LIFTS AND JACKS
When using a lift or jack-ridged rack to raise a vehicle, always follow instructions concerning jack-up points and weight limits to prevent the vehicle from falling, which could result in injury. Be especially careful to make sure the vehicle is balanced before raising it.
Scheme 1
Scheme 2
Scheme 3
| WARNING | Always use safety stands in conjunction with floor jacks. |
TIE-DOWNS
Tie downs are used when transporting vehicles and when using a chassis dynamo. Attach tie downs only to the specified points on the vehicle.
Scheme 4
Scheme 5
Scheme 6
VEHICLE SINKING VOLUME AT TIE-DOWN CONDITION
Measure the distance "L" between the tire's highest point to arch's highest point before and after tie-down.
The difference of measurement value (drop height) shall be within 50.8 mm (2.00 in).
Make sure vehicle is securely fastened.
