Horn System: Removal & Installation Subaru BRZ ZC

Installation

1. Installation of the low-pitched horn ASSY Using the bolt, install the low-pitched horn ASSY. Standard value: T=18N.m {184kgf.cm} {13.3ft.lbf} Connect the connector.
2. Installation of the horn bracket Using the bolt and nut, install the horn bracket on the high-pitched horn ASSY. Standard value: T=18N.m {184kgf.cm} {13.3ft.lbf}
3. Installation of the high-pitched horn ASSY Using the bolt, install the high-pitched horn ASSY as a unit with the horn bracket. Standard value: T=13N.m {132kgf.cm} {9.6ft.lbf} Connect the connector.
4. Installation of the front bumper cover (Refer to «INSTALLATION»(ref-619181-S05475449692014053000000) )

Scheme 7

Scheme 8

1. Inspection of the high-pitched horn ASSY Inspect if the high-pitched horn ASSY sounds when battery voltage is applied between each connector terminal. CRITERIA Inspection terminals Criteria Battery positive -->1 Battery ground -->2 The high-pitched horn ASSY sounds.
2. Inspection of the low-pitched horn ASSY Inspect if the low-pitched horn ASSY sounds when battery voltage is applied between the terminal and the bracket. CRITERIA Inspection terminals Criteria Battery positive -->1 Battery ground -->bracket The low-pitched horn ASSY sounds.
