Anti-Lock Braking System - Diagnostics: Specifications Subaru Forester SF рестайлинг

Anti-Lock/traction Control 10 illustrations ~317 words

Tire Specifications, Tire Wear And Air Pressure

Check tire specifications, tire wear and air pressure.

Identifying Warning Light Illumination Pattern. Scheme 6

Scheme 6: Identifying Warning Light Illumination Pattern
  1. When the ABS warning light does not illuminate in accordance with this illumination pattern, there must be an electrical malfunction.
  2. When the ABS warning light remains constantly OFF, repair the ABS warning light circuit or diagnosis circuit. See «DIAGNOSTICS CHART FOR ABS WARNING LIGHT CIRCUIT AND DIAGNOSIS CIRCUIT FAILURE»(ref-175571-S13269035122005042200000) .

Note. Even though the ABS warning light does not go out 1.5 seconds after it illuminates, the ABS system operates normally when the warning light goes out while driving at approximately 12 km/h (7 MPH). However, the Anti-lock brakes do not work while the ABS warning light is illuminated.

Identifying Electrical Components Location (1 Of 2). Scheme 7

Scheme 7: Identifying Electrical Components Location (1 Of 2)

Identifying Electrical Components Location (2 Of 2). Scheme 8

Scheme 8: Identifying Electrical Components Location (2 Of 2)
Scheme 9: Identifying ABS Sensors & Related Components

Tightening torque: N.m (kg-m, ft-lb)

  1. T1: 7.4+/-2.0 (0.75+/-0.2, 5.4+/-1.4)
  2. T2: 32+/-10 (3.3+/-1.0, 24+/-7)

Identifying ABS Control Module & Hydraulic Control Unit (ABSCM & H/U). Scheme 10

Scheme 10: Identifying ABS Control Module & Hydraulic Control Unit (ABSCM & H/U)

Tightening torque: N.m (kg-m, ft-lb)

  1. T1: 18+/-5 (1.8+/-0.5, 13.0+/-3.6)
  2. T2: 29+/-7 (3.0+/-0.7, 21.7+/-5.1)
  3. T3: 32+/-10 (3.3+/-1.0, 24+/-7)

ABS System Schematic. Scheme 11

Scheme 11: ABS System Schematic

Identifying ABS Control Module And Hydraulic Control Unit Connector Terminals. Scheme 12

Scheme 12: Identifying ABS Control Module And Hydraulic Control Unit Connector Terminals

Note. The terminal numbers in the ABS control module and hydraulic control unit connector are as shown in the figure. When the connector is removed from the ABSCM & H/U, the connector switch closes the circuit between terminal No. 21 and No. 23. The ABS warning light illuminates.

ABS Control Module And Hydraulic Control Unit Pin Voltage Chart. Scheme 13

Scheme 13: ABS Control Module And Hydraulic Control Unit Pin Voltage Chart

I/O Signal Diagram. Scheme 14

Scheme 14: I/O Signal Diagram

Basic Diagnostics Procedure Chart. Scheme 15

Scheme 15: Basic Diagnostics Procedure Chart
CAUTIONRemove foreign matter (dust, water, etc.) from the ABSCM & H/U connector during removal and installation.

Note. To check harness for broken wires or short circuits, shake it while holding it or the connector. When ABS warning light illuminates, read and record trouble code indicated by ABS warning light.
