Smart Key System (For Entry Function) (Diagnostics - Introduction): Other Scion tC II

PRECAUTION

1. PRECAUTIONS WHEN USING TECHSTREAM If the engine switch cannot be turned on (IG), it is possible to perform troubleshooting for the smart key system (for Entry Function) using the following method. Connect the Techstream to the DLC3 and turn any door courtesy light switch on and off by pressing it with your finger until communication between the Techstream and vehicle begins (when communication begins, the Techstream display changes). HINT: Make sure the interval between door courtesy light switch on and off operations is 1.5 seconds or less.
2. PRECAUTIONS WHEN REPLACING ECU When replacing the ID code box (immobiliser code ECU), certification ECU (smart key ECU assembly), steering lock actuator assembly (steering lock ECU), ECM or electrical key transmitter, refer to the registration procedures. Refer to «REGISTRATION»(ref-451065-S16272258382012020700000) . When the certification ECU (smart key ECU assembly) is replaced, the stored steering lock position will no longer match that of the steering lock actuator assembly (steering lock ECU) and it may not be possible to start the engine. Therefore, after replacement, perform the following procedure. Move the shift lever to P (for Automatic Transaxle). With the engine switch off, open and close a door, and then start the engine.
3. PRECAUTION FOR REGISTRATION If replacing any of the following parts, refer to the removal procedures. NOTE: Any electrical key transmitters or ECUs for which registration has been performed cannot be reused. ID code box (immobiliser code ECU). Refer to «REMOVAL»(ref-451232-S32596443462012020700000) Certification ECU (smart key ECU assembly). Refer to «REMOVAL»(ref-451232-S11677392442012020700000) Steering lock actuator assembly (steering lock ECU). Refer to «DISASSEMBLY»(ref-451194-S17610953872012020700000) Electrical key transmitter
4. PRECAUTIONS WHEN DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL After disconnecting and reconnecting the battery cable, the entry unlock function may not operate. If this occurs, the entry unlock function can be restored by performing a wireless door lock and unlock operation.
5. PRECAUTIONS FOR VEHICLE BATTERY AND BATTERY BUILT INTO ELECTRICAL KEY TRANSMITTER When the doors are locked, electric waves are transmitted from the vehicle, which continually uses power from the vehicle battery. Therefore, if the vehicle is left as is for a long time, the battery may be fully depleted. If the vehicle is not used for a long time, disconnect the battery or cancel the smart key system (for Entry Function). HINT: Refer to the following procedures to cancel the smart key system (for Entry Function). Refer to «CUSTOMIZE PARAMETERS»(ref-451055-S05571530312012020700000) . When the doors are locked and the electrical key transmitter is in the detection area of an electrical key antenna, periodic communication between the electrical key transmitter and vehicle is performed, which uses battery power. If the vehicle is not being used, do not place the electrical key transmitter within 2 m (6.56 ft.) of the vehicle.
6. PRECAUTIONS FOR ELECTRICAL KEY TRANSMITTER HINT: For the shape of the electrical key transmitter, refer to Parts Location. Refer to «PARTS LOCATION»(ref-451055-S28643817582012020700000) . The electrical key transmitter is a precision instrument. Be sure to observe the following: Do not subject the electrical key transmitter to strong physical shocks. Do not keep the electrical key transmitter in a high temperature area for a long time. Do not use an ultrasonic washing machine to clean the electrical key transmitter. Do not use the electrical key transmitter with any magnetic items such as magnetic key holders. Do not place the electrical key transmitter near magnetic equipment, such as digital audio players, induction cookers, medical devices that generate low-frequency electromagnetic waves, etc. Do not attach any stickers to the electrical key transmitter.
7. PRECAUTIONS WHEN INSPECTING SMART KEY SYSTEM (for Entry Function) General precautions for the smart key system (for Entry Function): Always carry the electrical key transmitter. Under the following conditions, the key detection area may be reduced or the electrical key transmitter may be unable to be properly detected. This is due to the weak electromagnetic waves used for key detection. The battery is depleted. There are TV towers, electric power plants, broadcasting stations, gas stations or other facilities that generate strong electric waves nearby. Wireless communication devices, such as walkie-talkies, cell phones, cordless telephones, digital audio players, portable game systems, etc., are carried together with the electrical key transmitter. The electrical key transmitter is covered by or in contact with objects made of metal, such as coins, certain types of cards, etc. Film with some metallic content is applied to the rear window glass. Electric wave-type keyless entry systems are being operated nearby. An electrical key transmitter from another vehicle is nearby. The electrical key transmitter is placed near equipment that generates high-voltage or electrical noise. Operating range of the smart key system (for Entry Function): Due to the body shape, there are some areas in which proper system operation is difficult. Even if the electrical key transmitter is in the vehicle exterior key detection area, the electrical key transmitter may not be properly detected if the electrical key transmitter is near a window, a door handle or the center of the bumper. Even if the electrical key transmitter is in the vehicle interior key detection area, the electrical key transmitter may not be properly detected if it is on the instrument panel, in the glove box or on the floor. Depending on the way the electrical key transmitter is held, the electrical key transmitter may not operate properly. As weak electric waves are emitted from the electrical key transmitter, if a pacemaker is being used, be sure to read the pacemaker instruction manual. The smart key system (for Entry Function) will not operate under the following conditions. The procedures to cancel the smart key system (for Entry Function) are performed. There is no transmitter battery (the LED of the electrical key transmitter does not blink when a key switch is pressed).
8. PRECAUTIONS FOR ENTRY UNLOCK FUNCTION When performing an entry unlock operation, be sure to touch the backside of the front door outside handle assembly (touch sensor). If the front door outside handle assembly is touched while wearing gloves, etc., the response of the system may be delayed. When performing an entry unlock operation, confirm that the door has unlocked, and then pull the front door outside handle assembly to open the door. If the vehicle is approached quickly or the front door outside handle assembly is operated quickly, the door may not unlock. In this case, the system automatically performs the door unlock operation 4 times. However, if the front door outside handle assembly is being pulled at this time, the door may not unlock for mechanical reasons. If the door does not open when the front door outside handle assembly is pulled once, return the front door outside handle assembly to its original position. Then the door can be unlocked. If the electrical key transmitter is brought too close to the front door outside handle assembly, it may not be possible to unlock the door with the entry unlock function. If the electrical key transmitter is within the vehicle exterior detection area, the door can be unlocked even when a person other than the person carrying the electrical key transmitter holds the front door outside handle assembly. However, doors other than the door for which the matching code is detected cannot be unlocked (If the electrical key transmitter is in the vehicle exterior detection area of the driver side door and the driver side front door outside handle assembly is held, the doors can be unlocked. However, if the front passenger side front door outside handle assembly is held, the doors cannot be unlocked). If a door is not opened after the door unlock operation, the doors automatically lock after approximately 30 seconds. If the electrical key transmitter is within the vehicle exterior detection area and a large amount of water is applied to the front door outside handle assembly, such as by a car wash or heavy rain, the sensor may react and the entry unlock operation may be performed. However, the doors will automatically lock after approximately 30 seconds if a door is not opened. If the electrical key transmitter is being carried together with an electrical key transmitter from another vehicle with a smart key system (for Entry Function) and the front door outside handle assembly is held, the time before the door is unlocked by the entry unlock operation may be more than normal.
9. PRECAUTIONS FOR ENTRY LOCK FUNCTION When performing an entry lock operation, if the lock sensor on the front door outside handle assembly is touched too quickly, the door may not lock. If the electrical key transmitter is brought near the vehicle interior (window, front door outside handle assembly), the entry lock function may not operate. Also, the key reminder warning buzzer may sound and the entry unlock operation may stop functioning. In this case, move the electrical key transmitter away from the vehicle interior (window, front door outside handle assembly), perform the entry lock operation, and then perform the entry unlock operation. If the electrical key transmitter is being carried and a lock operation is performed from the driver side door while the driver side door is open (the door is ajar), the door ajar warning does not operate. If the electrical key transmitter is left on the instrument panel, in the glove box or on the floor, the key reminder warning function may not operate and the electrical key transmitter may be locked in the vehicle when a door lock operation is performed. Always carry the electrical key transmitter. The entry unlock operation cannot be performed for approximately 3 seconds after an operation that locks the doors, such as an entry lock or wireless lock operation, is performed.

Scheme 86

Scheme 87

Scheme 88

SYSTEM DIAGRAM

1. This is a detailed diagram related to the certification ECU (smart key ECU assembly).

Scheme 89

Scheme 90

1. This is a detailed diagram related to the main body ECU (multiplex network body ECU).

Scheme 91

Scheme 92

1. VEHICLE BATTERY SAVING FUNCTION When the smart key system (for Entry Function) is operating, the vehicle performs key detection operations every 0.25 seconds. Therefore, if the vehicle is left as is for a long period of time, the battery may become fully depleted. The following functions help reduce the rate at which the battery is depleted. If the engine is not started for 6 days or more, periodic signal transmission from the electrical key antennas stops. However, the doors can still be unlocked by touching the unlock sensor of a front door outside handle assembly. If the engine is not started for 15 days or more, the lock and unlock sensors of the front door outside handle assembly RH are disabled. Therefore, only the unlock sensor of the front door outside handle assembly LH can be used to unlock the doors. If 10 minutes or more elapse while the electrical key transmitter is in the detection area (including the vehicle interior), smart key system (for Entry Function) control stops operating. To restore operation of the smart key system (for Entry Function), perform any of the following operations. While carrying the electrical key transmitter, touch the lock and unlock sensor of the front door outside handle assembly LH and perform a door lock or unlock operation. Lock or unlock the doors with the wireless operation. Insert the mechanical key into the door key cylinder of the driver side door and lock or unlock the doors.
2. WARNING FUNCTION Shift lever not in P (power source cut reminder) vehicle exit warning (for Automatic Transaxle) Situation A: The driver side door is opened and a vehicle exit is attempted while the shift lever is not in P. Item Content Reason for warning Prevention of sudden forward movement of vehicle Vehicle theft prevention Vehicle roll-away (vehicle starts moving even when nobody is aboard due to slope, etc.) prevention Warning start condition (All conditions are met) Shift lever is not in P Engine switch is turned on (ACC) or on (IG) Driver side door is opened Vehicle speed is 0 km/h (0 mph) Warning description Buzzer in combination meter assembly sounds continuously (beep) Warning stop condition (Any condition is met) Shift lever moved to P Engine switch is turned off Driver side door is closed Vehicle is driven Situation B: Under the conditions specified in situation A, the electrical key transmitter is brought out of the vehicle, the driver side door is closed and movement away from the vehicle is attempted. Item Content Reason for warning Prevention of sudden forward movement of vehicle Vehicle theft prevention Vehicle roll-away prevention Warning start condition (All conditions are met) Shift lever is not in P Engine switch is turned on (ACC) or on (IG) Driver side door is opened and then closed Vehicle speed is 0 km/h (0 mph) Electrical key transmitter is not inside vehicle (matching code is not detected in vehicle interior) Warning description Buzzer in combination meter assembly sounds continuously (beep) Warning stop condition (Any condition is met) Shift lever is moved to P or vehicle is driven: Buzzer stops Engine switch is turned off: All warnings stop Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior): Buzzer stops Key reminder warning The driver side door is opened and a vehicle exit is attempted while the steering lock is unlocked. Item Content Reason for warning Vehicle theft prevention Warning start condition (Any condition is met) Condition 1: Engine switch is turned on (ACC) Driver side door is opened Last mode is not operating* Condition 2: Engine switch is turned off Driver side door is opened Steering lock is unlocked Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Condition 1: Engine switch is turned on (IG) Condition 2: Driver side door is closed Condition 3: Engine switch is turned off Steering lock is locked Condition 4: Last mode is operating* *: For vehicles with last mode. Shift lever in P (power source cut reminder) vehicle exit warning (for Automatic Transaxle) Situation A: The driver side door is opened and a vehicle exit is attempted while the shift lever is in P and the engine switch is not turned off. Item Content Reason for warning Vehicle theft prevention Warning start condition (All conditions are met) Shift lever is in P Engine switch is turned on (ACC) or on (IG) Driver side door is opened and then closed Electrical key transmitter is not inside vehicle (matching code is not detected in vehicle interior) Vehicle speed is 0 km/h (0 mph) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Either condition is met) Engine switch is turned off Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior) Situation B: Under the conditions specified in situation A, the doors are closed and an entry lock operation is attempted. Item Content Reason for warning Vehicle theft prevention Warning start condition (All conditions are met) Shift lever is in P Engine switch is turned on (ACC) or on (IG) All doors are closed Electrical key transmitter is outside vehicle (matching code is detected outside of vehicle) Electrical key transmitter is not inside vehicle (matching code is not detected in vehicle interior) Entry lock operation is performed while carrying electrical key transmitter Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Engine switch is turned off Shift lever is moved to any position other than P Vehicle is driven Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior) Any door is opened (only buzzer stops) 10 seconds elapse after warning starts (only buzzer stops) Passenger has brought key out of vehicle warning Any door other than the driver side door is opened and a vehicle exit is attempted while carrying the key. Item Content Reason for warning Prevention of state in which engine is unable to be restarted Warning start condition (All conditions are met) Engine switch is turned on (ACC) or on (IG) Any door other than driver side door is opened and then closed Vehicle speed is 0 km/h (0 mph) Electrical key transmitter is not inside vehicle or transmitter battery is fully depleted (matching code is not detected in vehicle interior) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Either condition is met) Engine switch is turned off Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior) Starting to drive without key warning The driver starts driving while the electrical key transmitter is not in the vehicle. Item Content Reason for warning Prevention of state in which engine is unable to be restarted Warning start condition Warning due to electrical key transmitter being brought out of vehicle is operating and vehicle speed is more than 0 km/h (0 mph) (first time only) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Either condition is met) Engine switch is turned off Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior) Key is not within detection area warning An attempt is made to turn the engine switch on (ACC) or on (IG) or to start the engine while the electrical key transmitter cannot be detected inside the vehicle or while the electrical key transmitter is not operating properly. Item Content Reason for warning User confusion prevention Warning start condition (Both conditions are met) Electrical key transmitter is not inside vehicle or transmitter battery is fully depleted (matching code is not detected in vehicle interior) Engine switch is turned on (ACC) or on (IG) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Either condition is met) 15 seconds elapse after warning starts Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior) Key left inside vehicle warning An entry lock operation is attempted while the key is inside the vehicle. Item Content Reason for warning Vehicle theft prevention Warning start condition (All conditions are met) Engine switch is turned on (ACC) or on (IG) All doors are closed Any door is unlocked Electrical key transmitter is inside vehicle (matching code is detected in vehicle interior) and entry lock operation is performed Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Engine switch is turned on (ACC) or on (IG) Any door is opened (only buzzer stops) Electrical key transmitter is detected outside vehicle (matching code is detected outside of vehicle) and entry lock operation is performed Key lock-in prevention function The key is locked in the vehicle. Item Content Reason for warning Vehicle theft prevention Warning start condition (Either condition is met) Condition 1: Keyless lock operation* is performed Electrical key transmitter is inside vehicle (matching code is detected in vehicle interior) Condition 2: Engine switch is turned off All doors are closed Lock operation other than entry lock operation is performed Electrical key transmitter is inside vehicle (matching code is detected in vehicle interior) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Engine switch is turned on (ACC) or on (IG) 10 seconds elapse after warning starts (only buzzer stops) 60 seconds elapse after warning starts Vehicle is driven Lock operation is performed *: A keyless lock operation is when a door is locked by operating the door lock knob of an open door, and then closing the door while pulling the front door outside handle assembly. Key battery low warning The vehicle is driven while the transmitter battery is almost depleted. Item Content Reason for warning Helpful function Warning start condition (Both conditions are met) Engine switch is turned on (IG) for 20 minutes or more and then turned off Transmitter battery is almost depleted Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Engine starting support An attempt is made to start the engine by holding the electrical key transmitter against the engine switch while the transmitter battery is fully depleted. Item Content Reason for warning Helpful function Warning start condition (All conditions are met) Engine immobiliser is set Electrical key transmitter is not inside vehicle (matching code is not detected in vehicle interior) Unlock operation is performed with mechanical key or 2 consecutive attempts to turn engine switch turned on (IG) are made (matching code is not detected in vehicle interior) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) 60 seconds elapse after warning starts Electrical key transmitter is detected inside vehicle (matching code is detected in vehicle interior or near engine switch) 30 seconds elapse after any door is opened and closed The system judges that the driver does not understand how to start the engine. Item Content Reason for warning Helpful function Warning start condition (Both conditions are met) Engine switch is turned off and driver side door is opened Power source mode is changed from off to on (ACC) 2 times or more while brake pedal*1 or clutch pedal*2 is not depressed Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) 10 seconds elapse after warning starts Engine switch is turned off Engine switch is turned on (IG) *1: for Automatic Transaxle *2: for Manual Transaxle An attempt is made to start the engine while the shift lever is in a position that does not permit the engine to be started. Item Content Reason for warning Helpful function Warning start condition (All conditions are met) Shift lever is not in P or N* Engine is not running Vehicle is not being driven Starter motor is not operating 0.5 seconds or more have elapsed after engine switch is turned on (IG) Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Power source mode is changed to mode other than on (IG) Engine is started Vehicle is driven Shift lever is moved to P or N* *: for Automatic Transaxle Power source off operation advice An attempt is made to turn the engine switch off while the shift lever is not in P or N. Item Content Reason for warning Helpful function Warning start condition (Any condition is met) Shift lever is not in P or N* Engine switch is turned on (ACC) while engine switch is on (IG) or engine is running Warning description Buzzer in combination meter assembly sounds once ("pong" sound) Warning stop condition (Any condition is met) Shift lever is moved to P* Power source mode is changed to mode other than on (ACC) *: for Automatic Transaxle
3. SEQUENCE OF ACTIONS FOR SMART KEY SYSTEM This lists a sequence of actions pertaining to the smart key system (unlocking the doors, turning the power source mode to on (ACC) and on (IG), starting and stopping the engine, and locking the doors). The system can be inspected easily by confirming that the operations listed for each step occur. The following example shows how the information in this section is organized. The "Action" item indicates actions the user performs related to the smart key system, and the "Expected Vehicle Response" item indicates the normal vehicle behavior in response to those actions. The suspected problem areas when the vehicle does not behave as expected and troubleshooting hints for each area are listed under "Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information". Action - Expected Vehicle Response - Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information - SUSPECTED AREA Troubleshooting Information SUSPECTED AREA Troubleshooting Information Reference Waveform or Table See waveform See table HINT: Smart key system DTCs and Data List information can be confirmed with the Techstream. Check for DTCs using the following method. If any DTCs are output, perform troubleshooting for those DTCs first. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Smart Key, Starting Control, Power Source Control and Main Body / Trouble Codes. Check for DTCs. NOTE: When the engine switch cannot be turned on (IG), try to establish communication between the vehicle and the Techstream by using either of the following methods: 1) Connect the Techstream to the DLC3 and turn a courtesy light switch on and off at intervals of 1.5 seconds or less until communication between the Techstream and vehicle begins (the Techstream screen changes when communication begins), or 2) connect the Techstream to the vehicle and select "Manual" from the initial screen on the Techstream, and then select "Key Code Registration" under model code. If the smart key system functions have been canceled through the customize function due to a customer request, "Auto Entry Cancel SW" in the Data List displays "ON". ACTION 1 Action All the doors are locked while the key is carried and the user brings the key 3 m (9.84 ft.) or more away from the vehicle. HINT: The request signal is emitted from each door every 0.25 seconds at 134.2 kHz to form a key detection area of approximately 0.7 m (2.30 ft.). Reference Waveform or Table Pulse generation*. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) *: Tester Connection: "C35-3 (CLG1) - C35-15 (E)" ACTION 2 Action The electrical key transmitter is brought within 0.7 m (2.30 ft.) of the driver side door. Expected Vehicle Response The red LED of the electrical key transmitter starts blinking. HINT: When the electrical key transmitter is detected and the certification ECU (smart key ECU assembly) confirms that the key ID code of the electrical key transmitter and the key ID code stored in the certification ECU (smart key ECU assembly) match, it puts the touch sensor of the front door outside handle assembly in standby mode (the mode in which detection is possible when the sensor is touched by hand) and allows the door to be unlocked. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information If the LED of the electrical key transmitter does not blink, the following parts may be malfunctioning. ELECTRICAL KEY TRANSMITTER The electrical key transmitter is not a key which is registered to the vehicle. Confirm that the system operates normally with another electrical key transmitter that the customer possesses. If the electrical key transmitter is malfunctioning, the power source mode cannot be changed to on (ACC) and the engine cannot be started (under normal conditions, when the key is brought into the vehicle and the engine switch is pressed without depressing the brake pedal*1 or clutch pedal*2, the power source mode changes to on (ACC) and the indicator illuminates in orange). *1: for Automatic Transaxle *2: for Manual Transaxle If the door cannot be opened, use the mechanical key built into the electrical key transmitter. HINT: Before replacing the electrical key transmitter, check if the transmitter battery is depleted. ELECTRIC WAVE INTERFERENCE If a problem only occurs in a certain area or at a certain time, electric wave interference may be the problem. If a tool for checking electric waves, such as a signal strength meter, is available, move around the vehicle and check the tool display. A detection area is formed around the driver side door [within 0.7 m (2.30 ft.)]. Therefore, a signal strength meter will detect signals in the LF band (134 kHz). When the lock or unlock switch of the electrical key transmitter is pressed, a signal strength meter will detect signals in the RF band (between 300 to 400 MHz). If signals are detected in the LF or RF band even after moving away from the vehicle, wave interference may be present. If there are problems with the signals sent from the key due to an electrical key transmitter malfunction (including when a key from another vehicle is used), transmitter battery depletion, or wave interference, one of the following Data List items may display "Yes": "Unmatched Vehicle-ID" "No Response" "Unmatched Code or Form" "ID Code Difference" CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) - DOOR OUTSIDE HANDLE The vehicle exterior detection area cannot be formed properly. If the key LED does not blink when within 0.7 m (2.30 ft.) of the front door outside handle assembly LH, but does blink when within 0.7 m (2.30 ft.) of the front door outside handle assembly RH, the front door outside handle assembly LH is malfunctioning. When there are problems with the vehicle exterior detection area, the power source mode can still be changed to on (ACC) and the engine can still be started. Using the Techstream, proper formation of the vehicle exterior detection area can be confirmed using "Overhead + Driver Side" in key diagnostic mode. Refer to «OPERATION CHECK»(ref-451055-S07792322432012020700000) . Even if there are problems with the detection area, door unlock operations can be performed by pressing the wireless unlock switch on the electrical key transmitter. DOOR CONTROL RECEIVER When the door control receiver fails, the passenger side door cannot be unlocked. When the door control receiver fails, wireless door unlock operations cannot be performed. When the door control receiver fails, the power source mode cannot be changed to on (ACC) and the engine cannot be started. Using the Techstream, the door control receiver function can be checked using "Overhead + Driver Side" in key diagnostic mode. Refer to «OPERATION CHECK»(ref-451055-S07792322432012020700000) . VEHICLE BATTERY DEPLETED A simple method to determine whether the battery is depleted is to operate the horn. Reference Waveform or Table Pulse generation*1. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) Pulse generation*2. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) Pulse generation*3. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) Pulse generation*4. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) *1: Tester Connection: "C35-3 (CLG1) - C35-15 (E)" *2: Tester Connection: "C36-15 (RDA) - C35-15 (E)" *3: Tester Connection: "C36-5 (RCO) - C35-15 (E)" *4: Tester Connection: "C36-16 (RSSI) - C35-15 (E)" ACTION 3 Action The unlock sensor of the front door outside handle assembly LH is touched while the electrical key transmitter is carried. Expected Vehicle Response The doors unlock and an answer-back is performed (the hazard warning lights illuminate and the wireless door lock buzzer sounds). HINT: When the front door outside handle assembly (unlock sensor) is touched, an unlock sensor "ON" signal is sent to the certification ECU (smart key ECU assembly), and the main body ECU (multiplex network body ECU) supplies power to the door unlock relay in each door based on a command from the certification ECU (smart key ECU assembly) via CAN communication. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information When the doors do not unlock even though the unlock sensor is touched, the following parts may be malfunctioning. The same part as when the key LED does not blink is malfunctioning. DOOR OUTSIDE HANDLE UNLOCK SENSOR If the doors unlock when the passenger side door unlock sensor is touched while the electrical key transmitter is carried, the driver side door unlock sensor may be malfunctioning. Under normal conditions, "D-Door Touch Sensor" in the Data List displays "ON" when the unlock sensor is touched. DOOR LOCK/UNLOCK MECHANISM When a lock/unlock operation cannot be performed by operating the door control switch inside the vehicle, the door lock mechanism itself may be malfunctioning. Reference Waveform or Table Pulse generation*. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) See "Check Main Body ECU (Multiplex Network Body ECU)" (ACT-). Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) *: Tester Connection: "C35-20 (SEN1) - C35-15 (E)" ACTION 4 Action The driver side door is opened, the user sits in the driver seat and then closes the driver side door while carrying the key. With the shift lever in P*1, the engine switch is pressed once without depressing the brake pedal*1 or clutch pedal*2. *1: for Automatic Transaxle *2: for Manual Transaxle Expected Vehicle Response The engine switch illuminates in orange [the power source mode changes to on (ACC)]. The security indicator light stops blinking and turns off. The immobiliser changes from set to unset and engine start is permitted. The steering unlocks. HINT: When the engine switch is pressed, the indoor electrical key antenna forms the vehicle interior detection area (134.2 kHz) in order to detect the electrical key transmitter inside the vehicle. Upon receiving the request signal, the electrical key transmitter transmits an ID code at 300 to 400 MHz (at this time the red LED of the electrical key transmitter illuminates briefly). When the ID code from the electrical key transmitter and the ID code stored in the certification ECU (smart key ECU assembly) match, the ACC relay turns "ON" when the engine switch is pressed, and the engine switch indicator illuminates in orange. After the power source mode changes, S code verification*1 and L code verification*2 are completed, and then the steering wheel is unlocked. After the steering wheel is unlocked, the immobiliser is unset. "Immobiliser" in the Data List changes from "Set" to "Unset". When any of the following conditions are met, the vehicle interior detection area is formed. A door is opened. It is within approximately 30 seconds after a door is closed. The brake pedal*3 or clutch pedal*4 is depressed. It is within approximately 30 seconds after the brake pedal is depressed once. It is immediately after the engine switch is pressed. *1: Confirms the codes match between the certification ECU (smart key ECU assembly) and ID code box (immobiliser code ECU). *2: Confirms the codes match between the steering lock ECU and ID code box (immobiliser code ECU). *3: for Automatic Transaxle *4: for Manual Transaxle Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information If the power source mode does not change to on (ACC), the following parts may be malfunctioning. The electrical key transmitter, transmitter battery and vehicle battery are possible causes. However, they have already been confirmed using the previous procedures. CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) - ELECTRIC WAVE INTERFERENCE If a problem only occurs in a certain area or at a certain time, electric wave interference may be the problem. If a tool for checking electric waves, such as a signal strength meter, is available, move around the vehicle and check the tool display. A detection area is formed around the driver side door [within 0.7 m (2.30 ft.)]. Therefore, a signal strength meter will detect signals in the LF band (134 kHz). When the lock or unlock switch of the electrical key transmitter is pressed, a signal strength meter will detect signals in the RF band (between 300 to 400 MHz). If signals are detected in the LF or RF band even after moving away from the vehicle, wave interference may be present. If there are problems with the signals sent from the electrical key transmitter due to an electrical key transmitter malfunction (including when a key from another vehicle is used), transmitter battery depletion, or wave interference, one of the following Data List items may display "Yes": "Unmatched Vehicle-ID" "No Response" "Unmatched Code or Form" "ID Code Difference" INDOOR ELECTRICAL KEY ANTENNA (VEHICLE INTERIOR DETECTION AREA FORMATION) Using the Techstream, formation of the vehicle interior detection area can be confirmed using "Overhead + Front Room" in key diagnostic mode. Refer to «OPERATION CHECK»(ref-451055-S07792322432012020700000) . When there are problems with the vehicle interior detection area, the power source mode cannot be changed to on (ACC) and the engine cannot be started. However, if the electrical key transmitter is held against the engine switch, the engine can be started. ENGINE SWITCH Under normal conditions, "Start Switch1, Start Switch2" in the Data List changes from "OFF" to "ON" when the engine switch is pressed. PARK/NEUTRAL POSITION SWITCH (for Automatic Transaxle) Under normal conditions, "Neutral SW/Clutch SW" in the Data List displays "ON" when the shift lever is moved to P. ID CODE BOX (IMMOBILISER CODE ECU) It is necessary for "S Code Check" in the Data List to display "OK". If "S Code Check" displays "OK", the certification ECU (smart key ECU assembly) code and ID code box (immobiliser code ECU) code match. STEERING LOCK It is necessary for "L Code Check" in the Data List to display "OK". If "L Code Check" displays "OK", the steering lock ECU L code and ID code box (immobiliser code ECU) L code match. When the power source mode changes to on (ACC) and "S Code Check" and "L Code Check" are both "OK", power is supplied to the unlock circuit of the steering lock motor for approximately 10 seconds. At this time, "Unlock Request Receive" in the Data List changes from "NG" to "OK" momentarily. As a result, when the steering unlocks, "Steering Unlock" in the Data List changes from "OFF" to "ON". Reference Waveform or Table Pulse generation*1. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) Pulse generation*2. Refer to «TERMINALS OF ECU»(ref-451055-S39224741192012020700000) Pulse generation*3. Refer to «TERMINALS OF ECU»(ref-451228-S08289988422012020700000) *1: Tester Connection: "C36-15 (RDA) - C35-15 (E)" *2: Tester Connection: "C35-7 (CLG5) - C35-15 (E)" *3: Tester Connection: "C18-3 (IGE) - C18-1 (GND)" ACTION 5 Action The electrical key transmitter is carried and the brake pedal*1 or clutch pedal*2 is depressed with the shift lever in P*1. *1: for Automatic Transaxle *2: for Manual Transaxle Expected Vehicle Response The engine switch indicator illuminates in green. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information If the engine switch indicator does not illuminate in green, the following parts may be malfunctioning. STOP LIGHT SWITCH (for Automatic Transaxle) When the brake pedal is depressed, "Stop Light Switch" in the Data List changes from "OFF" to "ON". POWER SOURCE CONTROL ECU Refer to «TERMINALS OF ECU»(ref-451056-S32935164532012020700000) ACTION 6 Action The electrical key transmitter is carried and the engine switch is pushed while depressing the brake pedal*1 or clutch pedal*2 with the shift lever in P*1. *1: for Automatic Transaxle *2: for Manual Transaxle Expected Vehicle Response The starter operates. HINT: After it is confirmed that the engine switch is being pressed and the steering is unlocked, 12 V is applied to the ST relay from terminal STAR of the power source control ECU and the starter operates. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information If the starter does not operate, the following parts may be malfunctioning. STEERING LOCK SYSTEM Under normal conditions, the steering lock bar should be in the unlock position and "Steering Unlock Switch" in the Data List should display "ON". CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) - POWER SOURCE CONTROL ECU "Starter SW" in the Data List indicates the starter activation command. When this Data List item turns "ON", 12 V is output from terminal STAR of the power source control ECU and applied to the ST relay. STARTER RELAY "Starter Relay" in the Data List indicates the voltage at terminal STA and indicates whether voltage is actually applied to the starter relay. STARTER MOTOR Refer to «Engine does not Start»(ref-451247-S33559796352012020700000) VEHICLE BATTERY DEPLETED A simple method to determine whether the battery is depleted is to operate the horn. Expected Vehicle Response The engine starts. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information - ECM When the engine speed reaches 500 rpm, the ECM and ID code box (immobiliser code ECU) certify each other and "EFI Code Receive" in the Data List changes from "NG" to "OK". After that, fuel injection continues to be performed. ACTION 7 Action The engine switch is pressed. Expected Vehicle Response The engine stops and the engine switch stops illuminating in green and turns off (all power is turned off). The security indicator light starts blinking. ACTION 8 Action A door is opened with the engine switch is turned off. Expected Vehicle Response The steering is locked. Suspected Area when Expected Vehicle Response Fails and Troubleshooting Information If the steering does not lock, the following parts may be malfunctioning. STEERING LOCK SYSTEM - DOOR COURTESY SWITCH When the driver side door is opened, "FL Door Courtesy" in the Data List changes from "ON" to "OFF". ACTION 9 Action The lock sensor of the front door outside handle assembly LH is touched while the electrical key transmitter is carried. Expected Vehicle Response The doors are locked. At the same time, answer-back is performed (the hazard warning lights illuminate and the buzzer sounds).

CUSTOMIZE PARAMETERS

1. CUSTOMIZE SMART KEY SYSTEM (for Entry Function) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Smart Key/Access or Warning. Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Park Wait Time (Waiting time to permit unlocking door after locking) 2.5s Function that sets the period of time (lock confirmation time) that the door is prevented from being unlocked by operating the front door outside handle assembly after an entry lock operation is performed. 0.5s, 1.5s, 2.5s or 5s Certification ECU (smart key ECU assembly) Ignition Available Area (Area in which entry ignition function is available) All Function that sets the area that the electrical key transmitter must be in before the engine switch can be operated. Front or All Certification ECU (smart key ECU assembly) Back Door Opening Operation Long Function that sets the way the back door opener switch must be pressed in order to open the back door. Long, Twice or OFF Certification ECU (smart key ECU assembly) Key Low Battery Warning (Warning when transmitter battery becomes weak) ON Enables or disables the sounding of the buzzer when the transmitter battery is low and the engine switch is turned off after being on (IG) for 20 minutes or more. ON or OFF Certification ECU (smart key ECU assembly) Touch activation Over Threshold Active The function that limits the consecutive entry lock operation to only 2 times can be changed between Active and Not Active. When in Not Active mode, there is no limit for the number of times that the consecutive entry lock operation can be performed. Active or Not Active Certification ECU (smart key ECU assembly) Door Unlock Mode2 All Function that chooses the doors to be operated by entry unlock operation All or Driver Certification ECU (smart key ECU assembly) Entry cancel function HINT: While the smart key system (for Entry Function) is canceled, it is possible to lock and unlock the doors with the wireless operation, and the start system can be operated by holding the electrical key transmitter against the engine switch. The following functions are disabled when the smart key system (for Entry Function) is canceled. Entry unlock/lock functions Entry ignition function Key lock-in prevention function Entry warning functions When canceling the system through manual operation: Make sure the following conditions are met: The engine switch is off. The driver side door is closed. The driver side door is unlocked. Press the unlock switch of the electrical key transmitter. Open the driver side door within 5 seconds of completing the step above (driver side door: closed at beginning of step --> opened). With the driver side door open, press the unlock switch of the electrical key transmitter 2 times within 5 seconds of completing the step above. NOTE: If the driver side door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Close and open the driver side door twice within 30 seconds of completing the above step (driver side door: open at beginning of step --> closed --> opened --> closed --> opened). With the driver side door open, press the unlock switch of the electrical key transmitter 2 times within 30 seconds of completing the step above. NOTE: If the driver side door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Close and open the driver side door within 30 seconds of completing the step above (driver side door: open at beginning of step --> closed --> opened). Close the driver side door within 5 seconds of completing the above step. Perform the following procedure to restore the smart key system (for Entry Function) to the active state from the canceled state. Perform the procedures to cancel the smart key system (for Entry Function) again. HINT: The system changes between the canceled state and the active state each time the procedure to cancel the system through manual operation is performed.
