ABS: Adjustments Subaru Baja I

Anti-Lock/traction Control 18 illustrations ~487 words

ADJUSTMENT

Adjust the gap using spacer (Part No. 26755AA000).

Scheme 16

Scheme 16: REMOVAL

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22
  1. Disconnect ground cable from battery.
  2. Lift-up the vehicle.
  3. Remove fuel tank cover.
  4. Disconnect rear ABS sensor connector.
  5. Remove rear sensor harness from clip on body side.
  6. Remove bolts which hold rear sensor harness brackets.
  7. Remove rear ABS sensor from rear arm.
  8. When inspecting rear tone wheel, remove rear drive shaft as rear tone wheel is unitized with BJ assembly of rear drive shaft. Refer to «REMOVAL»(ref-166869-S02334333662004093000000) or «REMOVAL»(ref-166896-S25313898322004093000000) , Rear Drive Shaft. CAUTION: Be careful not to damage pole piece located at tip of the sensor and teeth faces during removal. Do not pull sensor harness during removal.

Scheme 23

Scheme 23: INSTALLATION

Scheme 24

Scheme 24

Scheme 25

Scheme 25

Scheme 26

Scheme 26

Scheme 27

Scheme 27

Scheme 28

Scheme 28

Scheme 29

Scheme 29
  1. Install rear drive shaft to the vehicle. Refer to «INSTALLATION»(ref-166869-S13401886102004093000000) or «INSTALLATION»(ref-166896-S18740226272004093000000) , Rear Drive Shaft.
  2. Temporarily install rear ABS sensor on rear arm. CAUTION: Be careful not to strike ABS sensor's pole piece and tone wheel's teeth against adjacent metal parts during installation.
  3. Install rear sensor harness brackets in the original positions and install harness on the clip. Tightening torque: 33 N.m (3.4 kgf-m, 24 ft-lb) Tightening torque: 33 N.m (3.4 kgf-m, 24 ft-lb)
  4. Place a thickness gauge between ABS sensor's and tone wheel's tooth face. After standard clearance is obtained over the entire perimeter, tighten ABS sensor on rear arm to specified torque. ABS sensor standard clearance: 0.44 - 0.94 mm (0.0173 - 0.0370 in) Tightening torque: 32 N.m (3.3 kgf-m, 24 ft-lb) CAUTION: Check the marks on the harness to make sure that no distortion exists. NOTE: If the clearance is outside specifications, adjust the gap using spacer (Part No. 26755AA000).
  5. After confirmation of the ABS sensor clearance, connect connector to ABS sensor and install fuel tank cover.
  6. Connect connector to battery ground cable.

Scheme 30

Scheme 30: ABS SENSOR

Scheme 31

Scheme 31
  1. Check pole piece of ABS sensor for foreign particles or damage. If necessary, clean pole piece or replace ABS sensor.
  2. Measure ABS sensor resistance. CAUTION: If resistance is outside the standard value, replace ABS sensor with new one. NOTE: Check ABS sensor cable for discontinuity. If necessary, replace with a new one.

Scheme 32

Scheme 32: SENSOR GAP

Scheme 33

Scheme 33
  1. Measure the distance "A" between ABS sensor surface and sensor pole face.
  2. Measure the distance "B" between surface where the front axle housing meets the ABS sensor, and the tone wheel. NOTE: Measure so that the gauge touches the tone wheel teeth top.
  3. Find the gap between the ABS sensor pole face and the surface of the tone wheel teeth by putting the measured values in the formula below and calculating. ABS sensor clearance = B - A ABS sensor standard clearance: 0.44 - 0.94 mm (0.0173 - 0.0370 in) NOTE: If the clearance is outside specifications, adjust the gap using spacer (Part No. 26755AA000).

Adjust the gap using spacer (Part No. 26755AA000).
