Airbag System (Diagnostics): Wiring Subaru Forester SG рестайлинг

WIRING DIAGRAM

SYSTEM WIRING DIAGRAMS . >

Scheme 107

Scheme 108

1. How to disconnect: Move the slide lock (A) in the direction of arrow. With the slide lock (A) moved, disconnect the connector. CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness.
2. How to connect: Holding the connector (A), and push it in carefully until a clicking sound is heard. CAUTION: Be sure to insert the connector in until it is locked. Then pull it lightly to make sure that it is locked.

Scheme 109

Scheme 110

Scheme 111

1. How to disconnect: Using a flat tip screwdriver, pry the push lock upward to unlock. Pull the connector to disconnect from driver's airbag module assembly or retractor assembly.
2. How to connect: Connect the connector in the reverse order of disconnecting. At this time, be sure to insert the push lock until a clicking sound is heard. CAUTION: Be sure to insert the connector in until it is locked. Then pull it lightly to make sure that it is locked. Be sure to push the push lock in securely. NOTE: You cannot connect the connector when the push lock is in the lock position. Move the push lock to the release position to connect the connector.

Scheme 112

Scheme 113

Scheme 114

1. How to disconnect: Push in the slide lock (A) in the direction of arrow. With the slide lock pushed in, disconnect the connector. CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness.
2. How to connect: Holding the connector, push it in securely until a clicking sound is heard. CAUTION: Be sure to insert the connector in until it is locked. Then pull it lightly to make sure that it is locked.

Scheme 115

Scheme 116

1. How to disconnect: Push the lock arm (A). With the lock arm (A) pushed in, move the slide lock (B) in the direction of arrow. With the slide lock moved, release the lock arm (return to original position) and disconnect the connector. CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness.

Scheme 117

1. How to disconnect: Holding outer part (A), pull it in the direction of arrow. CAUTION: When pulling the slide lock, be sure to hold the connector, not the harness.
2. How to connect: Holding the connector, push it in securely until a clicking sound is heard.

Scheme 118
