Air Conditioning: Overview Scion xB II

Scheme 1

Scheme 2

Scheme 3

1. DO NOT HANDLE REFRIGERANT IN AN ENCLOSED AREA OR NEAR AN OPEN FLAME
2. ALWAYS WEAR EYE PROTECTION
3. BE CAREFUL NOT TO GET LIQUID REFRIGERANT IN YOUR EYES OR ON YOUR SKIN If liquid refrigerant gets in your eyes or on your skin: Wash the area with lots of cold water. CAUTION: Do not rub your eyes or skin. Apply clean petroleum jelly to the skin. Go immediately to a hospital or see a physician for professional treatment.
4. NEVER HEAT CONTAINER OR EXPOSE THE CONTAINER TO OPEN FLAME
5. BE CAREFUL NOT TO DROP CONTAINER OR APPLY PHYSICAL SHOCKS TO IT
6. DO NOT OPERATE COMPRESSOR WITHOUT ENOUGH REFRIGERANT IN REFRIGERANT SYSTEM If there is not enough refrigerant in the A/C system, the oil lubrication will be insufficient and the compressor may be damaged. Necessary care should be taken to avoid this.
7. DO NOT OPEN HIGH PRESSURE MANIFOLD VALVE WHILE COMPRESSOR IS OPERATING Open and close only the low pressure valve. If the high pressure valve is opened, refrigerant flows in the reverse direction causing the charging cylinder to rupture.
8. BE CAREFUL NOT TO OVERCHARGE SYSTEM WITH REFRIGERANT If the refrigerant is overcharged, it causes problems such as insufficient cooling, poor fuel economy, engine overheating, etc.
9. DO NOT OPERATE ENGINE AND COMPRESSOR WITH NO REFRIGERANT CAUTION: Doing so may damage the inside of the compressor because the compressor parts always move regardless of whether the A/C system is turned on or off.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

SYSTEM DIAGRAM REFERENCE

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

1. GENERAL The air conditioning system has the following controls: SYSTEM DESCRIPTION Control Outline Variable Capacity Compressor Control Controls the compressor to turn ON or OFF and the discharge capacity based on the signals from various sensors.
2. MODE POSITION AND DAMPER OPERATION Mode Position and Damper Operation Functions of Main Dampers: FUNCTIONS OF MAIN DAMPERS Control Damper Operation Position Damper Position Operation Air Inlet Control Damper FRESH A Brings in fresh air. RECIRC B Recirculates internal air. Air Mix Control Damper MAX COLD to MAX HOT Temperature Setting 16°C (61°F) to 30°C (86°F) C - D - E Varies the mixture ratio of the fresh air and the recirculation air in order to regulate the temperature continuously from HOT to COLD. Mode Control Damper H, K Defrosts the windshield through the front defroster and side register. H, J Defrosts the windshield through the front defroster and side register, while air is also blown out from the front and rear footwell register ducts. H, I Air blows out of the footwell register duct, rear footwell duct, and side register. In addition, air blows out slightly from the front defroster. F, I Air blows out of the center register, side register, and front and rear footwell register ducts. F, K Air blows out of the center register, and side register.
3. AIR OUTLETS AND AIRFLOW VOLUME Air Outlets and Airflow Volume The size of the circle o indicates the proportion of airflow volume.
4. A/C COMPRESSOR General An A/C compressor is a continuously variable capacity type in which its capacity varies in accordance with the cooling load of the air conditioner. This compressor consists of the shaft, lug plate, piston, shoe, crank chamber, cylinder, and solenoid control valve. The solenoid control valve that adjusts the suction pressure so that the suction pressure can be controlled as desired is provided. The plastic DL (Damper Limiter) type A/C pulley is used. Operation The crank chamber is connected to the suction passage. A solenoid control valve is provided between the suction passage (low pressure) and the discharge passage (high pressure). The solenoid control valve operates under duty cycle control in accordance with the signals from the air conditioning amplifier. When the solenoid control valve closes (solenoid coil is energized), a difference in pressure is created and the pressure in the crank chamber decreases. Then, the pressure that is applied to the right side of the piston becomes greater than the pressure that is applied to the left side of the piston. This compresses the spring and tilts the lug plate. As a result, the piston stroke increases and the discharge capacity increases. When the solenoid control valve opens (solenoid coil is not energized), the difference in pressure disappears. Then, the pressure that is applied to the left side of the piston becomes the same as the pressure that is applied to the right side of the piston. Thus, the spring elongates and eliminates the tilt of the lag plate. As a result, there is small piston stroke and the discharge capacity decreases.
5. AMBIENT TEMPERATURE SENSOR The ambient temperature sensor detects the outside temperature based on changes in the resistance of its built-in thermistor and sends a signal to the A/C amplifier.
6. EVAPORATOR TEMPERATURE SENSOR The evaporator temperature sensor detects the temperature of the cool air immediately past the evaporator in the form of resistance changes, and outputs it to the A/C amplifier.
7. A/C PRESSURE SENSOR The A/C pressure sensor detects the refrigerant pressure and outputs it to the A/C amplifier in the form of voltage changes.

DESCRIPTION

The ambient temperature sensor is installed in front of the condenser. This sensor detects the temperature outside the cabin and sends the appropriate signals to the A/C amplifier via the CAN communication system.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. CHECK CAN COMMUNICATION SYSTEM Use an intelligent tester or Techstream to check if the CAN communication system DTC. Result RESULT DESCRIPTION Result Proceed to 61499 is not output A B1499 is output B B: Go TO «DTC B1499»(ref-289743-S20610801422008070700000) A: Go to Next Step
2. READ VALUE USING INTELLIGENT TESTER OR TECHSTREAM (AMBIENT TEMPERATURE SENSOR) Use the Data List to check if the ambient temperature sensor is functioning properly. Intelligent tester DATA LIST / AIR CONDITIONER: DATA LIST / AIR CONDITIONER Tester Display Measurement Item / Display (Range) Normal Condition Diagnostic Note AMBI TEMP SENS Ambient temperature sensor / Min: -23.3°C (-9.94°F), Max: 65.95°C (150.71 °F) Actual ambient temperature is displayed Open in circuit: -23.3°C (-9.94°F) Short in circuit: 65.95°C (150.71°F) Techstream DATA LIST / AIR CONDITIONER: DATA LIST / AIR CONDITIONER Tester Display Measurement Item / Display (Range) Normal Condition Diagnostic Note Ambient Temp Sensor Ambient temperature sensor/ Min: -23.3°C (-9.94°F), Max: 65.95°C (150.71°F) Actual ambient temperature is displayed Open in circuit: -23.3°C (-9.94°F) Short in circuit: 65.95°C (150.71°F) OK: The display is as specified in the normal condition column. Result RESULT DESCRIPTION Result Proceed to NG A OK (Checking from the PROBLEM SYMPTOMS TABLE) B OK (Checking from the DTC) C B: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000). C: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) ) A: Go to Next Step
3. INSPECT COMBINATION METER Disconnect the C37 combination meter connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C37-23 (TX1+) - C37-18 (TEMP) 25°C (77°F) 1.60 to 1.80 kohms C37-23 (TX1+) - C37-18 (TEMP) 40°C (104°F) 0.80 to 1.00 kohms Reconnect the combination meter connector. NG: Go to step 6 OK: Go to Next Step
4. REPLACE COMBINATION METER Replace the combination meter (See «REMOVAL»(ref-289740-S22813805032008070700000) ). HINT: Since the combination meter cannot be inspected while it is removed from the vehicle, replace the combination meter with a normal one and check that the condition returns to normal.
5. CHECK FOR DTC Clear the DTC (See «DIAGNOSIS SYSTEM»(ref-289743-S23169077172008070700000) ). Check for DTCs (See «DIAGNOSIS SYSTEM»(ref-289743-S23169077172008070700000) ). Result RESULT DESCRIPTION Result Proceed to DTC B1412 is not output A DTC B1412 is output B B: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) ) A: END
6. INSPECT AMBIENT TEMPERATURE SENSOR Remove the ambient temperature sensor. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition A15-1 - A15-2 10°C (50°F) 3.00 to 3.73 kohms A15-1 - A15-2 15°C (59°F) 2.45 to 2.88 kohms A15-1 - A15-2 20°C (68°F) 1.95 to 2.30 kohms A15-1 - A15-2 25°C (77°F) 1.60 to 1.80 kohms A15-1 - A15-2 30°C (86°F) 1.28 to 1.47 kohms A15-1 - A15-2 35°C (95°F) 1.00 to 1.22 kohms A15-1 - A15-2 40°C (104°F) 0.80 to 1.00 kohms A15-1 - A15-2 45°C (113°F) 0.65 to 0.85 kohms A15-1 - A15-2 50°C (122°F) 0.50 to 0.70 kohms A15-1 - A15-2 55°C (131°F) 0.44 to 0.60 kohms A15-1 - A15-2 60°C (140°F) 0.36 to 0.50 kohms NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 18) NG: REPLACE AMBIENT TEMPERATURE SENSOR (See «REMOVAL»(ref-289743-S11700354782008070700000) ) OK: Go to Next Step
7. CHECK HARNESS AND CONNECTOR (AMBIENT TEMPERATURE SENSOR - COMBINATION METER) Disconnect the A15 ambient temperature sensor connector. Disconnect the C37 combination meter connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C37-23 (TX1+) - A15-2 Always Below 1 ohms C37-18 (TEMP) - A15-1 Always Below 1 ohms C37-23 (TX1+) - Body ground Always 10 kohms or higher C37-18 (TEMP) - Body ground Always 10 kohms or higher Reconnect the ambient temperature sensor connector. Reconnect the combination meter connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
8. REPLACE COMBINATION METER Replace the combination meter (See «REMOVAL»(ref-289740-S22813805032008070700000) ). HINT: Since the combination meter cannot be inspected while it is removed from the vehicle, replace the combination meter with a normal one and check that the condition returns to normal.
9. CHECK FOR DTC Clear the DTC (See «DIAGNOSIS SYSTEM»(ref-289743-S23169077172008070700000) ). Check for DTCs (See «DIAGNOSIS SYSTEM»(ref-289743-S23169077172008070700000) ). Result RESULT DESCRIPTION Result Proceed to DTC B1412 is not output A ETC B1412 is output B B: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) ) A: END

The evaporator temperature sensor (A/C thermistor) is installed on the evaporator in the air conditioning unit. It detects the temperature of the cooled air that has passed through the evaporator and its signal is used to control the air conditioning. It sends a signal to the A/C amplifier. The resistance of the evaporator temperature sensor (A/C thermistor) changes in accordance with the temperature of the cooled air that has passed through the evaporator. As the temperature decreases, the resistance increases. As the temperature increases, the resistance decreases.

The A/C amplifier applies voltage (5 V) to the evaporator temperature sensor (A/C thermistor) and reads voltage changes as the resistance of the evaporator temperature sensor (A/C thermistor) changes. This sensor is used to prevent the evaporator from freezing.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 20

Scheme 21

Scheme 22

1. READ VALUE USING INTELLIGENT TESTER OR TECHSTREAM (EVAPORATOR FIN THERMISTOR) Use the Data List to check if the evaporator fin thermistor is functioning properly. OK: The display is as specified in the normal condition column. Intelligent tester Data List / Air Conditioner: DATA LIST / AIR CONDITIONER Tester Display Measurement Item/Range Normal Condition Diagnostic Note EVAP FIN TEMP Evaporator fin thermistor/ Min.: -29.7°C (-21.46°F), Max.: 59.55°C (139.19°F) Actual evaporator temperature is displayed Open in circuit: -29.7°C (-21.46°F) Short in circuit: 59.55°C (139.19°F) Techstream Data List / Air Conditioner: DATA LIST / AIR CONDITIONER Tester Display Measurement Item/Range Normal Condition Diagnostic Note Evaporator Fin Thermistor Evaporator fin thermistor / Min.: -29.7°C (-21.46°F), Max.: 59.55°C (139.19°F) Actual evaporator temperature is displayed Open in circuit: -29.7°C (-21.46°F) Short in circuit: 59.55°C (139.19°F) Result RESULT DESCRIPTION Result Proceed to NG A OK (When troubleshooting according to PROBLEM SYMPTOMS TABLE) B OK (When troubleshooting according to the DTC output) C B: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000). C: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) ) A: Go to Next Step
2. INSPECT EVAPORATOR TEMPERATURE SENSOR Disconnect the C32 evaporator temperature sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C32-1 - C32-2 -10°C (14°F) 7.30 to 9.10 kohms C32-1 - C32-2 -5°C (23°F) 5.65 to 6.95 kohms C32-1 - C32-2 0°C (32°F) 4.40 to 5.35 kohms C32-1 - C32-2 5°C (41 °F) 3.40 to 4.15 kohms C32-1 - C32-2 10°C (50°F) 2.70 to 3.25 kohms C32-1 - C32-2 15°C (59°F) 2.14 to 2.58 kohms C32-1 - C32-2 20°C (68°F) 1.71 to 2.05 kohms C32-1 - C32-2 25°C (77°F) 1.38 to 1.64 kohms C32-1 - C32-2 30°C (86°F) 1.11 to 1.32 kohms NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 21) Reconnect the evaporator temperature sensor connector. NG: REPLACE EVAPORATOR TEMPERATURE SENSOR (See «DISASSEMBLY»(ref-289743-S27366330812008070700000) ) OK: Go to Next Step
3. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - EVAPORATOR TEMPERATURE SENSOR) Disconnect the C32 evaporator temperature sensor connector. Disconnect the C8 A/C amplifier connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C8-10 (TE) - C32-1 Always Below 1 ohms C8-11 (SG-3) - C32-2 Always Below 1 ohms C8-10 (TE) - Body ground Always 10 kohms or higher C8-11 (SG-3) - Body ground Always 10 kohms or higher Reconnect the A/C amplifier connector. Reconnect the evaporator temperature sensor connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) )

This DTC is output when refrigerant pressure on the high pressure side is extremely low (0.19 MPa (2.0 kgf/cm 2 , 28 psi) or less) or extremely high (3.14 MPa (32.0 kgf/cm 2 , 455 psi) or more). The pressure sensor, which is installed on the pipe of the high pressure side to detect refrigerant pressure, outputs a refrigerant pressure signal to the A/C amplifier. The A/C amplifier converts this signal to pressure according to the sensor characteristics to control the compressor.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Disconnect the A10 A/C pressure sensor connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition A10-3 (+) - Body ground Ignition switch ON 4.5 to 5.5 V Reconnect the A/C pressure sensor connector. NG: Go to step 5 OK: Go to Next Step
2. CHECK HARNESS AND CONNECTOR (GROUND CIRCUIT) Disconnect the A10 A/C pressure sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition A10-1 (-) - Body ground Always Below 1 ohms Reconnect the A/C pressure sensor connector. NG: Go to step 6 OK: Go to Next Step
3. INSPECT A/C PRESSURE SENSOR (SENSOR SIGNAL CIRCUIT) Remove the A/C amplifier with connectors still connected. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C8-6 (PRE) - Body ground Ignition switch ON (A/C: OFF) 0.7 to 4.8 V HINT: If the measured voltage is not within the normal range, there may be a malfunction in the A/C amplifier, A/C pressure sensor, or wire harness. It is also possible that the amount of refrigerant may not be appropriate. NG: Go to step 7 OK: Go to Next Step
4. INSPECT A/C PRESSURE SENSOR (SENSOR SIGNAL CIRCUIT) Measure the voltage when the following conditions are satisfied. VOLTAGE SPECIFICATIONS Item Condition Vehicle Doors Fully open Temperature Setting MAX COLD Blower Speed HI A/C Switch ON R/F Switch RECIRCULATION Interior Temperature 25 to 35°C (77 to 95°F) or higher Engine Speed 2000 rpm NOTE: If refrigerant pressure on the high pressure side becomes extremely high during the inspection (if the voltage exceeds 4.8 V), the fail-safe function stops compressor operation. Therefore, measure the voltage before the fail-safe operation. It is necessary to measure the voltage for a certain amount of time (approximately 10 minutes) because the problem symptom may recur after a while. HINT: When the outside air temperature is low (below -1.5°C (29.3°F)), the compressor stops due to operation of the ambient temperature and the evaporator temperature sensor to prevent the evaporator from freezing. In this case, perform the inspection in a warm indoor environment. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C8-6 (PRE) - Body ground Ignition switch ON (A/C: ON) 0.7 to 4.8 V Result RESULT DESCRIPTION Result Proceed to OK (When troubleshooting according to DTC) A OK (When troubleshooting according to PROBLEM SYMPTOMS TABLE) B NG C B: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000). C: Go to step 13 A: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) )
5. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - A/C PRESSURE SENSOR) Disconnect the C8 A/C amplifier connector. Disconnect the A10 A/C pressure sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition A10-3 (+) - C8-1 (S5-3) Always Below 1 ohms A10-1 (S5-3) - Body ground Always 10 kohms or higher Reconnect the A/C amplifier connector. Reconnect the A/C pressure sensor connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) )
6. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - A/C PRESSURE SENSOR) Disconnect the C8 A/C amplifier connector. Disconnect the A10 A/C pressure sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition A10-1 (-) - C8-4 (SG-2) Always Below 1 ohms C8-4 (SG-2) - Body ground Always 10 kohms or higher Reconnect the A/C amplifier connector. Reconnect the A/C pressure sensor connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) )
7. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - A/C PRESSURE SENSOR) Disconnect the C8 A/C amplifier connector. Disconnect the A10 A/C pressure sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition A10-2 (PR) - C8-6 (PRE) Always Below 1 ohms C8-6 (PRE) - Body ground Always 10 kohms or higher Reconnect the A/C amplifier connector. Reconnect the A/C pressure sensor connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
8. CHECK FOR A/C SYSTEM LEAK Install the manifold gauge set. Recover the refrigerant from the A/C system using a refrigerant recovery unit. Evacuate the A/C system and check that vacuum can be maintained in it. OK: Vacuum can be maintained in the A/C system. HINT: If vacuum cannot be maintained in the A/C system, refrigerant may be leaking from it. In this case, it is necessary to repair or replace the leaking part of the A/C system. NG: Go to step 12 OK: Go to Next Step
9. CHARGE REFRIGERANT Add an appropriate amount of refrigerant (See «REFRIGERANT LINE»(ref-289743-S25365990302008070700000) ).
10. RECHECK DTC Recheck for the DTC when the following conditions are satisfied. DTC REFERENCE CHART Item Condition Vehicle Doors Fully open Temperature Setting MAX COLD Blower Speed HI A/C Switch ON R/F Switch RECIRCULATION Interior Temperature 25 to 35°C (77 to 95°F) or higher Engine Speed 2000 rpm NOTE: If refrigerant pressure on the high pressure side becomes high, the DTC will be set. Therefore, it is necessary to measure the voltage for a certain amount of time (approximately 10 minutes) because the DTC may be set after the A/C operates for a while. HINT: When the outside air temperature is low (below -1.5°C (29.3°F)), the compressor stops due to operation of the ambient temperature sensor and the evaporator temperature sensor to prevent the evaporator from freezing. In this case, perform the inspection in a warm indoor environment. Result RESULT DESCRIPTION Result Proceed to DTC B1423 is output A DTC B1423 is not output B NOTE: If the DTC was set due to an insufficient or excessive amount of refrigerant, the problem may have been solved after performing the previous step. However, the root cause of insufficient refrigerant may be refrigerant leaks. The root cause of excessive refrigerant may be adding refrigerant when the level was insufficient. Therefore, identify and repair the area where refrigerant leaks from as necessary. B : END A: Go to Next Step
11. INSPECT A/C PRESSURE SENSOR Install the manifold gauge set. Disconnect the A10 A/C pressure sensor connector. Connect the three 1.5 V dry cell batteries' positive (+) lead to terminal 3, and the negative (-) lead to terminal 1. Connect the voltmeter's positive (+) lead to terminal 2, and the negative (-) lead to terminal 1. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition 1 - 2 Refrigerant pressure: 0.39 to 3.187 MPa (57 to 463 psi) 1.0 to 4.8 V Reconnect the A/C pressure sensor connector. NG: REPLACE A/C PRESSURE SENSOR (See «REFRIGERANT LINE»(ref-289743-S25365990302008070700000) ) OK: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) )
12. REPAIR A/C SYSTEM LEAK Identify the area where refrigerant leaks from (See «REFRIGERANT»(ref-289743-S21409044942008070700000) ). Repair the identified area of the A/C system. Evacuate the A/C system. NEXT: CHARGE REFRIGERANT (See «REFRIGERANT LINE»(ref-289743-S25365990302008070700000) )
13. INSPECT COOLING FAN SYSTEM Inspect that the cooling fan operates normally (See «ON-VEHICLE INSPECTION»(ref-289752-S36792618822008070700000) ). NG: REPAIR COOLING FAN SYSTEM OK: Go to Next Step
14. CHARGE REFRIGERANT Use a refrigerant recovery unit to recover refrigerant. Evacuate the A/C system. Add an appropriate amount of refrigerant (See «REFRIGERANT»(ref-289743-S21409044942008070700000) ). HINT: If refrigerant is added and the system has not been properly evacuated (insufficient vacuum time), moisture in the air remaining in the system will freeze in the expansion valve, blocking the flow on the high pressure side. Therefore, in order to confirm the problem, recover the refrigerant, properly evacuate the system. Add an appropriate amount of refrigerant, and check for the DTC.
15. RECHECK DTC Recheck for the DTC when the following conditions are satisfied. DTC REFERENCE CHART Item Condition Vehicle Doors Fully open Temperature Setting MAX COLD Blower Speed HI A/C Switch ON R/F Switch RECIRCULATION Interior Temperature 25 to 35°C (77 to 95°F) or higher Engine Speed 2000 rpm NOTE: If refrigerant pressure on the high pressure side becomes high, the DTC will be set. Therefore, it is necessary to measure the voltage for a certain amount of time (approximately 10 minutes) because the DTC may be set after the A/C operates for a while. HINT: When the outside air temperature is low (below -1.5°C (29.3°F)), the compressor stops due to operation of the ambient temperature sensor and the evaporator temperature sensor to prevent the evaporator from freezing. In this case, perform the inspection in a warm indoor environment. If refrigerant is added and the system has not been properly evacuated (insufficient vacuum time), moisture in the air remaining in the system will freeze in the expansion valve, blocking the flow on the high pressure side. Therefore, in order to confirm the problem, recover the refrigerant, properly evacuate the system, add an appropriate amount of refrigerant, and check for the DTC. If the DTC is not output after this work, it indicates that the cooler dryer in the condenser is not able to absorb moisture in the refrigerant cycle. In this case, to complete the repair it is necessary to replace the cooler dryer. Result RESULT DESCRIPTION Result Proceed to DTC B1423 is output A DTC B1423 is not output B B: REPLACE COOLER DRYER (See «DISASSEMBLY»(ref-289743-S31248085192008070700000) ) A: Go to Next Step
16. REPLACE EXPANSION VALVE Replace the expansion valve with a normal one. HINT: Replace the expansion valve with a normal one because the expansion valve is either stuck or clogged.
17. CHARGE REFRIGERANT Add an appropriate amount of refrigerant (See «REFRIGERANT»(ref-289743-S21409044942008070700000) ).
18. RECHECK DTC Recheck for the DTC when the following conditions are satisfied. DTC REFERENCE CHART Item Condition Vehicle Doors Fully open Temperature Setting MAX COLD Blower Speed HI A/C Switch ON R/F Switch RECIRCULATION Interior Temperature 25 to 35°C (77 to 95°F) or higher Engine Speed 2000 rpm NOTE: If refrigerant pressure on the high pressure side becomes high, the DTC will be set. Therefore, it is necessary to measure the voltage for a certain amount of time (approximately 10 minutes) because the DTC may be set after the A/C operates for a while. HINT: When the outside air temperature is low (below -1.5°C (29.3°F)), the compressor stops due to operation of the ambient temperature sensor and the evaporator temperature sensor to prevent the evaporator from freezing. In this case, perform the inspection in a warm indoor environment. If refrigerant pressure is not normal after replacing the expansion valve with a normal one, the condenser or pipes may be clogged due to dirt, dust or other contaminants. In this case, clean or replace the condenser or pipes. Result RESULT DESCRIPTION Result Proceed to DTC B1423 is not output A DTC B1423 is output B B: REPLACE CONDENSER (See «REMOVAL»(ref-289743-S22988430552008070700000) ) A: END

In this circuit, the compressor receives a refrigerant compression demand signal from the air conditioning amplifier.

Based on this signal, the compressor changes the amount of compressor output.

DTC DETECTION CONDITION AND TROUBLE AREA

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. INSPECT A/C COMPRESSOR (COMPRESSOR SOLENOID) Disconnect the B7 A/C compressor (compressor solenoid) connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition B7-2 (SOL+) - B7-1 (SOL-) 20°C (68°F) 10 to 11 ohms Reconnect the A/C compressor (compressor solenoid) connector. NG: REPLACE A/C COMPRESSOR (See «REMOVAL»(ref-289743-S10414147652008070700000) ) OK: Go to Next Step
2. CHECK HARNESS AND CONNECTOR (A/C COMPRESSOR - BODY GROUND) Disconnect the B7 A/C compressor (compressor solenoid) connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition B7-1 (SOL-) - Body ground Always Below 1 ohms Reconnect the A/C compressor (compressor solenoid) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
3. CHECK HARNESS AND CONNECTOR (A/C COMPRESSOR - A/C AMPLIFIER) Disconnect the B7 A/C compressor (compressor solenoid) connector. Disconnect the C8 A/C amplifier connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C8-7 (SOL+) - B7-2 (SOL+) Always Below 1 ohms C8-7 (SOL+) - Body ground Always 10 kohms or higher Result RESULT DESCRIPTION Result Proceed to NG A OK (When troubleshooting according to the PROBLEM SYMPTOMS TABLE) B OK (When troubleshooting according to the DTC) C Reconnect the A/C compressor (compressor solenoid) connector. Reconnect the A/C amplifier connector. B: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000). C: REPLACE AIR CONDITIONING AMPLIFIER (See «REMOVAL»(ref-289743-S13758048292008070700000) ) A: REPAIR OR REPLACE HARNESS OR CONNECTOR

DTC DETECTION CONDITION AND TROUBLE AREA

The recirculation damper servo motor and No. 1 heater control (air inlet control switch) are powered through the HTR-IG fuse. Operating No. 1 heater control (air inlet control switch) drives the recirculation damper servo motor to switch between "FRESH" and "RECIRCULATION".

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. INSPECT FUSE (HTR-IG) Remove the HTR-IG fuse from the main body ECU. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition HTR-IG fuse Always Below 1 ohms NG: REPLACE FUSE (See «PARTS LOCATION»(ref-289743-S25036800912008070700000) ) OK: Go to Next Step
2. INSPECT RECIRCULATION DAMPER SERVO MOTOR Remove the recirculation damper servo motor. Apply battery voltage to the terminals and check that the recirculation damper servo motor operates. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION Measurement Condition Specified Condition Positive battery - terminal 5 Negative battery - terminal 2 Turns to the "FRESH" side smoothly. Positive battery - terminal 5 Negative battery - terminal 1 Turns to the "RECIRCULATION" side smoothly. Reinstall the recirculation damper servo motor. NG: REPLACE RECIRCULATION DAMPER SERVO MOTOR (See «REMOVAL»(ref-289743-S25756690142008070700000) ) OK: Go to Next Step
3. INSPECT NO. 1 HEATER CONTROL (AIR INLET CONTROL SWITCH) Remove the No. 1 heater control (air inlet control switch). Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C39-3 (FRS) - C39-4 (REC) Air inlet control switch: FREE Below 1 ohms C39-3 (FRS) - C39-4 (REC) Air inlet control switch: LOCK 10 kohms or higher Check that the indicator light comes on. Turn the No. 1 heater control (air inlet control switch) to LOCK. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION Measurement Condition Specified Condition Positive battery - terminal 2 Negative battery - terminal 4 The indicator light comes on. Reinstall the No. 1 heater control (air inlet control switch). NG: REPLACE NO. 1 HEATER CONTROL (AIR INLET CONTROL SWITCH) (See «DISASSEMBLY»(ref-289743-S26319538572008070700000) ) OK: Go to Next Step
4. CHECK HARNESS AND CONNECTOR (RECIRCULATION DAMPER SERVO MOTOR - BATTERY) Disconnect the C38 Recirculation damper servo motor connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C38-5 (IG+) - Body ground Ignition switch OFF Below 1 V C38-5 (IG+) - Body ground Ignition switch ON 11 to 14 V Reconnect the Recirculation damper servo motor connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
5. CHECK HARNESS AND CONNECTOR (NO. 1 HEATER CONTROL (AIR INLET CONTROL SWITCH) - BATTERY) Disconnect the C39 No. 1 heater control (air inlet control switch) connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C39-2 (A/C+) - Body ground Ignition switch OFF Below 1 V C39-2 (A/C+) - Body ground Ignition switch ON 11 to 14 V Reconnect the No. 1 heater control (air inlet control switch) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
6. CHECK HARNESS AND CONNECTOR (NO. 1 HEATER CONTROL (AIR INLET CONTROL SWITCH) - BODY GROUND) Disconnect the C39 No. 1 heater control (air inlet control switch) connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C39-4 (REC) - Body ground Always Below 1 ohms Reconnect the No. 1 heater control (air inlet control switch) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
7. CHECK HARNESS AND CONNECTOR (NO. 1 HEATER CONTROL - RECIRCULATION DAMPER SERVO MOTOR) Disconnect the C39 No. 1 heater control (air inlet control switch) connector. Disconnect the C38 Recirculation damper servo motor connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C39-3 (FRS) - C38-2 (FRS) Always Below 1 ohms C39-5 (LED+) - C38-1 (REC) Always Below 1 ohms C39-3 (FRS) - Body ground Always 10 kohms or higher C39-5 (LED+) - Body ground Always 10 kohms or higher Reconnect the No. 1 heater control (air inlet control switch) connector. Reconnect the Recirculation damper servo motor connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000).

When the No. 2 heater control (blower switch) is operated, the HTR relay will turn on to allow current to flow to the blower motor and then the motor will start rotating. Operating the No. 2 heater control (blower switch) switches the current flow between the blower resistor and body ground, thus, shifting the rotation speed of the blower motor.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. INSPECT FUSE (HTR, ECU-IG NO. 2) Remove the HTR fuse from the engine room relay block. Remove the ECU-IG No. 2 fuse from the main body ECU. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition HTR fuse Always Below 1 ohms ECU-IG NO. 2 fuse Always Below 1 ohms Reinstall the HTR and ECU-IG No.2 fuses. NG: REPLACE FUSE (See «PARTS LOCATION»(ref-289743-S25036800912008070700000) ) OK: Go to Next Step
2. INSPECT RELAY (HTR) Remove the HTR relay from the main body ECU. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition 3 - 4 Battery is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Apply the battery voltage between terminals 1 and 2 10 kohms or higher 3 - 5 Battery is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply the battery voltage between terminals 1 and 2 Below 1 ohms Reinstall the HTR relay. NG: REPLACE HTR RELAY (See «PARTS LOCATION»(ref-289743-S25036800912008070700000) ) OK: Go to Next Step
3. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - BATTERY) Disconnect the C8 A/C amplifier connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C8-9 (SBLW) - Body ground Ignition switch ON Blower switch: OFF 11 to 14 V C8-9 (SBLW) - Body ground Ignition switch ON Blower switch: ON Below 1 V Reconnect the A/C amplifier connector. NG: Go to step 4 OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000).
4. INSPECT BLOWER MOTOR Remove the blower motor. Connect the positive (+) lead from the battery to terminal 2 and negative (-) to terminal 1, and check that the motor operates. OK: The blower motor operates smoothly. NG: REPLACE BLOWER MOTOR (See «REMOVAL»(ref-289743-S23269749202008070700000) ) OK: Go to Next Step
5. INSPECT BLOWER RESISTOR Remove the blower resistor. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C21-1 (HI) - C21-4 (E) Always 3.12 to 3.60 ohms C21-3 (M2) - C21-4 (E) Always 1.45 to 1.67 ohms C21-2 (M1) - C21-4 (E) Always 0.52 to 0.60 ohms Reinstall the blower resistor. NG: REPLACE BLOWER RESISTOR (See «REMOVAL»(ref-289743-S35724451672008070700000) ) OK: Go to Next Step
6. INSPECT NO. 2 HEATER CONTROL (BLOWER SWITCH) Remove the No. 2 heater control (blower switch). Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C40-4 (LO), C40-6 (HI), C40-9 (M1), C40-10 (M2) - C40-5 (E) Blower switch: OFF 10 kohms or higher C40-4 (LO) - C40-5 (E) Blower switch: LO Below 1 ohms C40-4 (LO), C40-9 (M1) - E70-5 (E) Blower switch: M1 Below 1 ohms C40-4 (LO), C40-10 (M2) - C40-5 (E) Blower switch: M2 Below 1 ohms C40-4 (LO), C40-6 (HI) - C40-5 (E) Blower switch: HI Below 1 ohms Reinstall the No. 2 heater control (blower switch). NG: REPLACE NO. 2 HEATER CONTROL (See «REMOVAL»(ref-289743-S11445383872008070700000) ) OK: Go to Next Step
7. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER - BATTERY) Disconnect the C8 A/C amplifier connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C8-9 (SBLW) - Body ground Ignition switch ON 11 to 14 V C8-9 (SBLW) - Body ground Ignition switch OFF Below 1 V Reconnect the A/C amplifier connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
8. CHECK HARNESS AND CONNECTOR (NO. 2 HEATER CONTROL (BLOWER SWITCH) BATTERY) Disconnect the C40 No. 2 heater control (blower switch) connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C40-4 (LO) - Body ground Ignition switch ON 11 to 14 V C40-4 (LO) - Body ground Ignition switch OFF Below 1 V Reconnect the No. 2 heater control (blower switch) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
9. CHECK HARNESS AND CONNECTOR (BLOWER RESISTOR - NO. 2 HEATER CONTROL (BLOWER SWITCH)) Disconnect the C21 blower resistor connector. Disconnect the C40 No. 2 heater control (blower switch) connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C21-1 (HI) - C40-6 (HI) Always Below 1 ohms C21-3 (M2) - C40-10 (M2) Always Below 1 ohms C21-2 (M1) - C40-9 (M1) Always Below 1 ohms C21-4 (E) - Body ground Always Below 1 ohms C40-5 (E) - Body ground Always Below 1 ohms C21-1 (HI) - Body ground Always 10 kohms or higher C21-3 (M2) - Body ground Always 10 kohms or higher C21-2 (M1) - Body ground Always 10 kohms or higher Reconnect the blower resistor connector. Reconnect the No. 2 heater control (blower switch) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
10. CHECK HARNESS AND CONNECTOR (BLOWER MOTOR - BLOWER RESISTOR, NO. 2 HEATER CONTROL) Disconnect the C19 blower motor connector. Disconnect the C21 blower resistor connector. Disconnect the C40 No. 2 heater control (blower switch) connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified Condition C19-1-C21-1 (HI) Always Below 1 ohms C19-1-C40-6 (HI) Always Below 1 ohms C19-1 - Body ground Always 10 kohms or higher Reconnect the blower motor connector. Reconnect the blower resistor connector. Reconnect the No. 2 heater control (blower switch) connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
11. CHECK HARNESS AND CONNECTOR (BLOWER MOTOR - BATTERY, BODY GROUND) Disconnect the C19 blower motor connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED VOLTAGE CONDITION Tester Connection Switch Condition Specified Condition C19-2 - Body ground ignition switch ON Blower switch: OFF Below 1 V C19-2 - Body ground Ignition switch ON Blower switch: ON 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED RESISTANCE CONDITION Tester Connection Switch Condition Specified Condition C19-2 - Body ground Ignition switch OFF Blower switch: OFF Below 1 ohms Reconnect the blower motor connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: CHECK INTERMITTENT PROBLEMS (See «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-289756-S12371354092008070700000) )

The No. 3 heater control is powered through the HTR-IG fuse. The No. 3 heater control transmits operational signals of each switch to the A/C amplifier.

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. INSPECT FUSE (HTR-IG) Remove the HTR-IG fuse from the main body ECU. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Condition Specified condition HTR-IG fuse Always Below 1 ohms NG: REPLACE FUSE (See «PARTS LOCATION»(ref-289743-S25036800912008070700000) ) OK: Go to Next Step
2. INSPECT NO. 3 HEATER CONTROL Measure the resistance. Remove the No. 3 heater control. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified Condition C20-2 (B) - C20-3 (A/C) Heater control base (A/C): LOCK Below 1 ohms C20-2 (B) - C20-3 (A/C) Heater control base (A/C): FREE 10 kohms or higher Check that the indicator light comes on. Connect the positive (+) lead from the battery to terminal 3 and negative (-) to terminal 4, and check that the indicator light comes on. OK: The indicator light comes on. Reinstall the No. 3 heater control. NG: REPLACE NO. 3 HEATER CONTROL (See «DISASSEMBLY»(ref-289743-S26319538572008070700000) ) OK: Go to Next Step
3. CHECK HARNESS AND CONNECTOR (NO. 3 HEATER CONTROL - BATTERY) Disconnect the C20 No. 3 heater control connector. Measure the voltage according to the value(s) in the table below. Standard voltage TESTER CONNECTION AND SPECIFIED CONDITION Tester Connection Switch Condition Specified condition C20-2 (B) -Body ground Ignition switch ON 11 to 14 V C20-2 (B) - Body ground Ignition switch OFF Below 1 V Reconnect the No. 3 heater control connector. NG : REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to Next Step
4. CHECK HARNESS AND CONNECTOR (NO. 3 HEATER CONTROL - A/C AMPLIFIER) Disconnect the C20 No. 3 heater control connector. Disconnect the C8 A/C amplifier connector. Measure the resistance according to the value(s) in the table below. Standard resistance TESTER CONNECTION AND SPECIFIED CONDITION Tester connection Condition Specified condition C20-3 (A/C) - C8-15 (A/C) Always Below 1 ohms C20-4 (AIND) - C8-16 (LED) Always Below 1 ohms C20-3 (A/C) - Body ground Always 10 kohms or higher C20-4 (AIND) - Body ground Always 10 kohms or higher Reconnect the No. 3 heater control connector. Reconnect the A/C amplifier connector. NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN «PROBLEM SYMPTOMS TABLE»(ref-289743-S13413194042008070700000).

The main power source is supplied to the A/C amplifier when the ignition switch is turned to ON.

The power source is used for operating the A/C amplifier and servo motor, etc.

Scheme 64
