DISASSEMBLY
| CAUTION | If the mirror shatters during removal, flying debris may cause injuries. Be sure to wear protective clothing, gloves, glasses, etc. when performing these procedures. |
Note. When replacing the mirror body, prevent damage to the mirror body by placing a protective cloth on the work area.
Scheme 9
Scheme 10
Scheme 11
- DISCONNECT MIRROR Face the mirror holder upward and look at the bottom of the mirror. Find the 2 grooves between the mirror holder and holder base. Insert a screwdriver into a groove and twist it to release the claw. Then repeat for the other groove. HINT: Tape the screwdriver tip before use. CAUTION: To prevent the mirror from shattering and causing flying debris, apply tape to the front of the mirror. NOTE: To prevent damage to the vehicle, apply protective tape on the mirror holder base near the lower edge of the mirror. A piece of cloth can also be used. Lift up the lower part of the mirror holder and then release the 2 hooks on the top of the mirror. Remove the mirror holder.
- REMOVE MIRROR GARNISH Detach the 7 claws. Remove the garnish.
- REMOVE SIDE TURN SIGNAL LIGHT LENS LH Disconnect the connector. Remove the 2 screws and lens.
Scheme 12
Scheme 13
- INSTALL SIDE TURN SIGNAL LIGHT LENS LH First set the lens position by inserting the lens peg to the location labeled A in the illustration. Then insert the lens guide to the V-shaped groove as shown in C in the illustration. Install the lens with the 2 screws labeled B. Connect the connector.
- INSTALL MIRROR GARNISH
- CONNECT MIRROR HINT: Before connecting the mirror holder, use a dryer to sufficiently heat the backside of the mirror holder where the claws are located. NOTE: If the ambient temperature is low and the claws are not heated before installing, the claws may be broken.
