Automatic Transmission (Diagnostics) (H4DOTC): Overview Subaru Baja I

Scheme 699

Scheme 700

OPERATION

Refer to Subaru Select Monitor for information about how to obtain and understand DTC . Refer to OPERATION .

Note. DTC can not be read through AT OIL TEMP warning light.

1. Move the select lever to "D". range, and then drive the vehicle at 60 km/h (37 MPH) for at least 10 seconds.
2. Drive vehicle in SPORT shift mode.

1. WITHOUT SUBARU SELECT MONITOR Current diagnostic trouble codes (DTC) shown on display are cleared by turning the ignition switch to OFF after conducting on-board diagnostics operation. Previous diagnostic trouble codes (DTC), however, cannot be cleared since they are stored in the TCM memory which is operating on back-up power supply. These diagnostic trouble codes (DTC) can be cleared by removing the TCM connector for at least two minutes. CLEAR MEMORY: Removal of TCM connector (B56) (for at least two minutes) The TCM connector (B56) is located in the line to memory back-up power supply of TCM. Removal of this connector clears the previous diagnostic trouble codes (DTC) stored in TCM memory. Be sure to remove the TCM connector (B56) for at least the specified length of time. Otherwise, the diagnostic trouble codes (DTC) may not be cleared.
2. WITH SUBARU SELECT MONITOR Refer to «Subaru Select Monitor»(ref-208399-S03603121382005120700000) for information about how to clear DTC . Refer to «CLEAR MEMORY MODE»(ref-208399-S29872298192005120700000) .
