Entry Start System Start System (Keyless Start): Diagnosis Subaru BRZ ZC

How To Proceed With Troubleshooting

Note. Use the following procedure to troubleshoot the entry and start system (for start function). *: Use the SSM3.

1. VEHICLE BROUGHT TO WORKSHOP NEXT
2. CUSTOMER PROBLEM ANALYSIS CHECK NOTE: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency Where Road conditions Under what conditions? Running conditions, driving conditions, weather conditions How did it happen? Problem symptoms (1) (1) Be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem, and then check for DTCs. If the entry lock/unlock function does not operate for all doors. If the entry lock function does not operate. If the entry unlock function does not operate. If both the entry lock and unlock functions do not operate. If the wireless lock and unlock functions do not operate. If there is no power even when the engine switch is pressed [does not turn on (ACC)]. If the engine does not start with the entry ignition function. If the outside warning buzzers do not sound. If the customer attempted to start the engine by touching the electrical key to the engine switch and pressing the engine switch. If the interior warning buzzers do not sound. If the steering does not unlock. Any other details concerning the problem. If it is thought that wave interference is likely, be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem. Specific locations where the system does not operate (such as near TV towers, large video displays, wireless garage door opener systems, wireless security cameras, home security systems, etc.). Specific times when the system does not operate: Whether or not symptoms occurred immediately after purchase or only recently. Whether or not the symptoms occurred even when the key was near the vehicle (electrical key antenna). If the system does not operate only when near specific vehicles (there may be an effect from electric waves from the wireless systems of other vehicles). If the system operates intermittently. If the key is bundled together with other items. If the key is carried together with other electronic devices, such as cell phones, personal computers, portable music players, other electrical keys, etc. (keep the key at least 0.1m {0.33ft.} away from such items). Where the key is being kept when not in use: Whether or not the key being placed within 1m {3.28ft.} of items such as TVs, DVD recorders, induction cookers, rice cookers, dishwashers, modems, cell phones, personal computers, microwave ovens, desk or floor lamps, cordless telephones, etc. If there are electronic devices that transmit electric waves placed in the vehicle. When the key battery was last replaced (when the battery is low): The key battery can be checked using the "Key Low Battery" item in the [Current Data Display & Save]. (Refer to «DTC CHECK / CLEAR»(ref-619199-S29840500812014053000000) ) If the customer installed any optional components (theft deterrent devices, wireless fog lights, etc.) to the vehicle. NEXT
3. INSPECT BASIC OPERATION Inspect battery voltage. Standard voltage: 11 to 14 V CAUTION: If the voltage is below 11V, recharge or replace the battery before proceeding. Check for blown fuses, open or shorted wire harnesses, improperly connected connectors and other problems in areas that can be visually inspected. NEXT
4. Communication inspection of the CAN communication system Check CAN communication system. (Refer to «HOW TO TROUBLESHOOT»(ref-619155-S21491093182014053000000) ) RESULT Result Go to Functioning properly A Not functioning properly B B: Go to "CAN communication system (How to troubleshoot)" (Refer to «HOW TO TROUBLESHOOT»(ref-619155-S21491093182014053000000) ). A: Go to Next Step
5. Communication function inspection of large-scale multiplex communication system for vehicle body [LIN] Inspect the large-scale multiplex communication system for vehicle body. (Refer to «HOW TO TROUBLESHOOT»(ref-619156-S11469445542014053000000) ) RESULT Result Go to Functioning properly A Not functioning properly B B: Go to "large-scale multiplex communication system for vehicle body [LIN]" (Refer to «HOW TO TROUBLESHOOT»(ref-619156-S11469445542014053000000) ) A: Go to Next Step
6. CHECK FOR DTC* Check for DTCs and note any codes that are output. (Refer to «DIAGNOSIS SYSTEM»(ref-619195-S40231480312014053000000) ) RESULT Result Go to DTC is not output A Steering lock system DTC is output B Engine immobiliser system DTC is output C Entry and start system (for Entry Function DTC is output D Entry and start system (for Start Function) DTC is output E B: Go to "steering lock system (List of diagnostic codes)" (Refer to «LIST OF DIAGNOSTIC CODES»(ref-619170-S31027655792014053000000) ) C: GO TO ENGINE IMMOBILISER SYSTEM (DIAGNOSTIC TROUBLE CODE CHART) (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-619188-S37656271052014053000000) ) D: GO TO ENTRY AND START SYSTEM (for Entry Function) (DIAGNOSTIC TROUBLE CODE CHART) (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-619199-S24759487492014053000000) ) E: GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-619195-S29564556572014053000000) A: Go to Next Step
7. PROBLEM SYMPTOMS TABLE Refer to «PROBLEM SYMPTOMS TABLE.»(ref-619195-S17273977042014053000000) (Refer to «PROBLEM SYMPTOMS TABLE»(ref-619195-S17273977042014053000000) ) RESULT Result Proceed to Fault is not listed in the Problem Symptoms Table A Fault is listed in the Problem Symptoms Table B B: Go to step 9 A: Go to Next Step
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. (Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-619195-S00372456622014053000000) ) Current Data Display & Save / System Operation Check Mode (Refer to «CURRENT DATA DISPLAY & SAVE / SYSTEM OPERATION CHECK MODE»(ref-619195-S36273824362014053000000) ) Terminals of ECU. (Refer to «PROBLEM SYMPTOMS TABLE»(ref-619195-S17273977042014053000000) ) NEXT
9. REPAIR OR REPLACE NEXT
10. CHECK FOR DTC* Clear the DTCs. (Refer to «DTC CHECK / CLEAR»(ref-619195-S04953472982014053000000) ) Recheck for DTCs. (Refer to «DTC CHECK / CLEAR»(ref-619195-S04953472982014053000000) ) NOTE: Before checking for DTCs, perform the "DTC Output Confirmation Operation" procedure. RESULT Result Proceed to DTC is not output A DTC is output B B: GO TO «DIAGNOSTIC TROUBLE CODE CHART»(ref-619195-S29564556572014053000000) A: END

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

1. Operation explanation Entry ignition function (with automatic transmission): If the electrical key transmitter sub-assembly is in the vehicle interior detection area and the brake pedal is depressed, you can press the engine switch and start the engine. If the electrical key transmitter sub-assembly is in the vehicle interior detection area and the brake pedal is not depressed, you can press the engine switch to change the power mode. The power mode changes each time you press the engine switch, in the following order: OFF -->ACC ON--> IG ON -->OFF. In IG OFF, after you enter the vehicle interior carrying the electrical key transmitter sub-assembly, if you press the engine switch without stepping on the brake pedal, the power mode switches to ACC, and the entry key indicator light in the combination meter ASSY blinks green. With the engine switch turned off, after you enter the vehicle interior holding the electrical key transmitter sub-assembly in your hand, and with the shift lever put in P, if you step on the brake pedal, the entry key indicator light in the combination meter ASSY will light up green. If you press the engine switch when the entry key indicator light of the combination meter ASSY is lit up green, the engine will start. Changing the power mode when the electrical key transmitter sub-assembly doesn't operate properly due to radio wave interference or the battery of the electrical key transmitter sub-assembly being drained (for automatic transmission): Use the integrated mechanical key to unlock the door, hold the electrical key transmitter sub-assembly, and enter the vehicle interior. Step on the brake pedal and hold the ornament side of the electrical key transmitter sub-assembly up to the engine switch. The buzzer sounds and the vehicle turns to IG ON. NOTE: If the entry cancel function has been customized, the power mode changes to on (ACC). Starting the engine when the electrical key transmitter sub-assembly doesn't operate properly due to radio wave interference or the battery of the electrical key transmitter sub-assembly being drained (for automatic transmission): Use the integrated mechanical key to unlock the door, hold the electrical key transmitter sub-assembly, and enter the vehicle interior. Step on the brake, put the shift lever in P, and hold the ornament side of the electrical key transmitter sub-assembly up to the engine switch. The buzzer sounds and the vehicle turns to IG ON. When the entry key indicator light of the combination meter ASSY lights up green, press the engine switch while pressing the brake pedal, and start the engine. NOTE: If the entry cancel function has been customized, the power mode changes to on (ACC). Entry ignition function (with manual transmission): If the electrical key transmitter sub-assembly is in the vehicle interior detection area and the clutch pedal is depressed, you can press the engine switch and start the engine. If the electrical key transmitter sub-assembly is in the vehicle interior detection area and the clutch pedal is not depressed, you can press the engine switch to change the power mode. The power mode changes each time you press the engine switch, in the following order: OFF -->ACC ON--> IG ON -->OFF. In IG OFF, after you enter the vehicle interior carrying the electrical key transmitter sub-assembly, if you press the engine switch without stepping on the clutch pedal, the power mode switches to ACC, and the entry key indicator light in the combination meter ASSY blinks green. In IG OFF, after you enter the vehicle interior carrying the electrical key transmitter sub-assembly, if you step on the clutch pedal, the entry key indicator light in the combination meter ASSY will light up green. If you press the engine switch when the entry key indicator light of the combination meter ASSY is lit up green, the engine will start. Changing the power mode when the electrical key transmitter sub-assembly doesn't operate properly due to radio wave interference or the battery of the electrical key transmitter sub-assembly being drained (for manual transmission): Use the integrated mechanical key to unlock the door, hold the electrical key transmitter sub-assembly, and enter the vehicle interior. Step on the clutch pedal and hold the ornament side of the electrical key transmitter sub-assembly up to the engine switch. The buzzer sounds and the vehicle turns to IG ON. NOTE: If the entry cancel function has been customized, the power mode changes to ACC. Starting the engine when the electrical key transmitter sub-assembly doesn't operate properly due to radio wave interference or the battery of the electrical key transmitter sub-assembly being drained (for manual transmission): Use the integrated mechanical key to unlock the door, hold the electrical key transmitter sub-assembly, and enter the vehicle interior. Step on the clutch pedal and hold the ornament side of the electrical key transmitter sub-assembly up to the engine switch. The buzzer sounds and the vehicle turns to IG ON.
2. Function inspection for the entry ignition Inspect the entry ignition function (only for automatic transmission). In IG OFF, with the shift lever in P, while carrying the electrical key transmitter sub-assembly, step on the brake pedal, and check that the entry key indicator light of the combination meter ASSY lights up green. If the entry key indicator light of the combination meter ASSY lights up green, press the engine switch, and check that the engine starts. Without stepping on the brake pedal, after putting the vehicle in IG OFF, press the electrical key transmitter sub-assembly, and check that the power mode changes in the following way: OFF -->ACC ON -->IG ON -->OFF. However, in IG ON, if the shift lever is in a position other than P, the power mode will not turn OFF but will turn to ACC ON. Turn off the vehicle's engine, press the engine switch, and check that it turns to IG OFF (the engine stops, and all electrical systems turn off). However, with the vehicle stopped, if the shift lever is in a position other than P, even if you press the engine switch, the power mode will not turn OFF but will turn to ACC ON. In this case, put the shift lever back into P, press the engine switch, and check that the power mode changes to OFF. After the power turns OFF, open the door and check that the steering lock operates. Inspect the operation range of the entry ignition (front floor). In one of the inspection points, place the electrical key transmitter sub-assembly of the front seat in the direction shown in the figure, and check that the engine starts. CAUTION: Even when the electrical key transmitter sub-assembly is located within the key detection area inside the vehicle, it might not be detected properly if it is located on the instrument panel, inside the accessory box of the instrument panel, inside or near the front cup holder, inside the glove compartment, on the rear shelf, or on the floor. If the electrical key transmitter sub-assembly is within 0.2 m {0.66 feet} from the shift lever, communication may be impossible. If the electrical key transmitter sub-assembly is on the instrument panel or inside the glove compartment, the engine control system may not start. NOTE: Perform the inspection from both of these inspection points. Inspect the operation range of the entry ignition (rear floor). In one of the inspection points, place the electrical key transmitter sub-assembly, and check that the engine starts. CAUTION: Even when the electrical key transmitter sub-assembly is located within the key detection area inside the vehicle, it might not be detected properly if it is located on the instrument panel, inside the accessory box of the instrument panel, inside or near the front cup holder, inside the glove compartment, on the rear shelf, or on the floor. NOTE: Perform the inspection from both of these inspection points. Check the entry ignition function (only for manual transmission). In IG OFF, while carrying the electrical key transmitter sub-assembly, step on the clutch pedal, and check that the entry key indicator light of the combination meter ASSY lights up green. If the entry key indicator light of the combination meter ASSY lights up green, press the engine switch, and check that the engine starts. Without stepping on the clutch pedal, after putting the vehicle in IG OFF, press the electrical key transmitter sub-assembly, and check that the power mode changes in the following way: OFF -->ACC ON -->IG ON -->OFF. Turn off the vehicle's engine, press the engine switch, and check that it turns to IG OFF (the engine stops, and all electrical systems turn off). Open the door and check that the steering lock operates. Inspect the operation range of the entry ignition (front floor). In one of the inspection points, place the electrical key transmitter sub-assembly of the front seat in the direction shown in the figure, and check that the engine starts. CAUTION: Even when the electrical key transmitter sub-assembly is located within the key detection area inside the vehicle, it might not be detected properly if it is located on the instrument panel, inside the accessory box of the instrument panel, inside or near the front cup holder, inside the glove compartment, on the rear shelf, or on the floor. If the electrical key transmitter sub-assembly is within 0.2 m {0.66 feet} from the shift lever, communication may be impossible. If the electrical key transmitter sub-assembly is on the instrument panel or inside the glove compartment, the engine control system may not start. NOTE: Perform the inspection from both of these inspection points. CAUTION: If the electrical key transmitter sub-assembly is on the instrument panel or inside the glove compartment, the engine control system may not start. Inspect the operation range of the entry ignition (rear floor). In one of the inspection points, place the electrical key transmitter sub-assembly, and check that the engine starts. CAUTION: Even when the electrical key transmitter sub-assembly is located within the key detection area inside the vehicle, it might not be detected properly if it is located on the instrument panel, inside the accessory box of the instrument panel, inside or near the front cup holder, inside the glove compartment, on the rear shelf, or on the floor. NOTE: Perform the inspection from both of these inspection points.
3. Check the power mode change function Check the engine switch. With automatic transmission: check that the power mode changes based on the following table. Shift position Brake pedal Power mode when the engine switch is pressed P Don't step on Off -->On (ACC) -->On (IG) -->off P Don't step on Engine operation -->off P Don't step on On (ACC) (1) -->off P Step on Off -->The engine starts. P Step on On (ACC) -->The engine starts. P Step on On (IG) -->The engine starts. P Step on Engine operation -->off P Step on On (ACC) (1) -->off N Don't step on Off -->On (ACC) -->On (IG) (After the power mode changed to On [IG], each time you press the engine switch, the power mode switches between On [IG] and On [ACC].) N Don't step on Engine operating -->On (ACC) N Step on Off -->The engine starts. (2) N Step on On (ACC) -->The engine starts. (2) N Step on On (IG) -->The engine starts. (2) N Step on Engine operating -->On (ACC) The shift lever is not in P or in N. Don't step on Off -->On (ACC) -->On (IG) (After the power mode changed to On [IG], each time you press the engine switch, the power mode switches between On [IG] and On [ACC].) The shift lever is not in P or in N. Don't step on Engine operating -->On (ACC) The shift lever is not in P or in N. Step on Off -->On (IG) The shift lever is not in P or in N. Step on On (ACC) -->On (IG) The shift lever is not in P or in N. Step on Engine operating -->On (ACC) (1) This situation only applies to cases where the power mode changed from On (IG) to On (ACC). (2) Only in cases when the steering lock was unlocked. With manual transmission: Check that the power mode changes based on the following table. Clutch pedal Power mode when the engine switch is pressed Don't step on Off -->On (ACC) -->On (IG) -->off Don't step on Engine operation -->off Step on Off -->The engine starts. Step on On (ACC) -->The engine starts. Step on On (IG) -->The engine starts. Step on Engine operation -->off
4. Check the display for the power mode change Check the entry key indicator. INDICATOR UNIT INSPECTION Engine switch Indicator Off (Excluding conditions where the engine could start) Off On (ACC) (Excluding conditions where the engine could start (1) ) Blinking green On (IG) (Excluding conditions where the engine could start (1) ) Blinking green Conditions where the engine could start and shift P Lit up green After the engine starts Off (1) Excluding conditions where the engine could start, as following: WITH AUTOMATIC TRANSMISSION The engine starts if the engine switch is pressed in the following conditions. Condition 1 All conditions are met: The power mode switched from on (IG) to on (ACC). Key confirmation* or the engine immobilizer is unset (the engine switch is on (ACC) or on (IG)). The shift lever is in N (steering lock is unlocked). The stop light switch is on. Condition 2 All conditions are met: The power mode is not switched from on (IG) to on (ACC). Key confirmation* or the engine immobilizer is unset (the engine switch is on (ACC) or on (IG)). The shift lever is in P or in N. The stop light switch is on. WITH MANUAL TRANSMISSION The engine starts if the engine switch is pressed when the following conditions are met. Condition 1 All conditions are met: Key confirmation (1) or the engine switch is on (ACC) or on (IG). The clutch start switch is on. (1) When the electrical key transmitter sub-assembly is in the vehicle interior, the ID code sent as a result of the communication between the electrical key transmitter sub-assembly and the collation ECM (smart key ECM ASSY) and the ID code calculated by the collation ECM (smart key ECM ASSY) are compared. If these ID codes match, the vehicle recognizes that the electrical key transmitter sub-assembly is in the vehicle interior. List of indicator conditions Indicator Vehicle status Off Any condition is met: The engine is turning. With the engine switch off, the vehicle is in a state where even if the engine switch is pressed, the engine won't start. Lit up green All the following conditions are met, the vehicle is in a state where if the engine switch is pressed, the engine will start. The electrical key transmitter sub-assembly is in the vehicle interior, the stop light switch ASSY (1) or the clutch start switch ASSY (2) is on, and the shift lever is in P (1) . Blinking green (Blinking slowly) With the engine switch in on (ACC) or on (IG), the vehicle is in a state where even if the engine switch is pressed, the engine won't start. Blinking green (Blinking quickly) If the power is on, or the engine is started, the steering wheel is unlocked (steering lock is stuck). When the steering wheel is unlocked, the indicator begins blinking. When 30 seconds have passed since the blinking began, if the power is on, or if the engine was started again, the indicator stops blinking. Blinking yellow A defect is found in the steering lock ECM. If it is determined that there is a defect in the steering lock ECM or in the collation ECM (smart key ECM ASSY), the indicator begins blinking. If the ECM returns to its normal status, or if 15 seconds have passed since the blinking started, the indicator stops blinking. (1) With automatic transmission (2) for manual transmission NOTE: If the shift lever is in the N position, the engine can start only when the steering wheel is unlocked. (With automatic transmission)

Problem Symptoms Table

Note. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary. Inspect the fuses and relays related to the system before inspecting the suspected areas below.

ENTRY & START

Diagnosis System

1. Description of functions Entry and start system (for start function) data and the Diagnostic Trouble Codes (DTCs) can be read through the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use the SSM3 to check for malfunctions and perform repairs.
2. Check DLC3 Check DLC3.
3. INSPECT BATTERY VOLTAGE If the voltage is below 11V, recharge or replace the battery before proceeding. Standard voltage: 11 to 14 V

DTC Check / Clear

1. CHECK DTC (POWER SOURCE CONTROL) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Keyless access system] -->[Power Supply ECM] -->[Diagnostic Code(s) Display] Check for DTCs. NOTE: Refer to the SSM3 operator's manual for further details.
2. CHECK DTC (ENTRY AND START) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Keyless access system]--> [Collation ECM] -->[Diagnostic Code(s) Display] Check for DTCs. NOTE: Refer to the SSM3 operator's manual for further details.
3. CHECK DTC (ENGINE AND ECT) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Engine Control System] -->[Diagnostic Code(s) Display] Check for DTCs. NOTE: Refer to the SSM3 operator's manual for further details.
4. CLEAR DTC (POWER SOURCE CONTROL) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Keyless access system] -->[Power Supply ECM] -->[Clear Memory] Clear the DTCs by following the directions on the SSM3 display. NOTE: Refer to the SSM3 operator's manual for further details.
5. CLEAR DTC (ENTRY AND START) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Keyless access system]--> [Collation ECM] -->[Clear Memory] Clear the DTCs by following the directions on the SSM3 display. NOTE: Refer to the SSM3 operator's manual for further details.
6. CLEAR DTC (ENGINE AND ECT) Connect the SSM3 to the DLC3. Turn the engine switch on (IG). Turn the SSM3 on. Enter the following menus: [Engine Control System] -->[Clear Memory] Clear the DTCs by following the directions on the SSM3 display. NOTE: Refer to the SSM3 operator's manual for further details.

Scheme 138

Scheme 139

Scheme 140

Scheme 141

1. Current Data Display & Save NOTE: By using the SSM3 and reading [Current Data Display & Save], you can read the statuses and values for switches, sensors, actuators, and other items without removing parts. Because the non-intrusive inspection allows you to read the intermittent statuses or signals without interfering with parts or lines, it is very convenient. By reading the [Current Data Display & Save] information at the initial stage of troubleshooting, you can save on time for diagnosing trouble. CAUTION: The normal values written in the chart below are for reference. Do not depend on reference value only when judging if the part is faulty. Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save], or [Integ. unit mode] -->[Current Data Display & Save], or [Brake Control System] -->[ABS/VDC System] -->[Current Data Display & Save], or [Engine Control System] -->[Current Data Display & Save] SSM SCREEN: [EACH SYSTEM CHECK] -->[KEYLESS ACCESS SYSTEM] -->[POWER SUPPLY ECM] -->[CURRENT DATA DISPLAY & SAVE] Item Name Description/display range Normal value Remarks [Shift P signal] (1) Shift position is P Display range: [ON]/[OFF] [ON]: The shift is in the P position [OFF]: The shift is not in the P position Use this item to find out if the shift switch (P) is faulty. [Steering unlock SW] This item indicates the steering unlock sensor signal output from the steering lock actuator. Display range: [ON]/[OFF] [ON]: Steering unlocked [OFF]: Steering locked In IG OFF and with the shift in the P position (transmission A/T), open (or close) one of the doors to lock the steering. Change the power status to ACC ON or IG ON with the electrical key transmitter sub-assembly (electronic key) in the vehicle to unlock the steering. The engine cannot be started when the steering unlock signal is OFF. [Stop Light Switch 1] Brake pedal status Display range: [ON]/[OFF] [ON]: Stepping on the brake pedal [OFF]: Brake pedal is released Use this item to find out if the stop light switch is faulty. If the engine cannot be started due to a malfunction in the stop light switch signal, "OFF" is displayed. In case of a malfunction, you can start the engine by holding down the push button start switch. [System SW1] Push button start switch 1 status Display range: [ON]/[OFF] [ON]: Push button start switch is pressed [OFF]: Push button start switch is released This item may not be displayed if the push button start switch is pressed too quickly. Use this item to find out if the push button start switch input signal is faulty. [System SW2] Push button start switch 2 status Display range: [ON]/[OFF] [ON]: Push button start switch is pressed [OFF]: Push button start switch is released Back-up for push button start switch 1. However, when operating by holding down the push button start switch, if both push button start switch 1 and push button start switch 2 are not functioning properly, the control will not operate. This switch operates in the same way as push button start switch 1. [Neutral SW/Clutch SW (AT model)] Shift position (P, N) status Display range: [ON]/[OFF] [ON]: The shift is in the P or N position [OFF]: The shift is not in the P or N position Use this item to find out if the neutral start switch is faulty. If the engine cannot be started due to a malfunction in the neutral start switch, "OFF" is displayed. [Neutral SW/Clutch SW (MT model)] Clutch pedal status Display range: [ON]/[OFF] [ON]: Stepping on the clutch pedal [OFF]: Clutch pedal is released Use this item to find out if the clutch start switch is faulty. If the engine cannot be started due to a malfunction in the clutch start switch, "OFF" is displayed. [IG1 relay monitor (outside)] Coil voltage monitor status for the IG1 relay Display range: [ON]/[OFF] [ON]: IG ON [OFF]: IG OFF Use this item to find out if the IG1 relay is faulty. When in ACC ON, "OFF" is displayed. [IG1 relay monitor (inside)] Drive output monitor status for the IG1 relay Display range: [ON]/[OFF] [ON]: IG ON [OFF]: IG OFF Use this item to find out if the IG1 relay is faulty. When in ACC ON, "OFF" is displayed. [IG2 relay monitor (outside)] Coil voltage monitor status for the IG2 relay Display range: [ON]/[OFF] [ON]: IG ON [OFF]: IG OFF Use this item to find out if the IG2 relay is faulty. When in ACC ON, "OFF" is displayed. [IG2 relay monitor (inside)] Drive output monitor status for the IG2 relay Display range: [ON]/[OFF] [ON]: IG ON [OFF]: IG OFF Use this item to find out if the IG2 relay is faulty. When in ACC ON, "OFF" is displayed. [Starter request signal monitor] Engine start request signal status Display range: [ON]/[OFF] [ON]: With the shift in the P position, stepping on the brake, press and hold the push button start switch (transmission A/T) [ON]: Stepping on the clutch pedal, press and hold the push button start switch (transmission M/T) [OFF]: After approx. 1 second, release the push button start switch If the engine cannot be started due to a malfunction in the start request signal, "OFF" is displayed. If you press the push button start switch for a short time, the time "ON" is displayed will be very short. Therefore, you must press and hold it for a while. [ACC relay monitor] ACC relay drive status Display range: [ON]/[OFF] [ON]: ACC ON OFF: ACC OFF When in IG ON, "ON" is displayed. When the engine is cranking, "OFF" is displayed. [ACC Relay Cut Signal] ACC relay cut signal input status Display range: [ON]/[OFF] [ON]: When cranking [OFF]: When not cranking - [Engine Speed] Engine status Display range: [Stopped] / [rotating] [Rotating]: The engine is rotating [Stopped]: The engine is stopped - [Vehicle speed signal] Vehicle running/stopped status Display range: [Stopped status] / [Drive status] [Drive status]: The vehicle is running (at 5 km/h or faster) [Stopped status]: The vehicle is stopped - [Power supply status] Power status Display range: [All OFF status]/[ACC relay ON status] / [IG1 relay ON status] / [IG2 relay ON status] / [ST status] [All OFF]: ACC OFF and IG OFF [ACC ON]: ACC ON [IG1 ON]: IG ON [IG2 ON]: IG ON [st]: Start request signal transmitting Because "IG1 ON" and "IG2 ON" are displayed almost simultaneously, you may not be able to see the "IG1 ON" indication. (Because "IG1 ON" is displayed for a short time.) [Powertrain Type] Vehicle identification status Display range: [Cnv-MT] / [Cnv-AT] [Cnv-AT]: A conventional A/T vehicle (A/T vehicle not equipped with HV) [Cnv-MT]: A conventional M/T vehicle - [IG1 outside circuit abnormal] Malfunction in the coil-side circuit for the IG1 relay Display range: [Yes] / [No] [Yes]: Circuit not functioning properly [No]: Circuit functioning properly Use this item to find out if the IG1 relay is faulty. If the engine cannot be started due to a malfunction in the IG1 relay, "OFF" is displayed. [IG2 outside circuit abnormal] Malfunction in the coil-side circuit for the IG2 relay Display range: [Yes] / [No] [Yes]: Circuit not functioning properly [No]: Circuit functioning properly Use this item to find out if the IG2 relay is faulty. If the engine cannot be started due to a malfunction in the IG2 relay, "OFF" is displayed. [Start-stop SW fault] This item detects a mismatch between the push button start switch 1 signal and the push button start switch 2 signal. Display range: [Yes] / [No] [Yes]: Switch not functioning properly (mismatch between the signals of push button start switches 1 and 2) [No]: switches functioning properly You can start the engine even when the result is "[Yes]". However, you cannot use the "emergency IG OFF when running" or "emergency engine start when the brake is faulty" functions that are operated by pressing and holding the push button start switch. [Park Signal Mismatch] Shift position (P) signal malfunction Display range: [Yes] / [No] [Yes]: Signal not functioning properly (mismatch between the CAN communication and direct signal statuses) [No]: Signals functioning properly You can switch to OFF even when the result is "[Yes]". (vehicle will not be left ACC ON or IG ON.) [Steering lock unlock wait time-out] Malfunction in the steering lock / unlock function Display range: [Yes] / [No] [Yes]: Lock/unlock not functioning properly (Example: the lock bar gets stuck) [No]: Lock/unlock functioning properly If the engine cannot be started due to a malfunction in the steering lock/unlock, "[Yes]" is displayed. [Key collation wait time-out] Key collation malfunction Display range: [Yes] / [No] [Yes]: Collation not functioning properly (A collation malfunction is detected when the ID code sent from the electronic key and the ID code recorded in the Collation ECM do not match.) [No]: Collation functioning properly If the engine cannot be started due to a key collation malfunction, "[Yes]" is displayed. [Shift N signal (1) ] Shift in position N Display range: [ON]/[OFF] [ON]: The shift is in the N position [OFF]: The shift is not in the N position Use this item to find out if the shift switch (N) is faulty. (1) Automatic transmission
2. Using the SSM3 and [Current Data Display & Save], identify if there is a problem or not, and narrow down the location of the problem. NOTE: Get into the vehicle carrying the electrical key transmitter sub-assembly (electronic key) with you, and perform the following operations with the power status in IG OFF and the shift in position P to check the result for each [Current Data Display & Save] item. NOTE: Get into the vehicle carrying the electrical key transmitter sub-assembly (electronic key) with you, and perform the following operations with the power status in IG OFF to check the result for each [Current Data Display & Save] item. SSM SCREEN: [EACH SYSTEM CHECK] -->[KEYLESS ACCESS SYSTEM] -->[COLLATION ECM] -->[CURRENT DATA DISPLAY & SAVE] Item Name Description/display range Normal value Remarks [Ignition] This item indicates the IG power input status of the smart key ECM ASSY (collation ECM). Display range: [ON]/[OFF] [ON]: IG ON [OFF]: IG OFF When in ACC ON, "OFF" is displayed. [Immobilizer] This item indicates the engine immobilizer system status, as determined by the smart key ECM ASSY (collation ECM). Display range: [Unset] / [Set] [Unset]: The engine immobilizer is unset (engine start permitted) (ACC ON or further) [Set]: The engine immobilizer is set (engine start prohibited) (IG OFF) When [Set] is displayed for this item, you cannot start the engine. NOTE: The security indicator light blinks when [Set] is displayed for this item. The security indicator light is associated with the set/unset status of the immobilizer, but not with the lock/unlock status of the steering wheel. [Sleep possible status] This item indicates the sleep enabled status of the steering lock ECM. Display range: [Sleep-mode possible] / [Sleep-mode not possible] [Sleep-mode possible]: Sleep mode can be used [Sleep-mode not possible]: Sleep mode can not be used - [Wake-up transmission status] This item indicates the transmission status of the wake-up signal for the steering lock ECM. Display range: [Yes] / [No] [Yes]: The wake-up signal is transmitted [No]: The wake-up signal is not transmitted - [Lock confirmation] This item indicates the lock confirmation status of the steering lock actuator ASSY (steering lock ECM). Display range: [Set] / [UnSet] [Set]: The lock is set [UnSet]: The lock is not set When "[UnSet]" is displayed, the steering is not locked. [Unlock confirmation] This item indicates the unlock confirmation status of the steering lock actuator ASSY (steering lock ECM). Display range: [Set] / [UnSet] [Set]: The unlock is set. [UnSet]: The unlock is not set. When "[Unset]" is displayed, the steering is not locked. (The engine cannot be started.) [Engine start] This item indicates the status of the engine start permission signal, which is decided by the steering actuator ASSY (steering lock ECM) and sent to the smart key computer (collation ECM). Display range: [OK] / [NG] [OK]: The engine is permitted to start [NG]: The engine is prohibited from starting If "OK" is displayed for this item, the smart key ECM ASSY (collation ECM) receives the unlock confirmation signal from the steering lock actuator ASSY (steering lock ECM) and enables fuel injection and the engine to start. When "[NG]" is displayed for this item, you cannot start the engine. [Sensor abnormal (past)] This item indicates a history of malfunctions in the position sensor inside the steering lock actuator ASSY (steering lock ECM). Display range: [NG(Past)] / [OK] [NG(Past)]: There is an error history (Both the lock and unlock sensors inside the steering lock actuator ASSY (steering lock ECM) were ON at the same time. Normally, these sensors are not ON at the same time.) [OK]: There is no error history for the lock and unlock sensors inside the steering lock actuator ASSY (steering lock ECM). If "[NG(Past)]" is displayed for this item, the problem might be caused by a malfunction of the position sensor inside the steering lock actuator ASSY or a mechanical failure. [Motor power supply short-circuit abnormal (past)] This item indicates a history of malfunctions (circuit shorts) in the signal transmitted from the smart key ECM ASSY (collation ECM) to the steering lock actuator ASSY (steering lock ECM). Display range: [NG(Past)] / [OK] [NG(Past)]: There is a history of motor power supply short circuit [OK]: There is no history of motor power supply short circuit This item displays the history when a circuit malfunction occurs between the smart key ECM ASSY (collation ECM) and the steering lock actuator ASSY (steering lock ECM). [Motor driver short-circuit abnormal (past)] This item indicates a history of malfunctions (circuit shorts) in the motor drive circuit inside the steering lock actuator ASSY (steering lock ECM). (The diagnostic code B2781 is output) Display range: [NG(Past)] / [OK] [NG(Past)]: A history of motor driver short circuit is output [OK]: No history of motor driver short circuit is output This item indicates the malfunctions in the steering lock motor drive circuit inside the steering lock actuator ASSY (steering lock ECM). [Steering lock lock/unlock command reception history] This item indicates the unlock request signal reception history. Display range: [Unrec] / [Rec] [Rec]: There is a history of the unlock request signal being received [Unrec]: There is no history of the unlock request signal being received - [Lock bar engagement abnormal (history)] This item indicates a history of times when the steering lock bar was driven to the unlock position for a certain period of time but the steering wheel could not be properly unlocked. Display range: [With] / [Without] [With]: There is a lock bar engagement history [Without]: There is no lock bar engagement history - [Push start abnormal] This item indicates a history of push start malfunctions caused by the steering lock actuator ASSY (steering lock ECM). Display range: [NG(Past)] / [OK] [NG(Past)]: There is a push start error history [OK]: There is no push start error history - [EEPROM access abnormal] This item indicates the steering lock ECM status. Display range: [NG(Past)] / [OK] [Abnormal]: Steering lock ECM not functioning properly [Normal]: Steering lock ECM functioning properly - [Engine start permission request reception status] This item indicates the reception status of the engine start permission signal, which is decided by the steering lock actuator ASSY (steering lock ECM) and sent to the smart key ECM ASSY (collation ECM). Display range: [NG] / [OK] [NG]: Signal not received [OK]: Signal received If "[OK]" is displayed, the smart key ECM ASSY (collation ECM) has received the unlock confirmation signal from the steering lock actuator ASSY (steering lock ECM) and the engine injection and ignition have been permitted. If "[NG]" is displayed for this item, the engine cannot be started. [L Code Check] This item indicates the result of collation between the smart key ECM ASSY (collation ECM) and the steering lock actuator ASSY (steering lock ECM). Display range: [NG(Past)] / [OK] [Abnormal]: Collation not functioning properly [Normal]: Collation functioning properly The L code is not registered for the smart key ECM ASSY (collation ECM) or the steering lock actuator ASSY (steering lock ECM). The steering cannot be locked. The steering cannot be unlocked. (The engine cannot be started.) [Steering lock unlock request reception status] This item indicates the unlock request signal reception status. Display range: [NG(Past)] / [OK(10s)] [NG(Past)]: Not doing IG ON, ACC ON, or engine start operations [OK(10s)]: 10 seconds since IG ON, ACC ON, or engine start operations were done If the unlock request signal is not received, the engine cannot be started. If the steering unlock conditions are met but "[OK(10s)]" is not displayed, the smart key ECM ASSY (collation ECM) might have a malfunction. [Steering lock lock request reception status] This item indicates the lock request signal reception status. Display range: [OK(10s)] / [NG(Past)] [OK(10s)]: The lock request signal is received for 10 seconds after a door is opened with the shift in the P position (transmission A/T) and the power status in IG OFF. [NG(Past)]: Anything other than the above If the steering lock conditions are met but "[OK(10s)]" is not displayed, the smart key ECM ASSY (collation ECM) might have a malfunction. [L Code Collation result history] This item indicates the history of the results of collation between the smart key ECM ASSY (collation ECM) and the steering lock actuator ASSY (steering lock ECM). Display range: [NG(Past)] / [OK] [NG(Past)]: There is an error history of collation results [OK]: There is no error history of collation results - [S Code Check] This item indicates the collation result between the smart key ECM ASSY and the ID code box. Display range: [NG(Past)] / [OK] [Abnormal]: Collation not functioning properly [Normal]: Collation functioning properly The S code is not registered for the smart key ECM ASSY or the ID code box. The engine cannot be started. [S Code Collation result history] This item indicates the collation result history between the smart key ECM ASSY and the ID code box. Display range: [NG(Past)] / [OK] [NG(Past)]: There is an error history of collation results [OK]: There is no error history of collation results - NOTE: Get into the vehicle carrying the electrical key transmitter sub-assembly (electronic key) with you, and perform the following operations with the power status in IG OFF and the shift in position P (transmission A/T) to check the result for each [Current Data Display & Save] item. SSM SCREEN: [EACH SYSTEM CHECK] -->[ENGINE CONTROL SYSTEM] -->[CURRENT DATA DISPLAY & SAVE] Item Name Description/display range Normal value Remarks [Engine Speed] Indicates the engine speed Display range: 0 to 16383.75 r / min Varies depending on the engine speed - [Starter Switch] Starter drive request Display range: [ON]/[OFF] [ON]: The starter drive request is output. [OFF]: No starter drive request is output. If there is a malfunction, the engine cannot be cranked. [Starter cut relay] This item indicates the starter cut relay status. Display range: [ON]/[OFF] [ON]: The starter cut relay is ON [OFF]: The starter cut relay is OFF "ON" is displayed when the engine cannot be cranked. [Shift SW Status (P Range)] (1) This item indicates the neutral start switch status. Display range: [ON]/[OFF] [ON]: The shift is in the P position [OFF]: The shift is not in the P position If there is a malfunction, the engine cannot be cranked. [Shift SW Status (N Range)] (1) This item indicates the neutral start switch status. Display range: [ON]/[OFF] [ON]: The shift is in the N position [OFF]: The shift is not in the N position If there is a malfunction, the engine cannot be cranked. [ST1] This item indicates the signal from the stop light switch ASSY. Display range: [ON]/[OFF] [ON]: Stepping on the brake pedal [OFF]: Brake pedal is released - [Ignition Switch] This item indicates the IG2 status. Display range: [ON]/[OFF] [ON]: IG2 relay is ON [OFF]: IG2 relay is OFF - (1) Automatic transmission NOTE: Perform the following operations to check the result for each [Current Data Display & Save] item. SSM SCREEN: [EACH SYSTEM CHECK] -->[BRAKE CONTROL SYSTEM] -->[ABS/VDC SYSTEM] -->[CURRENT DATA DISPLAY & SAVE] Item Name Description/display range Normal value Remarks [Wheel speed] This item indicates the vehicle speed. Display range: 0.0 to 326.4 [km/h] 0.0 to 326.4 [km/h] (Approximately the same as the actual vehicle speed)
3. System Operation Check Mode Turn the ignition switch to OFF. Connect the SSM3 to the DLC3. Put the vehicle in IG ON, select [Keyless access system] -->[Power Supply ECM] -->[Work Support] -->[System Operation Check Mode], and display the [System Operation Check Mode] list. Using the [System Operation Check Mode], identify if there is a problem or not, and narrow down the location of the problem. SSM SCREEN: [EACH SYSTEM CHECK] -->[KEYLESS ACCESS SYSTEM] -->[POWER SUPPLY ECM] -->[WORK SUPPORT] -->[SYSTEM OPERATION CHECK MODE] Item Name Part to be forcibly driven Drive Remarks [Steering lock power supply] Smart key computer ASSY (collation ECM) Supply/stop When in IG ON [STSW] Smart key computer ASSY (collation ECM) Supply/stop Perform cranking in order to turn the starter switch ON. Be very careful regarding the service operation. When forcibly driving this item, implement it with the ignition ON. [IG2] Smart key computer ASSY (collation ECM) Supply/stop Turn the ignition power (relay upstream battery side) ON. If you forcibly drive this item, there may be failure codes registered for the engine, transmission, and the VDC unit. In that case, you must clear the failure codes. [IG1] Smart key computer ASSY (collation ECM) Supply/stop Turn the ignition power (relay upstream alternator side) ON. If you forcibly drive this item, there may be failure codes registered for the engine, transmission, and the VDC unit. In that case, you must clear the failure codes. [ACC] Smart key computer ASSY (collation ECM) Supply/stop Turn the ACC power ON. SSM SCREEN: [EACH SYSTEM CHECK] -->[KEYLESS ACCESS SYSTEM] -->[COLLATION ECM] -->[WORK SUPPORT] -->[SYSTEM OPERATION CHECK MODE] Item Name Part to be forcibly driven Drive Remarks [Power/Engine SW Light] Push button start switch illumination Output/stop Push button start switch illumination OFF (15 seconds or more since ON-->OFF) and in ACC ON, IG ON, or the engine is turning.

Diagnostic Trouble Code Chart

Circuit description

This DTC is output when a problem is detected in the IG1 drive circuit, the IG2 drive circuit, or the IG hold circuit in the collation ECM (smart key ECM ASSY).

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

Note. The IG1 and IG2 drive circuits drive the IG1 and IG2 relays. Even if the collation ECM (smart key ECM ASSY) performs an inaccurate operation, if the IG1 drive circuit and the IG2 drive circuit are on, the IG hold circuit will hold the engine switch in an on (IG) status.

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 142

Inspection steps

Scheme 143

Scheme 144

Scheme 145

1. Checking the harnesses and connectors (power supply) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D48-2 (+B) - chassis ground Always 9.5 to 16 V NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
2. Checking the harnesses and connectors (grounding) Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D48-11 (GND) - chassis ground Always 1 ohmsor less NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
3. Unit inspection of the collation ECM (smart key ECM ASSY) Reconnect the D48 connector of the collation ECM (smart key ECM ASSY). Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D41-6 (IG1D) - chassis ground Engine switch on (ACC) -->Engine switch on (IG) 1V or less -->9 V or more D48-9 (IG2D) - chassis ground Engine switch on (ACC) -->Engine switch on (IG) 1V or less -->9 V or more NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Complete (Possibly temporary poor contact)

This DTC is output when a problem is detected in the ACC output circuit between the ACC output terminal of the collation ECM (smart key ECM ASSY) and the ACC relay.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE UPON DETECTION

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 146

Scheme 147

Scheme 148

1. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
2. Checking the harnesses and connectors (grounding) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
3. Checking the harnesses and connectors (instrument panel junction block ASSY - collation ECM) Remove the D41 connector of the collation ECM (smart key ECM ASSY). Remove the 3A connector of the instrument panel junction block ASSY. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D41-4 (ACCD) - 3A-20 Always 1 ohmsor less 3A-12 - chassis ground Always 1 ohmsor less D41-4 (ACCD) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
4. Unit inspection of the instrument panel junction block ASSY (ACC relay) Remove the instrument panel junction block ASSY. Remove the main body ECM (multiplex network body ECM) from the instrument panel junction block ASSY. Measure the resistance according to the following table. Inspection terminals Inspection conditions Standard value 3E-1 - 3B-28 When there is no battery voltage 10 kohms or more When battery voltage is applied to terminals 3A-20 and 3A-12 1 ohmsor less 3E-1 - 3A-10 When there is no battery voltage 10 kohms or more When battery voltage is applied to terminals 3A-20 and 3A-12 1 ohmsor less NG: Replacement of the instrument panel junction block ASSY OK: Go to Next Step
5. Unit inspection of the collation ECM (smart key ECM ASSY) Install the main body ECM (multiplex network body ECM) on the instrument panel junction block ASSY. Install the instrument panel junction block ASSY. Reconnect the D41 connector of the collation ECM (smart key ECM ASSY). Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D41-4 (ACCD) - chassis ground Engine switch off -->Engine switch on (ACC) 1 V or less -->8.5 V or more NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Complete (Possibly temporary poor contact)

This DTC is output when a circuit problem is detected in the engine start permission signal output circuit of the collation ECM (smart key ECM ASSY), or when a malfunction is detected in the exterior engine start permission signal.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 149

Scheme 150

1. Checking the harnesses and connectors (collation ECM - ECM) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A33 connector of the ECM. Measure the resistance according to the following table. RESISTANCE Tester conditions Inspection conditions Standard value D48-7 (STSW) - A33-17 (START) Always 1 ohmsor less D48-11 (GND) - chassis ground Always 1 ohmsor less D48-7 (STSW) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
2. Unit inspection of the collation ECM (smart key ECM ASSY) Reconnect the D48 connector of the collation ECM (smart key ECM ASSY). Reconnect the A33 connector of the ECM. Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D48-7 (STSW) - D48-11 (GND) Step on the brake pedal (1) or the clutch pedal (2) and press the engine switch (starter on)--> After approx. 1 second, the engine switch is released (starter off) 2V or less -->9 V or more (1) With automatic transmission (2) for manual transmission Measure the voltage according to the following table. NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Proceed to the "EFI system" ("How to troubleshoot")

This DTC is output when an input problem occurs in the ACC relay cut input signal circuit of the collation ECM (smart key ECM ASSY).

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 151

Scheme 152

1. Checking the harnesses and connectors Remove the D40 and the D48 connectors of the collation ECM (smart key ECM ASSY). Remove the A35 connector of the ECM. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D40-28 (ACCR) - A35-32(ACCR) Always 1 ohmsor less D48-11 (GND) - chassis ground Always 1 ohmsor less D40-28 (ACCR) - chassis ground Always 10 kohms or more NG: Replacement of the harnesses or connectors OK: Go to Next Step
2. Unit inspection of the collation ECM (smart key ECM ASSY) Reconnect the D41, D40, and D48 connectors of the collation ECM (smart key ECM ASSY). Reconnect the A35 connector of the ECM. Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D40-28 (ACCR) - D48-11 (GND) (1) Step on the brake pedal (1) or the clutch pedal (2) and press the engine switch (starter on)--> After approx. 1 second, the engine switch is released (starter off) 2V or less -->9 V or more (1) With automatic transmission (2) for manual transmission NG: Replace the ECM OK: Replacement of the collation ECM (smart key ECM ASSY)

This DTC is output when a problem is detected in the water-exposure detection circuit of the smart key ECM ASSY (collation ECM).

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Note. Before performing troubleshooting, check the collation ECM (smart key ECM ASSY) for any damage due to water. If symptoms of damage from water are found, replace the collation ECM (smart key ECM ASSY), and take countermeasures against the cause of the damage from water.

1. Checking for damage from water Check for any evidence of water on the collation ECM (smart key ECM ASSY), surrounding parts, and wiring harnesses. RESULT Result Go to There is evidence of water. A There is no evidence of water. B B: Replacement of the collation ECM (smart key ECM ASSY) A: Taking the appropriate countermeasures against damage from water, and replacement the collation ECM (smart key ECM ASSY).

DTC B2282 is output when a mismatch is detected between the vehicle speed signal via the direct line sent from the brake actuator ASSY (skid control ECM) and the vehicle speed signal sent via the CAN communication.

DTC B2283 is output when a problem is detected in the speed sensor.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 153

Scheme 154

1. Reading the values using the SSM3 (vehicle speed) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Brake Control System] -->[ABS/VDC System] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ABS/VSC/TRC Tester display Measurement items / range Normal condition Notes for diagnosis [Wheel speed] Vehicle speed / hour: 0 km/h {0 MPH}, maximum speed: 255 km/h {158 MPH} Almost the same speed as the actual vehicle speed (speedometer tester) - Criteria: [Current Data Display & Save] is almost the same as the actual vehicle speed. NG: VSC system (How to troubleshoot) (Refer to «HOW TO TROUBLESHOOT»(ref-619166-S41894576322014053000000) ) OK: Go to Next Step
2. Reading the values using the SSM3 (vehicle speed signal) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Vehicle speed signal] Vehicle in running or stopped status / [stopped] or [rotating] [Rotating]: Vehicle is running at a speed of 5 km/h {3 MPH} or faster. [Stopped]: The vehicle is stopped. - Criteria: Based on the vehicle speed, [Stopped] (the vehicle is stopped) or [Driving] (the vehicle is running) is displayed on the screen. NG: Go to Step 3. OK: Proceed to the "vehicle stability control system" ("How to troubleshoot")
3. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
4. Checking the harnesses and connectors (grounding) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
5. Checking the harnesses and connectors (collation ECM - combination meter ASSY) Remove the D41 connector of the collation ECM (smart key ECM ASSY). Disconnect the connector A5 of the brake actuator ASSY (skid control ECM). Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D41-27 (SPD) - A5-2 (VSO) Always 1 ohmsor less D41-27 (SPD) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
6. Unit inspection of the collation ECM (smart key ECM ASSY) Reconnect the connector A5 of the brake actuator ASSY (skid control ECM). Reconnect the D41 connector of the collation ECM (smart key ECM ASSY). Using an oscilloscope, check the waveform of the vehicle speed input signal sent from the combination meter of the collation ECM (smart key ECM ASSY) terminal. Refer to the table below and check the signal waveform. Item Contents Tester connection D41-27 (SPD) - D48-11 (GND) Tool setting 5 V / DIV. 100 ms. / DIV. Conditions The engine switch on (IG), the vehicle running at approx. 5 km/h {3 MPH} Criteria: The waveform resembles the waveform shown in the figure. NOTE: If the system is functioning properly, 4 pulses are generated for each wheel revolution. The faster the vehicle speed, the shorter the width shown in the figure (A) becomes. NG: Proceed to the "vehicle stability control system" ("How to troubleshoot") OK: Replacement of the collation ECM (smart key ECM ASSY)

The collation ECM (smart key ECM ASSY) receives brake signal information from 2 sources. It receives signals from the stop light ASSY via the direct line, and receives signals from the ECM via CAN communication. If the information sent from these 2 sources are different, this DTC is output.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 155

Scheme 156

1. Reading the values using the SSM3 (stop light switch ASSY) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Stop Light Switch 1] Brake pedal status / [OFF] or [ON] [OFF]: The brake pedal is not being stepped on [ON]: The brake pedal is being stepped on Using this item, determine if there is any problem with the stop light switch. When this item is [OFF], the engine will not start. If there is a problem caused by this item, if you press the engine switch for a certain amount of time, you can start the engine. Criteria: "ON" (stepping on the brake pedal) and "OFF" (your foot removed from the brake pedal) are displayed on the screen. RESULT Result Go to NG A OK B B: See the «FUEL INJECTION SYSTEM»(ref-619185) A: Go to Next Step
2. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
3. Checking the harnesses and connectors (grounding) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
4. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - stop light switch ASSY) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A22 connector of the stop light switch ASSY. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D48-18 (STP1) - A13-4 Always 1 ohmsor less D48-18 (STP1) - chassis ground Always 10 kohms or more Reconnect the A22 connector of the stop light switch ASSY. Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D48-18 (STP1) - chassis ground The brake pedal is not being stepped on. 1 V or less The brake pedal is being stepped on. 9 V or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key ECM ASSY)

This DTC is output when the steering lock position signal sent from the lock actuator ASSY (steering lock ECM) via the direct line and the steering lock position signal sent via the LIN communication do not match.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 157

Note. If the entry key indicator of the combination meter ASSY is lit up green, there is a possibility the steering lock bar is stuck.

Scheme 158

1. DTC check (LIN communication system) Check the output of diagnostic codes from the smart key ECM ASSY (collation ECM). Criteria: The diagnostic code B2785, which indicates a LIN communication malfunction, is not output. NOTE: If the steering lock is being locked / unlocked, the engine switch will not turn on (IG), and you cannot start the engine. If you cannot use the LIN communication, you cannot lock / unlock the steering lock. NG: See the diagnostic code B2785 (Refer to «DTC B2785 LIN COMMUNICATION ERROR»(ref-619156-S30165461232014053000000) ). OK: Go to Next Step
2. Reading the values using the SSM3 (steering unlock switch) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Steering unlock SW] Status of the steering lock sensor output from the steering lock actuator ASSY / OFF or ON [OFF]: The steering is locked. [ON]: The steering is unlocked. When the shift lever is in P (1) , if a door is opened or closed with the engine switch off, the steering is locked. If the electrical key transmitter sub-assembly is in the vehicle interior, and the engine switch is on (ACC) or on (IG), the steering is unlocked. If the steering unlock signal is off, the engine will not start. (1) for automatic transmission RESULT Result Go to The [Current Data Display & Save] items do not change. A The [Current Data Display & Save] items changes. B B: Replacing the steering lock actuator ASSY (steering lock ECM) A: Go to Next Step
3. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
4. Checking the harnesses and connectors (grounding) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
5. Inspection of the steering lock actuator ASSY (steering lock ECM) Reconnect the D59 connector of the steering lock actuator ASSY (steering lock ECM). Measure the resistance according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value Positive (+) tester examination -->D59-4 (SLP) Ground (-) tester examination -->chassis ground The steering is locked. (1) 10 kohms or more Positive (+) tester examination -->D59-4 (SLP) Ground (-) tester examination -->chassis ground The steering is unlocked. 1 ohmsor less (1) When the shift lever is in P*, if a door is opened or closed with the engine switch off, the steering wheel is locked. After that, if the engine switch turns on (ACC) or on (IG), the steering wheel is unlocked. DTC B2285 may be output if there is a problem in the steering lock ECM (steering lock actuator ASSY). The steering lock position signal and the unlock position signal are sent from the steering lock ECM (steering lock actuator ASSY) to the collation ECM (smart key ECM ASSY). *: for automatic transmission RESULT Result Go to OK A NG B B: Replacing the steering lock actuator ASSY (steering lock ECM) A: Go to Next Step
6. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - steering lock actuator ASSY (steering lock ECM)) Remove the D41 connector of the collation ECM (smart key ECM ASSY). Remove the D59 connector of the steering lock actuator ASSY (steering lock ECM). Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D41-26 (SLP) - D59-4 (SLP1) Always 1 ohmsor less D41-26 (SLP) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key ECM ASSY)

This DTC is output when the engine speed signal sent from the ECM via the direct line and the engine speed signal sent via the CAN communication do not match.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE UPON DETECTION

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Scheme 159

Scheme 160

1. Reading the values using the SSM3 (engine speed) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Engine Speed] Engine status / [stopped] or [rotating] [Stopped]: The engine is stopped. [Rotating]: The engine is turning. - Input the following menus: [Engine Control System] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ENGINE AND ECT Tester display Measurement items / range Normal condition Notes for diagnosis [Engine Speed] Engine speed / 0 - 16383 r/min Changes based on engine speed - Criteria: The [Current Data Display & Save] items change based on the engine status. RESULT Result Go to NG A OK B B: Proceed to the "EFI system" ("How to troubleshoot") A: Go to Next Step
2. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
3. Checking the harnesses and connectors (grounding) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
4. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - ECM) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A35 connector of the ECM. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D48-17 (TACH) - A35-15 (TACHO) Always 1 ohmsor less D48-17 (TACH) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
5. Unit inspection of the collation ECM (smart key ECM ASSY) Reconnect the A35 connector of the ECM. Reconnect the D48 connector of the collation ECM (smart key ECM ASSY). Refer to the table below and check the signal waveform. CRITERIA Inspection terminals Inspection conditions Standard value D48-17 (TACH) - chassis ground The engine is stopped. A pulse is not generated. The engine is turning. A pulse is generated. NG: Proceed to the "EFI system" ("How to troubleshoot") OK: Replacement of the collation ECM (smart key ECM ASSY)

These DTCs are output when a CAN communication error is found between the collation ECM (smart key ECM ASSY) and the ECM, the main body ECM, the combination meter ASSY, or the engine stop and start ECM.

Note. After removing the cable, if you reconnect it to the battery ground terminal (-), the power mode returns to the same status it was before you removed the cable.

VEHICLE STATUS AND FAILSAFE FUNCTION WHEN A PROBLEM IS DETECTED

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

1. DTC check Record the output DTC. (Refer to «DIAGNOSIS SYSTEM»(ref-619195-S40231480312014053000000) ) Next: See the "CAN communication system (How to troubleshoot)" (Refer to «HOW TO TROUBLESHOOT»(ref-619155-S21491093182014053000000) )

With the electrical key transmitter sub-assembly in the vehicle interior, press the engine switch. The collation ECM (smart key ECM ASSY) receives the signal and the power mode changes. With the shift lever in P *1 or N *1, if you step on the brake pedal *1 or the clutch pedal *2 and press the engine switch, you can start the engine.

*1: With automatic transmission

*2: for manual transmission

Note. Only if the steering lock is unlocked, even if the shift lever is in the N position, you can start the engine. * In IG ON, if the shift lever is in a position other than P, if you press the engine switch, the power changes to ACC ON. After that, if you move the shift lever to P and press the engine switch while stepping on the brake pedal, the power changes to IG OFF. * If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

*: for automatic transmission

RELATED [CURRENT DATA DISPLAY & SAVE] AND [SYSTEM OPERATION CHECK MODE] ITEMS

Note. With the engine stopped, if you repeatedly step on the brake pedal, the brake booster pressure is released. This increases the force on the brake pedal necessary to make the stop light turn on.*

*: for automatic transmission

Scheme 161

1. Checking the battery Measure the battery voltage. Voltage: 11 to 14 V NOTE: You can check if the vehicle battery is discharged by operating the horn. If the battery voltage is 11 V or less, it is necessary to charge or replace the battery. OK: Go to Next Step
2. Checking the DTC (all) Using the SSM3, check the DTC output for all systems. Criteria: No DTC is output NG: Proceed to "List of diagnostic codes". (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-619195-S29564556572014053000000) ) OK: Go to Next Step
3. Checking the waveform environment If a problem occurs only in certain places or at certain times, it is likely the effect of radio wave interference. NOTE: You can check if the problem is due to radio wave interference or not by holding the electrical key transmitter ASSY up to the door control receiver (RF band). Next
4. Checking the engine switch status Enter the vehicle interior holding the electrical key transmitter sub-assembly. Put the shift lever in the P position.* *: for automatic transmission Stepping on the brake pedal *1 or the clutch pedal *2, press the engine switch, and check that the power mode changes. *1: With automatic transmission *2: for manual transmission RESULT Result Go to The power mode changes in the following way (functioning properly): OFF -->ACC ON -->IG ON -->OFF A The power mode does not change to IG ON or ACC ON. B The power mode does not change to IG ON but does change to ACC ON. C The power mode does not change to ACC ON but does change to IG ON. D B: See " «THE POWER MODE DOES NOT CHANGE TO ON (IG AND ACC)»(ref-619195-S34103250952014053000000) " (Refer to ) C: See " «THE POWER MODE DOES NOT CHANGE TO ON (IG)»(ref-619195-S15619040752014053000000) " (Refer to ) D: See " «THE POWER MODE DOES NOT CHANGE TO ON (ACC)»(ref-619195-S06888210032014053000000) " (Refer to ) A: Go to Next Step
5. Checking the cranking function Enter the vehicle interior holding the electrical key transmitter sub-assembly. Put the shift lever in the P position.* *: for automatic transmission Step on the brake pedal *1 or the clutch pedal *2. *1: With automatic transmission *2: for manual transmission If the entry key indicator light of the combination meter ASSY lights up green, press the engine switch, and check that the engine cranks. Criteria: The engine cranks. RESULT Result Go to NG A OK B B: See the " «EFI SYSTEM (FA20)»(ref-619158-S02351510182014053000000) " (Symptom table) A: Go to Next Step
6. Reading the values using the SSM3 (immobilizer) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [Immobilizer] Immobilizer system status, as determined by the collation ECM (smart key ECM ASSY) / [Set] or [Unset] [Set]: The engine immobilizer is set (starting the engine is prohibited) (IG OFF) [Unset]: The engine immobilizer is not set (starting the engine is permitted) (ACC ON or IG ON) If the immobilizer cannot be unset, this item is used to check if the collation ECM (smart key ECM ASSY) is causing the problem. If this item is [Set], the engine will not start. Criteria: When the power changes to ACC ON or IG ON, the [Current Data Display & Save] item changes to unset. RESULT Result Go to OK A NG (when there is an ID code box) B NG (when there is no ID code box) C B: Go to Step 10 . C: Go to Step 11 . A: Go to Next Step
7. Checking the combination meter ASSY (entry key indicator light) While carrying the electrical key transmitter sub-assembly, enter the vehicle interior, put the shift lever in P *1, and while stepping on the brake pedal *1 or the clutch pedal *2, check if the entry key indicator light of the combination meter ASSY changes. *1: With automatic transmission *2: for manual transmission Criteria: The entry key indicator light lights up green. NOTE: When performing the above procedure, if the entry key indicator of the combination meter ASSY lights up green, P, N, the brake pedal *1, and the clutch pedal *2 are operating properly. *1: With automatic transmission *2: for manual transmission RESULT Result Go to OK A NG (with automatic transmission) B NG (with manual transmission) C B: Go to Step 14 . C: Go to Step 20 . A: Go to Next Step
8. Reading the values using the SSM3 (STARTER REQUEST SIGNAL) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Starter request signal monitor] Status of the engine start command signal 1 / [OFF] or [ON] [OFF]: The engine switch is released after approx. 1 second. [ON]: Put the shift lever in P (1) , step on the brake pedal (1) or the clutch pedal (2) , and holding the electrical key transmitter ASSY, press the engine switch. If the engine does not start due to a problem in the start request signal, [OFF] is displayed. If you press the engine switch, the time [ON] is displayed will be very short. Therefore, it is necessary to press and hold the engine switch for a certain amount of time. (1) With automatic transmission (2) for manual transmission Criteria: The displayed contents change according to the engine switch operation. CAUTION: Before you press the engine switch, check that the entry key indicator of the combination meter ASSY lights up green. NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Go to Next Step
9. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - chassis ground) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A33 connector of the ECM. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value D48-7 (STSW) - A33-17 (START) Always 1 ohmsor less D48-7 (STSW) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: See the " «EFI SYSTEM (FA20)»(ref-619158-S02351510182014053000000) " (Symptom table)
10. Reading the values using the SSM3 (S Code Check) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [S Code Check] Confirmation result of the collation ECM (smart key ECM ASSY) code and the ID code box (immobilizer code ECM) code / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The S code is not registered for the collation ECM (smart key ECM ASSY) and the ID code box (immobilizer code ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: OK (OK result of the S Code Check) is displayed on the screen. NG: Go to Step 23 . OK: Go to Next Step
11. Checking the steering lock When in ACC ON, check that the steering can be unlocked. Criteria: The steering is unlocked. NG: Go to Step 25 . OK: Go to Next Step
12. Reading the values using the SSM3 (IMMOBILISER) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [Immobilizer] Immobilizer system status, as determined by the collation ECM (smart key ECM ASSY) / [Set] or [Unset] [Unset]: The engine immobilizer is not set (ACC ON or IG ON) [Set]: The engine immobilizer is set (IG OFF) If the immobilizer cannot be unset, this item is used to check if the collation ECM (smart key ECM ASSY) is causing the problem. If this item is [Set], the engine will not start. Criteria: When the power changes to ACC ON or IG ON, the [Current Data Display & Save] items changes to unset. RESULT Result Go to OK A NG (when there is an ID code box) B NG (when there is no ID code box) C B: Go to Step 29 . C: Replacement of the collation ECM (smart key ECM ASSY) A: Go to Next Step
13. Reading the values using the SSM3 (STARTER REQUEST SIGNAL) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Starter request signal monitor] Status of the engine start command signal 1 / [OFF] or [ON] [OFF]: The engine switch is released after approx. 1 second. [ON]: Put the shift lever in P (1) , step on the brake pedal (1) or the clutch pedal (2) , and holding the electrical key transmitter ASSY, press the engine switch. If the engine does not start due to a problem in the start request signal, [OFF] is displayed. If you press the engine switch, the time [ON] is displayed will be very short. Therefore, it is necessary to press and hold the engine switch for a certain amount of time. (1) With automatic transmission (2) for manual transmission Criteria: The displayed contents change according to the engine switch operation. CAUTION: Before you press the engine switch, check that the entry key indicator of the combination meter ASSY lights up green. NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Complete
14. Reading the values using the SSM3 (NEUTRAL SW / CLUTCH SW, SHIFT SWITCH STATUS P OR N) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Neutral SW/Clutch SW] Shift position (P, N) / [OFF] or [ON] [OFF]: The shift lever is not in P or N, the pedal is not being stepped on [ON]: The shift lever is in P or N, the pedal is being stepped on. Using this item, determine if there is any problem with the parking / neutral position switch. When this item is [OFF], the engine will not start. Input the following menus: [Engine Control System] -->[Current Data Display & Save] ENGINE AND ECT Tester display Measurement items / range Normal condition Notes for diagnosis [Shift SW Status (P Range)] Status of the parking / neutral position switch / [OFF] or [ON] [OFF]: The shift lever is not in P [ON]: The shift lever is in P. If a problem is found, the engine will not crank. [Shift SW Status (N Range)] Status of the parking / neutral position switch / [OFF] or [ON] [OFF]: The shift lever is not in N [ON]: The shift lever is in N. If a problem is found, the engine will not crank. Criteria: The [Current Data Display & Save] items change based on the shift position. NG: Go to Step 16 . OK: Go to Next Step
15. Reading the values using the SSM3 (STOP LIGHT SWITCH 1) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Stop Light Switch 1] Brake pedal status / [OFF] or [ON] [OFF]: The brake pedal is not being stepped on [ON]: The brake pedal is being stepped on Using this item, determine if there is any problem with the parking / neutral position switch. When this item is [OFF], the engine will not start. If there is a problem caused by this item, if you press the engine switch for a certain amount of time, you can start the engine. Criteria: If you remove your foot after stepping on the brake pedal, the [Current Data Display & Save] item changes. NG: Go to Step 18 . OK: Replacement of the collation ECM (smart key computer ASSY)
16. Unit inspection of the parking / neutral position switch ASSY Remove the parking / neutral position switch ASSY. Inspect the parking / neutral position switch ASSY. NG: Replacement of the parking / neutral position switch ASSY OK: Go to Next Step
17. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - parking / neutral position switch ASSY) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the L2 connector of the parking / neutral position switch ASSY. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D48-5 (N-SW) - L2-1 Always 1 ohmsor less L2-9 - Chassis ground Always 1 ohmsor less D48-5 (N-SW) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)
18. Unit inspection of the stop light switch ASSY Remove the stop light switch ASSY. (Refer to «REMOVAL»(ref-619164-S07479277662014060900000) ) Inspect the stop light switch ASSY. (Refer to «UNIT INSPECTION»(ref-619164-S00855877582014060900000) ) NG: Replacement of the stop light switch ASSY OK: Go to Next Step
19. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - stop light switch ASSY) (Refer to «DTC B2285 [STEERING LOCK POSITION SIGNAL ABNORMAL]»(ref-619195-S33945276412014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)
20. Reading the values using the SSM3 (NEUTRAL SW / CLUTCH SW) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Neutral SW/Clutch SW] Clutch pedal status / [OFF] or [ON] [OFF]: The brake pedal is not being stepped on [ON]: The brake pedal is being stepped on Using this item, determine if there is any problem with the clutch position switch. When this item is [OFF], the engine will not start. Criteria: Based on the status of the clutch pedal, [ON] (stepping on the clutch pedal) and [OFF] (your foot removed from the clutch pedal) are displayed on the screen. NG: Go to Step 21. OK: Replacement of the collation ECM (smart key computer ASSY)
21. Unit inspection of the clutch start switch ASSY Remove the clutch start switch ASSY. (Refer to «INSTALLATION»(ref-619187-S36611574332014053000000) ) Inspect the clutch start switch ASSY. (Refer to «ON-VEHICLE INSPECTION»(ref-619187-S01483217412014053000000) ) NG: Repair or replacement of wiring harness or connector OK: Go to Next Step
22. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - clutch start light switch ASSY) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A20 connector of the clutch start switch ASSY. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D48-10 (CLUT) - A20-2 Always 1 ohmsor less D48-10 (CLUT) - chassis ground Always 10 kohms or more Reconnect the A20 connector of the clutch start switch ASSY. Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D48-10 (CLUT) - chassis ground Remove your foot from the clutch pedal -->step on the clutch pedal 1V or less -->9 V or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)
23. Replacement of the collation ECM (smart key computer ASSY) Replace the collation ECM (smart key ECM ASSY) with a new one. CAUTION: When replacing the collation ECM (smart key ECM ASSY), it is also necessary to replace all the electrical key transmitter subassemblies. Perform the registration settings. (Refer to the "immobilizer registration manual") Using [Current Data Display & Save], check if S code collation is functioning properly. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [S Code Check] Confirmation result of the collation ECM (smart key ECM ASSY) code and the ID code box (immobilizer code ECM) code / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The S code is not registered for the collation ECM (smart key ECM ASSY) and the ID code box (immobilizer code ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: [OK] is displayed on the screen. NG: Go to Step 24. OK: Complete
24. Replacement of the ID code box (immobilizer code ECM) Replace the ID code box (immobilizer code ECM) with a new one. Perform the registration settings. (Refer to the "immobilizer registration manual") Using [Current Data Display & Save], check if S code collation is functioning properly. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [S Code Check] Confirmation result of the collation ECM (smart key ECM ASSY) code and the ID code box (immobilizer code ECM) code / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The S code is not registered for the collation ECM (smart key ECM ASSY) and the ID code box (immobilizer code ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: [OK] is displayed on the screen. Next: Complete
25. Reading the values using the SSM3 (STEERING UNLOCK SWITCH) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Steering unlock SW] Status of the steering lock sensor output from the steering lock actuator ASSY / [OFF] or [ON] [OFF]: The steering is locked. [ON]: The steering is unlocked. When the shift lever is in P, if a door is opened or closed with the engine switch off, the steering is locked. If the electrical key transmitter ASSY is in the vehicle interior, and the engine switch is on (ACC) or on (IG), the steering is unlocked. If the steering unlock signal is off, the engine will not start. Criteria: [ON] is displayed for the [Current Data Display & Save] item (Steering lock is unlocked). NG: Go to Step 26. OK: See " «STEERING LOCK SYSTEM»(ref-619170-S32752287462014053000000) " (steering lock cannot be unlocked)
26. Reading the values using the SSM3 (L Code Check) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Collation ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [L Code Check] Confirmation result of the ID code box (immobilizer code ECM) code and the steering lock actuator ASSY (steering lock ECM) / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The L code is not registered for ID code box (immobilizer code ECM) or the steering lock actuator ASSY (steering lock ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: If the electrical key transmitter ASSY is in the vehicle interior, the [Current Data Display & Save] item changes to [OK]. NOTE: Reasons for confirmation failure: There is a problem in the steering lock ECM and ID code box (immobilizer code ECM)*. There is a problem in communications between ECMs. The ECM was replaced, but is not yet registered. The ECM was replaced with an ECM that has a code that was already registered. *: The ID code box is included. NG: Go to Step 28 . OK: Go to Next Step
27. Replacement of the steering lock actuator ASSY (steering lock ECM) Replace the steering lock actuator ASSY (steering lock ECM) with a new one. Perform the registration settings. (Refer to the "immobilizer registration manual") Turn the ignition switch to ON. Operate the steering wheel to check the steering status. Next: Complete
28. Replacement the steering lock actuator ASSY (steering lock ECM) Replace the steering lock actuator ASSY (steering lock ECM) with a new one. Perform the registration settings. (Refer to the "immobilizer registration manual") Using [Current Data Display & Save], check if L code collation is functioning properly. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [L Code Check] Confirmation result of the ID code box (immobilizer code ECM) code and the steering lock actuator ASSY (steering lock ECM) / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The L code is not registered for ID code box (immobilizer code ECM) or the steering lock actuator ASSY (steering lock ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: OK ([L Code Check] OK) is displayed on the screen. RESULT Result Go to OK A NG (when there is an ID code box) B NG (when there is no ID code box) C B: Replacement of the ID code box (immobilizer code ECM) C: Replacement of the collation ECM (smart key computer ASSY) A: Go to Next Step
29. Replacement of the collation ECM (smart key computer ASSY) Replace the collation ECM (smart key ECM ASSY) with a new one. Perform the registration settings. (Refer to the "immobilizer registration manual") Using [Current Data Display & Save], check if S code collation is functioning properly. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [S Code Check] Confirmation result of the collation ECM (smart key ECM ASSY) code and the ID code box (immobilizer code ECM) code / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The S code is not registered for the collation ECM (smart key ECM ASSY) and the ID code box (immobilizer code ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: [OK] is displayed on the screen. NG: Go to Step 30. OK: Complete
30. Replacement of the ID code box (immobilizer code ECM) Replace the ID code box (immobilizer code ECM) with a new one. Perform the registration settings. (Refer to the "immobilizer registration manual") Using [Current Data Display & Save], check if S code collation is functioning properly. ENTRY & START Tester display Measurement items / range Normal condition Notes for diagnosis [S Code Check] Confirmation result of the collation ECM (smart key ECM ASSY) code and the ID code box (immobilizer code ECM) code / [OK] or [NG] [OK]: Normal confirmation result [NG]: Abnormal confirmation result If [NG] is displayed: The S code is not registered for the collation ECM (smart key ECM ASSY) and the ID code box (immobilizer code ECM). The steering is not locked. The steering is not unlocked (you cannot start the engine). Criteria: [OK] is displayed on the screen. Next: Complete

If any of the following operations are performed, the collation ECM (smart key ECM ASSY) receives a signal and changes the power mode.

1. When the electrical key transmitter sub-assembly is in the vehicle interior, press the engine switch.
2. When the transmitter battery of the electrical key transmitter sub-assembly is drained, step on the brake pedal *1 or the clutch pedal *2, and hold the electrical transmitter sub-assembly up to the engine switch.
3. If the entry cancel function has been customized, while stepping on the brake pedal *1 or the clutch pedal *2, hold the electrical key transmitter sub-assembly up to the engine switch.

*1: With automatic transmission

*2: With manual transmission

Note. If you remove and then reconnect the battery cable, the power returns to the power mode it was before you removed the cable. Related [Current Data Display & Save] and [System Operation Check Mode] items

Scheme 162

Scheme 163

Scheme 164

Scheme 165

1. Checking the wireless door lock control system (operation) Check that the wireless door lock function operates properly. (Refer to «OPERATION CHECK»(ref-619203-S19412758132014053000000) ) Criteria: The wireless door and lock function operates properly. NG: See "Entry & Start system" (The entry lock / unlock function and wireless function for all doors does not function) (Refer to «NEITHER SMART LOCK NOR SMART UNLOCK OPERATION WORKS ON ANY OF THE DOORS (WIRELESS FUNCTION DOES NOT WORK EITHER)»(ref-619199-S39377370932014053000000) ) OK: Go to Next Step
2. Checking the harnesses and connectors (power supply) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors of the circuits that connect to the power source OK: Go to Next Step
3. Checking the harnesses and connectors (GND) (Refer to «INSPECTION STEPS»(ref-619195-S06733884532014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
4. Checking the entry & start system Remove the battery from the electrical key transmitter sub-assembly. (Refer to «TRANSMITTER BATTERY (WITH SMART ENTRY)»(ref-619180-S06587919982014053000000) ) Step on the brake pedal *1 or the clutch pedal *2, and touch the logo side of the electrical key transmitter sub-assembly to the engine switch. *1: With automatic transmission *2: for manual transmission When you touch the logo side of the electrical key transmitter sub-assembly to the engine switch, check if the power mode changes. Criteria: The power mode changes. NOTE: If the power mode does not change, there is a problem in the cabin confirmation function. RESULT Result Go to NG (The power mode does not change) A OK (The power mode changes) B B: Go to Step 13 . A: Go to Next Step
5. Reading the values using the SSM3 (STOP LIGHT SWITCH 1, NEUTRAL SW / CLUTCH SW) With automatic transmission Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Stop Light Switch 1] Brake pedal status / [OFF] or [ON] [OFF]: The brake pedal is not being stepped on [ON]: The brake pedal is being stepped on Using this item, determine if there is any problem with the stop light switch. When this item is [OFF], the engine will not start. If there is a problem caused by this item, if you press the engine switch for a certain amount of time, you can start the engine. Criteria: Based on the status of the stop light switch, "ON" (stepping on the brake pedal) and "OFF" (your foot removed from the brake pedal) are displayed on the screen. With manual transmission Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Neutral SW/Clutch SW] Clutch pedal status / [OFF] or [ON] [OFF]: The brake pedal is not being stepped on [ON]: The brake pedal is being stepped on Using this item, determine if there is any problem with clutch switch. When this item is [OFF], the engine will not start. Criteria: Based on the status of the stop light switch, [ON] (stepping on the clutch pedal) and [OFF] (your foot removed from the clutch pedal) are displayed on the screen. RESULT Result Go to OK A NG (with automatic transmission) B NG (with manual transmission) C B: Go to Step 8 . C: Go to Step 10 . A: Go to Next Step
6. Reading the values using the SSM3 (POWER SUPPLY CONDITION) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Power supply status] Power supply status / [All OFF], [IG1 ON] or [ACC ON], [IG2 ON], [ST ON] [All OFF]: Engine switch off (ACC and IG) [ACC ON]: The engine switch is on (ACC) [IG1 ON]: The engine switch is on (IG) (IG1 relay on) [IG2 ON]: The engine switch is on (IG) (IG2 relay on) [ST ON]: The engine start request signal is sent. Because [IG1 ON] and [IG2 ON] occur almost simultaneously, [IG1] may not be displayed ([IG1 ON] is displayed for a very short period of time). Criteria: Based on the change of power mode when you pressed the engine switch, the change contents are displayed. NG: Go to Step 12 . OK: Go to Next Step
7. Inspection of the collation ECM (smart key ECM ASSY) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [Power supply status] Power supply status / [All OFF], [IG1 ON] or [ACC ON], [IG2 ON], [ST ON] [All OFF]: Engine switch off (ACC and IG) [ACC ON]: The engine switch is on (ACC) [IG1 ON]: The engine switch is on (IG) (IG1 relay on) [IG2 ON]: The engine switch is on (IG) (IG2 relay on) [ST ON]: The engine start request signal is sent. Because [IG1 ON] and [IG2 ON] occur almost simultaneously, [IG1] may not be displayed ([IG1 ON] is displayed for a very short period of time). Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D41-6 (IG1D) - chassis ground IG OFF 1 V or less ACC ON 1 V or less IG ON 9 V or more D48-9 (IG2D) - chassis ground IG OFF 1 V or less ACC ON 1 V or less IG ON 9 V or more D41-4 (ACCD) - chassis ground IG OFF 1 V or less ACC ON 8.5 V or more IG ON 8.5 V or more NG: Replacement of the collation ECM (smart key ECM ASSY) OK: Checking the circuits connected to the relay
8. Unit inspection of the stop light switch ASSY Remove the stop light switch ASSY. (Refer to «REMOVAL»(ref-619164-S07479277662014060900000) ) Inspect the stop light switch ASSY. (Refer to «UNIT INSPECTION»(ref-619164-S00855877582014060900000) ) NG: Replacement of the stop light switch ASSY
9. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - stop light switch ASSY) (Refer to «DTC B2285 [STEERING LOCK POSITION SIGNAL ABNORMAL]»(ref-619195-S33945276412014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)
10. Unit inspection of the clutch start switch ASSY Remove the clutch start switch ASSY. (Refer to «INSTALLATION»(ref-619187-S36611574332014053000000) ) Inspect the clutch start switch ASSY. (Refer to «ON-VEHICLE INSPECTION»(ref-619187-S01483217412014053000000) ) NG: Replacement of the clutch start switch ASSY OK: Go to Next Step
11. Checking the harnesses and connectors Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the A20 connector of the clutch start switch ASSY. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D48-10 (CLUT) - A20-1 Always 1 ohmsor less D48-10 (CLUT) - chassis ground Always 10 kohms or more Reconnect the A20 connector of the clutch start switch ASSY. Measure the voltage according to the following table. VOLTAGE Tester display Inspection conditions Standard value D48-10 (CLUT) - chassis ground Remove your foot from the clutch pedal -->step on the clutch pedal 1V or less -->9 V or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)
12. DTC check Check for DTC. (Refer to «DIAGNOSIS SYSTEM»(ref-619195-S40231480312014053000000) ) RESULT Result Go to No DTC is output A DTC B2784 is output B DTC B2785 is output C B: Proceed to "List of diagnostic codes" (B2784) (Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-619188-S37656271052014053000000) ) C: Proceed to "List of diagnostic codes" (B2785) A: Replacement of the electrical key transmitter sub-assembly
13. Reading the values using the SSM3 (START SWITCH 1, 2) Connect the SSM3 to the DLC3. Turn the ignition switch to ON. Turn on the SSM3. Input the following menus: [Keyless access system] -->[Power Supply ECM] -->[Current Data Display & Save] Based on the contents of the SSM3 display, read the [Current Data Display & Save]. POWER SOURCE CONTROL Tester display Measurement items / range Normal condition Notes for diagnosis [System SW1] Connection status of the engine switch 1 / [OFF] or [ON] [OFF]: The engine switch is not being pushed. [ON]: The engine switch is being pushed. If the engine switch is not pressed for a long enough time, the display contents may not change. Using this item, determine if there is any problem with the engine switch input signal. [System SW2] Connection status of the engine switch 2 / [OFF] or [ON] [OFF]: The engine switch is not being pushed. [ON]: The engine switch is being pushed. Back-up for engine switch 1. If you press the engine switch, the control function only works if the both engine switch 1 and 2 are operating properly. Works in the same way as engine switch 1. Criteria: According to the engine switch operation, the [Current Data Display & Save] display contents are changed. RESULT Result Go to NG A OK B B: Proceed to "Entry & Start system" (entry function) (ROOM OSCILLATOR does not recognize the key) (Refer to «ENTRY & START SYSTEM (START FUNCTION)»(ref-619195-S13997923402014053000000) ) A: Go to Next Step
14. Unit inspection of the engine switch Remove the engine switch ASSY. Inspect the engine switch ASSY. NG: Replacement of the engine switch OK: Go to Next Step
15. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - engine switch) Remove the D41 connector of the collation ECM (smart key ECM ASSY). Remove the D25 connector of the engine switch. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D41-28 (SSW1) - D25-5 (SS1) Always 1 ohmsor less D41-30 (SSW2) - D25-1 (SS2) Always 1 ohmsor less D41-28 (SSW1) - chassis ground Always 10 kohms or more D41-30 (SSW2) - chassis ground Always 10 kohms or more NG: Repair or replacement of the harnesses or connectors OK: Replacement of the collation ECM (smart key computer ASSY)

With the electrical key transmitter sub-assembly in the vehicle interior, press the engine switch. The collation ECM (smart key ECM ASSY) receives the signal and the power mode changes.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

Scheme 166

Scheme 167

Scheme 168

1. Checking the harnesses and connectors (collation ECM (smart key ECM ASSY) - IG2 relay) Remove the D48 connector of the collation ECM (smart key ECM ASSY). Remove the IG2 relay from the engine compartment relay block. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D48-9 (IG2D) - IG2 relay terminal 2 Always 1 ohmsor less IG2 relay terminal 1 - chassis ground Always 1 ohmsor less NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
2. Unit inspection of the IG2 relay Inspect the IG2 relay unit. NG: Replacement of the IG2 relay OK: Go to Next Step
3. Checking the harnesses and connectors (collation ECM - instrument panel junction block ASSY) Remove the D41 connector of the collation ECM (smart key ECM ASSY). Remove the 3A connector of the instrument panel junction block ASSY. Measure the resistance according to the following table. RESISTANCE Tester display Inspection conditions Standard value D41-6 (IG1D) - 3A-15 Always 1 ohmsor less 3A-12 - chassis ground Always 1 ohmsor less NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
4. Unit inspection of the instrument panel junction block ASSY (IG1 NO. 1, IG1 NO. 2, IG1 NO. 3, IG1 NO. 4 relay) Remove the instrument panel junction block ASSY. Remove the main body ECM (multiplex network body ECM) from the instrument panel junction block ASSY. Measure the resistance according to the following table. RESISTANCE Inspection terminals Inspection conditions Standard value 3E-1 - 3C-35 Battery voltage is not applied to terminals 3A-15 and 3A-12. 10 kohms or more Battery voltage is applied to terminals 3A-15 and 3A-12. 1 ohmsor less 3E-1 - 3C-34 Battery voltage is not applied to terminals 3A-15 and 3A-12. 10 kohms or more Battery voltage is applied to terminals 3A-15 and 3A-12. 1 ohmsor less 3E-1 - 3A-32 Battery voltage is not applied to terminals 3A-15 and 3A-12. 10 kohms or more Battery voltage is applied to terminals 3A-15 and 3A-12. 1 ohmsor less 3E-1 - 3A-3 Battery voltage is not applied to terminals 3A-15 and 3A-12. 10 kohms or more Battery voltage is applied to terminals 3A-15 and 3A-12. 1 ohmsor less NG: Replacement of the instrument panel junction block ASSY OK: Go to Next Step
5. Inspection of the collation ECM (smart key ECM ASSY) Reconnect the D41 and the D48 connectors of the collation ECM (smart key ECM ASSY). Measure the voltage according to the following table. VOLTAGE Inspection terminals Inspection conditions Standard value D41-6 (IG1D) - chassis ground ACC ON -->IG ON 1V or less -->9 V or more D48-9 (IG2D) - chassis ground ACC ON -->IG ON 1V or less -->9 V or more NG: Replacement of the collation ECM (smart key computer ASSY) OK: Checking the circuits connected to the relay

With the electrical key transmitter sub-assembly in the vehicle interior, press the engine switch. The collation ECM (smart key ECM ASSY) receives the signal and the power mode changes. If the power mode does not change to ACC ON but does change to IG ON, use these troubleshooting procedures.

Note. If you remove and then reconnect the battery cable, the power returns to the mode it was before you removed the cable.

Scheme 169

1. Checking the harnesses and connectors (instrument panel junction block ASSY - collation ECM) (Refer to «INSPECTION STEPS»(ref-619195-S33802691362014053000000) ) NG: Repair or replacement of the harnesses or connectors OK: Go to Next Step
2. Unit inspection of the instrument panel junction block ASSY (ACC relay) (Refer to «INSPECTION STEPS»(ref-619195-S33802691362014053000000) ) NG: Replacement of the instrument panel junction block ASSY OK: Go to Next Step
3. Inspection of the collation ECM (smart key ECM ASSY) (Refer to «DTC B2275 [STSW CIRCUIT ABNORMAL]»(ref-619195-S07174579192014053000000) ) NG: Replacement of the collation ECM (smart key computer ASSY) OK: Checking the circuits connected to the relay
