Lighting System (Interior) (Diagnostics & Circuit Tests): Other Scion tC II

Interior/illumination Lights 4 illustrations ~355 words

PRECAUTION

  1. IGNITION SWITCH EXPRESSION HINT: The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. Expression Ignition Switch (position) Engine Switch (condition) Ignition Switch off Off Off Ignition Switch ON ON On (IG) Ignition Switch ACC ACC On (ACC) Engine Start START Start

Scheme 25

Scheme 25: ILLUSTRATION
Scheme 25: ILLUSTRATION

Scheme 26

Scheme 26: ILLUSTRATION
Scheme 26: ILLUSTRATION

Scheme 27

Scheme 27: ILLUSTRATION
Scheme 27: ILLUSTRATION

Scheme 28

Scheme 28: SYSTEM DIAGRAM
Scheme 28: SYSTEM DIAGRAM
TransmitterReceiverSignalCommunication Line
Main body ECUCertification ECUEngine switch illumination signalCAN

COMMUNICATION TABLE

CUSTOMIZE PARAMETERS

  1. CUSTOMIZE LIGHTING SYSTEM (INT) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Customize Setting / Illuminated Entry. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Lighting Time 15 s Changes the lighting time after closing all of the doors (the lights will fade out immediately when turning the ignition switch from off to ACC or ON). 7.5 s, 15 s or 30 s Main body ECU (Multiplex network body ECU) I/L when ACC OFF ON This function turns on the room lights when the ignition switch is turned from ON or ACC to off (the room lights turns on when the interior light switches are set to DOOR). ON or OFF Main body ECU (Multiplex network body ECU) I/L ON W/Door Key Unlock ON This function turns on the room lights when the door is unlocked using a mechanical key or transmitter (the room lights turns on when the interior light switches are set to DOOR). ON or OFF Main body ECU (Multiplex network body ECU) Room Light when Aprchd* ON This function turns on the room lights when the key is brought within the vehicle exterior detection area (the room lights turns on when the interior light switches are set to DOOR). ON or OFF Main body ECU (Multiplex network body ECU) *: w/ Smart Key System
