Audio & Visual System: Removal & Installation Scion xA I

REPLACEMENT

Note. LOCATION: See LOCATION

Scheme 6

Scheme 7

Scheme 8

1. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 2 (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 1 (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
3. REMOVE HEATER CONTROL KNOB (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CTR (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
5. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET Remove the 4 bolts. Disconnect the connector. Remove the radio receiver assembly w/ bracket.
6. REMOVE RADIO BRACKET NO. 1 Remove the 4 screws and the radio bracket No. 1.
7. REMOVE RADIO BRACKET NO. 2 Remove the 4 screws and the radio bracket No. 2.
8. REMOVE RADIO RECEIVER ASSY

Note. LOCATION: See LOCATION

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
4. REMOVE FRONT NO. 1 SPEAKER ASSY Disconnect the connector. Using a drill of less than 4 mm (0.16 in.), drill out the 3 rivet heads and remove the front No. 1 speaker assy from the front door panel. Gently rotate the drill around the rivet head to cut the flanges. NOTE: Prizing the rivet out with the drill may lead to damage to the rivet hole or break the drill bit. CAUTION: Take care as the cut rivet is hot. Even if the flange is cut off, continue drilling and push out the remaining fragments with the drill. Using a vacuum cleaner, remove the drilled rivet and dust from the inside of the front door panel.
5. INSTALL FRONT NO. 1 SPEAKER ASSY Using an air riveter or a hand riveter, install 3 new strike rivets to the front No. 1 speaker assy on the front door panel. NOTE: Install the new strike rivets in order as shown in the illustration. NOTE: Do not prize with the riveter as it could be damaged, the rivet loosened on the mandrel could be bent. Do not tilt the riveter or disconnect the rivet from the materials because until the materials are securely tightened, misalignment may occur. Only install the rivet when there is no clearance between the materials to be secured. Connect the connector.

Note. LOCATION: See LOCATION

Scheme 14

1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
4. REMOVE FRONT DOOR SERVICE HOLE COVER LH (See «OVERHAUL»(ref-204166-S19977432462005110900000) )
5. REMOVE FRONT NO. 2 SPEAKER ASSY Disconnect the connector. Remove the nut and the front No. 2 speaker assy.
6. INSTALL FRONT NO. 2 SPEAKER ASSY Install the front No. 2 speaker assy with the nut. Torque: 8.0 N.m (82 kgf.cm, 71 in.lbf) Connect the connector.

Note. LOCATION: See LOCATION

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. REMOVE REAR DOOR REAR GUIDE BRACKET GARNISH LH (See «OVERHAUL»(ref-204167-S19961202542005110900000) )
2. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (See «OVERHAUL»(ref-204167-S19961202542005110900000) )
3. REMOVE REAR DOOR TRIM BOARD SUB-ASSY LH (See «OVERHAUL»(ref-204167-S19961202542005110900000) )
4. REMOVE REAR DOOR SERVICE HOLE COVER RH (See «OVERHAUL»(ref-204167-S19961202542005110900000) )
5. REMOVE REAR SPEAKER ASSY Disconnect the connector. Using a drill of less than 4 mm (0.16 in.), drill out the 3 rivet heads and remove the rear speaker assy from the rear door panel. Gently rotate the drill around the rivet head to cut the flanges. NOTE: Prizing the rivet out with the drill may lead to damage to the rivet hole or break the drill bit. CAUTION: Take care as the cut rivet is hot. Even if the flange is cut off, continue drilling and push out the remaining fragments with the drill. Using a vacuum cleaner, remove the drilled rivets and dust from the inside of the rear door panel.
6. INSTALL REAR SPEAKER ASSY Using an air riveter or a hand riveter, install 3 new strike rivets to the rear speaker assy on the rear door panel. NOTE: Install the new strike rivets in order as shown in the illustration. NOTE: Do not prize with the riveter as it could be damaged, the rivet loosened on the mandrel could be bent. Do not tilt the riveter or disconnect the rivet from the materials because until the materials are securely tightened, misalignment may occur. Only install the rivet when there is no clearance between the materials to be secured. Connect the connector.

Note. LOCATION: See LOCATION

Scheme 20

Scheme 21

1. REMOVE ROOF HEADLINING ASSY
2. REMOVE ROOF ANTENNA POLE SUB-ASSY (See «LOCATION»(ref-204157-S40850791212005110900000) 3)
3. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the connectors. Disengage the clamp. Remove the nut and the amplifier antenna assy.
4. INSTALL AMPLIFIER ANTENNA ASSY Set the amplifier antenna assy to the hole on the roof, and place the antenna cord on the cutout on the antenna nut. Install the amplifier antenna assy with the antenna nut. Torque: 5.0 N.m (51 kgf.cm, 44 in.lbf) Install the clamp.
5. INSTALL ROOF HEADLINING ASSY

Scheme 22

1. REMOVE ROOF ANTENNA POLE SUB-ASSY Remove the roof antenna pole sub-assy turning in the direction as shown in the illustration.

Note. LOCATION: See LOCATION

Scheme 23

1. REMOVE INSTRUMENT PANEL SUB-ASSY (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
2. REMOVE INSTRUMENT PANEL ASSY LOWER (See «REPLACEMENT»(ref-180045-S41226524402005072000000) )
3. REMOVE FRONT DOOR SCUFF PLATE RH
4. REMOVE REAR DOOR SCUFF PLATE RH
5. REMOVE COWL SIDE TRIM BOARD RH
6. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
7. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
8. REMOVE CENTER PILLAR GARNISH LOWER RH
9. REMOVE REAR SEAT BACK ASSY RH (See «REAR SEAT»(ref-204165) )
10. REMOVE REAR SEAT CUSHION W/COVER PAD SUB-ASSY (FF DRIVE TYPE) (See «REPLACEMENT»(ref-204165-S28236254112005110900000) )
11. REMOVE DECK BOARD NO. 2 (FF DRIVE TYPE)
12. REMOVE DECK BOARD NO. 1
13. REMOVE DECK TRIM COVER REAR
14. REMOVE DECK FLOOR BOX REAR (FF DRIVE TYPE)
15. REMOVE REAR SEAT BACK HINGE SUB-ASSY RH (See «REPLACEMENT»(ref-204165-S28236254112005110900000) )
16. REMOVE REAR SEAT 3 POINT TYPE BELT ASSY OUTER (See «REPLACEMENT»(ref-204165-S28236254112005110900000) )
17. REMOVE DECK TRIM SIDE PANEL ASSY RH
18. REMOVE ROOF SIDE GARNISH INNER RH
19. REMOVE ANTENNA CORD SUB-ASSY Disconnect the connector. Remove the 18 clamps. Remove the antenna cord sub-assy.
20. INSTALL REAR SEAT BACK HINGE SUB-ASSY RH (See «REPLACEMENT»(ref-204165-S28236254112005110900000) )
21. INSTALL REAR SEAT BACK ASSY RH (See «REPLACEMENT»(ref-204165-S28236254112005110900000) )
22. INSTALL INSTRUMENT PANEL ASSY LOWER (See «REPLACEMENT»(ref-180045-S41226524402005072000000) )
23. INSTALL INSTRUMENT PANEL SUB-ASSY (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )

Note. LOCATION: See LOCATION

Scheme 24

Scheme 25

Scheme 26

1. DISCONNECT BATTERY NEGATIVE TERMINAL (See «AIR BAG SAFETY PRECAUTIONS»(ref-170512-S06882444612005011000000) )
2. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 2 (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
3. REMOVE INSTRUMENT CLUSTER FINISH PANEL GARNISH NO. 1 (See «REPLACEMENT»(ref-180045-S38484436462005072000000) )
4. REMOVE FRONT ASH RECEPTACLE ASSY (See «REPLACEMENT»(ref-180045-S41226524402005072000000) )
5. REMOVE CIGARETTE LIGHTER COVER Disengage the 2 claws and remove the cigarette lighter cover.
6. REMOVE CIGARETTE LIGHTER ASSY Remove the cigarette lighter knob and element assy. Turn the socket in the direction as shown in the illustration, disengage the claw between the socket and the cigarette lighter bezel stay, and pull out the socket. Align the socket with the notch on the cigarette lighter bezel stay, and remove the cigarette lighter assy.
7. INSTALL CIGARETTE LIGHTER ASSY Align the socket with the notch on the cigarette lighter bezel stay and push the cigarette lighter assy in as hard as possible. Install the cigarette lighter knob and element assy.
