Air Conditioning: Removal & Installation Scion tC I рестайлинг

REMOVAL

1. REMOVE BLOWER ASSEMBLY Remove the blower assembly (see «REMOVAL»(ref-296255-S25447216122008082200000) ).
2. REMOVE AIR INLET SERVO MOTOR (See «DISASSEMBLY»(ref-296255-S32188679312008082200000) )

Scheme 76

1. INSPECT AIR INLET SERVO MOTOR Inspect the servo motor operation. Connect the positive (+) lead from the battery to terminal D1-3 and negative (-) lead to terminal D1-2, and then check that the arm turns to the "FRESH" side smoothly. Connect the positive (+) lead from the battery to terminal D1-3 and negative (-) lead to terminal D1-1, and then check that the arm turns to the "RECIRCULATION" side smoothly. If the operation is not as specified, replace the air inlet servo motor.

INSTALLATION

1. INSTALL AIR INLET SERVO MOTOR (See «REASSEMBLY»(ref-296255-S04646221672008082200000) )
2. INSTALL BLOWER ASSEMBLY Install the blower assembly (see «INSTALLATION»(ref-296255-S33609774952008082200000) ).

Scheme 77

1. REMOVE AIR CONDITIONING RADIATOR ASSEMBLY Remove the air conditioning radiator assembly (see «REMOVAL»(ref-296255-S15571277472008082200000) ).
2. REMOVE AIR OUTLET CONTROL SERVO MOTOR (See «DISASSEMBLY»(ref-296255-S11472666532008082200000) )

Scheme 78

1. INSPECT AIR OUTLET CONTROL SERVO MOTOR Inspect the servo motor operation. Connect the positive (+) lead from the battery to terminal D3-5 (FACE) and negative (-) lead to terminal D3-4 (DEF), and then check that the lever turns to the "FACE" position smoothly. Connect the positive (+) lead from the battery to terminal D3-4 (DEF) and negative (-) lead to terminal D3-5 (FACE), and then check that the lever turns to the "DEF" position smoothly. If the operation is not as specified, replace the air outlet control servo motor.

1. INSTALL AIR OUTLET CONTROL SERVO MOTOR (See «REASSEMBLY»(ref-296255-S02423920432008082200000) )
2. INSTALL AIR CONDITIONING RADIATOR ASSEMBLY Install the air conditioning radiator assembly (see «INSTALLATION»(ref-296255-S12452546332008082200000) ).

Scheme 79

1. REMOVE AIR CONDITIONING RADIATOR ASSEMBLY Remove the air conditioning radiator assembly (see «REMOVAL»(ref-296255-S15571277472008082200000) ).
2. REMOVE AIR MIX CONTROL SERVO MOTOR (See «DISASSEMBLY»(ref-296255-S11472666532008082200000) )

Scheme 80

1. INSPECT AIR MIX CONTROL SERVO MOTOR Inspect the servo motor operation. Connect the positive (+) lead from the battery to terminal D2-5 (MAXHOT) and negative (-) lead to terminal D2-4 (MAXCOOL), and then check that the lever turns to the "MAXHOT" position smoothly. Connect the positive (+) lead from the battery to terminal D2-4 (MAXCOOL) and negative (-) lead to terminal D2-5 (MAXHOT), and then check that the lever turns to the "MAXCOOL" position smoothly. If the operation is not as specified, replace the air mix control servo motor.

1. INSTALL AIR MIX CONTROL SERVO MOTOR (See «REASSEMBLY»(ref-296255-S02423920432008082200000) )
2. INSTALL AIR CONDITIONING RADIATOR ASSEMBLY Install the air conditioning radiator assembly (see «INSTALLATION»(ref-296255-S12452546332008082200000) ).

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-296255-S03425958222008082200000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
3. DISCONNECT NO. 1 COOLER REFRIGERANT SUCTION HOSE Remove the bolt and disconnect the cooler refrigerant suction hose from the cooler compressor. Remove the O-ring from the cooler refrigerant suction hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering them.
4. DISCONNECT NO. 1 COOLER REFRIGERANT DISCHARGE HOSE Remove the bolt and disconnect the cooler refrigerant discharge hose from the cooler compressor. Remove the O-ring from the cooler refrigerant discharge hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent moisture and foreign matter from entering them.
5. REMOVE ENGINE UNDER COVER RH
6. REMOVE FAN AND GENERATOR V BELT (See «REMOVAL»(ref-296237-S29030242902008082200000) )
7. REMOVE COOLER COMPRESSOR ASSEMBLY Disconnect the connector. Remove the 4 bolts and cooler compressor.

Scheme 85

Scheme 86

Scheme 87

1. REMOVE MAGNET CLUTCH ASSEMBLY Using SST, hold the magnet clutch hub. SST 95047-10400 Remove the bolt, magnet clutch hub and magnet clutch washer. HINT: There is no set number of magnet clutch washers since they are used for adjusting. Using a snap ring expander, remove the snap ring and magnet clutch rotor. NOTE: Do not damage the seal cover of the bearing when removing the snap ring. Disconnect the connector. Using a snap ring expander, remove the snap ring and magnet clutch starter.

Scheme 88

1. INSPECT COOLER COMPRESSOR ASSEMBLY Connect the positive (+) lead from the battery to terminal A1-1 and the negative (-) lead to the body ground. Check that the magnetic clutch is engaged. If the operation is not as specified, replace the magnet clutch.

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. INSTALL MAGNET CLUTCH ASSEMBLY Matching the parts shown in the illustration, install the magnet clutch starter. Using a snap ring expander, install a new snap ring with the chamfered side facing up. NOTE: Do not damage the seal cover of the bearing when installing the snap ring. Connect the connector. Using a snap ring expander, install the magnet clutch rotor and a new snap ring with the chamfered side facing up. NOTE: Do not expand the snap ring by more than 30.5 mm (1.2 in.) when installing it. Do not damage the seal cover of the bearing when installing the snap ring. Install the magnet clutch washer and magnet clutch hub. NOTE: Do not change the combination of the magnet clutch washers used before disassembly. Using SST, hold the magnet clutch hub and install the bolt. SST 95047-10400 Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) NOTE: Make sure that there is no foreign matter or oil on the compressor shaft, bolt, and clutch hub.
2. INSPECT MAGNETIC CLUTCH CLEARANCE Set the dial indicator to the magnet clutch hub. Connect the battery positive (+) lead to the terminal of the magnet clutch connector and the negative (-) lead to the earth wire. Turn the magnet clutch on and off and measure the clearance. Standard clearance: 0.35 to 0.60 mm (0.014 to 0.023 in.) If the measured value is not within the standard range, remove the magnet clutch hub and adjust it with magnet clutch washers. NOTE: Adjustment should be performed with 3 or less magnet clutch washers. Remove the compressor and magnetic clutch from the vise.
3. ADJUST COMPRESSOR OIL When replacing the cooler compressor with a new one, after gradually removing the refrigerant gas from the service valve, drain the following amount of oil from the new cooler compressor before installation. Standard: (Oil capacity inside new cooler compressor: 140 + 15 cc (4.7 + 0.5 fl. oz.)) - (Remaining oil amount in the removed cooler compressor) = (Oil amount to be removed when replacing) NOTE: When checking the compressor oil level, observe the precautions for the cooler removal/installation. Since compressor oil remains in the pipes of the vehicle, if a new cooler compressor is installed without removing some oil inside, the oil amount becomes excessive, preventing heat exchange in the refrigerant cycle and causing refrigerant failure. If the remaining oil in the removed cooler compressor is too small in volume, check for oil leakage. Be sure to use ND-OIL 8 for compressor oil.

Scheme 93

1. INSTALL COOLER COMPRESSOR ASSEMBLY Install the cooler compressor with the 4 bolts. Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) NOTE: Tighten the bolts in the order shown in the illustration to install the cooler compressor. Connect the connector.
2. INSTALL NO. 1 COOLER REFRIGERANT DISCHARGE HOSE Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the cooler compressor. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the cooler refrigerant discharge hose. Install the cooler refrigerant discharge hose on the cooler compressor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
3. INSTALL NO. 1 COOLER REFRIGERANT SUCTION HOSE Remove the attached vinyl tape from the hose. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the cooler compressor. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the cooler refrigerant suction hose. Install the cooler refrigerant suction hose on the cooler compressor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 7 ft.*lbf)
4. INSTALL FAN AND GENERATOR V BELT (See «INSTALLATION»(ref-296237-S08588171322008082200000) )
5. INSTALL ENGINE UNDER COVER RH
6. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
7. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
8. CHARGE REFRIGERANT (See «REPLACEMENT»(ref-296255-S03425958222008082200000) )
9. WARM UP ENGINE (See «REPLACEMENT»(ref-296255-S03425958222008082200000) )
10. INSPECT FOR REFRIGERANT LEAK (See «REPLACEMENT»(ref-296255-S03425958222008082200000) )

Scheme 94

1. REMOVE AIR CONDITIONING RADIATOR ASSEMBLY Remove the air conditioning radiator assembly (see «REMOVAL»(ref-296255-S15571277472008082200000) ).
2. REMOVE EVAPORATOR TEMPERATURE SENSOR (See «DISASSEMBLY»(ref-296255-S11472666532008082200000) )

Scheme 95

1. INSPECT EVAPORATOR TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition A8-1 - A8-2 -10°C(14°F) 7.40 to 9.20 kohms -5°C (23°F) 5.65 to 7.00 kohms 0°C (32°F) 4.35 to 5.40 kohms 5°C (41°F) 3.40 to 4.20 kohms 10°C(50°F) 2.68 to 3.30 kohms 15°C (59°F) 2.10 to 2.60 kohms 20°C (68°F) 1.66 to 2.10 kohms 25°C (77°F) 1.32 to 1.66 kohms 30°C (86°F) 1.05 to 1.35 kohms NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be almost the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (see the graph ). If the resistance value is not as specified, replace the sensor.

1. INSTALL EVAPORATOR TEMPERATURE SENSOR (See «REASSEMBLY»(ref-296255-S02423920432008082200000) )
2. INSTALL AIR CONDITIONING RADIATOR ASSEMBLY Install the air conditioning radiator assembly (see «INSTALLATION»(ref-296255-S12452546332008082200000) ).

Scheme 96

Scheme 97

1. INSPECT PRESSURE SWITCH (for magnet clutch control) Check the air conditioning operation. Disconnect the P5 pressure switch connector. Connect terminals P5-1 and P5-4 of the connector of the pressure switch on the vehicle wire harness side using a service wire. Start the engine. Turn the air conditioning switch on and check that the magnet clutch is turned on. Check that the magnet clutch is turned off when disconnecting terminals P5-1 and P5-4 (that were connected in the previous step). Standard: Terminals P5-1 and P5-4 are connected: magnet clutch is on Terminals P5-1 and P5-4 are disconnected: magnet clutch is off Replace the pressure switch if the magnet clutch is operated normally. Inspect and repair the wire harness between the pressure switch and the ECM.
2. INSPECT PRESSURE SWITCH (for cooling fan control) Set the manifold gauge. HINT: The switch turns the condenser fan on or off in accordance with pressure in the cycle so that heat exchange in the condenser can be performed effectively within the normal pressure range. Disconnect the P5 pressure switch connector and connect terminals P5-1 and P5-4 using a tool such as a service wire. Connect the positive (+) lead from the ohmmeter to terminal P5-2 and the negative (-) lead to terminal P5-3. Start the engine and turn the air conditioning switch on. Check that the continuity between terminals P5-2 and P5-3 changes in accordance with the refrigerant pressure as shown in the illustration. If the operation is not as specified, replace the pressure switch.

Scheme 98

1. INSPECT MAGNET CLUTCH RELAY (Marking: MG/C) Remove the magnet clutch relay from the No. 2 engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition 3 - 5 Always 10 kohms or higher 3 - 5 Battery voltage is applied to terminals 1 and 2 Below 1 ohms If the resistance is not as specified, replace the magnet clutch relay.

Scheme 99

1. INSPECT HEATER RELAY (Marking: HTR) Remove the heater relay from the instrument panel junction block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition 3 - 4 Always Below 1 ohms 3 - 4 Battery voltage is applied to terminals 1 and 2 10 kohms or higher 3 - 5 Always 10 kohms or higher 3 - 5 Battery voltage is applied to terminals 1 and 2 Below 1 ohms If the resistance is not as specified, replace the heater relay.

Scheme 100

Scheme 101

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL CAUTION: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) (See «REMOVAL»(ref-296246-S03403041552008082200000) )
3. REMOVE CONSOLE PANEL UPPER FRONT (See «REMOVAL»(ref-296246-S03403041552008082200000) )
4. REMOVE INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY Detach the 9 claws. NOTE: If the heater control is removed with the cover open, it may be broken. Be sure the cover is closed when removing it. Disconnect the connector, then remove the heater control.

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. REMOVE CENTER CLUSTER MODULE KNOB Remove the center cluster module knob.
2. REMOVE HEATER CONTROL BASE LOWER Remove the 6 screws. Detach the 2 claws and remove the heater control panel. Detach the 4 claws and remove the heater control base lower.
3. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY Detach the claw and remove the knob. Detach the 2 claws and remove the knob. Release the 2 claws and remove the knob.

1. INSTALL INSTRUMENT CLUSTER FINISH PANEL ASSEMBLY Connect the connector. Attach the 9 claws to install the instrument cluster finish panel.
2. INSTALL CONSOLE PANEL UPPER FRONT (See «INSTALLATION»(ref-296246-S19366412192008082200000) )
3. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transaxle) (See «INSTALLATION»(ref-296246-S19366412192008082200000) )
4. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
5. PERFORM INITIALIZATION Perform initialization (see «INITIALIZATION»(ref-296226-S09190278172008082200000) ). NOTE: Certain systems need to be initialized after disconnecting and reconnecting the cable from the negative (-) battery terminal.
