General Information & Specifications: Other Subaru BRZ ZC

List of procedures

1. List of replacement procedures Replaced parts and procedures Required procedures Possible phenomena/unavailable functions (unless required procedure is performed) Refer To Engine control computer 1. ID code registration Engine start inoperable Refer to "Immobilizer Registration Manual" for registration procedures. Transmission control computer ASSY Automatic transmission ASSY Transmission valve body ASSY Transmission wire Each solenoid Engine ASSY 1. AT learning values initialization High revving of engine Large shift shock «CHECKING PROBLEMS THAT DO NOT CONSTANTLY OCCUR»(ref-619150-S06245223752014053000000) Brake actuator ASSY Steering sensor Steering column ASSY Rack & pinion power steering gear ASSY Front wheel alignment adjustment 1. VSC sensor mid point setting VSC system does not operate normally (warning light is illuminated) «WORK SUPPORT»(ref-619151-S00270732952014053000000) Power steering computer ASSY 1. Steering zero point calibration. P/S warning light illumination EPS control «WORK SUPPORT»(ref-619152-S38082779532014053000000) Steering column ASSY 1. Steering zero point calibration. Different left/right steering control force «WORK SUPPORT»(ref-619152-S38082779532014053000000) With smart entry Electrical key transmitter SUB-ASSY ID CODE BOX (IMMOBILIZER CODE ECU) Smart key computer ASSY (collation ECM) Steering lock actuator ASSY (steering lock ECM) 1. ID code registration Wireless function Smart function Engine start inoperable Refer to "Immobilizer Registration Manual" for registration procedures. No smart entry Key Main body ECM (network gateway computer) TRANSPONDER KEY ECM Combination meter ASSY 1. ID code registration Engine start inoperable Refer to "Immobilizer Registration Manual" for registration procedures. Power window regulator motor ASSY (RH, LH) Front door window regulator SUB-ASSY RH (RH, LH) Front door glass SUB-ASSY (RH, LH), front door frame SUB-ASSY RR LWR (RH, LH) or front door sash (RH, LH) Front door opening trim weather strip (RH, LH) 1. Power window system initialization Door glass automatic opening/closing function Anti-pinching function Operating functions after key OFF (IG OFF) Seat remote operation using driver's seat switch «REGISTRATION SETTINGS»(ref-619153-S22744377692014053000000) Main body ECM (network gateway computer) 1. Customize Functions are inoperable «WORK SUPPORT»(ref-619154-S24632178142014053000000)

Scheme 27

1. Engine oil Specified oil Viscosity grade Quality grade 0W-20 (synthetic oil) For API certified: Products with SM "Energy Conserving" or SN "Resource Conserving" logos. For ILSAC certified: Products with GF-4 or GF-5 "Starburst mark" displayed on the container. CAUTION: Use 0W-20 (synthetic oil). When replacing the oil, it is acceptable to use a different brand oil but Subaru-specified engine oil should be used. Amount Engine type Only replacing oil Filling amount (L {US qt, Imp qt}) Oil and oil filter Filling amount at oil replacement (L {US qt, Imp qt}) FA20 5.2 {5.5, 4.6} 5.5 {5.8, 4.8} NOTE: The filling amount at engine oil replacement is the value when oil is drained from the drain plug.
2. Oils/Coolants other than engine oil CAUTION: For AT, using any ATF other than recommended product may cause malfunctions. Be sure to use the recommended product. For transmission gear oil and rear differential gear oil, use gear oil specified in the table below. When using the substitute product, the function and performance may be inferior. Item [Type] Amount (L {US qt, Imp qt}) (reference value) Recommended product Substitute product Coolant [FA20] 7.5 {15.9, 6.6} (AT) SUBARU Super Coolant (Diluted type) - 7.2 {15.2, 6.3} (MT) Automatic transmission fluid [TX6A] 7.5 {15.9, 6.6} Auto fluid WS - Manual transmission oil [TL70] 2.2 {4.7, 1.9} MG gear oil special II (API GL-3, SAE 75W-90) GL-3 or later (75W-90) Rear differential oil 1.1 to 1.2 {2.3 to 2.5, 1.0 to 1.1} (with LSD) Differential gear oil LX (API GL-5, SAE 75W-85) GL-5 (75W-85 or 75W-90) Clutch fluid - FMVSS No. 116 DOT3 or DOT4 - Brake fluid - FMVSS No. 116 DOT3 or DOT4 - A/C compressor oil - ND-OIL8

Procedures for malfunction phenomenon simulation

Note. The most difficult thing in troubleshooting is when there is no appearance of a malfunction phenomenon. In such cases, it is necessary to thoroughly analyze the malfunction information provided by the customer, and recreate the same conditions/environment of the customer's vehicle that existed when the malfunction occurred. Performing troubleshooting without confirming the malfunction phenomenon results in overlooking important points of repair procedures and making mistakes such that, ultimately, troubleshooting reaches a dead end. For example, checking a malfunction that occurs when starting a cold engine with the engine already warmed-up, or checking for a vibration that occurs while driving on the road with the vehicle stopped limit the amount of checking and makes it impossible to identify the malfunction location. Although there are malfunction with causes that cannot be reproduced, such as vibration, heat or entrance of water (moisture), the procedures indicated here for malfunction phenomenon reproduction are effective means in terms of providing for external causes when a vehicle is stopped.

Important points of malfunction simulation test

Although it is necessary to check the malfunction phenomenon using malfunction phenomenon reproduction procedures, it is necessary to also find the malfunction scope/location. Doing this requires you to narrow down the circuits containing the malfunction based on the malfunction phenomenon before performing tests and connect the tester beforehand. Afterwards, perform the malfunction reproduction procedures, and determine the circuits that are faulty and those that are normal during the testing while also checking the malfunction phenomenon. Refer to the malfunction phenomenon list for each system to narrow down the cause of the malfunction phenomenon. It is also necessary to use reproduction procedures that are according to the corresponding detection conditions/time of the corresponding diagnostic code in order to reproduce diagnostic code output.

Scheme 28

Scheme 29

Scheme 30

1. Vibration method: For malfunctions thought to be caused by vibration Parts and sensors Lightly tap by hand on the probable malfunctioning parts or use a similar method to vibrate them, and check if any malfunction occurs. NOTE: Subjecting relays to a strong impact can cause their points to IN open. Connectors Lightly shake the connectors up/down and right/left. Wire harnesses Lightly shake the wire harnesses up/down and left/right, and check if any malfunction occurs. NOTE: It is especially important to check the connector bases, vibration fulcrums and areas passing through the body.
2. Cooling/Heating method: For malfunctions thought to occur when cooled or heated Heat up or cool down (using a hair drier or coolant) the probable malfunctioning parts, and check if any malfunction occurs. CAUTION: If heating: Do not heat by +60°C (can be touched by hand) or more. Do not heat or cool with the cover of the ECM or similar parts open so as to not directly heat or cool any electrical parts. NOTE: Coolant can be purchased at electrical parts stores.
3. Water sprinkling method: For malfunctions thought to occur during rain or high temperature Sprinkle water on the vehicle and check if any malfunction occurs. CAUTION: Do not sprinkle water directly on the engine room. Spray a fine mist of water to the front surface of the radiator to indirectly change the temperature and humidity. Do not sprinkle water directly on electrical parts.
4. Other: For malfunctions thought to be caused during excessive electrical load Create an excessive electrical load by operating various electrical parts such as the heater blower, headlights and rear defogger, and check if any malfunction occurs.
