PROBLEM SYMPTOMS TABLE
Use the table below, with suspected areas listed in numerical order, to determine the cause of the problem. Inspect and repair or replace parts as necessary according to the steps on the following pages.
| Symptom/Suspected area | See | |
|---|---|---|
| No Sound Can Be Heard Only From The Front Speaker. | ||
| 1. Front No. 1 Speaker Assy | FRONT NO. 1 SPEAKER ASSY | |
| 2. Wire Harness | — | |
| No Sound Can Be Heard Only From The Tweeter Speaker. | ||
| 1. Front No. 2 Speaker Assy | FRONT NO. 2 SPEAKER ASSY | |
| 2. Wire Harness | — | |
| No Sound Can Be Heard Only From The Rear Speaker. | ||
| 1. Rear Speaker Assy | REAR SPEAKER ASSY | |
| 2. Wire Harness | — | |
PROBLEM SYMPTOMS
Scheme 3
Scheme 4
Scheme 5
- FRONT NO. 1 SPEAKER ASSY Inspect front No. 1 speaker assy continuity. Measure the resistance according to the value(s) in the table below. Standard: CONDITION AND SPECIFICATIONS Tester Connection Condition Specification 1 - 2 Always 4 ohm
- FRONT NO. 2 SPEAKER ASSY Inspect front No. 2 speaker assy continuity. Measure the resistance according to the value(s) in the table below. Standard: CONDITION AND SPECIFICATIONS Tester Connection Condition Specification 1 - 2 Always 4 ohm
- REAR SPEAKER ASSY Inspect rear speaker assy continuity. Measure the resistance according to the value(s) in the table below. Standard: CONDITION AND SPECIFICATIONS Tester Connection Condition Specification 1 - 2 Always 4 ohm
