Installation
| CAUTION | Replace gaskets with new ones. |
Scheme 20
Scheme 21
Scheme 22
- Install rear exhaust pipe bracket to rubber cushion. NOTE: To facilitate installation, apply a coat of SUBARU CRC or equivalent to mating area of rubber cushion in advance. SUBARU CRC (Part No. 004301003) (Scheme 20): Installing Rear Exhaust Pipe Bracket To Rubber Cushion
- Install rear exhaust pipe to muffler. Tightening torque: 48+/-5 N.m (4.9+/-0.5 kg-m, 35.4+/-3.6 ft-lb) (Scheme 21): Installing Rear Exhaust Pipe To Muffler
- Install rear exhaust pipe to center exhaust pipe. Tightening torque: 18+/-5 N.m (1.8+/-0.5 kg-m, 13.0+/-3.6 ft-lb) (Scheme 22): Installing Rear Exhaust Pipe To Center Exhaust Pipe
Removal And Installation
| WARNING | Be careful, exhaust pipe is hot. |
Scheme 23
Scheme 24
Scheme 25
Scheme 26
- Lift-up the vehicle.
- Separate muffler from rear exhaust pipe. (Scheme 23): Separating Muffler From Rear Exhaust Pipe
- Remove left and right rubber cushions. CAUTION: Be careful not to pull down muffler. NOTE: To facilitate removal, apply a coat of SUBARU CRC or equivalent to mating area of rubber cushions in advance. SUBARU CRC (Part No. 004301003) (Scheme 24): Removing Left & Right Rubber Cushions
- Remove front rubber cushion, and detach muffler assembly. NOTE: To facilitate removal, apply a coat of SUBARU CRC or equivalent to mating area of rubber cushion in advance. SUBARU CRC (Part No. 004301003) (Scheme 25): Removing Front Rubber Cushion, & Detach Muffler Assembly
- Install in the reverse order of removal. CAUTION: Replace gasket with a new one. Tightening torque: 48+/-5 N.m (4.9+/-0.5 kg-m, 35.4+/-3.6 ft-lb) (Scheme 26): Installing Muffler To Rear Exhaust Pipe
