2AZ-FE Starting: Overview Scion xB II

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
2. REMOVE AIR CLEANER CAP SUB-ASSEMBLY Disconnect the mass air flow meter connector. Loosen the hose clamp, unlock the air cleaner assembly clamp and remove the air cleaner cap sub-assembly.
3. REMOVE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Remove the air cleaner filter element sub-assembly from the air cleaner case sub-assembly.
4. REMOVE AIR CLEANER CASE SUB-ASSEMBLY Separate the wire harness clamp from the air cleaner case sub-assembly. Remove the 3 bolts and remove the air cleaner case sub-assembly.
5. REMOVE STARTER ASSEMBLY (for Manual Transaxle) Disconnect the terminal 50 connector from the starter assembly. Remove the nut and disconnect the wire harness from terminal 30. Remove the 3 bolts, clutch flexible hose bracket and starter assembly.
6. REMOVE STARTER ASSEMBLY (for Automatic Transaxle) Disconnect the terminal 50 connector from the starter assembly. Remove the nut and disconnect the wire harness from terminal 30. Remove the 2 bolts and starter assembly.

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. REMOVE MAGNET SWITCH BODY Remove the nut and disconnect the lead wire from terminal C. Remove the 2 screws that hold the magnetic switch to the motor terminal starter kit. Remove the magnet switch body. Remove the return spring and the plunger from the magnet switch body.
2. REMOVE STARTER YOKE ASSEMBLY Remove the 2 through bolts and pull out the starter yoke assembly together with the starter commutator end frame assembly. Remove the starter yoke assembly from the starter commutator end frame assembly.
3. REMOVE STARTER ARMATURE PLATE Remove the starter armature plate from the starter yoke assembly.
4. REMOVE STARTER COMMUTATOR END FRAME COVER Using a screwdriver, remove the starter commutator end frame cover.
5. REMOVE STARTER ARMATURE ASSEMBLY Using snap ring pliers, remove the snap ring and plate washer. Remove the starter armature assembly from the commutator end frame assembly.
6. REMOVE PLANETARY GEAR Remove the 3 planetary gears from the motor terminal starter kit.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. INSPECT STARTER ASSEMBLY CAUTION: Make sure to complete each of the following tests within 5 seconds to prevent the coil from burning out. Perform pull-in test: Disconnect the lead wire from terminal C. Connect the battery to the magnetic switch as shown in the illustration. Check that the clutch pinion gear moves outward. If the clutch pinion gear does not move outward, replace the magnet switch body. Perform hold-in test: Disconnect the negative (-) terminal lead from terminal C under the conditions for pull-in test. Check that the pinion gear remains out. If the clutch pinion gear moves inward, replace the magnet switch body. Inspect clutch pinion gear return: Disconnect the negative (-) lead from the starter body. Check that the clutch pinion gear moves inward. If the clutch pinion gear does not move inward, replace the repair service starter kit. Perform no-load performance test: Connect the field coil wire to terminal C with the nut. Make sure that the lead is not grounded. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Clamp the starter in a vise. Connect the battery and an ammeter to the starter as shown in the illustration. Check that the starter rotates smoothly and steadily with the clutch pinion gear extended. Check that the ammeter reads the specified current. Specified current SPECIFIED CURRENT Condition Specified condition at 11.5 V 90 A or less If the result is not as specified, overhaul the starter assembly.
2. INSPECT MAGNET SWITCH BODY Check the plunger. Push in the plunger and check that it returns quickly to its original position. If necessary, replace the magnet switch body. Inspect the resistance of the pull-in coil. Measure the resistance between terminals 50 and C. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester connection Specified condition Terminal 50 - Terminal C Below 1 ohms If the resistance is not as specified, replace the magnet switch body. Inspect the resistance of the hold-in coil. Measure the resistance between terminal 50 and the switch body. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester connection Specified condition Terminal 50 - Switch body Below 2 ohms If the resistance is not as specified, replace the repair service starter kit.
3. INSPECT STARTER ARMATURE ASSEMBLY Check the commutator surface for dirt or burning. If the surface is dirty or burnt, smooth the surface with 400-grit sandpaper or leather. Inspect the resistance of the commutator. Measure the resistance between the segments of the commutator. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester connection Specified condition Segment - Segment Below 1 ohms If the resistance is not as specified, replace the starter armature assembly. Measure the resistance between the commutator and armature coil core. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester connection Specified condition Commutator - Armature coil core 10 kohms or higher If the resistance is not as specified, replace the starter armature assembly. Using vernier calipers, measure the commutator depth. Specified depth: 3.1 mm (0.122 in.) Maximum depth: 3.8 mm (0.150 in.) If the depth is greater than the maximum, replace the starter armature assembly.
4. INSPECT STARTER COMMUTATOR END FRAME ASSEMBLY Check the brush length. Using vernier calipers, measure the brush length. Specified length: 9.0 mm (0.354 in.) Maximum length: 4.0 mm (0.157 in.) If the length is less than the minimum, replace the starter commutator end frame assembly. Check the resistance. Measure the resistance between the positive (+) and negative (-) brushes. Standard resistance: 10 kohms or higher If the resistance is not as specified, repair or replace the starter commutator end frame assembly.
5. INSPECT MOTOR TERMINAL STARTER KIT Check the starter clutch. Rotate the clutch pinion gear counterclockwise and check that it turns freely. Try to rotate the clutch pinion gear clockwise and check that it locks. If necessary, replace the motor terminal starter kit.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. INSTALL PLANETARY GEAR Apply high-temperature grease to the planetary gears and pin parts of the planetary shaft. Install the 3 planetary gears into the motor terminal starter kit.
2. INSTALL STARTER ARMATURE ASSEMBLY Apply high-temperature grease to the plate washer and the armature shaft. Install the starter armature assembly into the starter commutator end frame assembly. Using snap ring pliers, install the plate washer and a new snap ring. Using vernier calipers, measure the snap ring. Maximum length: 5.0 mm (0.197 in.) If the length is greater than the maximum, replace the snap ring with a new one.
3. INSTALL STARTER COMMUTATOR END FRAME COVER Install the starter commutator end frame cover onto the starter commutator end frame assembly.
4. INSTALL STARTER ARMATURE PLATE Align the claw of the armature plate with the groove inside the starter yoke assembly, and install the starter armature plate.
5. INSTALL STARTER COMMUTATOR END FRAME ASSEMBLY Align the starter commutator end frame rubber with the groove of the starter yoke assembly. Install the starter commutator end frame assembly to the starter yoke assembly. NOTE: The magnet of the starter yoke assembly may attract the starter armature assembly when the starter commutator end frame assembly is installed, causing the magnet to break.
6. INSTALL STARTER YOKE ASSEMBLY Align the claw of the starter yoke with the groove inside the motor terminal starter kit. Install the starter yoke with the 2 through bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf)
7. INSTALL MAGNET SWITCH BODY Apply high-temperature grease to the plunger and the hook. Hang the plunger hook of the magnet switch body to the drive lever hook. Install the plunger and the return spring. Install the repair service starter kit with the 2 screws. Torque: 7,5 N*m (76 kgf*cm, 66 in.*lbf) Connect the lead wire to terminal C with the nut. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)

Scheme 45

1. INSTALL STARTER ASSEMBLY (for Manual Transaxle) Install the starter assembly and clutch flexible hose bracket with the 3 bolts. Torque: Bolt A 37 N*m (377 kgf*cm, 27 ft.*lbf) Bolt B 12 N*m (120 kgf*cm, 9 ft.*lbf) Connect the wire harness to terminal 30 and install the nut. Then, attach the terminal cap. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Connect the terminal 50 connector to the starter assembly.
2. INSTALL STARTER ASSEMBLY (for Automatic Transaxle) Install the starter assembly with the 2 bolts. Torque: 37 N*m (377 kgf*cm, 27 ft.*lbf) Connect the wire harness to terminal 30 and install the nut. Then, attach the terminal cap. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Connect the terminal 50 connector to the starter assembly.
3. INSTALL AIR CLEANER CASE SUB-ASSEMBLY Install the air cleaner case sub-assembly with the 3 bolts. Torque: 7.0 N*m (71 kgf*cm, 62 in.*lbf) Install the wire harness clamp to the air cleaner case sub-assembly.
4. INSTALL AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Install the air cleaner filter element sub-assembly onto the air cleaner case sub-assembly.
5. INSTALL AIR CLEANER CAP SUB-ASSEMBLY Install and lock the air cleaner cap sub-assembly and then tighten the hose clamp. Connect the mass air flow meter connector.
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Torque: 5.4 N*m (55 kgf*cm, 47 in.*lbf)

Scheme 46

1. INSPECT STARTER RELAY Measure the resistance of the relay. Standard resistance STANDARD RESISTANCE SPECIFICATIONS Tester Connection Condition Specified Condition 3 - 5 When battery voltage absent 10 kohms or higher 3 - 5 When battery voltage applied to terminals 1 and 2 Below 1 ohms If the resistance is not as specified, replace the relay.
