PRECAUTION [12/2013 - ]

1. IGNITION SWITCH EXPRESSIONS HINT: The type of ignition switch used on this model differs depending on the specifications of the vehicle. The expressions listed in the table below are used in this service information. Expression Ignition Switch (Position) Engine Switch (Condition) Ignition Switch off LOCK Off (Lock) Ignition Switch ACC ACC On (ACC) Ignition Switch ON ON On (IG) Engine Start START On (Start)
2. CAN COMMUNICATION SYSTEM TROUBLESHOOTING Because the order of diagnosis is important to allow a correct diagnosis, make sure to begin troubleshooting using How to Proceed with Troubleshooting when CAN communication system related DTCs are output. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [12/2013 - ]»(ref-612381-S31527157402014042900000) .
3. PRECAUTIONS FOR STEERING SYSTEM HANDLING Be careful when replacing parts. Incorrect replacement could affect the performance of the steering system and result in hazardous driving.
4. PRECAUTIONS FOR SRS AIRBAG SYSTEM HANDLING This vehicle is equipped with a Supplemental Restraint System (SRS) which includes parts such as airbags for the driver and the front passenger. Failure to carry out service operations in the correct sequence could cause unexpected SRS deployment during servicing and may cause a serious accident. Before servicing (including removal or installation of parts, inspection or replacement), be sure to read Precaution for SRS. Refer to «PRECAUTION [12/2013 - ]»(ref-612421-S24190999222014042900000) .
5. BUS LINE REPAIR After repairing a bus line with solder, wrap the repaired part with electrical tape. NOTE: The CANL bus line and CANH bus line must be installed together at all times. When installing, make sure that these lines are twisted, because CAN bus lines are likely to be influenced by electrical noise if the bus lines are not twisted. Leave approximately 80 mm (3.150 in.) loose in the twisted wires around the connector. When repairing the CAN bus lines, do not change the length of the lines. (Make sure that the length of the CANH bus line and CANL bus line are the same.) Do not use bypass wiring between connectors. TEXT IN ILLUSTRATION *a Bypass Wire NOTE: The ability of the twisted bus lines to resist interference will be lost if bypass wiring is used. Do not use a twisted pair of wires for bypass wiring.
6. CONNECTOR HANDLING When checking resistance with a tester, insert the tester probes from the backside (harness side) of the connector. TEXT IN ILLUSTRATION *a Tester Probe Use service wires to check the connector if it is impossible to check continuity from the rear of the connector. TEXT IN ILLUSTRATION *a Service Wire
7. PRECAUTIONS FOR INSPECTING OR REPLACING CAN JUNCTION CONNECTOR If the CAN junction connector is removed from the vehicle for inspection or replacement, make sure to install the CAN junction connector and all wire harnesses to their original locations with tape and the clamps.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. OVERALL CAN BUS DIAGRAM Control system CAN is composed of 1 bus. TEXT IN ILLUSTRATION *1 V Bus *2 V Bus Terminating Resistor *3 ECM (for V Bus) *4 Combination Meter Assembly (for V Bus) *5 Main Body ECU (Network Gateway ECU) (for V Bus) *6 DLC3 (for V Bus) *7 Steering Angle Sensor (Spiral Cable Sub-assembly) (for V Bus) *8 PSP (Option Connector) (for V Bus) *9 Air Bag ECU Assembly (for V Bus) *10 TCM (for V Bus) *11 Power Steering ECU Assembly (for V Bus) *12 Skid Control ECU (Brake Actuator Assembly) (for V Bus)
2. V BUS HINT: The CAN communication system connects to other networks via ECUs that function as a gateway. Refer to «SYSTEM DIAGRAM [07/2013 - 12/2013]»(ref-612424-S05733493522014042900000) .

Scheme 33

Scheme 34

Scheme 35

1. OVERALL CAN BUS DIAGRAM Control system CAN is composed of 1 bus. TEXT IN ILLUSTRATION *1 V Bus *2 V Bus Terminating Resistor *3 ECM (for V Bus) *4 Combination Meter Assembly (for V Bus) *5 Main Body ECU (Network Gateway ECU) (for V Bus) *6 Certification ECU (Smart Key ECU Assembly) (for V Bus) *7 DLC3 (for V Bus) *8 Steering Angle Sensor (Spiral Cable Sub-assembly) (for V Bus) *9 PSP (Option Connector) (for V Bus) *10 Airbag ECU Assembly (for V Bus) *11 Air Conditioning Control Assembly (for V Bus) *12 TCM (for V Bus) *13 Power Steering ECU Assembly (for V Bus) *14 Skid Control ECU (Brake Actuator Assembly) (for V Bus)
2. V BUS HINT: The CAN communication system connects to other networks via ECUs that function as a gateway. Refer to «SYSTEM DIAGRAM [12/2013 - ]»(ref-612424-S32810444392014042900000) .

Scheme 36

1. BRIEF DESCRIPTION The Controller Area Network (CAN) is a serial data communication system for real time application. It is a vehicle multiplex communication system which has a high communication speed and the ability to detect malfunctions. Using the CANH and CANL bus lines as a pair, CAN communication is performed using a voltage differential. (A base voltage is applied to the pair of lines and a voltage differential is created when communicating.) Many ECUs or sensors installed on the vehicle operate by sharing information and communicating with each other. The CAN has two resistors of 120 ohms which are necessary to enable communication. Control system CAN is composed of 1 bus.
2. DEFINITION OF TERMS Main bus The main bus is a wire harness between the two terminating resistors on the bus. This is the main bus in the CAN communication system. Branch The branch is a wire harness which diverges from the main bus to an ECU or sensor. Terminating resistors Two resistors of 120 ohms are installed in parallel across the ends of the CAN main bus lines. They are called terminating resistors. These resistors allow the changes of the voltage differential between the CAN bus lines to be accurately judged. To allow proper function of CAN communication, it is necessary to have both terminating resistors installed. Since the two resistors are installed in parallel, this results in a measurement of approximately 60 ohms.
3. ECUS OR SENSORS WHICH COMMUNICATE THROUGH CAN COMMUNICATION SYSTEM V Bus Main body ECU (network gateway ECU) Combination meter assembly ECM TCM* Skid control ECU (brake actuator assembly) Steering angle sensor (spiral cable sub-assembly) Power steering ECU assembly Air bag ECU assembly * : for Automatic Transmission System
4. CIRCUIT DESCRIPTION The V bus has termination circuits with two resistors of 120 ohms.
5. TROUBLESHOOTING REMARKS DTCs for the CAN communication system can be checked using the Techstream. The DLC3 is connected to the CAN communication system, but no DTCs exist regarding problems in the DLC3 or the DLC3 branch lines. If there is any trouble in the DLC3 or the DLC3 branch lines, ECUs on the CAN cannot output DTCs to the Techstream. Troubles in the CAN V bus (communication lines) can be checked by measuring the resistance between the terminals of the DLC3. However, an open circuit in a branch line other than the DLC3 branch lines cannot be checked from the DLC3 (except branch line of the DLC3). NOTE: Do not insert the tester probes directly into the DLC3. Be sure to use service wires.
6. DIAGNOSTIC TROUBLE CODES FOR CAN COMMUNICATION SYSTEM HINT: See Diagnosis System. Refer to «DIAGNOSIS SYSTEM [07/2013 - 12/2013]»(ref-612381-S33318737382014042900000) .
7. HOW TO DISTINGUISH CONNECTOR OF CAN JUNCTION CONNECTOR In the CAN communication system, the shape of the connectors connected to the CAN junction connector which has an earth terminal is the same. The connectors connected to the CAN junction connector can be distinguished by the colors of the bus lines and the connecting side of the junction connector. HINT: See Terminals of ECU for bus line color or the shape of connecting surface. Refer to «TERMINALS OF ECU [07/2013 - 12/2013]»(ref-612381-S21504446002014042900000) .

TERMINALS OF ECU [07/2013 - 12/2013]

Note. After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION [07/2013 - ] . Turn the ignition switch off before measuring the resistances between CAN main bus lines and between CAN branch lines. Turn the ignition switch off before inspecting CAN bus lines for a ground short. Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the ignition switch, any other switches or the doors. If any doors need to be opened in order to check connectors, open the doors and leave them open. This information describes the standard values for all CAN related components.

HINT

1. Operating the ignition switch, any other switches or a door triggers the related ECU and sensor communication on the CAN. This communication will cause the resistance value to change.
2. Even after DTCs are cleared, if a DTC is stored again after driving the vehicle for a while, the malfunction may be occurring due to vibration of the vehicle. In such a case, wiggling the ECUs or wire harness while performing the inspection below may help determine the cause of the malfunction.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

1. CAN NO. 1 JUNCTION CONNECTOR Check the CAN No. 1 junction connector. HINT: The following tables contain information about the items and buses connected via junction connectors. The junction connector may be used for multiple separate buses. In this case, the name of the bus will be shown below the name of the item that terminals are connected to. The bus name will be shown in brackets (example: (for V bus)). Connection diagram TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM (for V bus)* *c to Skid Control ECU (Brake Actuator Assembly) (for V bus) *d to CAN No. 2 Junction Connector (for V bus) *e to Power Steering ECU Assembly (for V bus) - - Check the connection diagram of the components which are connected to the CAN No. 1 junction connector. Terminal No. Wiring Color Connected to A17-5 B-W TCM (for V bus)* A17-16 L A17-6 BR Skid Control ECU (Brake Actuator Assembly) (for V bus) A17-17 B-R A17-7 W-B CAN No. 2 Junction Connector (for V bus) A17-18 R-Y A17-8 B Power Steering ECU Assembly (for V bus) A17-19 W * : for Automatic Transmission System
2. CAN NO. 2 JUNCTION CONNECTOR Check the CAN No. 2 junction connector. Connection diagram TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector (for V bus) *c to Combination Meter Assembly (for V bus) *d to Main Body ECU (Network Gateway ECU) (for V bus) *e to DLC3 (for V bus) *f to Steering Angle Sensor (Spiral Cable Sub-assembly) (for V bus) *g to PSP (Option Connector) (for V bus) *h to Air Bag ECU Assembly (for V bus) *i to ECM (for V bus) - - Check the connection diagram of the components which are connected to the CAN No. 2 junction connector. Terminal No. Wiring Color Connected to D43-1 W-B CAN No. 1 Junction Connector (for V bus) D43-12 R-Y D43-2 BR Combination Meter Assembly (for V bus) D43-13 BR-W D43-3 P Main Body ECU (Network Gateway ECU) (for V bus) D43-14 LG D43-5 B-Y DLC3 (for V bus) D43-16 LG D43-6 G-W Steering Angle Sensor (Spiral Cable Sub-assembly) (for V bus) D43-17 G D43-7 P PSP (Option Connector) (for V bus) D43-18 L D43-8 P-L Air Bag ECU Assembly (for V bus) D43-19 R-W D43-9 O ECM (for V bus) D43-20 B-P
3. DLC3 Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a DLC3 Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D10-6 (CANH) - D10-14 (CANL) B-Y - LG HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D10-6 (CANH) - D10-4 (CG) B-Y - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-14 (CANL) - D10-4 (CG) LG - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-6 (CANH) - D10-16 (BAT) B-Y - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D10-14 (CANL) - D10-16 (BAT) LG - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
4. ECM TEXT IN ILLUSTRATION *a Component without harness connected (ECM) - - Disconnect the A33 and A36 ECM connectors. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) O - B-P HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 114 to 126 ohms A33-19 (CANH) - A36-4 (E01) O - B-L HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A33-18 (CANL) - A36-4 (E01) B-P - B-L LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A33-19 (CANH) - A33-2 (BATT) O - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A33-18 (CANL) - A33-2 (BATT) B-P - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
5. TCM (for Automatic Transmission System) TEXT IN ILLUSTRATION *a Component without harness connected (TCM) - - Disconnect the A18 TCM connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A18-29 (CANH) - A18-28 (CANL) B-W - L HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms A18-29 (CANH) - A18-3 (E02) B-W - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A18-28 (CANL) - A18-3 (E02) L - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A18-29 (CANH) - A18-26 (BM) B-W - Y-R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A18-28 (CANL) - A18-26 (BM) L - Y-R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
6. POWER STEERING ECU ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Power Steering ECU Assembly) - - Disconnect the A14 and A15 power steering ECU assembly connectors. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Steering ECU Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A15-1 (CANH) - A15-7 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms A15-1 (CANH) - A14-2 (PGND) B - B HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A15-7 (CANL) - A14-2 (PGND) W - B LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A15-1 (CANH) - A14-1 (PIG) B - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A15-7 (CANL) - A14-1 (PIG) W - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
7. COMBINATION METER ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Combination Meter Assembly) - - Disconnect the D7 combination meter assembly connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Combination Meter Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D7-6 (CANH) - D7-7 (CANL) BR - BR-W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D7-6 (CANH) - D7-20 (ES1) BR - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D7-7 (CANL) - D7-20 (ES1) BR-W - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D7-6 (CANH) - D7-1 (B BR - R-W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D7-7 (CANL) - D7-1 (B BR-W - R-W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
8. INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY AND MAIN BODY ECU (NETWORK GATEWAY ECU) TEXT IN ILLUSTRATION *a Component without harness connected (Instrument Panel Junction Block Assembly) *b Component without harness connected (Main Body ECU (Network Gateway ECU)) Disconnect the D5 main body ECU (network gateway ECU) connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Main Body ECU (Network Gateway ECU)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D5-14 (CANH) - D5-13 (CANL) P - LG HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D5-14 (CANH) - D10-4 (CG) P - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D5-13 (CANL) - D10-4 (CG) LG - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D5-14 (CANH) - D10-16 (BAT) P - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D5-13 (CANL) - D10-16 (BAT) LG - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
9. STEERING ANGLE SENSOR (SPIRAL CABLE SUB-ASSEMBLY) TEXT IN ILLUSTRATION *a Component without harness connected (Steering Angle Sensor (Spiral Cable Sub-assembly)) - - Disconnect the D56 steering angle sensor (spiral cable sub-assembly) connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Steering Angle Sensor (Spiral Cable Sub-assembly)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D56-3 (CANH) - D56-2 (CANL) G-W - G HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D56-3 (CANH) - D10-4 (CG) G-W - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D56-2 (CANL) - D10-4 (CG) G - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D56-3 (CANH) - D10-16 (BAT) G-W - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D56-2 (CANL) - D10-16 (BAT) G - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
10. PSP (OPTION CONNECTOR) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to PSP (Option Connector)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D29-4 (CANH) - D29-5 (CANL) P - L HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D29-4 (CANH) - D10-4 (CG) P - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D29-5 (CANL) - D10-4 (CG) L - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D29-4 (CANH) - D10-16 (BAT) P - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D29-5 (CANL) - D10-16 (BAT) L - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
11. AIR BAG ECU ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Air Bag ECU Assembly) - - Disconnect the D27 air bag ECU assembly connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Air Bag ECU Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D27-13 (CANH) - D27-22 (CANL) P-L - R-W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D27-13 (CANH) - D10-4 (CG) P-L - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D27-22 (CANL) - D10-4 (CG) R-W - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D27-13 (CANH) - D10-16 (BAT) P-L - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D27-22 (CANL) - D10-16 (BAT) R-W - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
12. SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) TEXT IN ILLUSTRATION *a Component without harness connected (Skid Control ECU (Brake Actuator Assembly)) - - Disconnect the A5 skid control ECU (brake actuator assembly) connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) BR - B-R HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 114 to 126 ohms A5-26 (CANH) - A5-13 (GND2) BR - B HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A5-14 (CANL) - A5-13 (GND2) B-R - B LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A5-26 (CANH) - A5-1 (+BM) BR - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A5-14 (CAN_L) - A5-1 (+BM) B-R - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher

TERMINALS OF ECU [12/2013 - ]

Note. After turning the ignition switch off, waiting time may be required before disconnecting the cable from the negative (-) battery terminal. Therefore, make sure to read the disconnecting the cable from the negative (-) battery terminal notices before proceeding with work. Refer to PRECAUTION [07/2013 - ] . Turn the ignition switch off before measuring the resistances between CAN main bus lines and between CAN branch lines. Turn the ignition switch off before inspecting CAN bus lines for a ground short. Before measuring the resistance, leave the vehicle as is for at least 1 minute and do not operate the ignition switch, any other switches or the doors. If any doors need to be opened in order to check connectors, open the doors and leave them open. This information describes the standard values for all CAN related components.

HINT

1. Operating the ignition switch, any other switches or a door triggers the related ECU and sensor communication on the CAN. This communication will cause the resistance value to change.
2. Even after DTCs are cleared, if a DTC is stored again after driving the vehicle for a while, the malfunction may be occurring due to vibration of the vehicle. In such a case, wiggling the ECUs or wire harness while performing the inspection below may help determine the cause of the malfunction.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. CAN NO. 1 JUNCTION CONNECTOR Check the CAN No. 1 junction connector. HINT: The following tables contain information about the items and buses connected via junction connectors. The junction connector may be used for multiple separate buses. In this case, the name of the bus will be shown below the name of the item that terminals are connected to. The bus name will be shown in brackets (example: (for V bus)). Connection diagram TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM (for V bus)* *c to Skid Control ECU (Brake Actuator Assembly) (for V bus) *d to CAN No. 2 Junction Connector (for V bus) *e to Power Steering ECU Assembly (for V bus) - - Check the connection diagram of the components which are connected to the CAN No. 1 junction connector. Terminal No. Wiring Color Connected to A17-5 B-W TCM (for V bus)* A17-16 L A17-6 BR Skid Control ECU (Brake Actuator Assembly) (for V bus) A17-17 B-R A17-7 W-B CAN No. 2 Junction Connector (for V bus) A17-18 R-Y A17-8 B Power Steering ECU Assembly (for V bus) A17-19 W * : for Automatic Transmission System
2. CAN NO. 2 JUNCTION CONNECTOR Check the CAN No. 2 junction connector. Connection diagram TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector (for V bus) *c to Combination Meter Assembly (for V bus) *d to Main Body ECU (Network Gateway ECU) (for V bus) *e to Certification ECU (Smart Key ECU Assembly)*1 (for V bus) *f to DLC3 (for V bus) *g to Steering Angle Sensor (Spiral Cable Sub-assembly) (for V bus) *h to PSP (Option Connector) (for V bus) *i to Airbag ECU Assembly (for V bus) *j to ECM (for V bus) *k to Air Conditioning Control Assembly*2 (for V bus) - - Check the connection diagram of the components which are connected to the CAN No. 2 junction connector. Terminal No. Wiring Color Connected to D43-1 W-B CAN No. 1 Junction Connector (for V bus) D43-12 R-Y D43-2 BR Combination Meter Assembly (for V bus) D43-13 BR-W D43-3 P Main Body ECU (Network Gateway ECU) (for V bus) D43-14 LG D43-4 G Certification ECU (Smart Key ECU Assembly)*1 (for V bus) D43-15 R D43-5 B-Y DLC3 (for V bus) D43-16 LG D43-6 G-W Steering Angle Sensor (Spiral Cable Sub-assembly) (for V bus) D43-17 G D43-7 P PSP (Option Connector) (for V bus) D43-18 L D43-8 P-L Airbag ECU Assembly (for V bus) D43-19 R-W D43-9 O ECM (for V bus) D43-20 B-P D43-10 L-W Air Conditioning Control Assembly*2 (for V bus) D43-21 L-Y *1: w/ Smart Key System *2: for Automatic Air Conditioning System
3. DLC3 Measure the resistance according to the value(s) in the table below. TEXT IN ILLUSTRATION *a DLC3 Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D10-6 (CANH) - D10-14 (CANL) B-Y - LG HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D10-6 (CANH) - D10-4 (CG) B-Y - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-14 (CANL) - D10-4 (CG) LG - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-6 (CANH) - D10-16 (BAT) B-Y - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D10-14 (CANL) - D10-16 (BAT) LG - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
4. ECM TEXT IN ILLUSTRATION *a Component without harness connected (ECM) - - Disconnect the A33 and A36 ECM connectors. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) O - B-P HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 114 to 126 ohms A33-19 (CANH) - A36-4 (E01) O - B-L HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A33-18 (CANL) - A36-4 (E01) B-P - B-L LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A33-19 (CANH) - A33-2 (BATT) O - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A33-18 (CANL) - A33-2 (BATT) B-P - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
5. TCM (for Automatic Transmission System) TEXT IN ILLUSTRATION *a Component without harness connected (TCM) - - Disconnect the A18 TCM connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A18-29 (CANH) - A18-28 (CANL) B-W - L HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms A18-29 (CANH) - A18-3 (E02) B-W - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A18-28 (CANL) - A18-3 (E02) L - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A18-29 (CANH) - A18-26 (BM) B-W - Y-R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A18-28 (CANL) - A18-26 (BM) L - Y-R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
6. POWER STEERING ECU ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Power Steering ECU Assembly) - - Disconnect the A14 and A15 power steering ECU assembly connectors. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Steering ECU Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A15-1 (CANH) - A15-7 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms A15-1 (CANH) - A14-2 (PGND) B - B HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A15-7 (CANL) - A14-2 (PGND) W - B LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A15-1 (CANH) - A14-1 (PIG) B - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A15-7 (CANL) - A14-1 (PIG) W - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
7. COMBINATION METER ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Combination Meter Assembly) - - Disconnect the D7 combination meter assembly connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Combination Meter Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D7-6 (CANH) - D7-7 (CANL) BR - BR-W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D7-6 (CANH) - D7-20 (ES1) BR - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D7-7 (CANL) - D7-20 (ES1) BR-W - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D7-6 (CANH) - D7-1 (B) BR - R-W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D7-7 (CANL) - D7-1 (B) BR-W - R-W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
8. INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY AND MAIN BODY ECU (NETWORK GATEWAY ECU) TEXT IN ILLUSTRATION *a Component without harness connected (Instrument Panel Junction Block Assembly) *b Component without harness connected (Main Body ECU (Network Gateway ECU)) Disconnect the D5 main body ECU (network gateway ECU) connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Main Body ECU (Network Gateway ECU)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D5-14 (CANH) - D5-13 (CANL) P - LG HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D5-14 (CANH) - D10-4 (CG) P - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D5-13 (CANL) - D10-4 (CG) LG - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D5-14 (CANH) - D10-16 (BAT) P - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D5-13 (CANL) - D10-16 (BAT) LG - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
9. CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) (w/ Smart Key System) TEXT IN ILLUSTRATION *a Component without harness connected (Certification ECU (Smart Key ECU Assembly)) - - Disconnect the D41 and D48 certification ECU (smart key ECU assembly) connectors. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Certification ECU (Smart Key ECU Assembly)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D41-14 (CANH) - D41-15 (CANL) G - R HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D41-14 (CANH) - D48-11 (GND) G - B HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D41-15 (CANL) - D48-11 (GND) R - B LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D41-14 (CANH) - D48-2 (+B) G - R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D41-15 (CANL) - D48-2 (+B) R - R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
10. STEERING ANGLE SENSOR (SPIRAL CABLE SUB-ASSEMBLY) TEXT IN ILLUSTRATION *a Component without harness connected (Steering Angle Sensor (Spiral Cable Sub-assembly)) - - Disconnect the D56 steering angle sensor (spiral cable sub-assembly) connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Steering Angle Sensor (Spiral Cable Sub-assembly)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D56-3 (CANH) - D56-2 (CANL) G-W - G HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D56-3 (CANH) - D10-4 (CG) G-W - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D56-2 (CANL) - D10-4 (CG) G - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D56-3 (CANH) - D10-16 (BAT) G-W - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D56-2 (CANL) - D10-16 (BAT) G - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
11. PSP (OPTION CONNECTOR) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to PSP (Option Connector)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D29-4 (CANH) - D29-5 (CANL) P - L HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D29-4 (CANH) - D10-4 (CG) P - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D29-5 (CANL) - D10-4 (CG) L - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D29-4 (CANH) - D10-16 (BAT) P - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D29-5 (CANL) - D10-16 (BAT) L - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
12. AIRBAG ECU ASSEMBLY TEXT IN ILLUSTRATION *a Component without harness connected (Airbag ECU Assembly) - - Disconnect the D27 airbag ECU assembly connector. TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to Airbag ECU Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D27-13 (CANH) - D27-22 (CANL) P-L - R-W HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D27-13 (CANH) - D10-4 (CG) P-L - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D27-22 (CANL) - D10-4 (CG) R-W - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D27-13 (CANH) - D10-16 (BAT) P-L - W-B HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D27-22 (CANL) - D10-16 (BAT) R-W - W-B LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
13. AIR CONDITIONING CONTROL ASSEMBLY (for Automatic Air Conditioning System) TEXT IN ILLUSTRATION *a Component without harness connected (Air Conditioning Control Assembly) - - Disconnect the D19 air conditioning control assembly connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Conditioning Control Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition D19-13 (CANH) - D19-12 (CANL) L-W - L-Y HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 57 to 63 ohms D19-13 (CANH) - D19-16 (GND) L-W - B-Y HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D19-12 (CANL) - D19-16 (GND) L-Y - B-Y LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher D19-13 (CANH) - D19-9 (+B) L-W - L-R HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher D19-12 (CANL) - D19-9 (+B) L-Y - L-R LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher
14. SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) TEXT IN ILLUSTRATION *a Component without harness connected (Skid Control ECU (Brake Actuator Assembly)) - - Disconnect the A5 skid control ECU (brake actuator assembly) connector. TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) BR - B-R HIGH-level CAN bus line - LOW-level CAN bus line Cable disconnected from negative (-) battery terminal 114 to 126 ohms A5-26 (CANH) - A5-13 (GND2) BR - B HIGH-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A5-14 (CANL) - A5-13 (GND2) B-R - B LOW-level CAN bus line - Ground Cable disconnected from negative (-) battery terminal 200 ohms or higher A5-26 (CANH) - A5-1 (+BM) BR - W HIGH-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher A5-14 (CANL) - A5-1 (+BM) B-R - W LOW-level CAN bus line - Battery positive (+) Cable disconnected from negative (-) battery terminal 6 kohms or higher

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. ECUS OR SENSORS WHICH COMMUNICATE THROUGH CAN COMMUNICATION SYSTEM V Bus Main body ECU (network gateway ECU) Combination meter assembly ECM TCM* Skid control ECU (brake actuator assembly) Steering angle sensor (spiral cable sub-assembly) Power steering ECU assembly Air bag ECU assembly PSP (option connector) *: for Automatic Transmission System
2. CHECK FOR INSTALLED SYSTEMS (ECUS AND SENSORS) THAT ADOPT CAN COMMUNICATION The systems (ECUs and sensors) that adopt CAN communication vary depending on the vehicle and optional equipment. Check which systems (ECUs and sensors) are installed on the vehicle. HINT: The names of ECUs and sensors shown on the Techstream display may differ from those shown in the DTC Table by ECU section that follows. ECU/Sensor Name Techstream Display Applicability Main body ECU (network gateway ECU) Main Body Installed on all vehicles Combination meter assembly Combination Meter Installed on all vehicles ECM ECM (Engine) Installed on all vehicles TCM TCM for Automatic Transmission System Skid control ECU (brake actuator assembly) Skid Control (ABS/VSC/TRAC) Installed on all vehicles Steering angle sensor (spiral cable sub-assembly) Spiral cable (Steering Angle Sensor) Installed on all vehicles Power steering ECU assembly Power Steering (EPS) Installed on all vehicles Air bag ECU assembly Airbag Installed on all vehicles PSP (option connector) - Installed on all vehicles
3. CAN BUS CHECK HINT: The ECUs and sensors that are properly connected to the CAN communication system can be displayed using the Techstream. Using the Techstream, select "CAN Bus Check" from "System Select". NOTE: It may be possible to select buses that do not have ECUs or sensors from the bus selection pull-down menu. This is not a malfunction. (This occurs when optional devices are not on a sub bus that is monitored by a gateway function equipped ECU.) In the bus selection pull down menu, all buses applicable to the model are displayed (e.g. LIN communication buses are also displayed). Therefore, refer to the wiring diagrams to check the names of the sub buses for CAN communication. Refer to «SYSTEM DIAGRAM [07/2013 - 12/2013]»(ref-612381-S20277102272014042900000) . HINT: Different connection statuses are indicated by the background color of the ECUs and sensors that are displayed. EXPLANATION OF CAN BUS CHECK (COMMUNICATION BUS CHECK) SCREEN Bus Type Background Color Connection Status V Bus White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring (unstable communication). Not displayed Communication stop has continued since the start of the CAN bus check.*1 Sub bus (gateway function equipped ECU that does not have history of connected ECUs)*2 White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring (unstable communication). Not displayed Communication stop has continued since the start of the CAN bus check.*1 Sub bus (gateway function equipped ECU that has history of connected ECUs)*3 White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Currently not communicating (either of the following): Communication stop has continued since the start of the CAN bus check Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring Not displayed Either of the following: If a gateway function equipped ECU cannot communicate, the sub bus and ECUs connected to the sub bus will not be displayed. If no ECUs are connected to the sub bus, "There is no system found on the Communication Bus" will be displayed. HINT: Gateway function equipped ECUs relay signals between the ECUs connected to the different buses. *1: ECUs that are present in the vehicle but are not displayed on the CAN Bus Check. *2: Gateway function equipped ECU that does not memorize the sub bus ECUs that are connected to it. *3: Gateway function equipped ECU that memorizes the sub bus ECUs that are connected to it. If none of the connected ECUs are displayed, or there is no response from the vehicle to the Techstream, check the DLC3 branch and the V bus main bus lines for a malfunction. Observe the connection response screen for approximately 2 minutes to check for a change in connection status of the connected ECUs and sensors. HINT: If an open occurs in one of the lines of a CAN branch (except DLC3), output from the other branch line (the line that is not open) will be unstable and it may interfere the response (display) of other ECUs and sensors. If the connection status changes during the inspection, repair the open in the branch line of the ECU or sensor that does not respond (is not detected) and then perform the CAN bus check again.
4. HOW TO INTERPRET CAN BUS CHECK (COMMUNICATION BUS CHECK) SCREEN When a communication stop is currently occurring, the probable malfunctioning part can be determined from the CAN bus check and by using the following methods. NOTE: The following CAN bus wiring diagram is provided only as an example. This wiring diagram is different from the actual wiring diagram for this vehicle. HINT: When a communication stop is currently occurring, it is easier to determine the probable malfunctioning part from the CAN bus check rather than from communication DTCs. Wait for approximately 2 minutes after turning the Ignition switch ON (or simulate the driving conditions that enable the malfunction to be reproduced) and select the CAN bus check. Then observe the communication status of each ECU on the screen. If a communication error of only 1 ECU or sensor is indicated on the CAN Bus Check screen, a communication stop of the ECU or sensor is suspected. Example: Open in both CAN branch lines of ECU B on the V bus TEXT IN ILLUSTRATION *a V Bus *b Sub bus *c Terminating Resistor *d Location of malfunction *e Not displayed or background color changes to red or yellow *f CAN Bus Check screen HINT: When there are communication stops, ECUs are present in the vehicle even though they are not displayed on the CAN Bus Check screen. If communication errors for multiple ECUs or sensors are indicated on the CAN Bus Check screen, then a communication stop of the ECU or sensor that shows a more serious communication stop (an ECU or a sensor which is not displayed) is suspected. Example: Open in a CAN branch line for ECU D on the V bus TEXT IN ILLUSTRATION *a Background color periodically changes to yellow or red *b Not displayed or background color is yellow or red *c Not displayed EXPLANATION OF CAN BUS CHECK (COMMUNICATION BUS CHECK) SCREEN Bus Type Background Color Connection Status V Bus White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring (unstable communication). Not displayed Communication stop has continued since the start of the CAN bus check.*1 Sub bus (gateway function equipped ECU that does not have history of connected ECUs)*2 White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring (unstable communication). Not displayed Communication stop has continued since the start of the CAN bus check.*1 Sub bus (gateway function equipped ECU that has history of connected ECUs)*3 White Communication has been normal since the start of the CAN bus check. Yellow Communication stop occurred at least once since the start of the CAN bus check, but communication is currently occurring (unstable communication). Red Currently not communicating (either of the following): Communication stop has continued since the start of the CAN bus check Communication was established at least once since the start of the CAN bus check, but communication is currently not occurring Not displayed Either of the following: If a gateway function equipped ECU cannot communicate, the sub bus and ECUs connected to the sub bus will not be displayed. If no ECUs are connected to the sub bus, "There is no system found on the Communication Bus" will be displayed. HINT: Gateway function equipped ECUs relay signals between the ECUs connected to the different buses. *1: ECUs that are present in the vehicle but are not displayed on the CAN Bus Check screen. *2: Gateway function equipped ECU that does not memorize the sub bus ECUs that are connected to it. *3: Gateway function equipped ECU that memorizes the sub bus ECUs that are connected to it. The example of the CAN Bus Check screen in the illustration shows the result of electrical noise on the CAN bus which is caused by an open in a CAN branch line of ECU D (output from the other branch line is unstable) and the communication of ECU C is also unstable. In addition, in this example, ECU C is equipped with a gateway function. Therefore, communication is also unstable between the sub bus ECUs of ECU C and the V bus. The example in the illustration shows that ECU D is not displayed on the CAN Bus Check screen. This indicates a more significant communication stop. In this case, a communication stop of ECU D is suspected. If a communication error is indicated on both the V bus and sub bus on the CAN Bus Check screen, suspect any communication stop displayed for the V bus first. Example: Open in both CAN branch lines of ECU C on the V bus TEXT IN ILLUSTRATION *a Not displayed or background color changes to red HINT: In the CAN bus check, it is possible to confirm the communication status of ECUs connected to the V bus after connecting the Techstream to the DLC3. As for the sub buses, it is possible to confirm which sub bus connected ECUs can communicate with a gateway function equipped ECU on the V bus. If a gateway function equipped ECU has a communication error, ECUs connected to the gateway function equipped ECU are also affected, and communication stops will be indicated. The CAN Bus Check screen in the illustration shows that ECU C has a gateway function and a communication stop in ECU C is suspected. If the CAN Bus Check screen indicates a communication stop only in the sub bus, a communication stop in the sub bus is suspected. Example: Open in both CAN branch lines of ECU G on the sub bus TEXT IN ILLUSTRATION *a Background color changes to red HINT: A communication error in a sub bus does not affect the V bus or other buses. When a gateway function equipped ECU has memorized the ECUs that are connected to the sub bus, if any of the ECUs connected to the gateway function equipped ECU has a communication error, the background color changes to yellow or red. (The displayed name will not disappear.) If both of the V bus main bus lines are open, ECUs or sensors that are located farther away from the DLC3 than the open part will be displayed as a communication stop on the CAN Bus Check screen. (In this case, ECU A and B are not displayed or their background color changes to red.) TEXT IN ILLUSTRATION *a V Bus *b Sub Bus *c Terminating Resistor *d Location of malfunction *e Not displayed or background color is red *f CAN Bus Check screen HINT: If a communication error occurs in an ECU, it is not displayed on the CAN Bus Check screen even though the ECU is present. If both of the sub bus main bus lines are open, the ECUs that are located farther away from the gateway function equipped ECU than the open part will be displayed as a communication stop on the CAN Bus Check screen. (In this case, ECU I and J are not displayed or their background color changes to red.) TEXT IN ILLUSTRATION *a V Bus *b Sub Bus *c Terminating Resistor *d Location of malfunction *e Not displayed or background color is red *f CAN Bus Check screen *g Gateway function equipped ECU - - When any of the following malfunctions occurs, CAN communication cannot be established and almost all ECUs and sensors on the bus show a communication error on the CAN Bus Check screen. TEXT IN ILLUSTRATION *a When any of the following malfunctions occurs on the V bus *b When any of the following malfunctions occurs on a sub bus *c Not displayed DETAILS OF MALFUNCTION Short between CAN lines (CANH and CANL) Short between a CAN line (CANH or CANL) and +B Short between a CAN line (CANH or CANL) and ground Open in a CAN main bus line HINT: When a malfunction occurs on the V bus, almost all ECUs and sensors on the V bus and sub bus indicate a communication error (almost all ECUs are not displayed). As communication with the gateway function equipped ECU that is connected to the V bus stops, communication from the ECUs connected to the sub bus that is monitored by the gateway function equipped ECU also stops (these ECUs are not displayed). When a malfunction occurs in a sub bus, almost all ECUs connected to the sub bus indicate a communication error. A communication error in a sub bus does not affect the V bus or other buses. The malfunctioning part can be determined by checking for a short circuit between CAN bus lines or between a CAN bus line and ground or +B short using an electrical tester.
5. HOW TO INTERPRET COMMUNICATION DTCS (DTCS THAT START WITH U) If a CAN communication error cannot be reproduced, determine the suspected malfunctioning part using the DTCs stored in ECUs that are connected to the CAN buses by following the procedure below. HINT: Communication DTCs (DTCs that start with U) indicate a communication error between the ECU that stores the DTC and the ECU that is indicated by the DTC. If multiple ECUs store a communication DTC for a particular ECU, a communication stop of the ECU is suspected. TEXT IN ILLUSTRATION *a Items to be checked - - NOTE: This DTC table is from another model, and is only used here to show an example of DTCs that are output when there is an open in a CAN branch line for the main body ECU. This table does not show DTCs applicable to this vehicle. Even though a DTC title may indicate a communication error with a specific ECU, the ECU name used in the DTC name on the Techstream may differ depending on the ECU that stores the DTC. (Regarding output DTCs, refer to step 6 and the DTC chart for each ECU.) HINT: As multiple ECUs indicate a communication stop with the main body ECU, the possibility of a communication stop of the main body ECU is high. If almost all of the communication DTCs of an ECU are stored, a communication stop of the ECU is suspected. TEXT IN ILLUSTRATION *a Items to be checked - - NOTE: This DTC table is from another model, and is only used here to show an example of DTCs that are output when there is an open in a CAN branch line for the main body ECU. This table does not show DTCs applicable to this vehicle. HINT: If almost all of the DTCs of the main body ECU are stored, the possibility of a communication stop of the main body ECU is high. When a CAN communication error occurs, many DTCs are output. DTCs other than communication error DTCs (such as DTCs that start with C or B) and communication DTCs for the ABS system are important DTCs, however it may be easier to determine the malfunctioning part by examining the overall situation without considering these DTCs. To help determine the part of the sub bus that has a communication error, prioritize the communication stop DTCs stored in the gateway function equipped ECU. TEXT IN ILLUSTRATION *a Items to be checked *b ECM *c Gateway function equipped ECU *d Location of malfunction *e V Bus *f Sub Bus NOTE: This DTC table is from another model, and is only used here to show the ECUs connected to both a V bus and a sub bus. It shows DTCs output when there is an open in the main bus lines for the ECM on the sub bus. This table does not show DTCs applicable to this vehicle. HINT: As gateway function equipped ECUs (sub bus monitor ECU) monitor signals from all ECUs that are connected to sub buses, gateway function equipped ECUs can detect ECUs with a communication stop more accurately. When there is a communication stop for the gateway function equipped ECU (gateway), communication with ECUs connected to other buses such as the V bus stops. Therefore, communication DTCs for ECUs connected to other buses are also stored. When any of the following malfunctions occurs, many DTCs are likely to be output from many ECUs. Because of this, it may be difficult to determine the probable malfunctioning part. Short between CAN lines (CANH and CANL) Short between a CAN line (CANH or CANL) and ground Short between a CAN line (CANH or CANL) and +B Open in a CAN branch line (CANH or CANL) of an ECU or sensor Open in a CAN main bus line (CANH or CANL) between 2 ECUs that have a terminating resistor
6. DTC TABLE BY ECU HINT: In the CAN communication system, the CAN communication DTCs of each ECU can be displayed using the Techstream. If CAN communication system DTCs are output, trouble cannot be determined only by the DTCs. Perform troubleshooting according to How to Proceed with Troubleshooting. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - 12/2013]»(ref-612381-S39654712422014042900000) . If system function temporarily returns to normal, DTCs may not be output again even though the following DTC check procedures are used. Main Body ECU (Network Gateway ECU) / Techstream Display "Main Body" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus "A" Off Main body ECU (network gateway computer) communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0100 Lost Communication With ECM/PCM "A" The main body ECU (network gateway ECU) does not receive data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0101 Lost Communication with TCM The main body ECU (network gateway ECU) does not receive data from the TCM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0122 Lost Communication with Vehicle Dynamics Control Module The main body ECU (network gateway ECU) does not receive data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0155 Lost Communication with Instrument Panel Cluster (IPC) Control Module The main body ECU (network gateway ECU) does not receive data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0401 Invalid Data Received From ECM/PCM "A" The main body ECU (network gateway computer) detects abnormal data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0402 Invalid Data Received From TCM The main body ECU (network gateway computer) detects abnormal data from the TCM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0416 Invalid Data Received From Vehicle Dynamics Control Module The main body ECU (network gateway computer) detects abnormal data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U0423 Invalid Data Received From Instrument Panel Cluster Control Module The main body ECU (network gateway computer) detects abnormal data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. U1201 CAN Fail/Error Counter Circuit Unstable communications because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the main body ECU (network gateway ECU) is 10 V or more. Turn the ignition switch to ON and wait for at least 15 seconds. - DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. Combination Meter Assembly / Techstream Display "Combination Meter" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus "A" Off The combination meter assembly communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0100 Lost Communication with ECM/PCM "A" The combination meter assembly does not receive data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0122 Lost Communication with Vehicle Dynamics Control Module The combination meter assembly does not receive data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0131 Lost Communication with Power Steering Control Module The combination meter assembly does not receive data from the power steering ECU assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0140 Lost Communication with Body Control Module The combination meter assembly does not receive data from the main body ECU (network gateway ECU). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0151 Lost Communication with Restraints Control Module The combination meter assembly does not receive data from the air bag ECU assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the combination meter assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. ECM / Techstream Display "Engine" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus "A" Off The ECM communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0101 Lost Communication with TCM The ECM does not receive data from the TCM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0122 Lost Communication with Vehicle Dynamics Control Module The ECM does not receive data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0155 Lost Communication With Instrument Panel Cluster (IPC) Control Module The ECM does not receive data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0402 Invalid Data Received from TCM The ECM detects abnormal data from the TCM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0416 Invalid Data Received from Vehicle Dynamics Control Module The ECM detects abnormal data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. U0423 Invalid Data Received from Instrument Panel Cluster Control Module The ECM detects abnormal data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the ECM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. MIL warning light illuminates. DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. TCM / Techstream Display "ECT" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus "A" Off The TCM communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0100 Lost Communication with ECM/PCM "A" The TCM does not receive data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0122 Lost Communication with Vehicle Dynamics Control Module The TCM does not receive data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0140 Lost Communication with Body Control Module The TCM does not receive data from the main body ECU (network gateway ECU). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0155 Lost Communication With Instrument Panel Cluster (IPC) Control Module The TCM does not receive data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0401 Invalid Data Received from ECM/PCM "A" The TCM detects abnormal data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0416 Invalid Data Received from Vehicle Dynamics Control Module The TCM detects abnormal data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0422 Invalid Data Received from Body Control Module The TCM detects abnormal data from the main body ECU (network gateway computer). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. U0423 Invalid Data Received from Instrument Panel Cluster Control Module The TCM detects abnormal data from the combination meter assembly. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the TCM is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. - DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. Skid Control ECU (Brake Actuator Assembly) / Techstream Display "ABS/VSC/TRAC" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus OFF The skid control ECU (brake actuator assembly) communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the skid control ECU (brake actuator assembly) is 10 V or more. Turn the ignition switch to ON and wait for at least 60 seconds. ABS warning light illuminates. DTC is stored until it is cleared using the Techstream. U0100 Lost Communication With ECM/PCM "A" The skid control ECU (brake actuator assembly) does not receive data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the skid control ECU (brake actuator assembly) is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. ABS warning light illuminates. DTC is stored until it is cleared using the Techstream. U0101 Lost Communication with TCM The skid control ECU (brake actuator assembly) does not receive data from the TCM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the skid control ECU (brake actuator assembly) is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. ABS warning light illuminates. DTC is stored until it is cleared using the Techstream. U0126 Lost Communication With Steering Angle Sensor Module The skid control ECU (brake actuator assembly) does not receive data from the steering angle sensor (spiral cable sub-assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the skid control ECU (brake actuator assembly) is 10 V or more. Turn the ignition switch to ON and wait for at least 60 seconds. ABS warning light illuminates. DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. Steering Angle Sensor (Spiral Cable Sub-assembly) / Techstream Display "-" HINT: The steering angle sensor is connected to the CAN communication system, but CAN communication DTCs are not output. Power Steering ECU Assembly / Techstream Display "EMPS" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0100 Lost Communication with ECM/PCM "A" The power steering ECU assembly does not receive data from the ECM. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the power steering ECU assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. EPS warning light illuminates. DTC is stored until it is cleared using the Techstream. U0122 Lost Communication with Vehicle Dynamics Control Module The power steering ECU assembly does not receive data from the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the power steering ECU assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. EPS warning light illuminates. DTC is stored until it is cleared using the Techstream. U0416 Invalid Data Received from Vehicle Dynamics Control Module The power steering ECU assembly does not send data to the skid control ECU (brake actuator assembly). Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the power steering ECU assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 10 seconds. EPS warning light illuminates. DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. Air Bag ECU Assembly / Techstream Display "SRS Airbag" DTC Detection Item DTC Detection Condition DTC Detection Pre-condition DTC Check Procedure Warning Indication in Meter DTC Storage Method U0073 Control Module Communication Bus "A" Off Air bag ECU assembly communications stopped because of an error with high-speed CAN. Both conditions are met: The ignition switch is turned to ON and 1 second elapses. The power source voltage of the air bag ECU assembly is 10 V or more. Turn the ignition switch to ON and wait for at least 60 seconds. - DTC is stored until it is cleared using the Techstream. HINT: This ECU uses the CAN communication system for DTC communication. PSP (Option Connector) / Techstream Display "-" HINT: The PSP (option connector) is connected to the CAN communication system, but CAN communication DTCs are not output.
7. DTC COMBINATION TABLE (OPEN IN CAN BRANCH OF V BUS, PAST COMMUNICATION ERROR) Regarding the past communication error of ECUs and sensors connected to the V bus (in this case, normal was displayed when performing the CAN bus check, but communication DTCs are output), the probable CAN branch that had a malfunction can be determined based on the following DTC combination table. HINT: Based on the table below and DTCs output from ECUs connected via CAN communication, the probable part for which communication stop occurred can be determined. Regarding an open in a CAN branch and a communication stop that is currently occurring, the malfunctioning part can be confirmed easily by performing the CAN bus check using the Techstream because the ECU or sensor connected to the CAN branch does not respond (the ECU or sensor name will not be displayed on the screen). If an open in a CAN main bus line, a short between the CAN bus lines (CANH and CANL) or a +B or ground short in the CAN bus occurs, DTCs of almost all ECUs (or sensors) on the CAN bus may be output, or a message indicating a communication error may be displayed on the Techstream screen. In this case, check the resistance of the CAN bus (steps 7 to 9) first. If an open occurs in just one of the lines of a CAN branch, DTCs which are not related to malfunctioning parts may be output (DTCs may be displayed randomly), or a message indicating a communication error may be displayed. DTC Trouble Mode Output ECU Output DTC Skid Control ECU Communication Stop Mode. Refer to «Skid Control ECU Communication Stop Mode»(ref-612381-S18945572432014042900000) Power Steering ECU Communication Stop Mode. Refer to «Power Steering ECU Communication Stop Mode»(ref-612381-S16110124022014042900000) Steering Angle Sensor Communication Stop Mode. Refer to «Steering Angle Sensor Communication Stop Mode»(ref-612381-S40552419602014042900000) ECM Communication Stop Mode. Refer to «ECM Communication Stop Mode»(ref-612381-S28164430972014042900000) Transmission Control ECU Communication Stop Mode. Refer to «Transmission Control ECU Communication Stop Mode»(ref-612381-S19004691582014042900000) Skid Control ECU (Brake Actuator Assembly) U0073 o*1 X X X X U0100 o*1 X X o X U0101 o*1 X X X o U0126 o*1 X o X X Power Steering ECU Assembly U0100 X o*1 X o X U0122 o o*1 X X X U0416 X X*1 X X X ECM U0073 X X X o*1 X U0101 X X X o*1 o U0122 o X X o*1 X U0155 X X X o*1 X U0402 X X X X*1 X U0416 X X X X*1 X U0423 X X X X*1 X TCM U0073 X X X X o*1 U0100 X X X o o*1 U0122 o X X X o*1 U0140 X X X X o*1 U0155 X X X X o*1 U0416 X X X X X*1 U0422 X X X X X*1 U0423 X X X X X*1 Main Body ECU (Network Gateway ECU) U0073 X X X X X U0100 X X X o X U0101 X X X X o U0122 o X X X X U0155 X X X X X U0401 X X X X*2 X U0402 X X X X X*2 U0416 X*2 X X X X U0423 X X X X X U1201 X X X X X Combination Meter Assembly U0073 X X X X X U0100 X X X o X U0122 o X X X X U0131 X X X X X U0140 X X X X X U0151 X X X X X Air Bag ECU Assembly U0073 X X X X X DTC Trouble Mode Output ECU Output DTC Main Body ECU Communication Stop Mode. Refer to «Main Body ECU Communication Stop Mode»(ref-612381-S37749534142014042900000) Combination Meter ECU Communication Stop Mode. Refer to «Combination Meter ECU Communication Stop Mode»(ref-612381-S35705289832014042900000) Center Airbag Sensor Communication Stop Mode. Refer to «Center Airbag Sensor Communication Stop Mode»(ref-612381-S21918793922014042900000) Bus Buffer ECU Communication Stop Mode. Refer to «Bus Buffer ECU Communication Stop Mode»(ref-612381-S12596552542014042900000) Skid Control ECU (Brake Actuator Assembly) U0073 X X X X U0100 X X X X U0101 X X X X U0126 X X X X Power Steering ECU Assembly U0100 X X X X U0122 X X X X U0416 X X X X ECM U0073 X X X X U0101 X X X X U0122 X X X X U0155 X o X X U0402 X X X X U0416 X X X X U0423 X X X X TCM U0073 X X X X U0100 X X X X U0122 X X X X U0140 o X X X U0155 X o X X U0401 X X X X U0416 X X X X U0422 X X X X U0423 X X X X Main Body ECU (Network Gateway ECU) U0073 o*1 X X X U0100 o*1 X X X U0101 o*1 X X X U0122 o*1 X X X U0155 o*1 o X X U0401 X*1 X X X U0402 X*1 X X X U0416 X*1 X X X U0423 X*1 X*2 X X U1201 o*1 X X X Combination Meter Assembly U0073 X o*1 X X U0100 X o*1 X X U0122 X o*1 X X U0131 X o*1 X X U0140 o o*1 X X U0151 X o*1 o X Air Bag ECU Assembly U0073 X X o*1 X HINT: o: Set X: Not set or may be set according to the malfunctioning part when one line of a CAN branch is open. -: DTC is not output. *:1 DTC is not output during communication error, but will be output as a history DTC (past DTC) when communication returns to normal. *:2 DTC may not be stored depending on conditions.
8. CAN BUS WAVEFORMS HINT: This waveform is measured between terminals CANH and GND, and terminals CANL and GND of the DLC3. (Use this as a reference for diagnosis of CAN communication lines.) When malfunctions in multiple ECUs are suspected based on CAN Bus Check and DTCs checked using the Techstream, check the resistance of the CAN bus using an ohmmeter first. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - 12/2013]»(ref-612381-S39654712422014042900000) . If no problems are found, check the following waveforms. If a waveform is not similar to one of the following 3 patterns (Group 1), then an open in a CAN main bus line, an open in a CAN branch line, or a short between a CAN line (CANH or CANL) and ground is suspected (Group 2). Wiggle the connector and wire harness to check if the waveform changes. CAN bus waveforms (Group 1) Normal waveform Open in both of the lines (CANH and CANL) of a CAN branch HINT: Waveforms (waveforms shown using dotted lines) are not present from an ECU or sensor connected to a CAN branch with an open circuit in both lines. (Waveforms from other ECUs or sensors are normal.) Because this waveform is similar to a normal waveform, instead of using the waveform, the malfunctioning part can be narrowed down by performing a CAN bus check. Short between the CAN bus lines (CANH and CANL) HINT: Waveforms disappear. If the malfunction is in an ECU, disconnecting the ECU will change the waveform. If the waveform does not change, a malfunction in the wire harness is suspected. CAN bus waveforms (reference) (Group 2) NOTE: The following CAN bus waveforms can be used only as reference. The actual measured waveform may differ significantly depending on the location of the open or short circuit. Open in a CAN branch line (CANH) HINT: An abnormal waveform is output from an ECU with an open in one of its CAN branch lines. Because this abnormal output interferes with the signals from other ECUs, the output of other ECUs will also appear abnormal. Narrow down the malfunctioning part by checking DTCs or performing a CAN bus check, or by checking waveform changes when ECUs or sensors are disconnected. The waveform will change to one for an open in both sides of a CAN branch when the ECU or sensor with an open CAN branch line is disconnected. Open in a CAN branch line (CANL) HINT: An abnormal waveform is output from an ECU with an open in one of its CAN branch lines. Because this abnormal output interferes with the signals from other ECUs, the output of other ECUs will also appear abnormal. Narrow down the malfunctioning part by checking DTCs or performing a CAN bus check, or by checking waveform changes when ECUs or sensors are disconnected. The waveform will change to one for an open in both sides of a CAN branch when the ECU or sensor with an open CAN branch line is disconnected. Open in a CAN main bus line (CANH) HINT: Waveforms of ECUs or sensors that are nearer to the DLC3 than the open part are almost normal. Waveforms of ECUs or sensors that are on the opposite side of the DLC3 from the open part are abnormal. An open in a CAN main bus line can be confirmed by measuring the resistance between the CANH and CANL terminals of any CAN branch. Short between a CAN bus line (CANH) and ground HINT: Narrow down the shorted part by checking for waveform changes when disconnecting connectors from the CAN junction connector or when disconnecting ECUs or sensors. A short to ground in the CANH line can be confirmed by measuring the resistance between CANH and ground using an ohmmeter. Short between a CAN bus line (CANL) and ground HINT: Narrow down the shorted part by checking for waveform changes when disconnecting connectors from the CAN junction connector or when disconnecting ECUs or sensors. A short to ground in the CANL line can be confirmed by measuring the resistance between CANL and ground using an ohmmeter.

PROCEDURE

1. CHECK FOR OPEN IN CAN BUS LINES (SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) MAIN LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the A5 skid control ECU (brake actuator assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) NG --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY) MAIN LINE) OK: Go to next step
2. CHECK FOR OPEN IN CAN BUS LINES (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A5-13 (GND2) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms A5-38 (GND1) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A5-1 (+BM) - Body ground Ignition switch off 11 to 14 V A5-25 (+BS) - Body ground Ignition switch off 11 to 14 V A5-28 (IG1) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY). Refer to «REMOVAL [07/2013 - ]»(ref-612418-S24597964742014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (AIR CONDITIONING CONTROL ASSEMBLY BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D19 air conditioning control assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Value D19-13 (CANH) - D19-12 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Conditioning Control Assembly) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (AIR CONDITIONING CONTROL ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Value D19-16 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Conditioning Control Assembly) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Condition Specified Value D19-9 (+B) - Body ground Ignition switch off 11 to 14 V D19-10 (IG) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Conditioning Control Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE AIR CONDITIONING CONTROL ASSEMBLY. Refer to «REMOVAL [12/2013 - ]»(ref-612431-S36383134372014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (POWER STEERING ECU ASSEMBLY BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the A14 and A15 power steering ECU assembly connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A15-1 (CANH) - A15-7 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Steering ECU Assembly) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (POWER STEERING ECU ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A14-2 (PGND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Steering ECU Assembly) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A14-1 (PIG) - Body ground Ignition switch off 11 to 14 V A15-6 (IG) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Steering ECU Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE POWER STEERING ECU ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612405-S27458328192014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (STEERING ANGLE SENSOR (SPIRAL CABLE SUB-ASSEMBLY) BRANCH WIRE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D56 steering angle sensor (spiral cable sub-assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D56-3 (CANH) - D56-2 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Steering Angle Sensor (Spiral Cable Sub-assembly)) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D56-1 (ESS) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Steering Angle Sensor (Spiral Cable Sub-assembly)) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D56-4 (IG1) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Steering Angle Sensor (Spiral Cable Sub-assembly)) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE STEERING ANGLE SENSOR (SPIRAL CABLE SUB-ASSEMBLY). Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612396-S28826002512014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (ECM MAIN LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the A33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (ECM MAIN LINE) OK: Go to next step
2. CHECK ECM POWER SOURCE CIRCUIT Check the ECM power source circuit. Refer to «ECM Power Source Circuit»(ref-612367-S33608067402014042900000) . NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (TCM BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the A18 TCM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A18-29 (CANH) - A18-28 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (TCM) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A18-3 (E02) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms A18-33 (E01) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A18-26 (BM) - Body ground Ignition switch off 11 to 14 V A18-34 (IG1) - Body ground Ignition switch ON 11 to 14 V A18-35 (IG2) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to TCM) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE TCM. Refer to «REMOVAL [07/2013 - ]»(ref-612361-S05336412892014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (MAIN BODY ECU (NETWORK GATEWAY ECU) BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D5 main body ECU (network gateway ECU) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D5-14 (CANH) - D5-13 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Main Body ECU (Network Gateway ECU)) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (MAIN BODY ECU (NETWORK GATEWAY ECU)) OK: Go to next step
2. CHECK INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY Remove the main body ECU (network gateway ECU). Refer to «REMOVAL [07/2013 - ]»(ref-612382-S37239791822014042900000) . Remove the instrument panel junction block assembly. Refer to «REMOVAL [07/2013 - ]»(ref-612382-S37239791822014042900000) . TEXT IN ILLUSTRATION *a Component without harness connected (Instrument Panel Junction Block Assembly) - - Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3E-1 - MB-8 (IG) Battery voltage is applied to terminals 3A-15 and 3A-12 Below 1 ohms MB-1 (BECU) - 3A-27 Always Below 1 ohms MB-11 (GND) - 3B-18 Always Below 1 ohms MB-32 (BMPX) - 3C-19 Always Below 1 ohms NG --> See step 5 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Install the instrument panel junction block assembly. TEXT IN ILLUSTRATION *a Component without harness connected (Instrument Panel Junction Block Assembly) *b Front view of wire harness connector (to Instrument Panel Junction Block Assembly) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D6-1 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms MB-11 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms Connect the cable to the negative (-) battery terminal. TEXT IN ILLUSTRATION *a Component without harness connected (Instrument Panel Junction Block Assembly) - - Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition MB-1 (BECU) - Body ground Ignition switch off 11 to 14 V MB-8 (IG) - Body ground Ignition switch ON 11 to 14 V MB-32 (BMPX) - Body ground Ignition switch off 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 4
4. REPLACE MAIN BODY ECU (NETWORK GATEWAY ECU). Refer to «REMOVAL [07/2013 - ]»(ref-612382-S37239791822014042900000)
5. REPLACE INSTRUMENT PANEL JUNCTION BLOCK ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612382-S37239791822014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (COMBINATION METER ASSEMBLY BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D7 combination meter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D7-6 (CANH) - D7-7 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Combination Meter Assembly) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (COMBINATION METER ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D7-20 (ES1) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms D7-40 (ES2) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Combination Meter Assembly) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D7-1 (B) - Body ground Ignition switch off 11 to 14 V D7-2 (IG+) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Combination Meter Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL [07/2013 - ]»(ref-612384-S14032382702014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D41 and D48 certification ECU (smart key ECU assembly) connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D41-14 (CANH) - D41-15 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Certification ECU (Smart Key ECU Assembly)) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (CERTIFICATION ECU (SMART KEY ECU ASSEMBLY) ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D48-11 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Certification ECU (Smart Key ECU Assembly)) Connect the cable to the negative (-) battery terminal. Connect the D41 and D48 certification ECU (smart key ECU assembly) connectors. TEXT IN ILLUSTRATION *a Component with harness connected (Certification ECU (Smart Key ECU Assembly)) - - Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D41-5 (IG2) - Body ground Engine switch on (IG) 11 to 14 V D48-2 (+B) - Body ground Engine switch off 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE CERTIFICATION ECU (SMART KEY ECU ASSEMBLY). Refer to «REMOVAL [12/2013 - ]»(ref-612386-S03752899672014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (AIR BAG ECU ASSEMBLY BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Disconnect the D27 air bag ECU assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D27-13 (CANH) - D27-22 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Bag ECU Assembly) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (AIR BAG ECU ASSEMBLY) OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (POWER SOURCE CIRCUIT) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D27-25 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms D27-26 (GND) - Body ground Cable disconnected from negative (-) battery terminal Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Bag ECU Assembly) Connect the cable to the negative (-) battery terminal. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition D27-21 (IG) - Body ground Ignition switch ON 11 to 14 V TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Air Bag ECU Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (POWER SOURCE CIRCUIT) OK --> See step 3
3. REPLACE AIR BAG ECU ASSEMBLY. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612230-S36935211862014042900000)

1. CHECK FOR OPEN IN CAN BUS LINES (PSP (OPTION CONNECTOR) BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D29-4 (CANH) - D29-5 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to PSP (Option Connector)) NG --> REPAIR OR REPLACE CAN BRANCH LINE OR CONNECTOR (PSP (OPTION CONNECTOR)) OK --> END

1. CHECK FOR OPEN IN CAN BUS LINES (DLC3 BRANCH LINE) Disconnect the cable from the negative (-) battery terminal. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-14 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *1 DLC3 NOTE: When the measured value is 127 ohms or higher and a CAN communication system DTC is output, there may be a fault besides disconnection of the DLC3 branch line. For that reason, troubleshooting should be performed again from How to Proceed with Troubleshooting after repairing the trouble area. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - 12/2013]»(ref-612381-S39654712422014042900000) . NG --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OK: Go to next step
2. CHECK FOR OPEN IN CAN BUS LINES (ECM) Disconnect the A33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 3 OK --> See step 8
3. CHECK FOR OPEN IN CAN BUS LINES (SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) Reconnect the A33 ECM connector. Disconnect the A5 skid control ECU (brake actuator assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) NG --> See step 4 OK --> See step 7
4. CHECK FOR OPEN IN CAN BUS LINES (CAN NO. 2 J/C) Reconnect the A5 skid control ECU (brake actuator assembly) connector. Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D43-12 Cable disconnected from negative (-) battery terminal 114 to 126 ohms CAN No. 1 junction connector D43-9 - D43-20 Cable disconnected from negative (-) battery terminal 114 to 126 ohms ECM TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to ECM Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C B --> See step 5 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
5. CHECK FOR OPEN IN CAN BUS LINES (CAN NO. 2 J/C - CAN NO. 1 J/C) Reconnect the wire harness connector to the D43 CAN No. 2 junction connector. Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A17-7 - A17-18 Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to CAN No. 2 Junction Connector NG --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - CAN NO. 2 J/C) OK: Go to next step
6. CHECK FOR OPEN IN CAN BUS LINES (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A17-6 - A17-17 Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to Skid Control ECU (Brake Actuator Assembly) NG --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) OK --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
7. REPLACE SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY). Refer to «REMOVAL [07/2013 - ]»(ref-612418-S24597964742014042900000)
8. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

1. CHECK FOR SHORT IN CAN BUS LINES (ECM) Disconnect the cable from the negative (-) battery terminal. Disconnect the A33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 2 OK --> See step 7
2. CHECK FOR SHORT IN CAN BUS LINES (SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) Reconnect the A33 ECM connector. Disconnect the A5 skid control ECU (brake actuator assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) NG --> See step 3 OK --> See step 6
3. CHECK FOR SHORT IN CAN BUS LINES (CAN NO. 2 J/C) Reconnect the A5 skid control ECU (brake actuator assembly) connector. Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D43-12 Cable disconnected from negative (-) battery terminal 114 to 126 ohms CAN No. 1 junction connector D43-2 - D43-13 Cable disconnected from negative (-) battery terminal 200 ohms or higher Combination meter assembly D43-3 - D43-14 Cable disconnected from negative (-) battery terminal 200 ohms or higher Main body ECU (network gateway ECU) D43-5 - D43-16 Cable disconnected from negative (-) battery terminal 1 Mohms or higher DLC3 D43-6 - D43-17 Cable disconnected from negative (-) battery terminal 200 ohms or higher Steering angle sensor (spiral cable sub-assembly) D43-7 - D43-18 Cable disconnected from negative (-) battery terminal 1 Mohms or higher PSP (option connector) D43-8 - D43-19 Cable disconnected from negative (-) battery terminal 200 ohms or higher Air bag ECU assembly D43-9 - D43-20 Cable disconnected from negative (-) battery terminal 114 to 126 ohms ECM TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to DLC3 *f to Steering Angle Sensor (Spiral Cable Sub-assembly) *g to PSP (Option Connector) *h to Air Bag ECU Assembly *i to ECM Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 4 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 5 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
4. CHECK FOR SHORT IN CAN BUS LINES (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - A17-16 Cable disconnected from negative (-) battery terminal 200 ohms or higher TCM A17-6 - A17-17 Cable disconnected from negative (-) battery terminal 114 to 126 ohms Skid control ECU (brake actuator assembly) A17-7 - A17-18 Cable disconnected from negative (-) battery terminal 1 Mohms or higher CAN No. 2 junction connector A17-8 - A17-19 Cable disconnected from negative (-) battery terminal 200 ohms or higher Power steering ECU assembly TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 5 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
5. CHECK FOR SHORT IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the connector that includes terminals CANH and CANL from the ECU (or sensor) to which the short circuited branch line is connected. Refer to «TERMINALS OF ECU [07/2013 - 12/2013]»(ref-612381-S21504446002014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-14 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance becomes normal (between 57 and 63 ohms) when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). If the resistance does not become normal (between 57 and 63 ohms) when the connector is disconnected from the ECU (or sensor), repair or replace the short circuited branch line or connector. NG --> REPAIR OR REPLACE CORRESPONDING ECU OR SENSOR BUS LINE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR
6. REPLACE SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY). Refer to «REMOVAL [07/2013 - ]»(ref-612418-S24597964742014042900000)
7. REPLACE ECM. Refer to «REMOVAL [07/2013 - 12/2013]»(ref-612354-S32372465292014042900000)

1. CHECK FOR SHORT IN CAN BUS LINES (ECM) Disconnect the cable from the negative (-) battery terminal. Disconnect the A33 ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A33-19 (CANH) - A33-18 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to ECM) NG --> See step 2 OK --> See step 7
2. CHECK FOR SHORT IN CAN BUS LINES (SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) Reconnect the A33 ECM connector. Disconnect the A5 skid control ECU (brake actuator assembly) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A5-26 (CANH) - A5-14 (CANL) Cable disconnected from negative (-) battery terminal 114 to 126 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Skid Control ECU (Brake Actuator Assembly)) NG --> See step 3 OK --> See step 6
3. CHECK FOR SHORT IN CAN BUS LINES (CAN NO. 2 J/C) Reconnect the A5 skid control ECU (brake actuator assembly) connector. Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D43-12 Cable disconnected from negative (-) battery terminal 114 to 126 ohms CAN No. 1 junction connector D43-2 - D43-13 Cable disconnected from negative (-) battery terminal 200 ohms or higher Combination meter assembly D43-3 - D43-14 Cable disconnected from negative (-) battery terminal 200 ohms or higher Main body ECU (network gateway ECU) D43-4 - D43-15 Cable disconnected from negative (-) battery terminal 200 ohms or higher Certification ECU (smart key ECU assembly) D43-5 - D43-16 Cable disconnected from negative (-) battery terminal 1 Mohms or higher DLC3 D43-6 - D43-17 Cable disconnected from negative (-) battery terminal 200 ohms or higher Steering angle sensor (spiral cable sub-assembly) D43-7 - D43-18 Cable disconnected from negative (-) battery terminal 1 Mohms or higher PSP (option connector) D43-8 - D43-19 Cable disconnected from negative (-) battery terminal 200 ohms or higher Airbag ECU assembly D43-9 - D43-20 Cable disconnected from negative (-) battery terminal 114 to 126 ohms ECM D43-10 - D43-21 Cable disconnected from negative (-) battery terminal 200 ohms or higher Air conditioning control assembly TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to Certification ECU (Smart Key ECU Assembly) *f to DLC3 *g to Steering Angle Sensor (Spiral Cable Sub-assembly) *h to PSP (Option Connector) *i to Airbag ECU Assembly *j to ECM *k to Air Conditioning Control Assembly Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 4 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 5 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
4. CHECK FOR SHORT IN CAN BUS LINES (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - A17-16 Cable disconnected from negative (-) battery terminal 200 ohms or higher TCM A17-6 - A17-17 Cable disconnected from negative (-) battery terminal 114 to 126 ohms Skid control ECU (brake actuator assembly) A17-7 - A17-18 Cable disconnected from negative (-) battery terminal 1 Mohms or higher CAN No. 2 junction connector A17-8 - A17-19 Cable disconnected from negative (-) battery terminal 200 ohms or higher Power steering ECU assembly TEXT IN ILLUSTRATION *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 5 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
5. CHECK FOR SHORT IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the connector that includes terminals CANH and CANL from the ECU (or sensor) to which the short circuited branch line is connected. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-612381-S16788908332014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-14 (CANL) Cable disconnected from negative (-) battery terminal 57 to 63 ohms TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance becomes normal (between 57 and 63 ohms) when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). If the resistance does not become normal (between 57 and 63 ohms) when the connector is disconnected from the ECU (or sensor), repair or replace the short circuited branch line or connector. NG --> REPAIR OR REPLACE CORRESPONDING ECU OR SENSOR BUS LINE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR
6. REPLACE SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY). Refer to «REMOVAL [07/2013 - ]»(ref-612418-S24597964742014042900000)
7. REPLACE ECM. Refer to «REMOVAL [12/2013 - ]»(ref-612354-S32380777172014042900000)

1. CHECK FOR SHORT TO +B IN CAN BUS LINE (CAN NO. 2 J/C) Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN No. 1 junction connector D43-12 - D10-16 (BAT) D43-2 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Combination meter assembly D43-13 - D10-16 (BAT) D43-3 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Main body ECU (network gateway ECU) D43-14 - D10-16 (BAT) D43-5 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher DLC3 D43-16 - D10-16 (BAT) D43-6 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Steering angle sensor (spiral cable sub-assembly) D43-17 - D10-16 (BAT) D43-7 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher PSP (option connector) D43-18 - D10-16 (BAT) D43-8 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Air bag ECU assembly D43-19 - D10-16 (BAT) D43-9 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher ECM D43-20 - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to DLC3 *f to Steering Angle Sensor (Spiral Cable Sub-assembly) *g to PSP (Option Connector) *h to Air Bag ECU Assembly *i to ECM Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 2 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 3 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
2. CHECK FOR SHORT TO +B IN CAN BUS LINE (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher TCM A17-16 - D10-16 (BAT) A17-6 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Skid control ECU (brake actuator assembly) A17-17 - D10-16 (BAT) A17-7 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN No. 2 junction connector A17-18 - D10-16 (BAT) A17-8 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Power steering ECU assembly A17-19 - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 3 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
3. CHECK FOR SHORT TO +B IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the ECU or sensor connected to the CAN bus line that is shorted to +B. HINT: If the ECU or sensor has multiple connectors, disconnect the connector that includes the CAN bus lines. To determine the ECU or sensor that is connected to the shorted bus line, refer to the terminals of ECU tables. Refer to «TERMINALS OF ECU [07/2013 - 12/2013]»(ref-612381-S21504446002014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher D10-14 (CANL) - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance changes to 6 kohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG --> REPAIR OR REPLACE REPAIR OR REPLACE CORRESPONDING ECU/SENSOR WIRE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR

1. CHECK FOR SHORT TO +B IN CAN BUS LINE (CAN NO. 2 J/C) Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN No. 1 junction connector D43-12 - D10-16 (BAT) D43-2 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Combination meter assembly D43-13 - D10-16 (BAT) D43-3 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Main body ECU (network gateway ECU) D43-14 - D10-16 (BAT) D43-4 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Certification ECU (smart key ECU assembly) D43-15 - D10-16 (BAT) D43-5 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher DLC3 D43-16 - D10-16 (BAT) D43-6 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Steering angle sensor (spiral cable sub-assembly) D43-17 - D10-16 (BAT) D43-7 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher PSP (option connector) D43-18 - D10-16 (BAT) D43-8 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Airbag ECU assembly D43-19 - D10-16 (BAT) D43-9 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher ECM D43-20 - D10-16 (BAT) D43-10 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Air conditioning control assembly D43-21 - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to Certification ECU (Smart Key ECU Assembly) *f to DLC3 *g to Steering Angle Sensor (Spiral Cable Sub-assembly) *h to PSP (Option Connector) *i to Airbag ECU Assembly *j to ECM *k to Air Conditioning Control Assembly Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 2 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 3 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
2. CHECK FOR SHORT TO +B IN CAN BUS LINE (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher TCM A17-16 - D10-16 (BAT) A17-6 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Skid control ECU (brake actuator assembly) A17-17 - D10-16 (BAT) A17-7 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher CAN No. 2 junction connector A17-18 - D10-16 (BAT) A17-8 - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher Power steering ECU assembly A17-19 - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 3 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
3. CHECK FOR SHORT TO +B IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the ECU or sensor connected to the CAN bus line that is shorted to +B. HINT: If the ECU or sensor has multiple connectors, disconnect the connector that includes the CAN bus lines. To determine the ECU or sensor that is connected to the shorted bus line, refer to the terminals of ECU tables. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-612381-S16788908332014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-16 (BAT) Cable disconnected from negative (-) battery terminal 6 kohms or higher D10-14 (CANL) - D10-16 (BAT) TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance changes to 6 kohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG --> REPAIR OR REPLACE REPAIR OR REPLACE CORRESPONDING ECU/SENSOR WIRE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR

1. CHECK FOR SHORT TO GND IN CAN BUS LINE (CAN NO. 2 J/C) Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher CAN No. 1 junction connector D43-12 - D10-4 (CG) D43-2 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Combination meter assembly D43-13 - D10-4 (CG) D43-3 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Main body ECU (network gateway ECU) D43-14 - D10-4 (CG) D43-5 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher DLC3 D43-16 - D10-4 (CG) D43-6 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Steering angle sensor (spiral cable sub-assembly) D43-17 - D10-4 (CG) D43-7 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher PSP (option connector) D43-18 - D10-4 (CG) D43-8 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Air bag ECU assembly D43-19 - D10-4 (CG) D43-9 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher ECM D43-20 - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to DLC3 *f to Steering Angle Sensor (Spiral Cable Sub-assembly) *g to PSP (Option Connector) *h to Air Bag ECU Assembly *i to ECM Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 2 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 3 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
2. CHECK FOR SHORT TO GND IN CAN BUS LINE (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher TCM A17-16 - D10-4 (CG) A17-6 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Skid control ECU (brake actuator assembly) A17-17 - D10-4 (CG) A17-7 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher CAN No. 2 junction connector A17-18 - D10-4 (CG) A17-8 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Power steering ECU assembly A17-19 - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 3 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
3. CHECK FOR SHORT TO GND IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the ECU or sensor connected to the CAN bus line that is shorted to ground. HINT: If the ECU or sensor has multiple connectors, disconnect the connector that includes the CAN bus lines. To determine the ECU or sensor that is connected to the shorted bus line, refer to the terminals of ECU tables. Refer to «TERMINALS OF ECU [07/2013 - 12/2013]»(ref-612381-S21504446002014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-14 (CANL) - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance changes to 200 ohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG --> REPAIR OR REPLACE REPAIR OR REPLACE CORRESPONDING ECU/SENSOR WIRE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR

1. CHECK FOR SHORT TO GND IN CAN BUS LINE (CAN NO. 2 J/C) Disconnect the wire harness connector from the D43 CAN No. 2 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to D43-1 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher CAN No. 1 junction connector D43-12 - D10-4 (CG) D43-2 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Combination meter assembly D43-13 - D10-4 (CG) D43-3 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Main body ECU (network gateway ECU) D43-14 - D10-4 (CG) D43-4 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Certification ECU (smart key ECU assembly) D43-15 - D10-4 (CG) D43-5 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher DLC3 D43-16 - D10-4 (CG) D43-6 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Steering angle sensor (spiral cable sub-assembly) D43-17 - D10-4 (CG) D43-7 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher PSP (option connector) D43-18 - D10-4 (CG) D43-8 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Airbag ECU assembly D43-19 - D10-4 (CG) D43-9 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher ECM D43-20 - D10-4 (CG) D43-10 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Air conditioning control assembly D43-21 - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 2 Junction Connector) *b to CAN No. 1 Junction Connector *c to Combination Meter Assembly *d to Main Body ECU (Network Gateway ECU) *e to Certification ECU (Smart Key ECU Assembly) *f to DLC3 *g to Steering Angle Sensor (Spiral Cable Sub-assembly) *h to PSP (Option Connector) *i to Airbag ECU Assembly *j to ECM *k to Air Conditioning Control Assembly Result Result Proceed to OK A NG (CAN No. 1 junction connector main line) B NG (ECM main line) C NG (ECU or sensor branch line) D NG (DLC3 branch line or PSP (option connector) branch line) E B --> See step 2 C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - ECM) D --> See step 3 E --> REPAIR OR REPLACE CAN BRANCH LINE CONNECTED TO DLC3 OR PSP (OPTION CONNECTOR) A --> REPLACE CAN NO. 2 JUNCTION CONNECTOR
2. CHECK FOR SHORT TO GND IN CAN BUS LINE (CAN NO. 1 J/C) Disconnect the wire harness connector from the A17 CAN No. 1 junction connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Connected to A17-5 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher TCM A17-16 - D10-4 (CG) A17-6 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Skid control ECU (brake actuator assembly) A17-17 - D10-4 (CG) A17-7 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher CAN No. 2 junction connector A17-18 - D10-4 (CG) A17-8 - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher Power steering ECU assembly A17-19 - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 *a Front view of wire harness connector (to CAN No. 1 Junction Connector) *b to TCM *c to Skid Control ECU (Brake Actuator Assembly) *d to CAN No. 2 Junction Connector *e to Power Steering ECU Assembly Result Result Proceed to OK A NG (CAN No. 2 junction connector main line) B NG (skid control ECU (brake actuator assembly) main line) C NG (ECU or sensor branch line) D B --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 2 J/C - CAN NO. 1 J/C) C --> REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN NO. 1 J/C - SKID CONTROL ECU (BRAKE ACTUATOR ASSEMBLY)) D --> See step 3 A --> REPLACE CAN NO. 1 JUNCTION CONNECTOR
3. CHECK FOR SHORT TO GND IN CONNECTED COMPONENT (ECU, SENSOR) Reconnect all the wire harness connectors (the A17 CAN No. 1 junction connector and D43 CAN No. 2 junction connector). Disconnect the ECU or sensor connected to the CAN bus line that is shorted to ground. HINT: If the ECU or sensor has multiple connectors, disconnect the connector that includes the CAN bus lines. To determine the ECU or sensor that is connected to the shorted bus line, refer to the terminals of ECU tables. Refer to «TERMINALS OF ECU [12/2013 - ]»(ref-612381-S16788908332014042900000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition D10-6 (CANH) - D10-4 (CG) Cable disconnected from negative (-) battery terminal 200 ohms or higher D10-14 (CANL) - D10-4 (CG) TEXT IN ILLUSTRATION *1 DLC3 HINT: If the resistance changes to 200 ohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG --> REPAIR OR REPLACE REPAIR OR REPLACE CORRESPONDING ECU/SENSOR WIRE OR CONNECTOR OK --> REPLACE CORRESPONDING ECU OR SENSOR

1. CHECK FOR OPEN IN ONE SIDE OF V BUS BRANCH LINE Based on the vehicle equipment and specifications, confirm the systems that use CAN communication. Refer to «DIAGNOSIS SYSTEM [07/2013 - 12/2013]»(ref-612381-S33318737382014042900000) . Using the Techstream, select and perform the CAN bus check. Refer to «DIAGNOSIS SYSTEM [07/2013 - 12/2013]»(ref-612381-S33318737382014042900000) . Observe the screen for approximately 2 minutes to check the ECUs and sensors that are not displayed on the screen and also those that repeatedly appear and disappear from the screen. Check the applicable communication stop mode for the ECU or sensor that is not displayed on the screen. NEXT --> See step 2
2. GO TO CORRESPONDING COMMUNICATION STOP MODE. Refer to «PROBLEM SYMPTOMS TABLE [07/2013 - 12/2013]»(ref-612381-S33003132002014042900000)

1. CHECK FOR OPEN IN ONE SIDE OF V BUS BRANCH LINE Based on the vehicle equipment and specifications, confirm the systems that use CAN communication. Refer to «DIAGNOSIS SYSTEM [12/2013 - ]»(ref-612381-S29831877552014042900000) . Using the Techstream, select and perform the CAN bus check. Refer to «DIAGNOSIS SYSTEM [12/2013 - ]»(ref-612381-S29831877552014042900000) . Observe the screen for approximately 2 minutes to check the ECUs and sensors that are not displayed on the screen and also those that repeatedly appear and disappear from the screen. Check the applicable communication stop mode for the ECU or sensor that is not displayed on the screen. NEXT --> See step 2
2. GO TO CORRESPONDING COMMUNICATION STOP MODE. Refer to «PROBLEM SYMPTOMS TABLE [12/2013 - ]»(ref-612381-S16253039562014042900000)
