Generators & Regulators: Removal & Installation Subaru Forester SF рестайлинг

Removal

1. Disconnect ground cable from battery.
2. Disconnect connector and terminal from generator. (Scheme 3)
3. Remove V-belt. (Scheme 4)
4. Remove the front side V-belt.
5. Remove bolt (A), and loosen bolt (B). Then, remove generator from bracket. (Scheme 5)

Scheme 3

Scheme 4

Scheme 5

Installation

Install in the reverse order of removal. (Scheme 5)

Note. Perform the following procedures with the engine installed to body.

1. Remove the V-belt cover. (Scheme 6)
2. Loosen the lock bolt (A). (Scheme 7)
3. Loosen the slider bolt (B).
4. Remove the front side belt (C).

Scheme 6

Scheme 7
