Occupant Classification System (Diagnostics - Introduction): Diagnosis Scion FR-S I

HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - ]

HINT

1. Use the following procedure to troubleshoot the occupant classification system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. CUSTOMER PROBLEM ANALYSIS Confirm problem symptoms. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [07/2013 - 12/2013]»(ref-612229-S16181698712014042900000) . NEXT: Go to next step
3. PASSENGER AIRBAG ON/OFF INDICATOR CHECK Proceed to Diagnosis System. Refer to «DIAGNOSIS SYSTEM [07/2013 - ]»(ref-612450-S30823090472014042900000) . NEXT: Go to next step
4. DTC CHECK (Present and History DTCs)* Proceed to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612450-S11859993622014042900000) . Result Result Proceed to DTC is output. A DTC is not output. B B --> GO TO PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE [07/2013 - ]»(ref-612450-S38099451582014042900000) A: Go to next step
5. DTC CHART Proceed to Diagnostic Trouble Code Chart. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - ]»(ref-612450-S29933604282014042900000) . NEXT: Go to next step
6. CIRCUIT INSPECTION* NEXT: Go to next step
7. REPAIR NEXT: Go to next step
8. CLEAR DTCS (Present and History DTCs)* Proceed to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612450-S11859993622014042900000) . NEXT: Go to next step
9. DTC CHECK* Proceed to DTC Check / Clear. Refer to «DTC CHECK / CLEAR [07/2013 - ]»(ref-612450-S11859993622014042900000) . Result Result Proceed to DTC is not output. A DTC is output. B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - ]»(ref-612450-S29933604282014042900000) A: Go to next step
10. SYMPTOM SIMULATION Check the passenger airbag ON/OFF indicator condition. Result Result Proceed to Passenger airbag ON/OFF indicator operates normally. A Passenger airbag ON/OFF indicator ("OFF") and SRS warning light come on. B B --> GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [07/2013 - ]»(ref-612450-S29933604282014042900000) A: Go to next step
11. CONFIRMATION TEST NEXT --> END

PROBLEM SYMPTOMS TABLE [07/2013 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

OCCUPANT CLASSIFICATION SYSTEM

Scheme 134

1. OCCUPANT DETECTION ECU Terminal No. (Symbol) Wiring Color Terminal Description Condition Specification G2-2 - G2-3 Y-G - Y Airbag ECU assembly communication line Ignition switch ON Pulse generation G2-1 - Body ground G - Body ground Power source Ignition switch ON 11 to 14 V

Scheme 135

Scheme 136

1. FUNCTION OF PASSENGER AIRBAG ON/OFF INDICATOR Initial check Turn the ignition switch to ON. The passenger airbag ON/OFF indicator comes on for approximately 6 seconds, then goes off for approximately 2 seconds. Approximately 8 seconds after the ignition switch is turned to ON, the passenger airbag ON/OFF indicator will indicate ON/OFF depending on the conditions listed below. INDICATOR OPERATION Front Passenger Seat Condition Passenger Airbag ON/OFF Indicator SRS Warning Light ON Indicator OFF Indicator Vacant OFF ON OFF*1 Occupied ON OFF OFF*1 Child restraint system is installed. OFF ON OFF*1 Occupant classification system failure OFF ON ON Undetermined OFF ON ON*1 *1: When the passenger side buckle switch has a malfunction, the SRS warning light is illuminated. HINT: The passenger airbag ON/OFF indicator illuminates based on the timing chart below in order to check the indicator light circuit. When the occupant classification system has trouble, both the SRS warning light and passenger airbag ON/OFF indicator ("OFF") come on. In this case, check the DTCs in the airbag system first.
2. CHECK PASSENGER AIRBAG ON/OFF INDICATOR Turn the ignition switch to ON. Check that the passenger airbag ON/OFF indicator ("ON" and "OFF") comes on for approximately 6 seconds, then goes off for approximately 2 seconds. HINT: Refer to the indicator operation table in the preceding step regarding the passenger airbag ON/OFF indicator when the ignition switch is turned to ON and approximately 6 seconds elapse.

DTC CHECK / CLEAR [07/2013 - ]

1. DTC CHECK Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Occupant Detection / Trouble Codes. Check for DTCs by following the prompts on the Techstream screen. HINT: Refer to the Techstream operator's manual for further details.
2. DTC CLEAR Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Occupant Detection / Trouble Codes. Clear the DTCs by following the prompts on the Techstream screen. HINT: Refer to the Techstream operator's manual for further details.

DATA LIST / ACTIVE TEST [07/2013 - ]

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Body Electrical / Occupant Detection / Data List. Check the values by referring to the table below. OCCUPANT DETECTION Tester Display Measurement Item/Range Normal Condition Diagnostic Note Passenger Detection Passenger detection status/ ON / OFF ON/OFF - Status of Passenger Side Buckle SW Passenger side buckle switch/ Set / Unset / NG Set/Unset - Number of Present DTC Number of present DTC recorded/ Min.: 0, Max.: 255 0

DIAGNOSTIC TROUBLE CODE CHART [07/2013 - ]

If a trouble code is displayed during the DTC check, check the circuit listed for the code in the table below (proceed to the procedure listed for that DTC).

HINT

When DTC B1650 is detected as a result of troubleshooting for the airbag system, perform troubleshooting for the occupant classification system as shown in the chart below.

OCCUPANT CLASSIFICATION SYSTEM
