Pinion Gear Return Test (Legacy & Outback): Overview Subaru Forester SF рестайлинг

Connect jumper wire from battery negative terminal to starter solenoid case. Connect another jumper wire from battery negative terminal to starter solenoid terminal No. 50. (Scheme 4) Momentarily touch positive jumper wire to starter solenoid terminal "C". Pinion gear should return immediately. If pinion gear does not return immediately, replace starter.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. Disconnect battery ground cable. (Scheme 5): Disconnecting Battery Ground Cable
2. Remove air cleaner case, see «AIR CLEANER»(ref-121721-S22491470682005050200000)
3. Disconnect connector and terminal from starter. (Scheme 6): Disconnecting Connector And Terminal From Starter
4. Remove starter from transmission. (Scheme 7): Removing Starter From Transmission
