Generators & Regulators: Removal & Installation Subaru Baja I

Removal

1. Disconnect ground cable from battery.
2. Disconnect connector and terminal from generator. (Scheme 4)
3. Remove V-belt. See «V-BELT»(ref-167575-S24055552802004101900000).
4. Remove bolt (A), and loosen bolt (B). Then, remove generator from bracket. (Scheme 5)

Scheme 4

Scheme 5

Installation

Install in the reverse order of removal. (Scheme 5)

Note. Perform the following procedures with the engine installed to the body.

1. Remove V-belt cover. (Scheme 6)
2. Loosen the lock bolt (A). (Scheme 7)
3. Loosen the slider bolt (B).
4. Remove the front side belt (C).

Scheme 6

Scheme 7

1. Wipe off any oil or water on the belt and pulley.
2. Install a belt (C), and tighten the slider bolt so as to obtain the specified belt tension. See «BELT TENSION»(ref-167575-S04706557142004101800000). (Scheme 7)
3. Tighten the lock bolt (A).
4. Tighten slider bolt (B).
5. Install V-belt cover.
