Engine & Transmission Mounting System: Overview Subaru Forester SF рестайлинг

Identifying Engine Mounting Components. Scheme 183

Tightening torque: N.m (kg-m, ft-lb)

1. T1: 34+/-5 (3.5+/-0.5, 25.3+/-3.6)
2. T2: 41+/-10 (4.2+/-1.0, 30+/-7)
3. T3: 83+/-15 (8.5+/-1.5, 61+/-11)

Identifying MT Transmission Mounting Components. Scheme 184

Tightening torque: N.m (kg-m, ft-lb)

1. T1: 34+/-5 (3.5+/-0.5, 25.3+/-3.6)
2. T2: 49+/-5 (5.0+/-0.5, 36.2+/-3.6)
3. T3: 57+/-10 (5.8+/-1.0, 42+/-7)
4. T4: 69+/-15 (7.0+/-1.5, 51+/-11)
5. T5: 137+/-20 (14+/-2, 101+/-14)

Identifying AT Transmission Mounting Components. Scheme 185

Tightening torque: N.m (kg-m, ft-lb)

1. T1: 34+/-5 (3.5+/-0.5, 25.3+/-3.6)
2. T2: 38+/-15 (3.9+/-1.5, 28+/-11)
3. T3: 49+/-5 (5.0+/-0.5, 36.2+/-3.6)
4. T4: 57+/-10 (5.8+/-1.0, 42+/-7)
5. T5: 69+/-15 (7.0+/-1.5, 51+/-11)
