received |
| Horn Output | ON/OFF | Body integrated unit output value | ON when security warning is operating |
| P-belt warning light O/P | ON/OFF | Body integrated unit output value | ON when Ignition switch is turned to ON, occupant is seated, and buckle switch is turned off |
| Illumination lamp O/P | ON/OFF | Body integrated unit output value | ON when illumination is illuminated |
| Room lamp output | ON/OFF | Body integrated unit output value | ON when keyless lock/unlock signal is received (when keyless switch connector is removed) |
| Key illumi. lamp o/p | ON/OFF | Body integrated unit output value | ON when key illumination light is illuminated |
| Immobilizer lamp output | ON/OFF | Body integrated unit output value | ON when immobilizer pilot light blinks |
| CC Main Lamp | ON/OFF | CAN data input value | Cruise control switch ON Reception from ECM and transmission to combination meter |
| CC Set Lamp | ON/OFF | CAN data input value | ON when cruise control vehicle speed is set Reception from ECM and transmission to combination meter |
| SPORT Lamp | ON/OFF | CAN data input value | SPORT mode switch ON Reception from TCM and transmission to combination meter (only AT) |
| SPORT Blink | Blink/OFF | CAN data input value | Blinks when there is an AT failure Reception from TCM and transmission to combination meter (only AT) |
| ATF Temperature Lamp | ON/OFF | CAN data input value | When ATF temperature rise (only AT) |
| ATF Blink | Blink/OFF | CAN data input value | Blinks when there is an AT failure Reception from TCM and transmission to combination meter (only AT) |
| Tire diameter abnormal 1 | ON/OFF | CAN data input value | Lit when FWD fuse is connected (4AT only) |
| Tire diameter abnormal 2 | Blink/OFF | CAN data input value | Blinks when the difference in rotation between front and rear wheels is 4% or more Reception from TCM and transmission to combination meter (only AT) |
| Shift Up Indication | UP/OFF | Body integrated unit input value | ON when shift lever can be operated up (only AT) |
| Shift Down Indication | DOWN/OFF | Body integrated unit input value | ON when shift lever can be operated down (only AT) |
| SPORT Shift (buzzer 1) | ON/OFF | CAN data input value | ON while the shift change prohibited warning buzzer is operating Reception from TCM and transmission to combination meter (only AT) |
| SPORT Shift (buzzer 2) | ON/OFF | CAN data input value | ON when the ATF high temperature warning buzzer is operating Reception from TCM and transmission to combination meter (only AT) |
| ABS/VDC Judging | ABS/VDC | CAN data input value | Transmission from vehicle dynamic control (VDC) to high speed control module |
| Lh Turn | ON/OFF | CAN data input value | Not supported |
| Rh Turn | ON/OFF | CAN data input value | Not supported |
| Rr Defogger SW | ON/OFF | CAN data input value | Rear defogger switch ON From A/C ECM |
| Australia Judging Flag | Australia/Others | Body integrated unit output value | North American specifications have others |
| Large Diameter Tire | Large Tire/Others | Body integrated unit output value | Large Tire when standard tire is 18 in. Reception from combination meter |
| Number of cylinders | 4 cylinders/6 cylinders | CAN data input value | Display engine equipped |
| Cam shaft specification | SOHC/DOHC | CAN data input value | Display engine equipped |
| Turbo | TURBO/Non-turbo | CAN data input value | Display engine equipped |
| E/G displacement (2.5 L) | 2.5 L7 OFF | CAN data input value | Display engine equipped |
| E/G displacement (3.0 L) | 3.0 L/OFF | CAN data input value | Display engine equipped |
| AT Vehicle ID Signal | AT model / MT model | CAN data input value | Display transmission equipped |
| Blower fan information | ON/OFF | CAN data input value | ON when blower fan is operating (always OFF for auto A/C equipped models) |
| Door lock SW (Open) | ON/OFF | CAN data input value | |
| Door lock SW (Close) | ON/OFF | CAN data input value | |
| Door Key SW (Open) | ON/OFF | CAN data input value | |
| Door Key SW (Close) | ON/OFF | CAN data input value | |
| Under hook registration | ON/OFF | CAN data input value | |
| Hook registration end | ON/OFF | CAN data input value | |
| Unlock request | ON/OFF | CAN data input value | |
| Center display failure | OK/NG | CAN data input value | NG when there is a center display failure Reception from center display (NAVI monitor) |
| NAVI Failure | OK/NG | CAN data input value | NG when there is a navigation system failure Reception from Center Display |
| IE Bus failure | Can not use | CAN data input value | Reception from Center Display |
| Auto A/C failure | OK/NG | CAN data input value | NG when there is a failure in auto air conditioning system Reception from auto A/C module |
| EBD Warning Light | OK/OFF | CAN data input value | OK when EBD warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| ABS Warning Light | OK/OFF | CAN data input value | OK when ABS warning light is illuminated Reception from VDC/ABS and transmission to combination meter |
| VDC OFF flag | ON/OFF | CAN data input value | Vehicle dynamics control OFF SW is ON Reception from VDC/ABS and transmission to combination meter |
| VDC/ABS OK B | OK/NG | CAN data input value | NG when there is an error in VDC/ABS system Reception from VDC/ABS |
| Lighting 1 Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch, illumination is ON |
| Lighting II Switch Input | ON/OFF | Body integrated unit input value | ON when lighting switch, headlight is ON |
| Dimmer Hi Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is Hi beam position |
| Dimmer Pass Switch Input | ON/OFF | Body integrated unit input value | ON when dimmer switch is passing position |
| Lighting 1 Lamp Output | ON/OFF | Body integrated unit output value | ON when small light is illuminated |
| Lighting II Lamp Output | ON/OFF | Body integrated unit output value | ON when headlight is illuminated |
| Lighting Hi Lamp Output | ON/OFF | Body integrated unit output value | ON when Hi beam is illuminated |
| Front Fog Lamp Output | ON/OFF | Body integrated unit output value | ON when Front fog light is ON. |
| DRL Cancel Output | ON/OFF | Body integrated unit output value | When lighting switch is "Head" or dimmer & passing switch is "passing", parking switch is ON, ignition switch is "ACC", engine speed is 500 RPM or less |
| Power Supply Tr | ON/OFF | Body integrated unit output value | ON when lighting switch is "Head" position without inserting key in key cylinder |
| Foot Lamp Output | ON/OFF | Body integrated unit output value | ON when foot light RH, foot light LH is illuminated |
| Front Fog Lamp Output | ON/OFF | Body integrated unit output value | When fog light illuminates |
| Lighting 1 Switch Input | ON/OFF | Body integrated unit input value | ON when small light is illuminated |
| Lighting II Switch Input | ON/OFF | Body integrated unit input value | When headlight LO is ON |
| Dimmer Hi Switch Input | ON/OFF | Body integrated unit input value | When headlight HI is ON |
| Dimmer Pass Switch Input | ON/OFF | Body integrated unit input value | When headlight Pass is ON |
| Lighting 1 Lamp Output | ON/OFF | Body integrated unit output value | ON when tail & illumination relay is operated |
| Lighting II Lamp Output | ON/OFF | Body integrated unit output value | ON when headlight Lo relay is operated |
| Lighting Hi Lamp Output | ON/OFF | Body integrated unit output value | ON when headlight Hi relay is operated |
| Power Supply Tr | ON/OFF | Body integrated unit output value | Headlight auxiliary power supply ON |
| Foot Lamp Output | ON/OFF | Body integrated unit output value | ON when foot light is illuminated |
| Rr defogger op. mode | Continuous/Normal | Body integrated unit setting items | Customize setting |
| Wiper deicer op. mode | Continuous/Normal | Body integrated unit setting items | Customize setting |
| Security Alarm Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact Sensor Setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Alarm delay setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Lockout prevention | ON/OFF | Body integrated unit setting items | Customize setting |
| Impact sensor | ON/OFF | Body integrated unit setting items | Customize setting |
| Hazard answer-back setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Automatic locking setup | ON/OFF | Body integrated unit setting items | Customize setting |
| Auto locking | ON/OFF | Body integrated unit setting items | Customize setting |
| Door open warning | ON/OFF | Body integrated unit setting items | Customize setting |
| Dome Light Alarm Setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Belt Warning Switch | ON/OFF | Body integrated unit setting items | Customize setting |
| A/C ECM setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Wiper deicer | ON/OFF | Body integrated unit setting items | Customize setting |
| Rear fog light setting | ON/OFF | Body integrated unit setting items | Customize setting |
| Illumination Control On/Off | ON/OFF | Body integrated unit setting items | Customize setting |
| Sedan/Wagon Setting | Sedan/wagon | Body integrated unit setting items | Customize setting |
| MT/AT Setting | MT/AT | Body integrated unit setting items | Customize setting |
| 6MT Setting | 6MT/Other than 6MT | Body integrated unit setting items | Customize setting |
| Destination Setting | 0 - 16 | Body integrated unit setting items | |
| Factory or Market setting | Factory/Market | Body integrated unit setting items | Customize setting |
DISPLAY SCREEN DATA REFERENCE CHART
Note. For details concerning the operation procedure, refer to the PC application help for Subaru Select Monitor.
CONFIRMATION OF CURRENT SETTING
- On the «Main Menu» display screen, select {Each System Check}.
- On the «System Selection Menu» display screen, select the {Integ. unit mode}.
- On the «Integ. unit mode failure diag» display screen, select the {Current Data Display & Save}.
- Using the scroll key, scroll the display screen up or down until the desired data is shown.
- Display the following item and record the settings. Required items for new registration (Except for system not equipped) CURRENT SETTING REFERENCE CHART Contents Item to confirm Remarks Key No. to register 1 2 3 4 Registered ID type Off delay OFF Long Normal Short Setting for lighting off time Auto lock 60, 50, 40, 30, 20 OFF (Unit: seconds) Rr defogger op. mode Normal Continuous Wiper deicer op. mode Normal Continuous Option setting Security Alarm Setup ON OFF Impact Sensor Setup ON OFF Option setting Alarm delay setup ON OFF Lockout prevention ON OFF Impact sensor support no support Option setting Answer-back buzzer setup ON OFF Hazard answer-back setup ON OFF Automatic locking setup ON OFF Ans.-back Buzzer support no support Auto locking support no support Initial button setting Execution - Initial Security setting Execution - Select unlock switch Selection ALL Passive Alarm ON OFF Door open warning (prevention of battery run-out) support no support Dome Light Alarm Setting ON OFF Belt Warning Switch ON OFF Switch the belt warning lighting and the buzzer sound. A/C ECM setting support no support Model with auto A/C Wiper deicer support no support Option setting Rear fog light setting support no support Not supported Illumination Control On/Off support no support Not supported Sedan/Wagon Setting Sedan Wagon MT/AT Setting AT MT 6MT Setting 6MT Other than 6MT Destination Setting Factory or Market setting Factory Market Do not change to factory mode.
REGISTRATION BODY INTEGRATED UNIT (EQUIPMENT SETTING)
| CAUTION | Body integrated unit is core of LAN system, and also can select the function of all vehicle system control. It is possible to control the original functions of vehicle when registrations of body integrated unit and function setting are corresponded to vehicle equipment. If registrations and function setting are different from vehicle equipment, vehicle system does not operate normally and diagnosis cannot be performed correctly. Pay attention to following item. Be sure to correspond registrations and function settings to vehicle equipment. Do not change the settings of vehicle improperly. Confirm key illumination does not blink or "Factory or Market setting" of body integrated unit registrations is "Market". If "Factory or Market setting" is set to "Factory," key illumination blinks when ignition key is turned ON, to notify that the settings are unconfirmed. Key illumination does not blink with ignition switch turned to ON and go off with door closed. Be sure to register immobilizer if body integrated unit is replaced with a new part, (models with immobilizer) Make a registration of immobilizer when the parts related to immobilizer have been replaced. Refer to the PC application help for Subaru Select Monitor. |
- On the «Main Menu» display screen, select {Each System Check}.
- On the «System Selection Menu» display screen, select the {Integ. unit mode}.
- Click the [OK] button after the control module name {Integ. Unit} is displayed.
- On the «Integ. unit mode failure diag» display screen, select the {ECM customizing}.
- Change the setting with UP/DOWN key. List of body integrated unit registration item NOTE: Setting is different depending on the grade of vehicle. BODY INTEGRATED UNIT REGISTRATION ITEM REFERENCE CHART Data Initial setting Registration Remarks A/C ECM setting OFF ON Illumination control does not operate if A/C ECM setting is set to "OFF" in case of model with auto A/C. OFF If A/C ECM setting is set to "ON" in case of model without auto A/C, illumination change to night illumination and it is difficult to be recognized. Wiper deicer (manufacturer option) OFF ON ON signal does not output with operation of wiper deicer switch if wiper deicer is set to "OFF" in models with a wiper deicer. OFF Rear fog light setting OFF ON Can not set to ON. OFF Vehicle is controlled in rear fog light non-equipped mode. (Always set to "OFF" for vehicles not equipped with the rear fog light). Illumination Control On/Off ON ON Lighting adjustment is not possible when "OFF" is set for the model with illumination volume control. OFF Sedan/Wagon Setting Wagon Wagon Door lock/unlock is controlled with wagon setting. Sedan Door lock/unlock is controlled with sedan setting. MT/AT Setting AT MT Shift lock solenoid and key lock solenoid are not controlled. AT Shift lock solenoid and key lock solenoid are controlled. 6MT Setting Other than 6MT 6MT Change to 6MT is possible when MT is set. Other than 6MT Factory or Market setting (Reset of body integrated unit) Factory Factory (Reset) If Factory or Market setting is set to "Factory", registrations of items above is changed to "OFF". Be sure to set to "Market". Market (Confirmed) CAUTION: To perform normal operation of vehicle and diagnosis, the above settings must match the actual vehicle equipment. When body integrated unit is a new part or "Factory" mode, key illumination blinks to show equipment settings have not been completed. Check the detailed procedures of function setting. Be sure not to change Factory or Market setting except installation of new body integrated unit. NOTE: "Factory" mode: Body integrated unit has not been set yet. It can be recognized by key illumination blinking with ignition switch turned to ON. All replacement body integrated units are set to Factory mode. When replacing a body integrated unit, be sure to perform the registration operation. "Market" mode: Each settings have been set. It can be recognized by key ring illumination coming on in concocting with room light and going off with ignition switch turned to ON.
- Perform the Factory or Market setting. On the «ECM customizing" display screen of Subaru Select Monitor, select the {Factory or Market setting}.
- Change the mode from Factory to Market.
- Change the Subaru Select Monitor system selection to «Immobilizer to register the immobilizer key.
- Perform the operation according to the "PC application help for Subaru Select Monitor".
- When key registration is completed, "Do you want to register remote engine start?" is displayed. Perform registration only for equipped models.
- Perform the function setting (ECM customizing). Refer to «OPERATION»(ref-325333-S36822760772009071800000) , Function Setting (Customize) . NOTE: For details concerning the operation procedure, refer to the PC application help for Subaru Select Monitor.
| DTC | Item | Diagnosis content | Index |
|---|---|---|---|
| None | Communication for Initializing Impossible | Open or short in Subaru Select Monitor communication line Back-up power supply circuit malfunction | Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1100 | Integ. Unit System Error | Body integrated unit internal error | Refer to DTC B1100 INTEG. UNIT SYSTEM ERROR , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1101 | BATT p/supply malfunction cont. | Open or short in battery power supply control circuit Voltage malfunction caused by poor contact | Refer to DTC B1101 BATT PI SUPPLY MALFUNCTION CONT , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1102 | BATT p/supply malfunction backup | Voltage malfunction caused by poor contact of battery power supply backup circuits | Refer to DTC B1102 BATT PI SUPPLY MALFUNCTION BACKUP , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1103 | Ignition power failure | Voltage malfunction caused by poor contact of IGN power supply circuits | Refer to DTC B1103 IGNITION POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1104 | ACC power failure | Voltage malfunction caused by poor contact of ACC power supply circuits | Refer to DTC B1104 ACC POWER FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1105 | Key interlock circuit abnormal | Ground short of key interlock circuit | Refer to DTC B1105 KEY INTERLOCK CIRCUIT ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1106 | Shift lock circuit Failure | Open or short in shift lock circuit | Refer to DTC B1106 SHIFT LOCK CIRCUIT FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1201 | CAN-HS counter abnormal | Communication is unstable because of high speed CAN communication error. | Refer to DTC U1201 CAN-HS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1202 | CAN-HS bus off | Open or power supply-output short, GND-output short occurs in CAN line. End resistance malfunction Internal error in each control module | Refer to DTC U1202 CAN-HS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1211 | CAN-HS ECM FRC abnormal | Received error data from ECM. | Refer to DTC U1211 CAN-HS ECM DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1212 | CAN-HS TEM FRC abnormal | Received error data from TCM. | Refer to DTC U1212 CAN-HS TCM DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1213 | CAN-HS VDC/ABS data abnormal | Received error data from VDC/ABS module. | Refer to DTC U1213 CAN-HS VDC/ABS DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1221 | CAN-HS ECM no-receive data | Not received error data from ECM. | Refer to DTC U1221 CAN-HS ECM NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1222 | CAN-HS TCM no-receive data | Not received error data from TCM. | Refer to DTC U1222 CAN-HS TCM NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1223 | CAN-HS VDC/ABS no-receive data | Not received error data from VDC/ABS CM. | Refer to DTC U1223 CAN-HS VDC/ABS NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1300 | CAN-LS malfunction | Open or short in CAN-LS circuit, on ether side | Refer to DTC U1300 CAN-LS MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1301 | CAN-LS counter abnormal | Communication is unstable because of low speed CAN communication error. | Refer to DTC U1301 CAN-LS COUNTER ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1302 | CAN-LS bus off | Open or power supply-output short, GND-output short occurs in both CAN line. Internal error in each control module | Refer to DTC U1302 CAN-LS BUS OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1311 | CAN-LS meter unit FRC abnormal | Received error data from meter. | Refer to DTC U1311 CAN-LS METER UNIT DATA ABNORMAL , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| U1321 | CAN-LS meter no-receive data | Not received error data from meter. | Refer to DTC U1321 CAN-LS METER NO-RECEIVE DATA , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
| B1401 | M collation NG | Malfunction related immobilizer | Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
| B1402 | Immobilizer Key collation NG | Malfunction related immobilizer | Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
| B1403 | E/G request NG | Malfunction related immobilizer | Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . |
| B1500 | Keyless UART com. Malfunction | Open or short circuit in keyless UART circuit | Refer to DTC B1500 KEYLESS UART COM. MALFUNCTION , Diagnostic Procedure with Diagnostic Trouble Code (DTC) . |
DIAGNOSTIC TROUBLE CODE CHART
LAN SYSTEM
| Item | Operation | Specifications | Note | |
|---|---|---|---|---|
| YES | NO | |||
| DTC | DTC is not displayed when inspecting all DTCs. | DTC is not displayed. | Perform the diagnosis according to DTC. | |
| Coolant Temp. | Check the current data display of ECM, TCM and body integrated unit. Three data value are the same. | Same values | Inspect LAN system. | If engine coolant temperature sensor is not OK, inspect the sensor circuit. |
| Rr Defogger SW | It turns to ON when pressing switch. (Low-speed CAN is OK) | Turns to ON. | Inspect rear defogger switch. | Rear defogger switch is connected with Low-speed CAN. |
| Rr defogger output | When switch input, it is output. | Output | Replace the body integrated unit. | If not operating with output, check the rear defogger relay. |
| Door lock SW (Open) | When locked with door lock switch, it turns to ON. | Turns to ON. | Inspect door lock switch. | The door lock switch is connected to the Low-speed CAN. |
| Door lock actuator | When locked with door lock switch, it is output. | Output | Replace the body integrated unit. | |
LAN SYSTEM SPECIFICATION
BODY INTEGRATED UNIT
| Item | Operation | Specifications | Note | |
|---|---|---|---|---|
| YES | NO | |||
| Illumination VR power supply | Operate the illumination volume, illumination light is controlled according to the change of voltage on data display. | Illumination light is controlled with changing of data. | Inspect the illumination volume. | |
| Fuel level resistance | Check the fuel level resistance and fuel level resistance 2. Both resistances are same. | Same values | Inspect the body integrated unit. | Compare the input and output values of body integrated unit. |
| R wiper ON/INT SW input | When rear wiper SW to ON, data display turns to ON. | Turns to ON. | Inspect the rear wiper switch. | |
| R wiper output | When rear wiper switch to ON, output signal turns to ON. | Turns to ON. | Replace the body integrated unit. | If not operate with output turned to ON, check the rear wiper motor. |
| Keyless Entry | Keyless entry LOCK/UNLOCK the doors. | Operate | Inspect the keyless antenna. | If the antenna is OK, replace the body integrated unit. |
| Brake Switch | When brake pedal is depressed, it turns to ON. | Turns to ON. | Inspect the brake switch. | |
| Shift Lock Solenoid | The shift lock releases when depressing the brake pedal. | Released | Inspect the shift lock. | |
| Registration function setting of body integrated unit | Does Vehicle equipment correspond to setting values? | Correspondence | Reconfigure the values according to vehicle equipment. | |
| Customizing | When changing customize setting, the registration completes correctly. | Registered | Inspect the body integrated unit. | |
| Manual Mode | Switch the shift (UP/DOWN) on Manual mode. Indicator is changed in 1 - 2. | Change | Inspect the shift lever. | |
| Function check | Each checking item operate correctly. (Except for not equipped) | Operate | Inspect for nonfunctional actuator. | |
| Security | After locking with keyless entry system and open the door, the security system operates and the horn sounds. | Horn sounds. (Security system operates). | Inspect the security system. | |
BODY INTEGRATED UNIT SPECIFICATION
