Transfer Case - MJ8: Specifications Saturn VUE II

Transfer Case 1 illustration

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Cover Bolts26 N.m20 lb ft
Drain Plug44 N.m33 lb ft
Fill Plug44 N.m33 lb ft
Output Shaft/Yoke Locknut - Tighten the Nut Within the Specification Range to Achieve the Proper Output Shaft Rotating Torque108-294 N.m75.6-217 lb ft
Output Yoke-to- J 44873 Retaining Bolts48 N.m35 lb ft
Propeller Shaft-to-Transfer Case Output Yoke Bolts25 N.m19 lb ft
Transfer Case-to-Transmission Bolts51 N.m38 lb ft
Ventilation Baffle Bolt11.8 N.m104 lb in

Fastener Tightening Specifications

Transfer Case Mechanical Specifications

ApplicationSpecification
MetricEnglish
Output Shaft and Input Gear Backlash0.06-0.16 mm0.0024-0.0063 in
Output Shaft Rotating Torque1.15-1.71 N.m10.2-15.1 lb in
Output Shaft/Input Gear Rotating Torque - Measured With the Unit Assembled3.20-4.16 N.m28.2-34.3 lb in
Transfer Case Fill Quantity - Overhaul of Unit0.45 Liters0.48 quarts
Transfer Case Fill Quantity - Replacement of Unit0.43 Liters0.45 quarts
Transmission Type - RPO MJ85-Speed Automatic

Transfer Case Mechanical Specifications

Scheme 1

Scheme 1: Transfer Case Disassembled View
Scheme 1: Transfer Case Disassembled View
CalloutComponent Name
100Case
101Cover
102Bolt
103Bolt
104Ventilation Baffle
105Locating Pin - Transfer Case-to-Transaxle
201Output Shaft
202Shim - 40 mm
203Bearing
204Spacer
205Race
206Race
207Bearing
208Output Yoke
209Washer
210Nut
211Shim - 80 mm
212Race
213Bearing
214Input Gear
215Washer
216Shim - 25 mm
217Bearing
218Race
301Seal - Output Shaft
302O-Ring
303Sealing Washer
304O-Ring
305Seal - Input Shaft
401Fill Plug
402Washer
403Drain Plug
404Washer
406Clamp
407Ventilation Hose
408Ventilation Valve
