Ignition (H4DOTC): Diagnosis Subaru Baja I

INSPECTION

Check the electrodes and inner and outer porcelain of plugs, noting the type of deposits and the degree of electrode erosion.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Normal: Brown to grayish-tan deposits and slight electrode wear indicates correct spark plug heat range.
2. Carbon fouled: Dry fluffy carbon deposits on insulator and electrode are mostly caused by slow speed driving in city, weak ignition, too rich fuel mixture, dirty air cleaner, etc. It is advisable to replace with plugs having hotter heat range.
3. Oil fouled: Wet black deposits show excessive oil entrance into combustion chamber through worn rings and pistons or excessive clearance between valve guides and stems. If the same condition remains after repair, use a hotter plug.
4. Overheating: White or light gray insulator with black or brown spots and bluish burnt electrodes indicates engine overheating. Moreover, the appearance results from incorrect ignition timing, loose spark plugs, wrong selection of fuel, hotter range plug, etc. It is advisable to replace with plugs having colder heat range.

For inspection, refer to the following. Refer to IGNITION CONTROL SYSTEM , Diagnostics for Engine Starting Failure.
