DESCRIPTION
The steering lock ECU and steering lock motor are built into the steering lock actuator assembly.
The steering lock ECU detects whether the steering lock is in the lock or unlock position by using the lock position sensor of the steering lock motor.
The steering lock ECU receives lock and unlock command signals from the certification ECU (smart key ECU assembly) and responds with lock and unlock operation signals.
HINT
The steering lock actuator assembly (steering lock ECU) is not connected to the CAN communication system. However, the steering lock actuator assembly (steering lock ECU) is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Condition | Trouble Area | DTC Output Confirmation Operation |
|---|---|---|---|
| B2781 | One of the following conditions is met (1-trip detection logic*1): The steering lock/unlock position sensor is malfunctioning*2. The steering lock motor activation circuit has a short circuit. The steering lock motor activation circuit has an open circuit. | Steering lock actuator assembly (steering lock ECU) LIN communication system | No confirmation operation is necessary (monitoring is continuous). |
- *1: Only output while a malfunction is present and the engine switch is on (IG).
- *2: When both detection switches turn on, the system is determined to be malfunctioning.
Scheme 69
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. | Prohibits the engine from being started (the engine does not crank). |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC | Data List Item | Active Test Item |
|---|---|---|
| B2781 | Smart Key Sensor Value Power Supply Short |
RELATED DATA LIST AND ACTIVE TEST ITEMS
The certification ECU (smart key ECU assembly) has a power source mode switching function.
This DTC is stored when the SLR+ input (the steering lock motor activation permission signal) sent directly from the certification ECU (smart key ECU assembly) to the steering lock actuator assembly (steering lock ECU) is determined to be abnormal.
HINT
The steering lock actuator assembly (steering lock ECU) is not connected to the CAN communication system. However, the steering lock actuator assembly (steering lock ECU) is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Condition | Trouble Area | DTC Output Confirmation Operation |
|---|---|---|---|
| B2782 | Either condition is met (1-trip detection logic): The steering lock motor activation command circuit has a short circuit. The steering lock motor activation command circuit has an open circuit. HINT: If the power supply signal from the LIN communication line does not match the power supply signal from the direct line, the system is determined to be malfunctioning. | Steering lock actuator assembly (steering lock ECU) Certification ECU (Smart key ECU assembly) Harness or connector | Perform a steering lock/unlock operation. (The steering locks when a door is opened with the shift lever in P* and the engine switch off. The steering unlocks when the engine switch is turned on (ACC) or on (IG) while carrying the key) |
- *: for Automatic Transmission
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. | Prohibits the engine from being started (the engine does not crank). |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC | Data List Item | Active Test Item |
|---|---|---|
| B2782 | Smart Key Power Supply Short |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 70
This DTC is stored when the steering lock actuator assembly (steering lock ECU) detects an IG2 power supply malfunction.
HINT
The steering lock ECU is not connected to the CAN communication system. However, the steering lock ECU is connected to the certification ECU (smart key ECU assembly) via LIN communication and communicates with other components via CAN communication through the certification ECU (smart key ECU assembly).
| DTC No. | Detection Condition | Trouble Area | DTC Output Confirmation Operation |
|---|---|---|---|
| B2788 | Mismatch between the steering lock actuator assembly (steering lock ECU) IGN1 input from the LIN communication system and from the direct line (1-trip detection logic*). | GAUGE fuse Steering lock actuator assembly (steering lock ECU) Harness or connector | No confirmation operation is necessary (monitoring is continuous). |
- *: Only output while a malfunction is present and the engine switch is on (IG).
| Vehicle Condition when Malfunction Detected | Fail-safe Function when Malfunction Detected |
|---|---|
| The steering cannot be locked or unlocked. For this reason, the engine cannot be started. |
VEHICLE CONDITION AND FAIL-SAFE FUNCTION WHEN MALFUNCTION DETECTED
| DTC Code | Data List Item | Active Test Item |
|---|---|---|
| B2788 |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 71
The steering lock actuator activates the steering lock motor and moves the lock bar into the steering column to lock the steering.
When the steering lock is operating, the steering may not lock when the lock bar is not aligned with the lock hole of the steering column. In this case, the steering can be locked by turning the steering wheel a little in the same manner as is done for a vehicle with a mechanical key to change the position of the lock hole.
| Problem Symptom | Data List Item | Active Test Item |
|---|---|---|
| Unable to lock steering wheel | Smart Key All items. Refer to DATA LIST / ACTIVE TEST [12/2013 - ] Main Body D Door Courtesy SW |
RELATED DATA LIST AND ACTIVE TEST ITEMS
Scheme 72
The steering lock actuator assembly activates the steering lock motor and moves the lock bar into the steering column to lock the steering.
The steering may not unlock when the lock bar gets stuck in the lock hole of the steering column. In this case, if an engine start operation is performed while shaking the steering wheel in the same manner as is done for a vehicle with a mechanical key, the lock bar will be unlocked. If the certification ECU (smart key ECU assembly), ID code box (immobiliser code ECU) (w/ ID Code Box) or ECM is replaced, the system needs to be initialized and registered. Otherwise, the steering cannot be unlocked and the engine cannot be started.
| Problem Symptom | Data List Item | Active Test Item |
|---|---|---|
| Unable to unlock steering wheel (Engine cannot start) | Smart Key All items. Refer to DATA LIST / ACTIVE TEST [12/2013 - ] |
RELATED DATA LIST AND ACTIVE TEST ITEMS
