Power Window Control System (Diagnostic Codes & Symptom Tests): Diagnosis Scion tC II рестайлинг

INSPECTION PROCEDURE

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Scheme 95

1. CHECK DTC Clear the DTC. Refer to «DTC CHECK / CLEAR [05/2013 - ]»(ref-615126-S07851877672014050900000) . Check for DTC. Refer to «DTC CHECK / CLEAR [05/2013 - ]»(ref-615126-S07851877672014050900000) . OK DTC B2311 is not output. NG --> See step 2 OK --> See step 8
2. CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY LH - BATTERY AND BODY GROUND) Disconnect the power window regulator motor assembly LH connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition E2-2 (B) - Body ground Always 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E2-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Window Regulator Motor Assembly LH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (POWER WINDOW) Select the Active Test, use the Techstream to generate a control command, and then check that door window regulator operates. Refer to «DATA LIST / ACTIVE TEST [05/2013 - ]»(ref-615126-S20850968782014050900000) . WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function does not operate. D-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Driver side power window OFF/UP/DOWN - HINT: Up and down movement does not occur if the arrow is not pressed and held. OK Power window regulator motor assembly LH operates. NG --> See step 7 OK: Go to next step
4. PERFORM INITIALIZATION Initialize the power window regulator motor assembly LH. Refer to «INITIALIZATION [05/2013 - 01/2014]»(ref-615126-S30519448012014050900000) . NEXT: Go to next step
5. CHECK POWER WINDOW CONTROL SYSTEM (DRIVER SIDE POWER WINDOW) Check that driver side power window operates normally by opening and closing the window. Refer to «OPERATION CHECK [05/2013 - ]»(ref-615126-S17723362982014050900000) . OK Power window regulator motor assembly LH operates normally. NG --> See step 9 OK: Go to next step
6. CHECK WHETHER PARTS HAVE BEEN INSTALLED CORRECTLY Check that the power window components are installed correctly. OK Power window components are installed correctly. HINT: If the power window components are installed correctly, the problem has been caused by battery disconnection while the ignition switch was ON, or the power window regulator motor assembly LH being overheated. NG --> INSTALL PARTS CORRECTLY OK --> END
7. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S27652866252014050900000)
8. USE SIMULATION METHOD TO CHECK. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [05/2013 - 01/2014]»(ref-615109-S39439522442014050900000)
9. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S27652866252014050900000)

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Scheme 96

1. CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH ASSEMBLY - BATTERY) Disconnect the power window regulator switch assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition D1-3 (B) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Window Regulator Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch assembly. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S34007597102014050900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 4 (U) - 3 (B) UP Below 1 ohms 1 (D) - 2 (SD) 4 (U) - 5 (SU) OFF 1 (D) - 2 (SD) 4 (U) - 5 (SU) DOWN 1 (D) - 3 (B) NG --> See step 6 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH ASSEMBLY - POWER WINDOW REGULATOR MOTOR ASSEMBLY RH) Disconnect the D1 power window regulator switch assembly connector. Disconnect the D2 power window regulator motor assembly RH connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D1-1 (D) - D2-1 Always Below 1 ohms D1-4 (U) - D2-2 Always Below 1 ohms D1-1 (D) or D2-1 - Body ground Always 10 kohms or higher D1-4 (U) or D2-2 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH Remove the power window regulator motor assembly RH. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S27652866252014050900000) . Check that the window regulator motor moves smoothly as follows. Refer to «INSPECTION [05/2013 - ]»(ref-615314-S15094213422014050900000) . NG --> See step 7 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY - POWER WINDOW REGULATOR SWITCH ASSEMBLY) Disconnect the E1 power window regulator master switch assembly connector. Disconnect the D1 power window regulator switch assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition E1-12 (U) - D1-5 (SU) Always Below 1 ohms E1-16 (D) - D1-2 (SD) Always Below 1 ohms E1-12 (U) or D1-5 (SU) - Body ground Always 10 kohms or higher E1-16 (D) or D1-2 (SD) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 8
6. REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - ]»(ref-615314-S37566776652014050900000)
7. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S27652866252014050900000)
8. REPLACE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY. Refer to «REMOVAL [05/2013 - 01/2014]»(ref-615314-S34007597102014050900000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. If a power window regulator motor assembly LH has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION [05/2013 - 01/2014] .

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure. If a power window regulator motor assembly LH has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION [01/2014 - ] .

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Note. When a power window regulator motor assembly LH is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the power window regulator master switch assembly and holding it in the auto up position. Open the power window by fully pushing down the power window regulator master switch assembly.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.
