PROCEDURE

BASIC DIAGNOSTIC PROCEDURE CHART

Scheme 142

CAUTION

1. When servicing a vehicle, be sure to turn the ignition switch OFF, disconnect the ground cable from battery, and wait for more than 20 seconds before starting work.
2. The airbag system is fitted with a backup power source. After disconnecting the battery ground cable, the airbag may deploy if you do not wait for more than 20 seconds before starting the service of airbag system.

Scheme 143

1. If the airbag warning light illuminates, repair the vehicle immediately. Otherwise, the airbag or pre-tensioner may activate incorrectly, or not inflate in an actual collision.
2. If sensors, airbag module, airbag control module, pretensioner or harness is deformed or damaged, replace with new part.
3. Do not use the airbag system and pretensioners on other vehicles. When replacing parts, be sure to replace them with new ones.

Scheme 144

Scheme 145

1. Do not check continuity of the airbag modules on the driver's side, passenger's side, side airbag modules, or the pretensioner.
2. Use of an analog circuit tester may cause the air-bag to activate in error. When checking the airbag system, be sure to use a digital circuit tester.

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

1. When checking, use a test harness. Do not touch the tester probe directly to the airbag connector terminal. Do not drop the airbag module parts, subject them to high temperature over 93°C (199°F), or come into contact with water, oil or grease; the internal parts may become damaged and/or reliability may be greatly lowered. If damage, open circuit or rust is found on airbag system wire harness, do not use solder to repair. Replace the faulty harness with a new factory part. Install the wire harness securely with the specified clips to avoid interference or becoming tangled with other parts. Do not allow water or oil to come in contact with the connector terminals. Also, do not touch the connector terminals. Do not disassemble the airbag modules on the drivers side, passengers side, or for the side airbag system. A deployed airbag module cannot be reused. After removal, keep the airbag module with the pad facing upward on a dry, clean, and flat surface away from heat and light sources, and moisture and dust. The removed front seat with airbag module must be kept at least 200 mm (8 in) away from walls and other objects. When painting or performing sheet metal work on the front part of the vehicle, including the front wheel apron, front fender and front side frame, remove the front sub sensors and wire harness of air-bag system. When painting or performing sheet metal work on the side of the vehicle, including the side sill, center pillar and front and rear doors, remove the side airbag sensors and wire harness of the airbag system. When storing a removed airbag module, do not place any objects on it or stack other airbag modules on top of each other. If the airbag inflates for some reason when it is placed with its pad side facing downward or under any object, a serious accident may result. Do not discard an undeployed airbag module. They could easily cause a serious accident if accidentally deployed.

BATTERY

Measure the battery voltage and check electrolyte.

Standard voltage

12 V

Specific gravity

1.260 or more

PREPARATION TOOL

DISPLAY OF STATUS INFORMATION

Check the operating condition of each sensor in the event of malfunction in the seat belt buckle switch and seat position sensor, or when the seat belt buckle switch and seat position sensor has been replaced.

1. On the «Main Menu» display screen, select {Each System Check} and press the [YES] key.
2. On the «System Selection Menu» display screen, select the {Airbag System} and press the [YES] key.
3. On the «Airbag System» display screen, select the {Status Data} and press the [YES] key. The following table is for support data.

DIAGNOSIS PROCEDURE

Note. For details concerning operation procedure, refer to the "SUBARU SELECT MONITOR OPERATION MANUAL ".

3. CLEAR MEMORY MODE

Clear the DTC stored in the airbag control module after repairing the airbag system. (After the breakdown is recovered, the breakdown code for completed recoveries are read out when the next breakdown occurs if the memory clear work is not performed.)

1. On the «Main Menu» display screen, select {Each System Check} and press the [YES] key.
2. On the «System Selection Menu» display screen, select the {Airbag System} and press the [YES] key.
3. On the {Airbag System} menu screen, select the {Clear Memory} and press the [YES] key.
4. When the "Clear Memory?" is shown on the screen, press the [YES] key.
5. When "Done" is displayed, turn the Subaru Select Monitor OFF.

Note. For details concerning operation procedure, refer to the "SUBARU SELECT MONITOR OPERATION MANUAL ".

COMMUNICATION FOR INITIALIZING IMPOSSIBLE

DETECTING CONDITION

Defective harness connector

TROUBLE SYMPTOM

Communication is impossible between the airbag control module and the Subaru Select Monitor.

WIRING DIAGRAM

Scheme 157

DIAGNOSIS PROCEDURE

Recreate the condition by referring to the fault conditions described in the checklist.

AIRBAG WARNING LIGHT REMAINS ON

DETECTING CONDITION

1. Airbag warning light failure
2. Airbag control module to airbag warning light circuit is shorted or open.
3. Grounding circuit is faulty.
4. Airbag control module is faulty.
5. Improper connection of (AB1) and (B31)
6. Improper connection of (AB3) to airbag control module

WIRING DIAGRAM

Scheme 158

DIAGNOSIS PROCEDURE

AIRBAG WARNING LIGHT REMAINS OFF

DETECTING CONDITION

1. Blown fuse No. 14 (in fuse box)
2. Body harness is open.
3. Airbag warning light failure
4. Airbag main harness is faulty.
5. Airbag control module is faulty.

WIRING DIAGRAM

DIAGNOSIS PROCEDURE

LIST

DIAGNOSTIC TROUBLE CODE
